Thermorail SV24 User manual

Thermorail Swivel Rails
240Volt Heated Towel Rail
Installation Guide
SV24 / SV35 / SV43 / SV68

Contents
What’s in the box?
Installation
Safety & Care Information
Warranty
Technical Specifications
Contact Us
3
4
6
7
8
8
2

3
What’s in the box?
• Thermorail Swivel Rail
• Screw Kit including:
- 4 x Wall plugs
- 4 x Screws
- 1 x Concealed wiring cap
Check you’ve got everything:
• Cross Head Screwdriver
• Pencil
• Spirit Level
• Tape Measure
• Drill Bits
• Cordless Drill
• Electrical Supply
You will also need:
Please note these parts are not to scale
Wall PlugScrew Concealed Wiring Cap

Installation
4
The Thermorail models in this guide can be installed with either concealed or exposed wiring,
with the electrical supply connected at the bottom. For concealed wiring follow the three below
steps. For exposed wiring (plug-in) follow only step 1 and 3.
1. Plan and Measure Your Installation
Ensure the mains power supply is switched off before attempting to carry out any electrical work.
Unscrew the grey plastic screw cap from under the lower bracket. Pull the connection capsule
through the back of the lower bracket, open up the connection capsule and unwire the lead from
the terminal block. Pull the lead through the grey grommet and out the bottom of the lower
bracket. Remove the plastic grommet completely and push the concealed wiring cap into the hole
in the lower bracket. The supply cable can be wired directly into the terminal block or the lead
can be rewired in and connected to the supply cabling in the wall or ceiling cavity. Insert the
terminal block back into the protective connection capsule and press the capsule into the bracket.
See diagrams on next page.
2. Connect to Main Supply (Concealed Wiring)
6543
1Wall Cavity 2Plasterboard 3Wall Plugs 4Wall Bracket 5Screw 6Wall Bracket
21
KEY
Ensure that you have all the parts needed for installation of this towel rail. Wall plugs and screws
are provided with the rail however alternative fixings may be required depending on wall
construction.
Measure and mark out the four screw positions making sure they are level. The easiest way to do
this is to put some masking tape or similar at the location of the two mounting positions and then
hold the rail against the wall and once it is straight and level mark the four screw positions on the
tape. For safety reasons, we recommend that the heated towel rail is installed at least 600mm
above the floor. Drill a 8mm hole in the centre of each of the four marked screw positions and
insert the wall plugs provided.

Installation
Fix the towel rail to the wall by screwing the brackets onto the wall using the screws. Ensure that
no wires are trapped between the wall and the bracket.
3. Fix the Rail to the Wall
5
Open up the terminal block and unwire the
lead. Pull the lead through the grey grommet
and out the bottom of the lower bracket.
Pull the connection capsule through the back
of the lower bracket.
Unscrew the grey plastic screw cap from
under the lower bracket.
Wire the supply cable into the terminal block
and insert the terminal block back into the
protective connection capsule.
Press the connection capsule back inside the
lower bracket and proceed with fixing the rail
to the wall.
Remove the plastic grommet completely and
push the concealed wiring cap into the hole
in the lower bracket.
1 2
3 4
5 6

Safety & Care Information
Thermorail Heated Towel Rails should be installed and tested by a qualified electrician and in
accordance with current local regulations. We recommend that the rail is installed onto a flat
uniform wall at least 600mm from the floor and with a 300mm clearance from permanent
fixtures. Where possible the Thermorail Heated Towel Rail should be screwed into studs or if fixing
to hollow walls suitable anchors should be used to ensure rail is secure.
Please read and understand this installation guide in full before commencing installation. If you
have any queries in regards to installation, please call 1300 368 631.
• Observe and adhere to electrical guidelines and IP ratings when placing your Thermorail in
wet areas
• Ensure any timers or switches used are installed in correct zones according to the IP rating of
the timer/switch
• Ensure that your Thermorail is protected by a suitably rated RCD circuit
• Do not use the towel rail to hold towels or other articles that have been in contact with oil,
petroleum based products or dry cleaning fluids
• This appliance is intended to warm and dry towels and therefore is hot to touch. When near
young children or infirm persons, close supervision is necessary.
• Do not immerse your Thermorail in any liquid
Safety Information
The Stainless Steel finish of your Thermorail Heated Towel Rail is hard wearing and easy to
maintain. However any harsh scrubbing, scratching or acid based cleaning products will damage
the surface of your towel rail. Cleaning with a soft cloth and a non-abrasive cleaning agent will
give the best results.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
In order to avoid a hazard for very young children,
this appliance should be installed so that the lowest
heated rail is at least 600mm above the floor.
Care Information
6
WARNING
!

Warranty Registration
Thermogroup covers all its products with a satisfaction guarantee. In addition, Thermogroup will
supply a replacement product where a fault is shown to be caused by manufacture, materials or
workmanship providing the goods have been installed correctly and according to installation
instructions. This guarantee does not include removal, freight or installation costs. Thermogroup’s
products come with guarantees that cannot be excluded under Australian Consumer Law and you
are entitled to a replacement or refund for a major failure & compensation for any other
reasonable foreseeable loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does not amount to a major
failure.
All of the Thermorail Heated Towel Rails – Swivel Range have a 10 year warranty. To use the
warranty, repair or service the customer must provide purchase invoice/receipt, and completed
warranty registration form. The online warranty form should be completed within 60days of
installation. The warranty form can be accessed at thermogroup.com.au/warranty
If the product develops a fault within the warranty period due to normal wear and tear,
Thermogroup at its discretion will recognise whether it’s a faulty product or not. If it is impossible
or not economical for the manufacturer to repair the product, the manufacturer will replace the
faulty product with a new unit of the same model or if there is no stock available of the same
model as the product, the manufacturer will replace the product with a new unit of a similar size.
No responsibility can be taken for altered dimensions and lining up of existing holes.
The repair service offered within the warranty period only covers the faults and problems as
developed from the manufacturer’s errors. Any damage caused by improper use or carelessness or
incorrect wiring is not covered.
Thermogroup is not responsible for any monetary loss or injuries caused by improper use of this
product.
7

Contact Us
Thermogroup
[email protected]
Phone: [phone]
Technical Helpline: 1300 989 464
www.thermogroup.com.au
Technical Specications
SIZE (MM)
NO. OF BARS OUTPUT (W) IP RATINGSTOCK CODE
SV24
SV35
SV34
SV68
4
4
6
8
W600 x H540 x D99
W600 x H540 x D99
W675 x H740 x D99
W570 x H1260 x D99
48
48
77
88
IP44
IP44
IP44
IP44
Supply Voltage
Wiring Method
Warranty
240V 50Hz
Hardwired or Plug in
10 Years
