THERMOROSSI WAIR6 Installation and operating instructions

ITA - Informazioni importanti per la sicurezza ed il corretto funzionamento.
FRA - À lire impérativement ! Informations importantes pour la sécurité et le bon fonctionnement.
ENG - Must read! Important information for safety and correct operation.
DEU - Unbedingt lesen! Wichtige Informationen zur Sicherheit und zum sicheren Betrieb.
ESP - ¡Leer! Informaciones importantes para la seguridad y el correcto funcionamiento.
NL - Belangrijke informatie voor de veiligheid en de correcte werking.
WAIR6 –WAIR8 –WAIR10
ITA - MANUALE DI INSTALLAZIONE, USO E MANUTENZIONE.
FRA - MANUEL D’INSTALLATION, D’UTILISATION ET ENTRETIEN.
ENG - INSTALLATION, USE AND MAINTENANCE GUIDE.
DEU - INSTALLATIONS, BETRIEBS UND WARTUNGSANLEITUNG.
ESP - MANUAL DE INSTALACIÓN USO Y MANTENIMIENTO.
NL - HANDLEIDING VOOR INSTALLATIE, GEBRUIK EN ONDERHOUD.

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 1
ENG

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 2
ENG
INDEX
1 –INTRODUCTION.................................................................................................................................. 5
2 –TECHNICAL CHARACTERISTICS...................................................................................................... 7
3 –GENERAL DESCRIPTION.................................................................................................................. 8
4 –INSTALLATION..................................................................................................................................10
5 –USE OF THE APPLIANCE.................................................................................................................13
6 –CLEANING AND MAINTENANCE .....................................................................................................16
7 –SMOKE DISCHARGE TUBE AND VENTILATION OF THE ROOMS.................................................18
8 –PROBLEMS, CAUSES AND SOLUTIONS.........................................................................................20
EU Declaration of Conformity (DoC) / Dichiarazione di Conformità UE (DoC)
Company name:
Azienda:
THERMOROSSI S.P.A.
Postal address:
Indirizzo:
VIA GRUMOLO, N° 4
Postcode and city:
Codice postale e città:
36011 ARSIERO (VI)
Telephone number:
Numero di telefono:
0445/741310
E-mail address:
Indirizzo e-mail:
[email protected]
declare that the DoC is issued under our sole responsibility and belongs to the following product:
dichiara che la dichiarazione viene rilasciata sotto la propria responsabilità e si riferisce al seguente prodotto:
Apparatus model / Product:
Descrizione prodotto:
Stufa a legna
Wood stove
Trademark:
Marchio:
THERMOROSSI
Models:
Modelli:
WAIR6
WAIR8
WAIR10
The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:
L'oggetto della dichiarazione di cui sopra è conforme alla pertinente normativa di armonizzazione dell'Unione:
•Direttiva 2014/30/UE, EMCD
•Direttiva 2014/35/UE, LVD
•Direttiva 2011/65/UE, RoHS
•2014/30/EU Directive, EMCD
•2014/35/EU Directive, LVD
•2011/65/EU Directive, RoHS
Sono state applicate le seguenti norme armonizzate e/o specifiche tecniche:
The following harmonised standards and/or technical specifications have been applied:
EN 55014-1
EN 55014-2
EN 61000-3-2
EN 61000-3-3
EN 60335-1
EN 60335-2-102
EN 62233
EN 50581
EN 13240 for WAIR10 tests carried out by the notified laboratory Kiwa Cermet Italia S.p.a (N.B. 0476) Viale Venezia, 45 31020
San Vendemiano (TV).
EN 13240 for WAIR6 –WAIR8 tests carried out by the notified laboratory TÜV Rheinland Energy GmbH (NB 2456), Am Grauen
Stein D-51105, Koln (DE).
Arsiero, 10/02/2023
Firma/Sign.

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 3
ENG
DICHIARAZIONE DI PRESTAZIONE IN ACCORDO CON IL REGOLAMENTO (UE) 305/2011
DECLARATION OF PERFORMANCE ACCORDING TO REGULATION (EU) 305/2011
N° 64
1
Codice di identificazione unico del prodotto-tipo: WAIR6
Unique identification code of the product type:
2
Modello, lotto, serie ai sensi dell'articolo 11, paragrafo 4: WAIR6
Model, batch or serial number required under Article 11(4):
3
Usi previsti del prodotto da costruzione, conformemente alla relativa specifica tecnica armonizzata:
Intended uses of the construction product, in accordance with the applicable harmonised technical specification:
Apparecchio per il riscaldamento domestico, senza acqua, alimentato a ceppi di legna / Residential space heating appliance without water fired by wood logs
4
Nome registrato e indirizzo del fabbricante ai sensi dell'articolo 11, paragrafo 5:
Namek and contact address of the manufacturer as required pursuant Article 11 (5):
THERMOROSSI S.P.A. Via Grumolo, n° 4 36011 Arsiero (VI)
5
Nome e indirizzo del mandatario ai sensi dell’articolo 12, paragrafo 2:
Name and address of the agent as required pursuant Article 12 (2):
-
6
Sistema di valutazione e verifica della costanza della prestazione del prodotto da costruzione di cui all'allegato V: Sistema 3
System of assessment and verification of constancy of performance of the construction product as set out in Annex V: System 3
7
Laboratorio notificato: Notified laboratory:
TÜV Rheinland Energy und Umwelt GmbH N° 2456
Numero del rapporto di prova secondo il sistema 3 / Test report number based on System 3:
K15832015T1
8
Prestazione dichiarata / Declared performance
Specifica tecnica armonizzata/Harmonized technical specification:
EN 13240:2001
Caratteristiche Essenziali / Essential characteristics
Prestazione / Performance
Reazione al fuoco / Reaction to fire
A1
Distanza da materiali combustibili
Distance to combustible materials
Minime distanze / Minimum distances (mm):
posteriore/rear = 200 lati/sides = 500 frontale / front = 1.000
soffitto/ceiling = - pavimento / floor = -
Rischio di fuoriuscita di braci incandescenti / Risk of burning fuel falling out
Conforme/Compliant
Temperatura superficiale/Surface temperature
Conforme/Compliant
Sicurezza elettrica / Electrical safety
-
Pulizia / Cleanability
Conforme/Compliant
Emissione di prodotti della combustione /Emission of combustion products
CO = 987 mg/m3 a potenza termica nominale / CO at Nominal heat output
Pressione massima di esercizio / Maximum operating pressure
- bar
Temperatura fumi a potenza termica nominale / Flue gas temperature at nominal heat output
T 207 °C
Resistenza meccanica (per sopportare il camino) / Mechanical resistance (to carry a
chimney)
NPD {Nessuna Prestazione Determinata}
Potenza termica nominale / Nominal heat output
Potenza termica resa in ambiente / Room heating output
Potenza termica ceduta all’acqua / Water heating output
6,06 kW
6,06 kW
-- kW
Rendimento / Efficiency
86,77 % alla potenza termica nominale / Nominal heat output
9
La prestazione del prodotto di cui ai punti 1 e 2 è conforme alla prestazione dichiarata di cui al punto 8. Firma:
Si rilascia la presente dichiarazione di prestazione sotto la responsabilità esclusiva del fabbricante di cui al punto 4.
The performance of the product identified in points 1 and 2 is in conformity with the declared performance in point 8.
This declaration of performance is issued under the sole responsibility of the manufacturer identified in point 4.
Arsiero, 01/10/2015
DICHIARAZIONE DI PRESTAZIONE IN ACCORDO CON IL REGOLAMENTO (UE) 305/2011
DECLARATION OF PERFORMANCE ACCORDING TO REGULATION (EU) 305/2011
N° 64A
1
Codice di identificazione unico del prodotto-tipo: WAIR8
Unique identification code of the product type:
2
Modello, lotto, serie ai sensi dell'articolo 11, paragrafo 4: WAIR8
Model, batch or serial number required under Article 11(4):
3
Usi previsti del prodotto da costruzione, conformemente alla relativa specifica tecnica armonizzata:
Intended uses of the construction product, in accordance with the applicable harmonised technical specification:
Apparecchio per il riscaldamento domestico, senza acqua, alimentato a ceppi di legna / Residential space heating appliance without water fired by wood logs
4
Nome registrato e indirizzo del fabbricante ai sensi dell'articolo 11, paragrafo 5:
Namek and contact address of the manufacturer as required pursuant Article 11 (5):
THERMOROSSI S.P.A. Via Grumolo, n° 4 36011 Arsiero (VI)
5
Nome e indirizzo del mandatario ai sensi dell’articolo 12, paragrafo 2:
Name and address of the agent as required pursuant Article 12 (2):
-
6
Sistema di valutazione e verifica della costanza della prestazione del prodotto da costruzione di cui all'allegato V: Sistema 3
System of assessment and verification of constancy of performance of the construction product as set out in Annex V: System 3
7
Laboratorio notificato: Notified laboratory:
TÜV Rheinland Energy und Umwelt GmbH N° 2456
Numero del rapporto di prova secondo il sistema 3 / Test report number based on System 3:
K15832015T1
8
Prestazione dichiarata / Declared performance
Specifica tecnica armonizzata/Harmonized technical specification:
EN 13240:2001
Caratteristiche Essenziali / Essential characteristics
Prestazione / Performance
Reazione al fuoco / Reaction to fire
A1
Distanza da materiali combustibili
Distance to combustible materials
Minime distanze / Minimum distances (mm):
posteriore/rear = 200 lati/sides = 500 frontale / front = 1.000
soffitto/ceiling = - pavimento / floor = -
Rischio di fuoriuscita di braci incandescenti / Risk of burning fuel falling out
Conforme/Compliant
Temperatura superficiale/Surface temperature
Conforme/Compliant
Sicurezza elettrica / Electrical safety
-
Pulizia / Cleanability
Conforme/Compliant
Emissione di prodotti della combustione /Emission of combustion products
CO = 543,7 mg/m3 a potenza termica nominale / CO at Nominal heat output
Pressione massima di esercizio / Maximum operating pressure
- bar
Temperatura fumi a potenza termica nominale / Flue gas temperature at nominal heat output
T 226 °C
Resistenza meccanica (per sopportare il camino) / Mechanical resistance (to carry a
chimney)
NPD {Nessuna Prestazione Determinata}
Potenza termica nominale / Nominal heat output
Potenza termica resa in ambiente / Room heating output
Potenza termica ceduta all’acqua / Water heating output
8,53 kW
8,53 kW
-- kW
Rendimento / Efficiency
87,16 % alla potenza termica nominale / Nominal heat output
9
La prestazione del prodotto di cui ai punti 1 e 2 è conforme alla prestazione dichiarata di cui al punto 8. Firma:
Si rilascia la presente dichiarazione di prestazione sotto la responsabilità esclusiva del fabbricante di cui al punto 4.
The performance of the product identified in points 1 and 2 is in conformity with the declared performance in point 8.
This declaration of performance is issued under the sole responsibility of the manufacturer identified in point 4.
Arsiero, 01/10/2015

