Thermon Terminator DE-B Reference guide

Terminator
TM DE-B Beacon
LED End of Circuit Light Kit
INSTALLATION PROCEDURES

2
Kit Contents . . .
Tools Required . . .
Receiving, Storing and Handling . . .
1. Inspect materials for damage incurred during shipping.
2. Report damages to the carrier for settlement.
3. Identify parts against the packing list to ensure the proper
type and quantity has been received.
4. Store in a dry location.
Dimensions . . .
TerminatorTM DE-B Beacon
Item Quantity Description
11
Expediter Assembly
Grommet Compressor
Grommet
Support Base with O-Ring
2 1 Light Module Cover
3 1 Banding Guide
4 1 Banding (fits 10" pipe and below)
5 1 LED Light Module
12
4
3
210mm
(8.25")
76mm
(3")
89mm
(3.5")
64mm
(2.5")
2 43 5
Order Separately . . .
SCTK Connection Termination Kits (per cable)
SCTK-1D for BSX, RSX, VSX
SCTK-2D for KSX, HTSX
SCTK-3D for FP, HPT
Item Quantity Description
1 2 Connection Boots
2 2 Large Wire Nut
3 2 Medium Wire Nuts
4 2 Small Wire Nuts
5 1 RTV Tube
6 1 GRW-G Grommet (SCTK-3D only)
61
5
IP66/Type 4X -60°C ≤Ta ≤+45°C
Ordinary & Hazardous Locations
Class I, Division 2, Groups A, B, C, & D, Zone 2 IIC T6
Class II, Division 2, Groups F & G, Class III
Certifications/Approvals . . .
Installation Precautions . . .
• To minimize the potential for arcing and fire caused by product
damage or improper installation use ground-fault protection.
The National Electrical Code (NEC) and Canadian Electrical Code
(CEC) require ground-fault protection of equipment for each
branch circuit supplying electric heat tracing.
• Installation must comply with Thermon requirements and be in-
stalled in accordance with the NEC, CEC, or any other applicable
national and local codes.
• Component approvals and performance ratings are based on
the use of Thermon specified parts only. User supplied power
connection fittings must be listed or certified for intended use.
• De-energize all power sources before opening enclosure.
• Keep ends of heating cable and kit components dry before and
during installation.
• Individuals installing these products are responsible for complying
with all applicable safety and health guidelines. Proper personal
protective equipment, or PPE, should be utilized during installa-
tion. Contact Thermon if you have any additional questions.

3
1. Locate bus connection (HPT and FP only) and
cable as shown. Cut end of cable at angle to aid
in piercing grommet. Leave additional cable for
expansion loop.
TerminatorTM DE-B Beacon
3. Slide expediter toward pipe and route cable
through support base entry.
4. Insert banding guide into expediter and snap into
place.
5. Mount expediter to pipe using pipe band. Do not
band over cable.
2. Insert cable into expediter. If mounted on bottom
of pipe, punch out weep hole.
6. Cut off end of cable.
7. Terminate cable with appropriate SCTK termination
kit. Refer to SCTK installation instructions. Push
excess cable back through expediter. Tape cable
expansion loop to pipe.
8. Connect bus wires using small wire nuts (for BSX,
HTSX and KSX) or medium wire nuts (for RSX, VSX,
HPT and FP). See wiring schematic for connec-
tions.
50mm
(2")
Max.
300mm
(12")
Bus
Connection
Weep Hole
180mm
(7") Min.
Do Not Band
Over Cable
Wiring Schematic for LED Light
Light Module
Expediter Assembly
Wire Connector
Expediter Assembly
Boot
LED Light PigtailHeating Cable
Min.
300mm
(12")

THERMON . . . The Heat Tracing Specialists®
100 Thermon Dr. •PO Box 609 •San Marcos, TX 78667-0609
Phone: [phone] •Facsimile: 512-396-3627 •1-800-820-HEAT
www.thermon.com In Canada call 1-800-563-8461
Specifications and information subject to change without notice. Form No. 50843-0411
Locked
Position
11. To remove cap, lift latch mechanism, as shown
and unscrew cap. De-energize all power sources
before opening enclosure.
10. Engage threads. Rotate light module cover
clockwise and tighten cap securely. Make sure
latch mechanism is in the locked position.
9. Slide the light module cover over light module.
Light Module
Cover
Lens
Expediter Assembly
Light Module
Unlocked
Position
