Think ahead SR-2805ST User manual

RF Single color & CTT & RGB wall mount/ stick controller
Feature
3M glue stick on the wall or Screw mounted on the wall
SR-2805ST
Parameter
Installation
Part No. Iuput Voltage Remarks
Current
SR-2501N 12-36VDC Constant voltage
4x(60-180)W
4x5A
Output
SR-2501NEA 12-36VDC Constant voltage
4x(96-288)W4x8A
Remote
Part No. Operation Voltage Operation
Frequency
SR-2805ST 3VDC 434MHz/868MHz
Receiver for single color
SR-2502N 12-36VDC Constant current
4x(4.2-12.6)W
4x350mA
SR-2503N 12-36VDC Constant current
4x(8.4-25.2)W4x700mA
Remarks
RF Wireless
SR-2501NS 12-36VDC Constant voltage
1x(96-288)W1x8A
SR-2502NS 12-36VDC Constant current
1x(4.2-12.6)W
1x350mA
SR-2503NS 12-36VDC Constant current
1x(8.4-25.2)W1x700mA
Power Supply
12-36VDC
LN
110V-230VAC
GND
SR-2501N
RF Easy Dimmer
123
4
Learning Key
Pus h Switch
GND
SR-2501N
RF Easy Dimmer
123
4
Learning Key
Push
Switch
GND
SR-2501N
RF Easy Dimmer
123
4
Learning Key
Push
Switch
Wiring diagram
Work with corresponding receivers to control single
color, CCT or RGB LED lighting.
Push button on the receivers.
SR-2805ST is a RF wall sticks/ mounted controller for single color, CCT or RGB LED lighting. Each white can
achieve 256 levels brightness adjustment. Key part can be uninstall every easily to change battery and frames
from other factory.
Part No. Iuput Voltage Remarks
Current
SR-2501M 12-36VDC Constant voltage
4x(60-180)W
4x5A
Output
SR-2501MEA 12-36VDC Constant voltage
4x(96-288)W4x8A
Receiver for CCT
SR-2502M 12-36VDC Constant current
4x(4.2-12.6)W
4x350mA
SR-2503M 12-36VDC Constant current
4x(8.4-25.2)W4x700mA
Part No. Iuput Voltage Remarks
Current
SR-2501RGB 12-36VDC Constant voltage
3x(60-180)W
3x5A
Output
SR-2501RGBEA 12-36VDC Constant voltage
3x(96-288)W3x8A
Receiver for RGB
SR-2502RGB 12-36VDC Constant current
3x(4.2-12.6)W
3x350mA
SR-2503RGB 12-36VDC Constant current
3x(8.4-25.2)W3x700mA
86.0
86.0
27.0
Product Size
Think ahead ESC GmbH I Anzengruberstr. 39 I A-9020 Klagenfurt a. W. I T [phone] I [email protected] I www.think-ahead.at

The key part of this controller is a universal, extremely rotary standard switch element that can be integrated in
numerous frames by different manufactures as below list:
Mounting
Safety & Warnings
Warranty Agreement
1) The product shall be installed and serviced by a qualified person.
2) IP20.Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof
enclosure.
3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.
4) Please check if the output voltage of any LED power supplies used comply with the working voltage of the
product.
5) Never connect any cables while power is on and always assure correct connections to avoid short circuits
before switching on.
6)
7) For update information please consult your supplier.
Please ensure that the cable is secured tightly in the connector
1) We provide lifelong technical assistance with this product:
3-year warranty. We print date on every products, for example :1125 means year 2011,week 25.The
warranty is for free repair or replacement and covers manufacturing faults only.
For faults beyond the 3-year warranty we reserve the right to charge for time and parts.
2) Limited Warrenty
Any defects caused by wrong operation.
BEKER S1, B1, B3, B7 glass
GIRA Standard55, E2, Event, Esprit
JUNG A500, Aplus
MERTEN M-smart, M-Arc, M-Plan
Operation
a.Learning
Press shortly the learning Key on the receiver, then push the rotary button .Once successfully learn, the LED
lights will blink on the receiver. Do the same for the other receivers if you use them, you can add as many
optional receivers as you want.
b.Single color operation
-Short push rotary button to switch ON/OFF
-Adjust dim brightness by the rotary button from left to right 1-100%
-Adjust dim brightness by the rotary button from right to left 100-1%
c.CCT operation
-Short push rotary button to switch ON/OFF
-Adjust dim brightness by the rotary button from left to right 1-100%
-Adjust dim brightness by the rotary button from right to left 100-1%
-Long press rotary button, the light will be 100% brightness
-Double click rotary button, it will enter into dimming color temperature mode, dim WW and CW associatively ,
for example if WW is 70%, CW is 30% .Double click again, will enter into dimming brightness mode.
d.RGB operation
-Short push rotary button to switch ON/OFF
-Adjust dim brightness by the rotary button from left to right 1-100%
-Adjust dim brightness by the rotary button from right to left 100-1%
-Long press rotary button, the light will be 100% brightness
-Double click rotary button, it will change color of RGB light. Double click again, will enter into dimming
brightness mode
Any damages caused by unauthorized removal, maintenance, modifying, incorrect connection and
replacement of chips.
Any damages due to transportation, vibration etc. after purchase.
Any damages caused by earthquake, fire, lightning, pollution and abnormal voltage.
Any damages caused by negligence, inappropriate storing at high temperatures and humidity or near
harmful chemicals.
Product has been updated
3) Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