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 4
ENG
DICHIARAZIONE DI PRESTAZIONE IN ACCORDO CON IL REGOLAMENTO (UE) 305/2011
DECLARATION OF PERFORMANCE ACCORDING TO REGULATION (EU) 305/2011
N° 48
1
Codice di identificazione unico del prodotto-tipo: WAIR10
Unique identification code of the product type:
2
Modello, lotto, serie ai sensi dell'articolo 11, paragrafo 4: WAIR10
Model, batch or serial number required under Article 11(4):
3
Usi previsti del prodotto da costruzione, conformemente alla relativa specifica tecnica armonizzata:
Intended uses of the construction product, in accordance with the applicable harmonised technical specification:
Apparecchio per il riscaldamento domestico, senza acqua, alimentato a ceppi di legna / Residential space heating appliance without water fired by wood logs
4
Nome registrato e indirizzo del fabbricante ai sensi dell'articolo 11, paragrafo 5:
Name and contact address of the manufacturer as required pursuant to Art. 11 (5):
THERMOROSSI S.P.A. Via Grumolo, n° 4 36011 Arsiero (Vicenza)
5
Nome e indirizzo del mandatario ai sensi dell’articolo 12, paragrafo 2:
Name and address of the agent as required pursuant to Article 12 (2):
-
6
Sistema di valutazione e verifica della costanza della prestazione del prodotto da costruzione di cui all'allegato V: Sistema 3
System of assessment and verification of constancy of performance of the construction product as set out in Annex V: System 3
7
Laboratorio notificato: Notified laboratory:
KIWA CERMET ITALIA S.p.A. N° 0476
Numero del rapporto di prova secondo il sistema 3 / Test report number based on System 3:
2011771
8
Prestazione dichiarata / Declared performance
Specifica tecnica armonizzata / Harmonized technical specification:
EN 13240:2001
Caratteristiche Essenziali / Essential characteristics
Prestazione / Performance
Reazione al fuoco / Reaction to fire
A1
Distanza da materiali combustibili
Distance to combustible materials
Minime distanze / Minimum distances (mm):
posteriore/rear = 300 lati/sides = 300 frontale / front = 1.000
soffitto/ceiling = - pavimento / floor = -
Rischio di fuoriuscita di braci incandescenti / Risk of burning fuel falling out
Conforme /Compliant
Temperatura superficiale/Surface temperature
Conforme /Compliant
Sicurezza elettrica / Electrical safety
-
Pulizia / Cleanability
Conforme /Compliant
Emissione di prodotti della combustione /Emission of combustion products
CO = 353 mg/m3a potenza termica nominale / CO at Nominal heat output
Pressione massima di esercizio / Maximum operating pressure
- bar
Temperatura fumi a potenza termica nominale / Flue gas temperature at nominal heat output
T 186 °C
Resistenza meccanica (per sopportare il camino) / Mechanical resistance (to carry a
chimney)
NPD {No Determined Performance}
Potenza termica nominale / Nominal heat output
Potenza termica resa in ambiente / Room heating output
Potenza termica ceduta all’acqua / Water heating output
10,1 kW
10,1 kW
-- kW
Rendimento / Efficiency
88,0 % alla potenza termica nominale / Nominal heat output
9
La prestazione del prodotto di cui ai punti 1 e 2 è conforme alla prestazione dichiarata di cui al punto 8. Firma/Signature:
Si rilascia la presente dichiarazione di prestazione sotto la responsabilità esclusiva del fabbricante di cui al punto 4.
The performance of the product identified in points 1 and 2 is in conformity with the declared performance in point 8.
This declaration of performance is issued under the sole responsibility of the manufacturer identified in point 4.
Arsiero, 10/02/2023
IT –SCHEDA PRODOTTO (UE 2015/1186)
EN –PRODUCT FICHE (EU 2015/1186)
FR –FICHE PRODUIT (UE 2015/1186)
NL –PRODUCTGEGEVENSBLAD (EU 2015/1186)
DE –PRODUKTDATENBLATT (EU 2015/1186)
ES –FICHA DE PRODUCTO (UE 2015/1186)
IT –MARCHIO
EN –BRAND
FR –MARQUE
NL –MERK
DE –MARKE
ES –MARCA
THERMOROSSI S.P.A.
IT –MODELLO
EN –MODEL
FR –MODÈLE
NL –MODEL
DE –MODELL
ES –MODELO
WAIR 6
WAIR 8
WAIR10
IT –CLASSE DI EFFICIENZA ENERGETICA
EN –ENERGY EFFICIENCY CLASS
FR –CLASSE D'EFFICACITÉ ÉNERGÉTIQUE
NL –ENERGIE EFFICIENTIEKLASSE
DE –ENERGIEEFFIZIENZKLASSE
ES –CLASE DE EFICIENCIA ENERGÉTICA
A+
A+
A+
IT –POTENZA TERMICA DIRETTA
EN –DIRECT HEAT OUTPUT
FR –PUISSANCE THERMIQUE DIRECTE
NL –DIREKTE WARMTEAFGIFTE
DE –DIREKTE WÄRMELEISTUNG
ES –POTENCIA CALORÍFICA DIRECTA
6,1 kW
6,5 kW
10,1 kW
IT –POTENZA TERMICA INDIRETTA
EN –INDIRECT HEAT OUTPUT
FR –PUISSANCE THERMIQUE INDIRECTE
NL –INDIRECTE WARMTEAFGIFTE
DE –INDIREKTE WÄRMELEISTUNG
ES –POTENCIA CALORÍFICA INDIRECTA
-
-
-
IT –INDICE DI EFFICIENZA ENERGETICA
EN –ENERGY EFFICIENCY INDEX
FR –INDICE D'EFFICACITÉ ÉNERGÉTIQUE
NL –ENERGIE-EFFICIENTIE-INDEX
DE –ENERGIEEFFIZIENZINDEX
ES –ÍNDICE DE EFICIENCIA ENERGÉTICA
117
117
118
IT –EFFICIENZA UTILE ALLA POTENZA TERMICA NOMINALE
EN –USEFUL ENERGY EFFICIENCY AT NOMINAL HEAT OUTPUT
FR –RENDEMENT UTILE À LA PUISSANCE THERMIQUE NOMINALE
NL –NUTTIG RENDEMENT BIJ NOMINAAL VERMOGEN
DE –BRENNSTOFF-ENERGIEEFFIZIENZ BEI NENNWÄRMELEISTUNG
ES –EFICIENCIA ENERGÉTICA ÚTIL A POTENCIA CALORÍFICA NOMINAL
86,8 %
87,2 %
88,0 %
IT –EFFICIENZA UTILE AL CARICO MINIMO
EN –USEFUL ENERGY EFFICIENCY AT MINIMUM LOAD
FR –RENDEMENT UTILE À LA CHARGE MINIMALE
NL –NUTTIG RENDEMENT BIJ MINIMALE WARMTEAFGIFTE
DE –BRENNSTOFF-ENERGIEEFFIZIENZ BEI MINDESTLAST
ES –EFICIENCIA ENERGÉTICA ÚTIL A CARGA MINIMA
-
-
-
IT –RISPETTARE TUTTE LE ISTRUZIONI RIPORTATE SUL MANUALE DI INSTALLAZIONE USO E MANUTENZIONE
EN –ALWAYS FOLLOW THE INSTRUCTIONS PROVIDED IN THE OPERATING AND MAINTENANCE MANUAL
FR –RESPECTER TOUTES LES INSTRUCTIONS CITÉES DANS LA NOTICE D’INSTALLATION, UTILISATION ET ENTRETIEN
NL –VOLG ALTIJD DE INSTRUCTIES VAN DE INSTALLATIE-, GERUIKERSHANDLEIDING EN DE ONDERHOUDSVOORSCHRIFTEN
DE –ERFÜLLEN DIE ANWEISUNGEN DER INSTALLATION, NUTZUNG UND WARTUNG, DIE IN DER ANLEITUNGBUCH SIND
ES –RESPECTAR LAS INSTRUCCIONES REPORTADAS EN EL MANUAL DE UTILIZACIÓN Y MANTENIMENTO

