Thinklogical Velocitykvm Series User manual

Multi-Mode Fiber Extension Systems
Velocitykvm
Multi-Mode Fiber Extension Systems
Milford, Connecticut, USA
An overview of the
Velocitykvm Dual-link and
Single-link, Multi-Mode
Fiber Extension Systems
-4, 5, 8, 24, 28, 34, 35 & 38
Extend Distribute Innovate

Copyright Notice
Copyright © 2011. All rights reserved. Printed in the U.S.A.
Thinklogical LLC™100 Washington Street
Milford, Connecticut 06460 U.S.A.
Telephone [phone]
All trademarks and service marks are property of their respective owners.
Subject: Velocity Multi-Mode Fiber Extension System Product Overview
Revision: B, July 2011
Visit us online at www.thinklogical.com for more
product information, current updates and the
complete line of Thinklogical™ products.
Powered by
MRTS Technology
Telephone
Telephone Product Support: Contact Product Support by telephone in Milford, CT at 1-203-647-8700. The support
lines are manned Monday through Friday, 8:30am to 5:00pm, Eastern Time Zone.
Telephone Sales: Contact our expert sales staff by telephone in Milford, CT at 1-203-647-8700 or, if in the continental
US, you may use our toll-free number 1-800-291-3211. We are here Monday through Friday from 8:30am to 5:00pm,
Eastern Time Zone. Ask for your representative’s direct dial phone number when you call.
International Sales: Please contact our US sales staff in Milford, CT at 1-203-647-8700. We are here Monday
through Friday, 8:30am to 5:00pm, Eastern Time Zone (same as New York City). If leaving a voice message please let
us know the best time to call back so we may reach you at your convenience.
Our switchboard attendant will direct your call during regular business hours. We have an automated attendant
answering our main telephone switchboard after regular business hours and on holidays. You can leave a voice
message for any individual at any time. Our sales representatives have direct numbers to speed up your next call to us.
Email
Thinklogical™ is staffed Monday through Friday from 8:30am to 5:00pm, Eastern Time Zone. We will do our best to
respond to your email inquiries promptly. Please use the following email addresses for your various needs:
[email protected] – Information on Thinklogical™ and our products.
[email protected] – Sales Department - orders, questions or issues.
[email protected] – Product support, technical issues or questions, product repairs and request for a
Return Merchandise Authorization (RMA) number.
Fax
Our company facsimile number is 1-203-783-9949. Please indicate the nature of the fax on your cover sheet and
provide return contact information.
HOW TO CONTACT US:
2
Extend Distribute Innovate
PHONE: [phone]
WEBSITE: www.thinklogical.com
EMAIL: [email protected]
PHONE: [phone]
WEBSITE: www.thinklogical.com
EMAIL: [email protected]

The Logical Solution
Velocity KVM Extension Systems are designed for high performance visual applications that require video as well as peripheral support. The system allows users, via optical fiber, to station and operate a
digital monitor(s) and peripherals from just a few meters away to up to 40 kilometers away from the controlling computer, securely and without loss of resolution.
Velocity KVM products are ideally suited for a wide range of applications in the broadcast and post-production field, as well as command and control centers, universities, large scale digital signage and other
commercial KVM applications.
The Velocity KVM Multi-Mode Fiber Extender standard model from Thinklogical™ includes:
Multi-mode fiber for extension distances up to 350 meters
Two DVI Displays
Supports USB HID, USB 1.1 and (optional) USB 2.0 (up to 480 Mbps)
The Future of Access and Control Velocitykvm-24
enter
Powered by
MRTS Technology
Multi-Mode Fiber KVM Extension System
DVI Two Display
Transmitter
System Features
Each Velocity KVM Multi-mode Fiber system includes the following features:
Supports all single-link DVI video resolutions (Velocity KVM Extension. System-5 supports one single-link DVI or RGB and all single-link DVI resolutions).
6.25 Gbps signal transmission via fiber optic cable; No RF interference.
Requires one, two, three, four or five fiber optic cables, depending on application.
Flawless image quality with no frame dropping.
Local KVM connections on transmitter.
Additional video output(s) on the receiver.
Extends KVM audio and serial signals up to 350 meters using standard multi-mode fiber; 1000 meters using eSX+ multi-mode fiber; 40 kilometers using single-mode fiber.
USB HID compliant, 4-port hub.
Full USB 1.1 compliant, 4-port hub.
USB 2.0 compliant (high speed 480 Mbps, 4 port hub).
Stereo Emitter BNC connections.
DDC2B/EDID complaint.
Fully compatible with all of Thinklogical’s VX Router line of products.
Full keyboard and mouse emulation through the transmitter.
Full duplex stereo audio.
Simple plug and play.
3Extend Distribute Innovate

