Thermo King Precedent C-600 User manual

Operator’s Manual
Ingersoll Rand’s Climate Solutions sector delivers energy-efficient HVACR solutions for
customers globally. Its world class brands include Thermo King, the leader in transport
temperature control and Trane, a provider of energy effi cient heating, ventilating and
air conditioning systems, building and contracting services, parts support and advanced
controls for commercial buildings and homes.
©2013 Ingersoll-Rand Company
Printed in U.S.A.
Precedent™
C-600
TK 55692-2-OP (Rev. 1, 10/14)
Operator’s Manual
Ingersoll Rand’s Climate Solutions sector delivers energy-efficient HVACR solutions for
customers globally. Its world class brands include Thermo King, the leader in transport
temperature control and Trane, a provider of energy effi cient heating, ventilating and
air conditioning systems, building and contracting services, parts support and advanced
controls for commercial buildings and homes.
©2013 Ingersoll-Rand Company
Printed in U.S.A.
Precedent™
C-600
TK 55692-2-OP (Rev. 1, 10/14)

Copyright© 2013 Thermo King Corp., Minneapolis, MN, USA
Printed in USA
PrecedentTM
C-600
TK 55692-2-OP (Rev. 1, 10/14)

Disclaimer
This manual is published for informational purposes only. Thermo King Corporation makes no
representations or warranties, express or implied, with respect to the information, recommendations
and descriptions contained in this manual and such information, recommendations and descriptions
should not be regarded as all-inclusive or covering all contingencies. In the event you have any
questions or require further information, please contact your local Thermo King dealer.
The procedures described herein should only be undertaken by suitably qualified personnel. Failure to
implement these procedures correctly may cause damage to the Thermo King unit or other property or
personal injury.
Thermo King Corporation and its affiliates shall have no liability in contract or tort (including negligence
and/or strict liability) or otherwise, to any person or entity for any personal injury, property damage or
any other direct, indirect, special or consequential damage or liability whatsoever, arising out of or
resulting from any actions by any person that are contrary to this manual or any of the information,
recommendations or descriptions contained herein or the failure of any person to implement the
procedures described herein correctly or to follow caution and safety decals located on the Thermo
King unit.

3
Table Of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
EPA Emission Control System Warranty Statement 8
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . 11
General Safety Practices . . . . . . . . . . . . . . . . . . . . . . 11
Automatic Start/Stop Operation . . . . . . . . . . . . . . . . . 12
Electrical Hazard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Battery Installation and Cable Routing . . . . . . . . . . . . 12
Refrigerant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Refrigerant Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
First Aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
First Aid–Refrigerant . . . . . . . . . . . . . . . . . . . . . . . 14
First Aid–Refrigerant Oil . . . . . . . . . . . . . . . . . . . . 14
Safety Decals and Locations . . . . . . . . . . . . . . . . . . . 15
Condenser and Evaporator Fans . . . . . . . . . . . . . 15
High Voltage Components . . . . . . . . . . . . . . . . . . 15
Do Not Use Ether Starting Aids . . . . . . . . . . . . . . 17
Unit Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Unit Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Features and Options . . . . . . . . . . . . . . . . . . . . . . . . .19
Diesel Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
ELC (Extended Life Coolant) . . . . . . . . . . . . . . . . . . . .21
EMI 3000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Thermo King X430L Reciprocating Compressor . . . . .22
Electronic Throttling Valve . . . . . . . . . . . . . . . . . . . . . .22
SMART REEFER 4 (SR-4) Control System . . . . . . . . .23
Diesel Operation . . . . . . . . . . . . . . . . . . . . . . . . . .23
Electric Operation . . . . . . . . . . . . . . . . . . . . . . . . .24
CYCLE-SENTRY Start-Stop Controls . . . . . . . . . . . . .24
Data Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
OptiSet Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
FreshSet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Defrost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Opening the Front Doors . . . . . . . . . . . . . . . . . . . . . . .27
Engine Compartment . . . . . . . . . . . . . . . . . . . . . . . . . .28
Unit Protection Devices . . . . . . . . . . . . . . . . . . . . . . . .28