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 5
ENG
1 –INTRODUCTION
1.1 SAFETY GUIDELINES
This installation, use and maintenance manual is an integral and essential part of the product and must be kept by the user. Before
commencing with the installation, use and maintenance of the product, carefully read this guide. All local, national and European
regulations regarding the installation and use of the appliance must be met. The Manufacturer recommends carrying out all the
maintenance operations described in this manual.
This appliance must only be used as intended by the manufacturer. Any other use is considered incorrect and therefore hazardous;
consequently, the user shall be totally liable for the product if used improperly. Installation, maintenance and repairs must be carried
out by professionally qualified personnel, certified according to Decree no. 37 of 22 January 2008 and in compliance with current
regulations. In case of repairs only original spare parts supplied by the manufacturer must be used. Incorrect installation or poor
maintenance can injure or damage people, animals or things; in this case the manufacturer shall be relieved of all responsibility. Any
repairs or actions carried out on any systems, components or internal parts of the appliance, or on any of the accessories supplied
with it, that are not specifically authorised by Thermorossi S.p.A, will automatically void the warranty and the manufacturer's
responsibility, pursuant to Italian Decree no. 224 of the President of the Republic of 24/05/1988, art. 6/b. It is recommended to keep
this manual in a safe place that is easily accessible to all users. If the manual is lost or deteriorated contact the manufacturer for a
replacement copy. If the appliance is sold or transferred to another user ensure that the manual is handed over with it. The images
and figures featured in this manual are purely illustrative and may differ from the actual product. Furthermore, Thermorossi reserves
the right to apply changes to the content of this manual anytime and without notice.
Thermorossi S.p.A. retains copyright on this manual. These instructions may not be reproduced or communicated to third parties or
used in any other way without the necessary authorisation.
1.2 SAFETY STANDARDS
PERSONAL INJURY
This safety symbol identifies important messages throughout the manual. Read the information marked
by this symbol carefully as non-observance of this message can cause serious injury to persons using
the appliance.
DAMAGE TO PROPERTY
This safety symbol identifies messages or instructions that are fundamental for the appliance and
system to function well. To avoid serious damage to the appliance adhere strictly to these instructions.
INFORMATION
This symbol indicates important instructions for good functioning of the appliance. If this information
is not correctly observed, the performance of the appliance will not be satisfactory.
1.3 RECOMMENDATIONS
Read this entire use and maintenance manual carefully before using the appliance as familiarity with the information
and instructions contained in it are essential for the correct use of the appliance. No responsibility will be accepted for
damages, even to third parties, if the instructions for installation, use and maintenance of the appliance are not followed
scrupulously. Modifications made to the appliance by the user or on his behalf, must be considered to be under his
complete responsibility. The user is responsible for all the operations required for the maintenance of the appliance
before and during its use.
Should you notice an excessive stagnation of flue gas in the combustion chamber, move away from the appliance
immediately. In particular move away from the glass door of the combustion chamber. The excessive concentration of
unburned gases could create an explosion that could break the glass. Do not open the loading door for any reason
whatsoever and do not approach the product until the flame has died down. Contact a technical service centre to
determine the causes. Do not turn on the appliance for any reason whatsoever following an event such as this.
1.4 GENERAL GUIDELINES
The product must not be used by children under the age of 8 years, by persons with physical, mental or sensorial impairments, or by
persons who are not familiar with the instructions for use and maintenance of the product (the instructions are found in this manual).
Children must not play with the appliance.
ATTENTION: before lighting check that the grate of the combustion chamber is clean and that the ash pan is clean. ATTENTION: it
is strictly forbidden to open the door while the flame is still burning. During operation, the smoke exhaust pipes, door, handles and
some parts of the appliance may reach extremely high temperatures: be careful not to touch them and also educate children to be
aware of said risks. Do not expose your body to hot air for long, do not overheat the room in which the appliance is installed, as these
actions could cause health problems.
Do not expose plants or animals directly to the hot air flow as this could have noxious effects on them. Donot place non-heat resistant
or inflammable or combustible objects in the vicinity of the appliance: keep them at a suitable distance. Do not place wet clothing to
dry on the appliance. When using a clothes horse, keep at a suitable distance.
Attention: do not wet the appliance. Never vacuum hot ash: this could damage the vacuum device. All the cleaning
operations described in this manual must be carried out when the appliance is cold.

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 6
ENG
Attention! Warning for Swiss users.
Refer to the local cantonal regulations imposed by the Fire Department (Mandatory signalling and safety distances)
and the Note concerning installation of heaters issued by the Association of Cantonal Fire Agencies (VKF - AEAI).
1.5 TRANSPORTATION AND STORAGE
TRANSPORTATION AND HANDLING
The appliance body must always be handled exclusively by means of trolleys. Take special care to protect the glass and all the fragile
parts from mechanical impact which could damage them and their correct functioning.
STORAGE
The appliance must be stored in a humid-free environment and sheltered from the weather; avoid placing the appliance directly on
the ground. The Company denies all responsibility for damage caused to wood floors or floors made from any other material. It is
inadvisable to store the product for long periods of time.
1.6 GUIDELINES FOR CORRECT DISPOSAL OF THE PRODUCT
At the end of the product’s useful life, it must be disposed of in compliance with applicable regulations and in respect
of the environment, not with urban waste. The product must be consigned todesignated sorted waste collection centres
for the disposal of waste authorised by the local municipal councils. Correct disposal not only helps safeguard the
environment but it also promotes recovery and recycling of the materials.

