Symmons Duro 363DTB-18 Manual

Duro®
Model Numbers Specification
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
Accessory Suite
Operation & Maintenance Manual
363DTB-18, 363DTB-24, 363RH, 363TB-18,
363TB-24, 363TP, 363TR, 363TS-22, 363-SD2
Note: Append appropriate -sufx to model number.
Modifications
-STN Satin Nickel finish
For California Residents
WARNING: This product contains chemicals known to
the State of California to cause cancer, birth defects, or
other reproductive harm.
Compliance
363DTB-18 18" Double Towel Bar
363DTB-24 24" Double Towel Bar
363RH Robe Hook
363TB-18 18" Towel Bar
363TB-24 24" Towel Bar
363TP Toilet Paper Holder
363TR Towel Ring
363TS-22 Towel Shelf with Bar
363-SD2 Soap Basket
All premium accessories constructed from metal materials,
plated in standard polished chrome nish.

2
Dimensions
FF
C
C
AA
D
DG
G
A
A
A
A
A
A
A
A
A
A
E
E
H
H
I
I
K
K
L
L
H
H
I
I
K
K
N
N
O
O
P
P
Q
Q
R
R
L
L
J
J
J
J
M
M
M
M
E
E
B
B
363RH
363TB-18
363TB-24
363DTB-18
363DTB-24
363TS-22
363TP 363TR
363-SD2
SS
TT
EE UU
Measurements
A 1-13/16", 46 mm
B 2", 51 mm
C 5-3/8", 137 mm
D 4-1/8", 105 mm
E 2-1/2", 64 mm
F 6-7/8", 175 mm
G 5-3/4", 146 mm
H 18", 457 mm
I 19-13/16", 503 mm
J 3-1/4", 82 mm
K 24", 610 mm
L 25-13/16", 656 mm
M 5-3/8", 136 mm
N 22", 559 mm
O 23-13/16", 605 mm
P 4-3/4", 121 mm
Q 9-5/8", 244 mm
R 3/8", 10 mm
S 9", 228 mm
T 4-1/4", 108 mm
U 2-3/8", 60 mm
Replacement Parts
Description Part Number
Mounting
Hardware Kit RA-017
Note: Dimensions subject to change without notice.

3
Installation
1) Measure and mark centerlines
for mounting bracket installation
using dimensions on page 2.
3) With mounting brackets in posi-
tion, secure to wall using screws.
5) Hang top of accessory on mount-
ing bracket. Lower into position.
2a) Dry Wall Option: Place
mounting brackets into desired
position. Using brackets as a
guide, carefully drill 5/16" holes
into wall. Remove brackets and
install anchors.
2b) Stud Option: Center bracket on
centerline. Using brackets as a
guide, carefully drill 3/16" holes
into wall.
Note:
363DTB-18, 363DTB-24, 363TB-18,
363TB-24, 363TS-22 only. Make
sure both centerline marks are level.
33
1
2
Note:
For plaster walls 1/2" thick or
less, insert toggle tool into toggle
to secure behind wall prior to
installing accessory trim.
1
2
1
2
4) Secure with set screw.
1
2
363-SD2 Only: Carefully drill 5/16"
holes into wall and install anchors.
Secure to wall using screws.

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2017 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-3020 REV E ■062017
Troubleshooting Chart
Problem Cause Solution
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then quickly
rinse with water.