QUICK START GUIDE
PS/2 or USB
connectors
1LINE IN
MIC OUT
SER IAL PORT
HID
P
S
2
LOCAL FROM CPU
CAUTION!Replace with same type and rating fuse.
CLINK
PWR FOL
DVI OUT
DVI IN
L1 L2
100-240V-,0.5A, 50/60 Hz T 2A ,250VAC
HOST
CTRL
DEV
USB 1.1
USB HID
UPDATES
CP
STEREO
EMITTER
INPUT
USE ONLY WITH 250V FUSE
100-240V-,0.5A,50/60 Hz T 2A ,250VAC
CAUTION! Replace with same type and rating fuse.
USB 2.0 USB 1.1
HOST
CTRL
USB HID
FOL SER IAL PORT
MIC IN
LINE OUT
U
P
D
A
T
E
S
P
S
2
L1
L2
PWR
DVI OUT DDC DVI OUT
STEREO
EMITTER
OUTPUT
USE ONLY WITH 250V FUSE
STEP 5: If desired, connect your optional
local keyboard & mouse by inserting the PS/2
or USB HID connectors into the VelocityKVM
Transmitter’s local devices receptacles and
connect the optional local DVI display to the
Transmitter’s DVI OUT Port. Ensure all system
functions are operating properly.
USB HID or PS2
Keyboard/Mouse
USB HID or PS2
Keyboard/Mouse
QUICK START GUIDE
Velocitykvm-4
Velocitykvm-4
Multi-Mode Fiber Extension System –Single Head, Single Link DVI
Multi-Mode Fiber Extension System –Single Head, Single Link DVI
3
1
4
55
Local DVI OUT
DVI OUT DDC
USB 2.0 Option Audio IN/OUT
Stereo 3-D
USB 2.0
Option
Audio OUT ►
DVI IN
STEP 1: Connect your Multi-Mode Fiber
Optic Cables between the Transmitter and
Receiver units (up to 1000 meters) as shown.
L1: Data Tx to Rx and Video
L2: Data Rx to Tx
◄Audio IN
PS/2 Keyboard
PS/2 Mouse USB HID (Kybd/Mouse)
USB 1.1 (Kybd/Mouse)
Stereo Emitter IN
STEP 2: Ensure that
the POWER ON/OFF
switch is in the OFF
position (0) on both
the Tx and Rx units.
Connect the supplied
AC Power Cords to
both units and plug
each into a standard
AC supply. Turn both
switches ON (1).
DVI OUT
STEP 4: Connect the
DVI and KVM cables
between the Source
CPU and the
VelocityKVM
Transmitter using
the cables supplied in
KIT-000005-R.
Ensure the CPU is
turned ON.
STEP 3: Connect the destination DVI and KVM devices to the
VelocityKVM Receiver using standard cables. Ensure the
devices are turned ON.
2
VELOCITY-4_Manual_QSG
Source CPU
4
Extend Distribute Innovate