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 7
ENG
2 –TECHNICAL CHARACTERISTICS
M.U.
WAIR6
WAIR8
WAIR10
Height
mm
1.079
1.079
1,079
Depth
mm
600
600
600
Width
mm
463
463
463
Empty weight without casing
Kg
142
142
142
Firebox power *
kW
6,98
9,79
11.4
Power output to the room *
kW
6,06
8,53
10.1
Maximum permitted fuel feed ***
Kg
1,64
1,92
2.0
Maximum hourly consumption ***
Kg/h
1,64
2,30
2.6
Average load duration *
Min
60
50
46
Ø smoke exhaust pipe
mm
150
150
150
Minimum draft required
Pa - mbar
10 –0,10
10 –0,10
12 –0.12
Average smoke temperature *
°C
207
226
186
Smoke flow rate *
g/sec
4,4
5,4
7.0
Efficiency *
%
86,77
87,16
88.0
Average CO emission at 13% O2 *
mg/m³
987,0
543,7
353
Heatable volume **
m³
160
230
270
* All the data were measured using billets of wood with 12% moisture content and thermal value of 15,604 KJ/Kg.
** Important: take into consideration the fact that the heatable volume is greatly influenced by the insulation of the house,
i.e., the energy class of the building and by the position of the appliance in the planimetry of the house. The indicated values,
therefore, can vary considerably. The data refer to an absorption coefficient of 37 W/m3.
*** It is strictly prohibited to load a greater quantity of fuel than that specified in the table. The warranty will not cover
damages caused by the prolonged exposure of the appliance to temperatures that are too high.
2.1 DIMENSIONS
The appliance’s smoke outlet collar is female. So, to
mount the exhaust pipe, it is necessary to firstly fit a
heavy steel male tube with 2mm thick walls to it.
Legenda
Key
USCITA FUMI PER TUBO Φ154
SMOKE OUTLET FOR TUBE Φ 154
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Tiziano Pegoraro 27/01/2012
PIDRA 14 Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
PELLET IDRA 14 KW
8/42
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessore
Approv. Data approv.
Formato
MATERIALE OMOLOGA E LIBRETTO - WAIR 2024_DEFINITIVO
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
376.612 kg 74701106.74 mm^3
\\tr-pdm\ArchivioTecnico\STORICO\Tecnico\DWG\Solid_edge\DORICA A LEGNA\70019433.asm!AROMY - 70018653
Descrizione
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta realizzazione del
particolare come indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed eventualmente modificato dal
fornitore in funzione delle macchine di piegatura che
andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore, prima di
realizzare qualsiasi attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari definitivi
X
SENZA RIVESTIMENTO
VISTA FRONTALE
SCALA 1:20
1079
600
O80
O80
925
142
USCITA FUMI
PER TUBO O154
463

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 8
ENG
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Tiziano Pegoraro 27/01/2012
PIDRA 14 Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
PELLET IDRA 14 KW
25/42
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessore
Approv. Data approv.
Formato
MATERIALE OMOLOGA E LIBRETTO - WAIR 2024_DEFINITIVO
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
376.612 kg 74701106.74 mm^3
\\tr-pdm\ArchivioTecnico\STORICO\Tecnico\DWG\Solid_edge\DORICA A LEGNA\70019433.asm!AROMY - 70018653
Descrizione
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta realizzazione del
particolare come indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed eventualmente modificato dal
fornitore in funzione delle macchine di piegatura che
andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore, prima di
realizzare qualsiasi attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari definitivi
X
Figura 1 Figura 2
A
B
C
L
M
E
G
H
D
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Tiziano Pegoraro 27/01/2012
PIDRA 14 Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
PELLET IDRA 14 KW
25/42
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessore
Approv. Data approv.
Formato
MATERIALE OMOLOGA E LIBRETTO - WAIR 2024_DEFINITIVO
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
376.612 kg 74701106.74 mm^3
\\tr-pdm\ArchivioTecnico\STORICO\Tecnico\DWG\Solid_edge\DORICA A LEGNA\70019433.asm!AROMY - 70018653
Descrizione
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta realizzazione del
particolare come indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed eventualmente modificato dal
fornitore in funzione delle macchine di piegatura che
andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore, prima di
realizzare qualsiasi attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari definitivi
X
Figura 1 Figura 2
A
B
C
L
M
E
G
H
D
3 –GENERAL DESCRIPTION
3.1 THE FUEL
The fuel for this appliance is ordinary wood billets with a moisture content between 10% and 20% and with a thermal value of 10,400
to 16,400 KJ/kg. We recommend using beech or common hornbeam.
If using wood with a lower moisture content or with a higher thermal value the heat produced by the stove will be greater. The
awareness and use of the right fuel are important aspects to be observed in order to ensure correct operation and long service life of
the appliance.
To this end we recommend using only dry, well-seasoned wood. We recommend against using wet wood or wood that has been
seasoned for less than 18/20 months, as this could be the cause of malfunctions and the formation of tarry deposits that could
permanently blacken the walls of the combustion chamber.
We recommend the use of 250 mm long wood billets; load a maximum of 2-3 billets at the time and in any case do not exceed the
maximum weight stated in the technical data. The fuel feed intervals must not be less than those specified in the technical data table.
LOADING A LARGER QUANTITY OF FUEL OR LOADING SEVERAL TIMES IN AN HOUR EXPOSES THE
COMPONENTS OF THE APPLIANCE TO VERY HIGH TEMPERATURES. FOR THIS REASON, THE WARRANTY
WILL NOT COVER ANY DAMAGE CAUSED BY PROLONGED EXPOSURE OF THE APPLIANCE TO THESE
TEMPERATURES.
The use of fuel that does not comply with the above specifications or the use of different substances or fuels
will immediately void the appliance warranty. The appliance must not be used as an incinerator, and it is
prohibited to use any liquid or gas fuel. Do not overload the stove with excessive quantities of fuel; adhere
strictly to the maximum declared consumption.
3.2 MAIN COMPONENTS
A –Primary air lever
It is used to regulate the primary air inflow. The primary air passes through the grate of the combustion chamber
and feeds the combustion and determines the combustion power and speed.
Regulation of the air is facilitated by 6 bars printed on the upper glass. To decrease the air inflow, shift the lever
in the direction of the smallest bar. Whereas to increase the inflow air shift it in the direction of the bigger bars.
ATTENTION: When the appliance is operating the temperature of the primary air lever is very high, so take care
not to touch it. Use only the handle provided to move the lever.
KEY
A
Primary air lever
B
Secondary air lever
C
Smoke Bypass device
D
Door firebox
E
Combustion chamber
G
Combustion chamber grate
H
Ash pan
L
RH channelling lever
M
LH channelling lever