4
Remote Status Display (Optional) . . . . . . . . . . . . . .32
Manual Pretrip Inspection
(Before Starting the Unit) . . . . . . . . . . . . . . . . . . . . .35
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . .37
SMART REEFER 4 (SR-4) Controller Overview . . . . .37
Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Control Panel Display . . . . . . . . . . . . . . . . . . . . . .38
Display Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Hard Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Soft Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Turning Unit On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
If a Flash Drive is Connected: . . . . . . . . . . . . . . . .41
Configurable Soft Keys . . . . . . . . . . . . . . . . . . . . .43
Display Heater . . . . . . . . . . . . . . . . . . . . . . . . . . .44
If a Language is Enabled . . . . . . . . . . . . . . . . . . .44
If Log Alarms are Present . . . . . . . . . . . . . . . . . . .45
Turning The Unit Off . . . . . . . . . . . . . . . . . . . . . . . . . .47
The Standard Display . . . . . . . . . . . . . . . . . . . . . . . . .47
The TemperatureWatch Display . . . . . . . . . . . . . . . . .48
Changing The Setpoint . . . . . . . . . . . . . . . . . . . . . . . .49
Numerical Setpoints . . . . . . . . . . . . . . . . . . . . . . .49
Named Products - OptiSet Plus . . . . . . . . . . . . . .50
Both Numerical Setpoints and Named Products . 50
Changing the Setpoint - Numerical Setpoint . . . . 51
Changing the Setpoint - Named Product . . . . . . . 55
Changing the Setpoint - Both Numerical Setpoint
and Named Product Available . . . . . . . . . . . . . . . 59
Starting the Diesel Engine . . . . . . . . . . . . . . . . . . . . . 60
Starting the Electric Motor . . . . . . . . . . . . . . . . . . . . . 61
Switching from Diesel to Electric . . . . . . . . . . . . . . . . 62
Switching from Electric to Diesel . . . . . . . . . . . . . . . . 63
Initiating a Manual Defrost Cycle . . . . . . . . . . . . . . . . 64
Terminating a Defrost Cycle . . . . . . . . . . . . . . . . . . . . 67
Selecting Cycle Sentry or Continuous Mode . . . . . . . 67
Using the Gauges Key . . . . . . . . . . . . . . . . . . . . . . . . 71
Gauges Available . . . . . . . . . . . . . . . . . . . . . . . . . 71
Using The Sensors Key . . . . . . . . . . . . . . . . . . . . . . . 73
Sensors Available . . . . . . . . . . . . . . . . . . . . . . . . 74
Using the Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . 75
Pretrip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Performing a Pretrip Test . . . . . . . . . . . . . . . . . . . 78
Flash Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Flash Drive Icon . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Selecting the Flash Drive Menu from the Main Menu
(If Already Connected) . . . . . . . . . . . . . . . . . . . . . . . . 84
Removing the Flash Drive . . . . . . . . . . . . . . . . . . . . . 85