QUICK START GUIDE
PS/2 or USB
connectors
1LINE IN
MIC OUT
SER IAL PORT
HID
P
S
2
LOCAL FROM CPU
CAUTION! Replace with same type and rating fuse.
CLINK
PWR FOL
RGB/DVI OUT
RGB/DVI IN
L1L2
100-240V-,0.5A, 50/60 Hz T2A ,250VAC
HOST
CTRL
DEV
USB 1.1
USB HID
UPDATES
CP
STEREO
EMITTER
INPUT
USE ONLY WITH 250V FUSE
100-240V-,0.5A, 50/60 Hz T 2A ,250VAC
CAUTION! Replace with same type and rating fuse.
USB 2.0 USB 1.1
HOST
CTRL
USB HID
FOL SER IAL PORT
MIC IN
LINE OUT
U
P
D
A
T
E
S
P
S
2
L1
L2
PWR
RGB/DVI OUT DDC RGB/DVI OUT
STEREO
EMITTER
OUTPUT
USE ONLY WITH 250V FUSE
STEP 5: If desired, connect your optional
local keyboard & mouse by inserting the PS/2
or USB HID connectors into the VelocityKVM
Transmitter’s local devices receptacles and
connect the optional local RGB/DVI display to
the Transmitter’s RGB/DVI OUT Port. Ensure
all system functions are operating properly.
USB HID or PS2
Keyboard/Mouse
USB HID or PS2
Keyboard/Mouse
QUICK START GUIDE
Velocitykvm-5
Velocitykvm-5
Multi-Mode Fiber Extension System –Single Head, Single Link RGB/DVI
Multi-Mode Fiber Extension System –Single Head, Single Link RGB/DVI
3
1
4
55
Local RGB/DVI
OUT
RGB/DVI OUT DDC
USB 2.0 Option
Audio IN/OUT
Stereo 3-D
USB 2.0
Option
Audio OUT ►
RGB/DVI IN
STEP 1: Connect your Multi-Mode Fiber
Optic Cables between the Transmitter and
Receiver units (up to 1000 meters) as shown.
L1: Data Tx to Rx and Video
L2: Data Rx to Tx
◄Audio IN
PS/2 Keyboard
PS/2 Mouse USB HID (Kybd/Mouse)
USB 1.1 (Kybd/Mouse)
Stereo Emitter IN
STEP 2: Ensure that
the POWER ON/OFF
switch is in the OFF
position (0) on both
the Tx and Rx units.
Connect the supplied
AC Power Cords to
both units and plug
each into a standard
AC supply. Turn both
switches ON (1).
RGB/DVI OUT
STEP 4: Connect the
RGB/DVI and KVM
cables between the
Source CPU and the
VelocityKVM
Transmitter using
the cables supplied in
KIT-000005-R.
Ensure the CPU is
turned ON.
STEP 3: Connect the destination RGB/DVI and KVM devices
to the VelocityKVM Receiver using standard cables. Ensure
the devices are turned ON.
2
VELOCITY-5_Manual_QSG
Source CPU
5
Extend Distribute Innovate

QUICK START GUIDE
STEP 5: If desired, connect an optional local keyboard
& mouse by inserting the PS/2 or USB HID connectors
into the VelocityKVM Transmitter’s local devices
receptacles and connect the optional local dual-link
DVI display to the Transmitter’s Dual-link DVI OUT Port.
Ensure all system functions are operating properly.
USB HID or PS2
Keyboard/Mouse
USB HID or PS2
Keyboard/Mouse
QUICK START GUIDE
Velocitykvm-8
Velocitykvm-8
Multi-Mode Fiber Extension System –Dual-Link DVI
Multi-Mode Fiber Extension System –Dual-Link DVI
3
1
4
Local Dual-Link
DVI OUT
USB 2.0 Option Audio IN/OUT
Stereo 3-D
USB 2.0 Option
Audio OUT ►
Dual-Link DVI IN
STEP 1: Connect the 3 Multi-Mode Fiber Optic Cables
between the Transmitter and Receiver units (up to 1000
meters) as shown.
Audio
◄IN
PS/2 Keyboard
PS/2 Mouse
USB HID (Kybd/Mouse)
USB 1.1 (Kybd/Mouse)
Stereo Emitter IN
*STEP 2: Ensure that
the POWER ON/OFF
switch is in the OFF
position (0) on both the
Tx and Rx units.
Connect the supplied
AC Power Cords to
both units and plug
each into a standard
AC supply. Turn both
switches ON (1).
Dual-Link DVI OUT DDC
STEP 4: Connect the Dual-link DVI and KVM cables
between the Source CPU and the VelocityKVM
Transmitter using the cables supplied in KIT-000005-R.
Ensure the CPU is turned ON.
STEP 3: Connect the destination Dual-link DVI and KVM
devices to the VelocityKVM Receiver using standard
cables. Ensure the devices are turned ON.
2
VELOCITY-8_Manual_QSG
Source CPU
5
Fiber-Optic Cables:
L1: Data Tx to Rx and Video Primary
L2: Data Rx to Tx
L3: Video Secondary
Dual-Link DVI
OUT
Local Dual-Link DVI OUT
STEP 2: *
6
Extend Distribute Innovate