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 9
ENG
B –Secondary air lever
It is used to regulate the secondary air inflow. As the secondary air passes through the holes in the back wall of
the combustion chamber, it preheats and contributes to the second combustion as well as having the function
of keeping the glass clean.
Regulation of the air is facilitated by 6 bars printed on the upper glass. To decrease the air inflow, shift the lever
in the direction of the smallest bar. Whereas to increase the inflow air shift it in the direction of the bigger bars.
ATTENTION: When the appliance is operating the temperature of the secondary air lever is very high, so take
care not to touch it. Use only the handle provided to move the lever.
C –Smoke Bypass Device
This device creates a direct bypass for the flue gases which facilitates both the lighting and refuelling operations. It must only be
activated with the special handle supplied and only when lighting or refuelling the wood; take care not to damage the majolica tiles or
the upper glass.
IT IS STRICTLY PROHIBITED TO LEAVE THE SMOKE BYPASS DEVICE OPEN DURING NORMAL OPERATION.
Leaving the Smoke Bypass open during normal operation results in higher fuel consumption than the declared
quantity, a considerable drop in efficiency and exposure of the appliance to extremely high temperatures. For
this reason, the warranty will not cover any damage caused by prolonged exposure of the appliance to these
temperatures.
ATTENTION: The temperature of the Smoke Bypass device during operation is very high so take care not to
touch it. Use only the handle provided to move the lever.
Pulling the Smoke Bypass Device upwards activates the direct bypass of the flue gases, whereas pushing the Smoke Bypass Device
downwards activates the normal flue gas path.
D –Firebox door
When the appliance is operating the door must remain firmly closed
and airtight. It must only be opened to refuel.
E –Combustion chamber
The combustion chamber is made of cast iron. We recommend you
do not throw the firewood into the combustion chamber as it could
crack. The presence of cracks does not affect the correct operation
of the appliance. Replacement is not covered by the product warranty.
G –Combustion chamber grate
H –Ash pan
Collects the ash produced by combustion. It must be emptied regularly.
L –RH channelling lever
This lever is used to regulate the hot air inflow from the front or back. If the appliance is fitted with Airbox 1 (optional) it enables
regulation of the flow from the right rear channelling.
M –LH channelling lever
This lever is used to regulate the hot air inflow from the front or back. If the appliance is fitted with Airbox 1 (optional) it enables
regulation of the flow from the left rear channelling.
Legenda
Key
Dispositivo Smoke By-Pass
Smoke Bypass Device
APERTO
OPEN
CHIUSO
CLOSED
Figura
Figure

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 10
ENG
4 –INSTALLATION
4.1 APPLIANCE LOCATION
Follow the general guidelines set out in paragraph 1.1 to the letter. Above all keep in mind that the floor of the installation
site must be capable of bearing the weight of the appliance added to the weight of the casing. If this requirement is not
met, it is obligatory to adopt counter measures (for example, load distribution plate …)
ATTENTION: The room where the appliance is installed must be well ventilated and free
from humidity and salty air. A high level of humidity or saltiness in the room can lead to
the onset of rust or corrosion which will not be covered by warranty. The appliance must
be positioned at a minimum safe distance from walls and furnishings. If inflammable
materials are located in the vicinity of the appliance (e.g.: matchboarding, furniture,
curtains, pictures and paintings, sofas) it is mandatory to comply with the minimum
distances illustrated on the side.
If the flooring is made of wood or any other combustible material, it is recommended to
install a fireproof floor protector plate between the appliance and the floor. Installation in
the vicinity of heat-sensitive materials is only permitted if suitable insulating and fireproof
protection is placed between the object and the appliance (ref. Uni 10683). Failure to
observe this instruction will immediately invalidate the warranty.
The installer must issue a certificate of conformity for the installation which includes the design plans and the following documents:
a) Report containing the type of materials utilised.
b) Project as defined in Article 5 of Ministerial Decree n° 37 22 January 2008.
d) References to existing partial or previous declarations of conformity (e.g. flue outlet).
e) Copy of the certificate of recognition of the professional technical qualifications.
These documents must, by law, be kept together with the use and maintenance booklet. The customer is responsible
for verifying, directly or indirectly, that the installation has been carried out to perfection in accordance with relevant
regulations in force. Do not install the appliance in unsuitable rooms such as bedrooms, bathrooms, garages and/or
lock-ups. It is forbidden to place the appliance in environments with an explosive atmosphere.
ATTENTION, the appliance is not simply a household appliance: if the instructions set out in this booklet are not
followed and/or if installation of the appliance is not executed perfectly and/or the provisions in force are not strictly
complied with, dangerous conditions could arise for both objects and persons. It is the user’s responsibility to verify
the presence, in the room, of a vent necessary for supplying oxygen to the appliance.
A = 1,000 mm
L = 300 mm
P = 300 mm

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 11
ENG
4.2 UNPACKING THE APPLIANCE
The appliance is supplied packaged on a pallet; before positioning and installing it dismantle the appliance from the pallet
as described.
- Remove the cover and the side panels of the pallet (A) and also the protection panel (B) (Figure 1).
- Use a screwdriver to undo the 2 screws (C) (see Figures 2 and 3).
- Remove the protection panel (D) from the combustion chamber (see Figure 4).
ATTENTION IMPORTANT: HANDLE THE BOILER WITH CARE AS DAMAGE CAUSED DURING THE UNPACKING OPERATION
WILL NOT BE COVERED BY THE WARRANTY.
4.3 UNPACKING/MOUNTING THE CASING
See the specific manual for the dedicated casing.
4.4 CONNECTING THE APPLIANCE TO THE FLUE OUTLET
Connection of the appliance to the flue outlet must be carried out in strict compliance with the instructions
contained in this booklet and particularly with those in the dedicated chapter.
Il presente disegn o è di proprietà esclusiva di THERMOROSSI S.p.A.. La riprod uzione totale e/o parziale e la divulgazio ne aterzi, senza nostro esplicito consenso scrit to, verrà perseguito secondo i termini di leg ge in vigore.
Tiziano Pegoraro 27/01/2012
PIDRA 14Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
PELLET IDRA 14 KW
18/25
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza)- ITALY
S.p.A.
Spessore
Approv. Data approv.
Formato
MATERIALE OMOLOGA E LIBRETTO
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
376.612 kg 74701106.74 mm^3
\\tr-dc01\DatiOffice\Reparti\Tecnico\DWG\Solid_edge\DORICA A LEGNA\70019433.asm!AROMY- 70018653
Descrizione
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta realizzazione del
particolare come indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed eventualmente modificato dal
fornitore in funzione delle macchine di piegatura che
andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore, prima di
realizzare qualsiasi attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari definitivi
X
Figura 1
A
B
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione aterzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Tiziano Pegoraro 27/01/2012
PIDRA 14Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
PELLET IDRA 14 KW
19/25
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza)- ITALY
S.p.A.
Spessore
Approv. Data approv.
Formato
MATERIALE OMOLOGA E LIBRETTO
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
376.612 kg 74701106.74 mm^3
\\tr-dc01\DatiOffice\Reparti\Tecnico\DWG\Solid_edge\DORICA A LEGNA\70019433.asm!AROMY- 70018653
Descrizione
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta realizzazione del
particolare come indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed eventualmente modificato dal
fornitore in funzione delle macchine di piegatura che
andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore, prima di
realizzare qualsiasi attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari definitivi
X
Figura 2 Figura 3
CC
Il presente disegno è di p roprietà esclusiva di THERMOROSSI S. p.A.. La riproduzione totale e/ o parziale e la divulgazione a terzi, senza nostro esplici toc onsenso scritto, verrà perseguito s econdo i termini di legge in vigore.
Tiziano Pegoraro 27/01/2012
PIDRA 14 Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
PELLET IDRA 14 KW
20/25
TEL. [phone] - FAX[phone]
ViaG rumolo,4 - 36 011ARSIERO (Vicenza) - ITALY
S.p.A.
Spessore
Approv. Data approv.
Formato
MATERIALE OMOLOGA E LIBRETTO
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
376.612 kg 74701106.74 mm^3
\\tr-dc01\DatiOffice\Reparti\Tecnico\DWG\Solid_edge\DORICA A LEGNA\70019433.asm!AROMY- 70018653
Descrizione
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta realizzazione del
particolare come indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed eventualmente modif icatoda l
fornitore in funzione delle macchine di piegatura che
andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore, prima di
realizzare qualsiasi attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari definitivi
X
Figura 4
D

