Thermo Scientific AutoWAVE 1-0479-013 User manual

Part of Thermo Fisher Scientific
AutoWAVE®
Handheld Radio
User Guide
P/N 1-0479-013
Revision B

AutoWAVE®
Handheld Radio
User Guide
P/N 1-0479-013
Revision B

©2007 Thermo Fisher Scientific Inc. All rights reserved.
All trademarks are the property of Thermo Fisher Scientific Inc. and its subsidiaries.
Thermo Fisher Scientific (Thermo Fisher) makes every effort to ensure the accuracy and completeness of
this manual. However, we cannot be responsible for errors, omissions, or any loss of data as the result of
errors or omissions. Thermo Fisher reserves the right to make changes to the manual or improvements to
the product at any time without notice.
The material in this manual is proprietary and cannot be reproduced in any form without expressed
written consent from Thermo Fisher.
Thermo Fisher Scientific
1410 Gillingham Lane
Sugar Land, TX 77478
USA
Phone: [phone]
Fax: [phone]
Web: www.thermofisher.com
Thermo Fisher Scientific
14 Gormley Industrial Avenue
Gormley, Ontario L0H 1G0
Canada
Phone: [phone]
Fax: [phone]

This page intentionally left blank.

Document 1-0479-013 Rev B
1
AutoWAVE
HAND-HELD RADIO
USER MANUAL
CONTENTS
Section Title Page
1.0 GENERAL INFORMATION ..............................................3
1.1 SPECIFICATIONS ...................................................4
2.0 QUICK SETUP ........................................................5
3.0 TUNING TRANSCEIVER PERFORMANCE .................................6
3.1 (0)Set Operation Mode ................................................7
4.0 OPERATION MODE SELECTIONS ........................................8
(0)Point-to-PointMaster............................................8
(1)Point-to-PointSlave.............................................8
(2)Point-to-MultipointMaster .......................................8
(3)Point-to-Multipointslave.........................................8
(4)Point-to-PointSlave/Repeater .....................................8
(5)Point-to-PointRepeater ..........................................9
(6)Point-to-PointSlave/MasterSwitchable .............................9
(7)Point-to-MultipointRepeater.....................................13
5.0 MULTIPOINT OPERATION .............................................14
(0)NumberRepeaters .............................................14
(1)MasterPacketRepeat...........................................14
(2)MaxSlaveRetry...............................................15
(3)RetryOdds ...................................................15
(4)DTRConnect .................................................15
(5)RepeaterFrequency ............................................15
(6)NetworkID...................................................15
(8) Multimaster Synch .............................................16
6.0 BAUD RATE SELECTIONS ............................................17
(1)SetBaudRate.................................................17
(2)DataWordLengthandParity ....................................17
(3)ModBusRTU.................................................18

Document 1-0479-013 Rev B
2
7.0 CALL BOOK SELECTIONS .............................................19
(2)EditCallBook ................................................19
8.0 RADIO TRANSMISSION PARAMETERS .................................22
(0)FreqKey .....................................................22
(1)MaxPacketSizeand(2)MinPacketSize...........................23
(3)XmitRate ....................................................25
(4)RFDataRate .................................................25
(5)RFXmitPower................................................25
(6)SlaveSecurity.................................................26
(7)RTStoCTS ..................................................26
(8)RetryTimeOut................................................27
9.0 RADIO STATISTICS ...................................................27
10.0 TRANSCEIVER LOCATION .............................................27
11.0 STATUS LEDS ........................................................28
12.0 USING AN EXTERNAL ANTENNA ......................................30
13.0 RS-232 PIN ASSIGNMENTS .............................................31
14.0 DATA COMMUNICTIONS SETTINGS ....................................32
15.0 ESTABLISHING DATA COMMUNICTION LINKS ..........................33
16.0 TROUBLESHOOTING ..................................................36

Document 1-0479-013 Rev B
3
1.0 GENERAL INFORMATION
This document describes applications for the AutoWAVE hand-held
radio when used with Thermo Scientific AutoPILOT, AutoMATE
or SuperFlo II Flow Computers.
The AutoWAVE hand-held radio uses spread spectrum technology
which allows a high bit rate (1200 baud to 115.2 kilobaud) while
maintaining low bit error rates. The radios operate in the 902-928
MHZ frequency band which does not require Federal Communications
Commission (USA) licensing.
Features of the AutoWAVE hand-held radios include:
* 1,005 frequencies over 902-928 MHZ, with 15
selectable hop patterns.
* Compact size (4” wide x 1.75” deep x 6.3” high
without antenna) and low weight. Compact enclosure
contains radio/ modem and power supply (including
batteries).
* Standard RS-232 asynchronous interface operates at up
to 115.2 Kbps.
* AllconfigurationoptionsbyprogrammingradiousingapersonalcomputerorASCII
terminal.
* Same radio hardware used for master or remote radio.
* Low power consumption:
650 ma at 12V for 1W.
600 ma at 8.5V for 400 mW.
5 mA sleep mode current.
* Operates on standard AA batteries (4) or external 5-15 Vdc..

Document 1-0479-013 Rev B
4
1.1 SPECIFICATIONS
Frequency.................................................. 902 - 928 MHZ
Transmitter
OutputPower.................................. 1W(+30dBm)at9.5V to 14V
400 mW (+25 dBm) at 7.5V to 9.5V
Modulation .......................................... GFSK,120 kBs-170kBs
OccupiedBandwidth ............................................... 230kHz
Receiver
Sensitivity ....................................... -108 dBm at 10-6 raw BER
Selectivity .............................................40dB at fc ±230 kHz
60dB at fc ±460kHz
Data Transmission
ErrorDetection ................................... 32bitCRC, resend on error
Dataencryption .....................................Substitution, dynamic key
Link throughput .................................................115 Kbaud
Interface ..................RS-232, 0- to 5V TTL levels, 1200 Baud to 115.2 Kbaud
Power Requirements:
Transmitcurrent................ 650 ma at 12V for 1W, 600ma at 8.5V for 400 mW
Receive current ..............................................100 ma at 12V
Idle ...............................................................65ma
Sleep...............................................................5ma