5
Languages (If Enabled) . . . . . . . . . . . . . . . . . . . . . . . . 86
Available Languages . . . . . . . . . . . . . . . . . . . . . . 86
Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Log Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Check Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Shutdown Alarms . . . . . . . . . . . . . . . . . . . . . . . . . 91
Pretrip Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Clearing Alarm Codes . . . . . . . . . . . . . . . . . . . . . 92
Displaying and Clearing Alarm Codes . . . . . . . . . 93
Gauges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Displaying Gauges . . . . . . . . . . . . . . . . . . . . . . . . 98
Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Displaying Sensors . . . . . . . . . . . . . . . . . . . . . . . . 99
Data Logger (CargoWatch) . . . . . . . . . . . . . . . . . . . . 100
Sending Start of Trip Marker to CargoWatch and Service-
Watch Data Loggers . . . . . . . . . . . . . . . . . . . . . . . . . 101
Hourmeters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Viewing Hourmeters . . . . . . . . . . . . . . . . . . . . . . 104
Mode Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
SmartPower Electric Standby Option . . . . . . . . . 113
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Clear All ECU Faults . . . . . . . . . . . . . . . . . . . . . . 118
Optional Rear Remote Control Panel . . . . . . . . . . .121
Rear Remote Control Panel Functionality . . . . . . . . .121
Rear Remote Control Action Set to Run . . . . . . .121
Rear Remote Control Action Set to STAND BY .122
Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
Reading a Typical Remote Standard Display . . .126
Remote Control Panel Lockout . . . . . . . . . . . . . .126
Turning the Unit ON or OFF (Configured for STAND
BY Operation) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127
Turning the Unit On and Off (Configured for RUN
Operation) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127
Changing the Setpoint . . . . . . . . . . . . . . . . . . . . . . . .128
Selecting Cycle-Sentry or Continuous Mode . . . . . . .129
Displaying the Discharge Air Temperature . . . . . . . .130
Viewing and Clearing Alarm Codes . . . . . . . . . . . . . .131
Starting a Manual Defrost Cycle . . . . . . . . . . . . . . . .132
Sending a Start of Trip Marker . . . . . . . . . . . . . . . . . .133
Running a Pretrip Test . . . . . . . . . . . . . . . . . . . . . . . .134
Loading and Enroute Inspections . . . . . . . . . . . . .136
Pre-Loading Inspection . . . . . . . . . . . . . . . . . . . . . . .136
Post-Loading Inspection . . . . . . . . . . . . . . . . . . . . . .138
Enroute Inspections . . . . . . . . . . . . . . . . . . . . . . . . . .139

6
Alarm Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142
Alarm Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142
Clearing Alarm Codes . . . . . . . . . . . . . . . . . . . . . . . .145
Jump Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .175
Belt Tension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .178
Refrigeration System . . . . . . . . . . . . . . . . . . . . . . . . .179
Electrical Control System . . . . . . . . . . . . . . . . . . . . .181
Electrical Components . . . . . . . . . . . . . . . . . . . . . . . .182
Electric Heater Strips . . . . . . . . . . . . . . . . . . . . . . . . .184
Electrical Standby (Smart Power Units Only) . . . . . .184
Electric Motor and Overload Relay . . . . . . . . . . .184
Standby Power Cord Requirements . . . . . . . . . .185
Electric Fuel Heater (Optional) . . . . . . . . . . . . . . . . .185
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
Maintenance Inspection Schedule . . . . . . . . . . . . 193
Serial Number Locations . . . . . . . . . . . . . . . . . . . . 198
Emergency Cold Line . . . . . . . . . . . . . . . . . . . . . . . 201
Recover Refrigerant . . . . . . . . . . . . . . . . . . . . . . . . 202
CALIFORNIA
Proposition 65 Warning . . . . . . . . . . . . . . . . . . . . . 203
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204

7
Introduction
There is nothing complicated about operating and maintaining
your Thermo King unit, but a few minutes studying this
manual will be time well spent.
Performing pre-trip checks and enroute inspections on a
regular basis will minimize on-the-road operating problems. A
regular maintenance program will also help to keep your unit
in top operating condition. If factory recommended procedures
are followed, you will find that you have purchased the most
efficient and dependable temperature control system available.
All service requirements, major and minor, should be handled
by a Thermo King dealer for four very important reasons:
• They are equipped with the factory recommended tools to
perform all service functions
• They have factory trained and certified technicians
• They have genuine Thermo King replacement parts
• The warranty on your new unit is valid only when the
repair and replacement of component parts is performed
by an authorized Thermo King dealer.
IMPORTANT: This manual is published for informational
purposes only and the information furnished herein should
not be considered as all-inclusive or meant to cover all
contingencies. If more information is required, consult your
Thermo King Service Directory for the location and
telephone number of the local dealer.