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 12
ENG
4.5 DRAWING COMBUSTION AIR FROM OUTSIDE
It is possible to draw combustion air directly from outside the building. In this case it is necessary to remove the back (A) by unscrewing
the four screws (B) and install the appropriate flange (C) supplied in the accessories bag with screws (D) (Figures 1 and 2). Connect
the air intake on the appliance to the exterior of the building with suitable piping. The maximum length of the piping is 60 cm.
4.6 HANDLE
Your appliance is supplied with a handle for opening and closing the firebox door (Figure 2) to enable you to refuel the wood and to
carry out cleaning operations (see dedicated paragraph). When not in use, the handle can be stowed on the rear of the appliance as
indicated in Figure 1. Moreover, the handle will serve to regulate the primary air and the secondary air, to open and close the Smoke
Bypass Device.
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Tiziano Pegoraro 27/01/2012
PIDRA 14 Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
PELLET IDRA 14 KW
43/43
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessore
Approv. Data approv.
Formato
MATERIALE OMOLOGA E LIBRETTO - WAIR 2024_DEFINITIVO
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
376.612 kg 74701106.74 mm^3
\\tr-pdm\ArchivioTecnico\STORICO\Tecnico\DWG\Solid_edge\DORICA A LEGNA\70019433.asm!AROMY - 70018653
Descrizione
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta realizzazione del
particolare come indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed eventualmente modificato dal
fornitore in funzione delle macchine di piegatura che
andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore, prima di
realizzare qualsiasi attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari definitivi
X
A
B
B
C
D
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Tiziano Pegoraro 27/01/2012
PIDRA 14 Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
PELLET IDRA 14 KW
21/42
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessore
Approv. Data approv.
Formato
MATERIALE OMOLOGA E LIBRETTO - WAIR 2024_DEFINITIVO
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
376.612 kg 74701106.74 mm^3
\\tr-pdm\ArchivioTecnico\STORICO\Tecnico\DWG\Solid_edge\DORICA A LEGNA\70019433.asm!AROMY - 70018653
Descrizione
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta realizzazione del
particolare come indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed eventualmente modificato dal
fornitore in funzione delle macchine di piegatura che
andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore, prima di
realizzare qualsiasi attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari definitivi
X
Figura 2
Figura 1

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 13
ENG
5 –USE OF THE APPLIANCE
The appliance, when operating, is hot to the touch, particularly the door of the combustion chamber: consequently, take
care not to touch any surface. Your appliance has obtained the CE marking. The product must not be used by children,
by persons with physical or mental impairments, by persons who are not familiar with the instructions for use and
maintenance of the product (the instructions are found in this installation, use and maintenance manual). During the
heating and cooling stages, the appliance is exposed to considerable thermal expansions that can cause light expansion
sounds. This is a normal process and is not a defect of the product.
ATTENTION: the door must always remain shut tight when the appliance is operating. While the appliance is in operation,
the smoke exhaust pipes can reach extremely high temperatures: do not touch them! It is strictly forbidden to use any
type of liquid or gaseous fuel to light the appliance. Do not place non-heat resistant or inflammable or combustible objects
in the vicinity of the appliance: keep them at a suitable distance. Do not place wet clothing to dry on the appliance. When
using a clothes horse, keep at a suitable distance. During the first lighting it is quite normal for the paint on the product
to give off a slight smell as it completes its drying process. It is recommended to ventilate the room until the paint has
completely dried.
5.1 LIGHTING
Before using the appliance check that all the movable parts are correctly fitted. Also remove any labels and stickers from
the glass to avoid that permanent traces remain on the surfaces. Also, check that the connection to the flue outlet has
been made correctly.
To startup the stove proceed as follows:
1) Open the Smoke Bypass Device (C) by pulling it up with the special handle provided.
2) Open the primary air (A) and the secondary air (B) completely by pushing the two levers outwards (see figure above).
3) Open the firebox door (D) with the special handle, place some kindling in the firebox and light it with paper or any other tinder
available on the market, then close the firebox door (D).
IT IS PROHIBITED TO USE ANY LIQUIDS OR GASES SUCH AS ALCOHOL, PETROL, ETC., TO LIGHT OR
REKINDLE THE FIRE.
4) Do not leave the appliance unsupervised while the lighting process is still in progress (roughly 30 minutes to complete the
process) or whenever there are abundant burning embers present.
5) Once the lighting process is completed close the Smoke Bypass Device (C) using the special handle by pushing downward.

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 14
ENG
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Tiziano Pegoraro 27/01/2012
PIDRA 14 Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
PELLET IDRA 14 KW
22/42
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessore
Approv. Data approv.
Formato
MATERIALE OMOLOGA E LIBRETTO - WAIR 2024_DEFINITIVO
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
376.612 kg 74701106.74 mm^3
\\tr-pdm\ArchivioTecnico\STORICO\Tecnico\DWG\Solid_edge\DORICA A LEGNA\70019433.asm!AROMY - 70018653
Descrizione
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta realizzazione del
particolare come indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed eventualmente modificato dal
fornitore in funzione delle macchine di piegatura che
andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore, prima di
realizzare qualsiasi attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari definitivi
X
IN ACCENSIONE
ABAB
IN LAVORO
INOLTRE SUL 5.2 ELIMINARE LE SPONDINE
5.2 REFUELLING
The stove is an intermittent combustion appliance so it requires refuelling. Once combustion is achieved inside the combustion
chamber and consequently there are embers present, proceed with the first fuel feed:
1) Open the Smoke Bypass Device (C) by pulling it upwards with the special handle.
2) Wait a few seconds then slowly open the firebox door to avoid smoke outpour and spread out the embers using the supplied
poker, as shown in Figure 1.
N.B. It is very important to ensure that the initial level of embers is approximately two centimetres. It is prohibited
to light and reload the fuel with the embers at a higher or lower level as this will not guarantee correct use of the
appliance.
3) Lay two billets of wood that do not exceed the weight specified in the technical data table, in a parallel position in the centre
of the grate, approx 8-10 cm from the back of the combustion chamber (see Figure 2).
4) Slowly close the firebox door airtight using the special handle, close the Smoke Bypass Device (C) using the special
handle by pushing it downwards.
5) It is recommended to regulate the primary air (A) and the secondary air (B) as follows:
WAIR6
WAIR8
WAIR10
Primary air lever
Open 2 bars
Open 2 bars
Open 2 bars
Secondary air lever
Open 5 bars
Open 6 bars
Totally opened
FIGURE 1
FIGURE 2

