Thermokon PDE2 Series User guide

Measured Differential Air Pressure
Sensor Characteristics
Passive
Sensor Output (s) ON / OFF
Measuring Range (s) See Product Range, Page 1
Default TOP Switching Point (s) See Product Range, Page 1
Differential Gap See Product Range, Page 1
Repeatability 2%
Over Pressure Max. 7.5kPa
Switching Cycles > 1.000.000
Switch Type Single-pole, change over contact
Screw terminal, max. 2.5mm²
Relay Rating
AC 250V, max. 3A; DC 30V, max. 2A
Connection Nozzle Dimension
Cable Entry M16, Ø6...Ø8mm cables
Internal, bottom of the housing
Set Point Adjustments
See Product Range, Page 1
No button / Automatically
Housing Cover White PC, RAL9010 (Pure White), with Clear Window
Grey PC, RAL7042 (Traffic Grey A)
Lock Screws US:AISI 304; EU: EN X 6 CrNi 18 10; GER: W.N. 1.301
Lock Nuts Brass
Cable Gland Red ABS, RAL2002 (Vermilion)
Gland Rubber Seal White TBS, RAL9010 (Pure White)
Protection Caps Red ABS, RAL2002 (Vermilion)
User element Red ABS, RAL2002 (Vermilion)
Connection Nozzle Grey PC, RAL7042 (Traffic Grey A)
Silicone, emission free
Operation Temperature
Operation Humidity <85% r.h., no condensation
Transport Temperature -35⁰C...+70⁰C
Transport Humidity < 90% r.h.
Storage Humidity < 85% r.h., no condensation
IP- Rating IP54 to IEC60529
Safety Class III to EN 60 730
Product Standard 1
2009/EN 60 730-1
CE Conformities to
2004/108/EG Electromagnetic Compatibility EMV
CE Electromagnetic Compatibility Emitted Interference 2000/EN60730-1 Emitted Interference
CE Electromagnetic Compatibility Interference resistance 2000/EN60730-1 Interference Resistance
RoHS Compatibility RoHS 2011/65/EC
Operation Climatic Condition IEC 60 721-3-3
Operation Mechanical Condition IEC 60 721-3-2 to class2M2
Transport to Climatic Condition IEC 60 721-3-2
Transport Mechanical Condition IEC 60 721-3-2 to class2M2
Storage Climatic Condition
IEC 60 721-3-1
Storage Mechanical Condition IEC 60 721-3-1 to class2M2
Automatic Electric. Controls for household and similar use
Product Standard 2
3250e_MIS
Mounting Instruction
PDE2- Series (dP)
Air Differential Pressure Switch
Terminal Clamp
Mechanical Information
Storage Temperature
-10⁰C...+70⁰C
Norms and Directives
All Information and technical data are subject to alternation
Thermokon
PDE2- Series (dP)
V1.2
Page 1/2
The PDE2-Series is designed to measure differential pressure in HVAC systems with non-flammable gases and non-
aggressive gases. The control output is 2-point (ON/OFF). The differential switch has an internal set point adjuster.
Product Range
Sensor Specifications
Technical Information
Ø6.3 x 1.15mm, L=10mm
Sensing Element Position
User Interface
Release Button
Color and Materials
Housing Bottom
Diaphragm
Environmental Conditions
-25⁰C...+70⁰C
Sensor Specification
Electrical Information

Connection Instruction
1 2 3 4 5 6 7 8
Wiring / Function Diagrams
use a Philips #2
screwdriver
use a Philips #2
screwdriver
turn left, than right and
left again to select the
setpoint. Use a slotted
8mm screw driver.
Dimensional Drawing
Wireing / Funtion Diagram
use a Philips #2
screwdriver
Advices
Security Advice
The installation and assembly of electrical equipment may only be performed by a skilled electrician.
The products must not be used in any relation with equipment that supports, directly or indirectly, human health, life or with applications that
can result in danger for people, animals or real value.
Mounting Advices
The products are suitable to be mounted on walls or air ducts.
Each product is individually calibrated.
The product can be mounted in any position, but we recommend to install the product vertically. If this is not possible, following deviations
are expected: Cover facing upwards +20Pa; Cover facing downwards -10Pa.
Installation Notes
The product must be installed at a suitable place and within the range of validity of the local electrical installation laws and regulations.
Commissioning Notes
Check carefully that no electrical power is applied to the product before you remove the housing cover.
For the electrical connection and the selection of the set point, remove the housing cover by opening the 2 screws located on the housing cover.
Connect the electrical wire (see Terminal Connection, Page 2) accordingly. Select with the set point dial the desired switching point TOP.
Please use a solid screw driver as the set point dial is rather tight. Put the cover back on the bottom housing.
Never apply electrical power until the housing cover is securely mounted on the bottom part.
All Information and technical data are subject to alternation
Thermokon
PDE2- Series (dP)
V1.2
Page 2/2
2
3
Phase
NC / Low
Pressure
NO / High
Pressure
1