8
EPA Emission Control System Warranty
Statement
Thermo King warrants to the initial owner and each subsequent
owner that the certified, non-road diesel engine in your unit is:
1. Designed, built and equipped so as to conform, at the time
of sale, with all applicable regulations adopted by the
United States Environmental Protection Agency (EPA).
2. Free from defects in materials and workmanship in
specific emission related parts for a period of five years or
3,000 hours of operation, whichever comes first, after date
of delivery to the initial owner.
If an emission-related part or component fails during the
warranty period, it will be repaired or replaced. Any such part
or component repaired or replaced under warranty is warranted
for the warranty period.
During the term of this warranty, Thermo King will provide,
through a Thermo King authorized service dealer or other
establishment authorized by Thermo King, repair or
replacement of any warranted part at no charge to the non-road
engine owner.
In emergency, repairs may be performed at any service
establishment, or by the owner, using any replacement part.
Thermo King will reimburse the owner for their expenses,
including diagnostic charges for such emergency repair. These
expenses shall not exceed Thermo King’s suggested retail price
for all warranted parts replaced, and labor changes based on
Thermo King’s recommended time allowance for the warranty
repair and the geographically appropriate hourly labor rate.

EPA Emission Control System Warranty Statement
9
Any replacement part can be used for maintenance or repairs.
The owner should ensure that such parts are equivalent in
design and durability to genuine Thermo King parts. However,
Thermo King is not liable for parts that are not genuine
Thermo King parts.
A part not being available within 30 days or repair not being
completed within 30 days constitutes an emergency.
As a condition of reimbursement, replaced parts and received
invoices must be presented at a place of business of a Thermo
King authorized service dealer or other establishment
authorized by Thermo King.
This warranty covers the following emission-related parts and
components:
• Fuel Injection System
• Intake Manifold
•ExhaustManifold
• Miscellaneous hoses, clamps, connectors and sealing
devices used in the above systems.
If failure of one of these parts or components results in failure
of another part or component, both will be covered by this
warranty.
Responsibilities
This warranty is subject to the following:
Thermo King Corporation
Responsibilities
During the emission warranty period, if a defect in material or
workmanship of a warranted part or component is found,
Thermo King will provide:
• New, remanufactured, or repaired parts or components
required to correct the defect.
NOTE: Items replaced under this warranty become the
property of Thermo King.
• Labor, during normal working hours, required to make the
warranty repair. This includes diagnosis and labor to
remove and install the engine, if necessary.

EPA Emission Control System Warranty Statement
10
Owner Responsibilities
During the emission warranty period, the owner is responsible
for:
• The performance of all required maintenance. A warranty
claim will not be denied because the scheduled
maintenance was not performed. However, if the lack of
required maintenance was the reason for the repair, then
the claim will be denied.
• Premium of overtime cost.
• Cost to investigate complaints that are not caused by
defects in Thermo King material or workmanship.
• Providing timely notice of a warrantable failure and
promptly making the product available for repair.
Limitations
Thermo King is not responsible for resultant damages to an
emission-related part or component resulting from:
• Any application or installation Thermo King deems
improper as explained in this Operator’s Manual, or any
other manuals provided for the unit.
• Attachments, accessory items, or parts not authorized for
use by Thermo King.
• Improper off-road engine maintenance, repair or abuse.
• Owner’s unreasonable delay in making the product
available after being notified of a potential product
problem.
This warranty is in addition to Thermo King’s standard
warranty applicable to the off-road engine product involved.
Remedies under this warranty are limited to the provision of
material and services as specified herein. Thermo King is not
responsible for incidental or consequential damages such as
downtime or loss of engine powered equipment.