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 15
ENG
5.3 CHANNELLING
In the models fitted with Airbox1 (Optional) it is possible to convey the hot air flow to the front or to the channelling pipes at the rear.
It is also possible to choose to distribute the flow partly to the front and partly to the channelling pipes at the rear.
ATTENTION: If one or both of the channelling collars are not used to channel the air it is mandatory to check the
back of the appliance to make sure that there are no objects and /or materials that could be damaged by the
heat.
To regulate the air flow, shift the left or right channelling levers.
ATTENTION: The temperature of the left and right channelling levers is very hot while the stove is operating, so
take care not to touch them. Use only the handle provided to activate them.
L –RH channelling lever
Regulates the flow from the right side of the appliance and the setting options are as follows:
100% Front 50% Front 50% Rear 100% Rear
M –LH channelling lever
Regulates the flow from the left side of the appliance and the setting options are as follows:
100% Front 50% Front 50% Rear 100% Rear
Prescriptions for correct channelling:
- It is prohibited to use plastic or internally corrugated pipes.
- It is prohibited to position sections with a downward slope.
- Reduce the number of bends as much as possible (maximum 4).
- To ensure a good result it is obligatory to insulate the pipes.
- Maintain a distance of at least 20 cm between the channelling pipes and any inflammable materials.
- It is prohibited to reduce any pipe sections, even partially, with respect to the outlet diameter.
- It is prohibited to install devices that could simultaneously close the channelling pipes.
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione aterzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Tiziano Pegoraro 27/01/2012
PIDRA 14Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
PELLET IDRA 14 KW
23/38
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessore
Approv. Data approv.
Formato
MATERIALE OMOLOGA E LIBRETTO - WAIR
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
376.612 kg 74701106.74 mm^3
\\tr-dc01\DatiOffice\Reparti\Tecnico\DWG\Solid_edge\DORICA A LEGNA\70019433.asm!AROMY- 70018653
Descrizione
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta realizzazione del
particolare come indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed eventualmente modificato dal
fornitore in funzione delle macchine di piegatura che
andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore, prima di
realizzare qualsiasi attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari definitivi
X
CANALIZZAZIONE LATO DX
100%
100%
CANALIZZAZIONE LATO SX
50%
50%
CANALIZZAZIONE LATO SX
CANALIZZAZIONE LATO DX
50%
50%
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione aterzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Tiziano Pegoraro 27/01/2012
PIDRA 14Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
PELLET IDRA 14 KW
23/38
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessore
Approv. Data approv.
Formato
MATERIALE OMOLOGA E LIBRETTO - WAIR
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
376.612 kg 74701106.74 mm^3
\\tr-dc01\DatiOffice\Reparti\Tecnico\DWG\Solid_edge\DORICA A LEGNA\70019433.asm!AROMY- 70018653
Descrizione
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta realizzazione del
particolare come indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed eventualmente modificato dal
fornitore in funzione delle macchine di piegatura che
andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore, prima di
realizzare qualsiasi attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari definitivi
X
CANALIZZAZIONE LATO DX
100%
100%
CANALIZZAZIONE LATO SX
50%
50%
CANALIZZAZIONE LATO SX
CANALIZZAZIONE LATO DX
50%
50%
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione aterzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Tiziano Pegoraro 27/01/2012
PIDRA 14Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
PELLET IDRA 14 KW
23/38
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessore
Approv. Data approv.
Formato
MATERIALE OMOLOGA E LIBRETTO - WAIR
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
376.612 kg 74701106.74 mm^3
\\tr-dc01\DatiOffice\Reparti\Tecnico\DWG\Solid_edge\DORICA A LEGNA\70019433.asm!AROMY- 70018653
Descrizione
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta realizzazione del
particolare come indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed eventualmente modificato dal
fornitore in funzione delle macchine di piegatura che
andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore, prima di
realizzare qualsiasi attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari definitivi
X
CANALIZZAZIONE LATO DX
100%
100%
CANALIZZAZIONE LATO SX
50%
50%
CANALIZZAZIONE LATO SX
CANALIZZAZIONE LATO DX
50%
50%
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione aterzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Tiziano Pegoraro 27/01/2012
PIDRA 14Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
PELLET IDRA 14 KW
24/38
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessore
Approv. Data approv.
Formato
MATERIALE OMOLOGA E LIBRETTO - WAIR
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
376.612 kg 74701106.74 mm^3
\\tr-dc01\DatiOffice\Reparti\Tecnico\DWG\Solid_edge\DORICA A LEGNA\70019433.asm!AROMY- 70018653
Descrizione
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta realizzazione del
particolare come indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed eventualmente modificato dal
fornitore in funzione delle macchine di piegatura che
andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore, prima di
realizzare qualsiasi attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari definitivi
X
100%
CANALIZZAZIONE LATO SX
CANALIZZAZIONE LATO DX
100%
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione aterzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Tiziano Pegoraro 27/01/2012
PIDRA 14Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
PELLET IDRA 14 KW
24/38
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessore
Approv. Data approv.
Formato
MATERIALE OMOLOGA E LIBRETTO - WAIR
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
376.612 kg 74701106.74 mm^3
\\tr-dc01\DatiOffice\Reparti\Tecnico\DWG\Solid_edge\DORICA A LEGNA\70019433.asm!AROMY- 70018653
Descrizione
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta realizzazione del
particolare come indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed eventualmente modificato dal
fornitore in funzione delle macchine di piegatura che
andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore, prima di
realizzare qualsiasi attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari definitivi
X
100%
CANALIZZAZIONE LATO SX
CANALIZZAZIONE LATO DX
100%
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione aterzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Tiziano Pegoraro 27/01/2012
PIDRA 14Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
PELLET IDRA 14 KW
23/38
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessore
Approv. Data approv.
Formato
MATERIALE OMOLOGA E LIBRETTO - WAIR
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
376.612 kg 74701106.74 mm^3
\\tr-dc01\DatiOffice\Reparti\Tecnico\DWG\Solid_edge\DORICA A LEGNA\70019433.asm!AROMY- 70018653
Descrizione
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta realizzazione del
particolare come indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed eventualmente modificato dal
fornitore in funzione delle macchine di piegatura che
andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore, prima di
realizzare qualsiasi attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari definitivi
X
CANALIZZAZIONE LATO DX
100%
100%
CANALIZZAZIONE LATO SX
50%
50%
CANALIZZAZIONE LATO SX
CANALIZZAZIONE LATO DX
50%
50%

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 16
ENG
5.4 PRESCRIPTIONS FOR CORRECT OPERATION
- Respect the maximum declared consumption, do not overload the stove with excessive quantities of fuel as this could cause damage.
LOADING A LARGER QUANTITY OF FUEL OR LOADING SEVERAL TIMES IN AN HOUR EXPOSES THE
COMPONENTS OF THE APPLIANCE TO VERY HIGH TEMPERATURES. FOR THIS REASON, THE WARRANTY
WILL NOT COVER ANY DAMAGE CAUSED BY PROLONGED EXPOSURE OF THE APPLIANCE TO THESE
TEMPERATURES.
DO NOT THROW THE WOOD INTO THE COMBUSTION CHAMBER, PLACE IT IN GENTLY. THROWING THE
WOOD COULD END UP BREAKING PARTS. DAMAGE CAUSED IN THIS WAY IS NOT COVERED BY
WARRANTY.
- The appliance must not be used as an incinerator, the use of liquid or gaseous fuels is prohibited.
- Adhere strictly to the operating instructions set out in this manual.
- Always verify that the fuel loaded into the combustion chamber lights correctly. Make sure that this always occurs to avoid any
buildup of combustible gases. The buildup of a high quantity of combustible gases could exceed the mechanical resistance of the
glass and other components of the stove. For this reason, the manufacturer disclaims all responsibility.
- In adverse weather conditions, such as for example low pressure, windy or rainy days or days with high outside temperatures, the
effect could be a drop in draught or reverse draught. In these situations, the flue gases may not be completely exhausted.
Consequently, in these cases it is necessary to increase the primary air and load the smallest amount of fuel in order to reactivate
the draught of the flue outlet. If you notice the smell of smoke in the room or stagnation of gases inside the combustion chamber
avoid using the appliance.
- The manufacturer recommends using 250 mm long firewood billets, and loading a maximum of 2-3 billets at a time, and in any case
do not exceed the weight declared in the technical data.
6 –CLEANING AND MAINTENANCE
6.1 FOREWORD
To guarantee correct operation and optimal performance of the appliance at all times carry out theoperations described
below. Observe the recommended frequency.
If the product is unused for a prolonged period of time before starting up, it is mandatory to inspect the smoke channel
and outlet to ensure that there are no obstructions. It is important to carefully follow the instructions set out below:
failure to observe these instructions could cause serious damage to the product, to the system, to objects and to
persons using the appliance.
Attention: do not wet or touch the appliance with wet hands. Never vacuum hot ash: this could damage the vacuum
device. All the cleaning operations described in this manual must be carried out when the appliance is cold.
To clean the glass simply use a damp soft, non-abrasive cloth and ash. The use of any other product is strictly
prohibited. Damage to the glass or the print will not be covered by warranty.
Do not clean the glass until it has cooled completely.
The user must periodically clean the appliance, or have an authorised service centre clean it, as described in this manual.
Moreover, once a year it is advisable to have an inspection carried out of the functionality of the flue outlet.