11
Safety Precautions
Thermo King recommends that servicing be done only by a
Thermo King dealer. However, you should be aware of several
safety practices. This chapter gives basic safety precautions for
working with Thermo King units and describes the safety
stickers on your unit that you should be familiar with.
General Safety Practices
DANGER: NEVER operate the unit with the
compressor discharge valve closed. Doing so could
cause the compressor to explode, causing death or
serious injury.
WARNING: Always wear goggles or safety glasses
when working with or around the refrigeration system
or battery. Refrigerant or battery acid can cause
permanent damage if it comes in contact with your
eyes.
WARNING: Keep hands and loose clothing clear of
fans and belts at all times when the unit is operating
or when opening or closing compressor service
valves.
WARNING: Exposed coil fins can cause painful
lacerations. Service work on the evaporator or
condenser coils should be done by a certified Thermo
King technician.
WARNING: Do not apply heat to a closed cooling
system. Before applying heat to a cooling system,
drain it. Then flush it with water and drain the water.
Antifreeze contains water and ethylene glycol. The
ethylene glycol is flammable and can ignite if the
antifreeze is heated enough to boil off the water.
CAUTION: Use extreme caution when drilling holes
in the unit. Drilling into electrical wiring or
refrigerant lines could cause a fire. Do not drill into
structural components.

Safety Precautions
12
Automatic Start/Stop Operation
This unit is capable of automatic operation and could start at
any time without warning.
Electrical Hazard
Battery Installation and Cable
Routing
WARNING: The unit can start at any time without
warning. Press the OFF key on the control panel and
place the microprocessor On/Off switch in the Off
position before inspecting or servicing any part of the
unit.
DANGER: Dangerous three phase AC electric power
is present whenever the unit is operating in either
Diesel Mode or Electric Mode and whenever the unit
is connected to a source of external standby power.
Voltages of this magnitude can be lethal. Exercise
extreme caution when working on the unit.
WARNING: Improperly installed battery could result
in a fire or explosion. A Thermo King approved
battery must be installed and properly secured to the
battery tray.
WARNING: Improperly installed battery cables could
result in fire or explosion. Battery cables must be
installed, routed and secured properly to prevent
them from rubbing, chaffing or making contact with
hot, sharp or rotating components.
WARNING: Do not attach fuel lines or any
additional wiring harnesses to the battery cables as
this could cause an electrical fire.
CAUTION: Do not connect other manufacturer’s
equipment or accessories to the Thermo King unit.
This could result in severe damage to equipment and
void the warranty.

Safety Precautions
13
Refrigerant
Although fluorocarbon refrigerants are classified as safe, use
caution when working with refrigerants or in areas where they
are being used.
CAUTION: Set all unit electrical controls to the OFF
position before connecting battery cables to the
battery to prevent unit fromstarting unexpectedly and
causing personal injury.
CAUTION: Always wear protective clothing, gloves
and eye wear when handling and installing batteries.
Battery acid can cause serious burns when exposed to
eyes or skin. If battery acid contacts skin or clothing,
wash immediately with soap and water. If acid enters
your eye, immediately flood it with running cold
water for at least twenty minutes and get medical
attention immediately.
CAUTION: Always cover battery terminals to prevent
them from making contact with metal components
during battery installation. Battery terminals
grounding against metal could cause the battery to
explode.
DANGER: Fluorocarbon refrigerants can produce
toxic gases. In the presence of an open flame or
electrical short, these gases are severe respiratory
irritants CAPABLE OF CAUSING DEATH.
DANGER: Fluorocarbon refrigerants tend to
displace air and can cause oxygen depletion which
could result in DEATH BY SUFFOCATION. Provide
adequate ventilation in enclosed or confined areas.
WARNING: Fluorocarbon refrigerants evaporate
rapidly, freezing anything they contact if accidentally
released into the atmosphere from the liquid state.

Safety Precautions
14
Refrigerant Oil
Observe the following precautions when working with or
around refrigerant oil:
First Aid
First Aid–Refrigerant
Eyes: For contact with liquid, immediately flush eyes with
large amounts of water. Get prompt medical attention.
Skin: Flush areas with large amounts of warm water. Do not
apply heat. Wrap burns with dry, sterile, bulky dressing to
protect from infection or injury. Get prompt medical attention.
Inhalation: Move victim to fresh air and restore breathing if
necessary. Stay with victim until emergency personnel arrive.
First Aid–Refrigerant Oil
Eyes: Immediately flush eyes with large amounts of water for
at least 15 minutes while holding the eyelids open. Get prompt
medical attention.
Skin: Remove contaminated clothing. Wash thoroughly with
soap and water. Get medical attention if irritation persists.
Inhalation: Move victim to fresh air and restore breathing if
necessary. Stay with victim until emergency personnel arrive.
Ingestion: Do not induce vomiting. Immediately contact
local poison control center or physician.
WARNING: Always wear goggles or safety glasses to
protect eyes from refrigerant oil contact.
WARNING: Protect skin and clothing from
prolonged or repeated contact with refrigerant oil.
Rubber gloves are recommended.
WARNING: Wash thoroughly immediately after
handling refrigerant oil to prevent irritation.

Safety Precautions
15
Safety Decals and Locations
Condenser and Evaporator Fans
Be aware of the warning nameplates near the condenser fans
and evaporator fans (example in Figure 1).
Figure 1: Fan Warning
High Voltage Components
Various components on the Precedent unit operate using
220/3/60 or 460/3/60 high voltage and are identified by
warning nameplates (examples in Figure 2). All high voltage
wiring is identified by ORANGE conduiting. Be aware of the
locations of these components. Only certified, trained
technicians can service them.
Figure 2: High Voltage Warning
NOTE: See Figure 3 and Figure 4 for high voltage
component locations.
AMA1581
AMA1580
AMA1579

Safety Precautions
16
1. Condenser Motors 4. High Voltage Control Box
2. Evaporator Motor 5. AC Generator
3. High Voltage
Distribution Box 6. Electric Standby Motor & Power Receptacle
(SmartPower Option)
Figure 3: High Voltage Component Locations (Front)
1
2
3
4
5
6
7. Evaporator Motor 9. High Voltage Junction
Box
8. High Voltage Heater
Strips All ORANGE conduiting contains High Voltage
Figure 4: High Voltage Component Locations (Rear)
7
8
9
9

Safety Precautions
17
Do Not Use Ether Starting Aids
Figure 5: Do Not Use Ether Starting Aids
(Near Engine)

18
Unit Description
Unit Overview
The Thermo King Precedent C-600 is a one piece,
self-contained, diesel powered, air cooling/heating unit
operating under the control of a SMART REEFER 4 (SR-4)
programmable microprocessor controller. The unit mounts on
the front of the trailer with the evaporator extending through an
opening in the front wall.
The units feature all-new DDE (Diesel Direct Electric)
architecture, the quiet running Thermo King TK486V25
engine and the Thermo King X-430 reciprocating compressor.
The C-600 is available in the following models:
Standard : Cooling and heating on diesel engine operation.
SmartPowerTM Option: Cooling and heating on diesel
engine operation and electric standby operation.
See the following Features and Options.
Figure 6: C-600 Front View

Unit Description
19
Features and Options
The following chart lists key design features and options.
lStandard Features
mOption/Factory installed
oOption/Dealer Installed
Precedent C-600 Key Features & Options
SMART REEFER SR-4 Controller l
SmartPower Electric Standby m
SmartPower High-Output m
SmartPower Prep Package m
OptiSet Plus l
ETV (Electronic Throttling Valve) l
ServiceWatch Data Logger l
CargoWatch Data Logger l
CargoLink Sensor Kits m / o
CargoLink Wireless Sensors m / o
EMI-3000 l
High-Capacity Condenser Coil l
Easy-access door design l
Composite Exterior Panels l
Long-Life Coolant/Silicone Hoses l
Remote Status Display m / o
Standard Unit Color White l
Standard Grille Color Black l
Directional Air Delivery l
Vibration Isolation System l
Aluminum Undermount Fuel Tank 50 Gal.
(186 Liter) l
Fuel Level Sensor l
Severe Duty Package m
Fuel Tanks with Ultrasonic Fuel level
Sensor m
Electric Fuel Heater m
Frost Plug Heater m
Alternator, 65 Amp, 12 Vdc m
Appearance Packages m
Precedent C-600 Key Features & Options