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 17
ENG
6.2 CLEANING AND MAINTENANCE
Figure 1 Figure 2
Figure 3 Figure 4
EVERY DAY:
• Thoroughly clean the grate of the combustion chamber (Figure 1) by making the ash drop through the holes in the grate;
EVERY TWO DAYS or WHENEVER NECESSARY:
• Empty the ash pan (Figure 2).
EVERY WEEK:
• Clean the exchanger of the smoke bypass with a vacuum device (Figure 3).
EVERY MONTH:
• Clean the gas tubes behind the smoke bypass with a special brush (Figure 4).
AT LEAST TWICE A YEAR:
• Clean the flue outlet. If there are any horizontal sections, inspect them and clean out any ash and soot deposits before they block
the passage of the flue gases.
AT THE END OF THE WINTER SEASON (or whenever necessary)
•Perform a thorough overall cleaning of the firebox and pans with brushes and vacuum cleaners.
A vacuum device simplifies the ash cleaning procedure. The front and side casings must be cleaned when the heater
is cold using a soft cloth and water. The door of the combustion chamber must only be opened when the appliance has
completely cooled down: when it is opened it is normal for some ash to spill onto the floor.

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 18
ENG
ATTENTION: after cleaning it is mandatory to carefully check that the combustion chamber door is firmly closed and
airtight.
ATTENTION: the generator, the smoke channel and flue outlet must be cleaned in accordance with the specifications
described above and use of inflammable products is strictly forbidden: using inflammable products can create
dangerous situations. Failure to carry out the necessary maintenance or if only partial maintenance is carried out will
affect the correct functioning of the appliance. Any problems resulting from total or partial lack of cleaning or
maintenance will immediately void the warranty.
ATTENTION: if the appliance remains inactive (and/or not used for over a month) the generator, the smoke discharge
tube and the flue outlet must be thoroughly cleaned and checked for any possible obstructions (e.g., birds nests in the
chimney cap) before restarting.
7 –SMOKE DISCHARGE TUBE AND VENTILATION OF THE ROOMS
7.1 FOREWORD
Due to the frequent accidents caused by poor functioning of flue outletsinstalled in private dwellings, wehave prepared
the following paragraph to assist the installer in his inspection of the parts concerned with eliminating the gases
produced by combustion.
The smoke outlet must be fitted in compliance with standard UNI 7129/92 and UNI 10683 and it must observe the
reference values laid down in the standard, in particular, the outlet must comply with fire prevention regulations.
It is important to carefully follow the instructions set out below: failure to observe these instructions could
cause serious damage to the product, to the system, to objects and to persons using the appliance.
7.2 ROOM VENTILATION
ATTENTION: the presence of extraction fans or similar appliances, if operating in the same room or space in which the
product is installed, could cause problems for the correct operation of the product.
ATTENTION: do not obstruct the vents or the air inlets on the appliance.
The room where the appliance is installed must have a good air flow to guarantee air for the appliance for the combustion process
and for ventilation of the room. The natural air flow must take place directly through permanent openings on the outer walls or through
single or multiple ventilation ducting.
The ventilation air intake must be located away from pollution sources.
The openings in the walls must comply with the following conditions:
• have an unobstructed section of at least 6cm² for each Kw of installed thermal power, with a minimum limit of 100cm²;
• be made in such a way that the vent openings, both on the inside and outside of the wall, cannot be obstructed;
• be protected with grills or similar systems that do not reduce the opening section indicated above;
• be situated at a height near-floor level and they must not obstruct the correct operation of the combustion product discharge devices;
if this position is not possible, the section of the ventilation openings must be enlarged by at least 50%.
7.3 SMOKE OUTLET
The smoke channel, the exhaust pipe, chimney and flue outlet (defined as the system for the evacuation of combustion
products), are parts of the heating system and they must comply with the legislative requirements of the Ministerial
Decree DM 37/08 (ex Italian Law 46/90) and to the applicable specific installation regulations, according to the type of
fuel. Fireplaces, stoves and barbecues must not be installed in locations where gas appliances type A and type B are
present and operating (for the classification see UNI 10642 and UNI 7129). The connection between the appliance and
the flue outlet must only receive exhaust from one heat generator.
The installer must provide one or more access points on the flue outlet to check the emissions once the appliance has
been installed; these access points must be made in such a way as to be airtight sealable to prevent exhaust gas leaks.
It is recommended to provide insulation and to ensure the optimal sizing of the flue outlet in order to avoid the possible
risk of condensation forming in the flue outlet.
7.3.1 CHIMNEY TYPES
The following types of chimneys, constructed as described, are possible:
• System: Chimney installed using a combination of compatible components (flue liner, insulation, outer casing etc…), constructed or
specified by a single manufacturer and CE certified in accordance with the applicable standard;
• Composite chimney: Chimney installed or constructed on site using a combination of compatible components such as flue liner (wall
directly in contact with the smoke), and possibly also insulation and outer casing (wall) that may be supplied by different manufacturers
or by the same manufacturer.
• Relining: operation involving the installation of a specific pipe in an existing shaft (even if newly constructed) made of non-
combustible materials, free from obstructions and for single use.

Installation, use and maintenance guide
WAIR 6 –WAIR 8 –WAIR 10
Page 19
ENG
7.3.2 FLUE OUTLET / FLUE SYSTEM COMPONENTS
Every chimney must have minimum number of components as laid down by
standard UNI EN 1443 which are also indicated in the figure below:
ATTENTION: Wall outlets, that is outlets installed on the outer front wall
without the use of a chimney/flue outlet /flue pipe to convey the combustion
products to the roof, are strictly prohibited.
7.3.3 CONTROLS PRIOR TO INSTALLING THE APPLIANCE
The user must possess a certificate of conformance for the flue outlet
(Ministerial Decree 22 January 2008, no. 37).
The flue outlet must be built in compliance with UNI 10683.
The smoke exhaust illustrated in the following figure is the best solution required
to ensure that the flue gases are discharged. If you prefer to exhaust the smoke
from the roof insert a union tee with inspection cap, connecting brackets suitable
for the height of the flue outlet, flashing that crosses the roof and chimney cap
to protect against bad weather conditions.
If you decide to use the classic masonry exhaust provide a union tee with
inspection cap and suitable supporting brackets. If the flue outlet is too big, it is
necessary to insert a stainless steel or porcelain-coated steel tube with suitable
diameter.
Seal area where the inlet and outlet part of the smoke exhaust meets the wall.
It is strictly forbidden to apply mesh to the end of the outlet tube, as it could
cause the appliance to malfunction.
If the smoke tube is installed in a fixed position, it is advisable to provide
inspection openings for clean-out purposes especially in the horizontal sections.
See the diagram. These openings are essential to allow for the removal of ash
and unburned products which tend to accumulate along the discharge path.
Seal the fittings with red silicone (resistant to 350°C).
The outer casing of the tube must be made with
insulating material (mineral wool, ceramic fibre) or
use pre-insulated tubing.
THE FLUE OUTLET MUST BE USED ONLY FOR THE APPLIANCE.
It must be possible to inspect and remove all the smoke tube sections for clean-out purposes.
ATTENTION: if the flue outlet is not sufficiently insulated and /or if it is too long it could generate condensation. It is
advisable to provide a condensation drain near the smoke outlet of the appliance. The appliance must always and only
be installed in a single flue outlet system dedicated exclusively to the appliance.
If the generator is connected to a non-compliant flue system the appliance could rapidly deteriorate due to anabnormal,
continuous overheating: in this case the damaged parts will not be covered by warranty.
IF THE CHIMNEY CATCHES FIRE CLOSE THE PRIMARY AND SECONDARY AIR LEVERS IMMEDIATELY AND CALL THE FIRE
BRIGADE.
LEGENDA
KEY
COMIGNOLO E CANNA FUMARIA
SECONDO NORMA UNI 10683
CHIMNEY CAP AND FLUE OUTLET
ACCORDING TO UNI 10683 STANDARD
Tutte le tubazioni devono essere
termicamente isolate
All the pipes must be thermally insulated
ISPEZIONE
INSPECTION
2 metri MAX
2 metres MAX
2 -3 metri MAX
2 -3 metres MAX.
Pendenza non inferiore al 5%
Minimum slope 5%
ALTEZZA SUPERIORE A 4 m
HEIGHT MORE THAN 4 m.
Components and accessories of a chimney
Key
1 Chimney
2 Flow path
3 Smoke discharge tube
4 Thermal insulation
5 External wall
6 Outer lining
7 Flue outlet section
8 Multiwall chimney
9 Connector
10 Flue pipe
11 Heat generator