QUICK START GUIDE
STEP 5: If desired, connect your optional local
keyboard & mouse by inserting the PS/2 or USB HID
connectors into the VelocityKVM Transmitter’s local
devices receptacles and connect the optional local DVI
displays to the Transmitter’s DVI OUT Ports 1 & 2.
Ensure all system functions are operating properly.
USB HID or PS2
Keyboard/Mouse
QUICK START GUIDE
Velocitykvm-24
Velocitykvm-24
Multi-Mode Fiber Extension System –DVI Two Display
Multi-Mode Fiber Extension System –DVI Two Display
3
14
Local DVI OUT
1
DVI OUT 2 DDC
USB 2.0 Option Audio IN/OUT
Stereo 3-D
USB 2.0 Option
Audio OUT ►
DVI IN 1
STEP 1: Connect the 3 Multi-Mode Fiber Optic Cables
between the Transmitter and Receiver units (up to 1000
meters) as shown.
Audio
◄IN
PS/2 Keyboard
PS/2 Mouse
USB HID (Kybd/Mouse)
USB 1.1 (Kybd/Mouse)
Stereo Emitter IN
*STEP 2: Ensure that
the POWER ON/OFF
switch is in the OFF
position (0) on both the
Tx and Rx units.
Connect the supplied
AC Power Cords to
both units and plug
each into a standard
AC supply. Turn both
switches ON (1).
DVI OUT 1 DDC
STEP 4: Connect the DVI and KVM cables between the
Source CPU and the VelocityKVM Transmitter using
the cables supplied in KIT-000005-R. Ensure the CPU is
turned ON.
STEP 3: Connect the destination DVI and KVM devices
to the VelocityKVM Receiver using standard cables.
Ensure the devices are turned ON.
2
VELOCITY-24_Manual_QSG
Source CPU
DVI IN 2
Local DVI OUT
2
5
Fiber-Optic Cables:
L1: Data Tx to Rx and Video 1
L2: Data Rx to Tx
L3: Video 2
STEP 2: *
USB HID or PS2 Keyboard/Mouse
5
7
Extend Distribute Innovate

Local DVI
OUT 2
QUICK START GUIDE
STEP 5: If desired, connect your optional local keyboard &
mouse by inserting the PS/2 or USB HID connectors into the
VelocityKVM Transmitter’s local devices receptacles and
connect the optional local DVI displays to the Transmitter’s
DVI OUT Ports 1 & 2. Ensure all system functions are
operating properly.
USB HID or PS2 Keyboard/Mouse
USB HID or PS2
Keyboard/Mouse
QUICK START GUIDE
Velocitykvm-28
Velocitykvm-28
Multi-Mode Fiber Extension System –Dual- & Single-Link DVI, Two Display
Multi-Mode Fiber Extension System –Dual- & Single-Link DVI, Two Display
3
1
4
5
Local Dual-Link
DVI OUT 1
DVI OUT 2
USB 2.0 Option
Audio IN/OUT
Stereo 3-D
USB 2.0 Option
Audio OUT ►
Dual-Link DVI IN 1
STEP 1: Connect the four Multi-Mode Fiber-Optic Cables
between the Transmitter and Receiver units (up to 1000
meters) as shown: L1 to L1, L2 to L2, etc.
Audio
◄IN
PS/2 Keyboard
PS/2 Mouse
USB HID (Kybd/Mouse)
USB 1.1 (Kybd/Mouse)
Stereo Emitter IN
*STEP 2: Ensure that
the POWER ON/OFF
switch is in the OFF
position (0) on both the
Tx and Rx units.
Connect the supplied
AC Power Cords to
both units and plug
each into a standard
AC supply. Turn both
switches ON (1).
Dual-Link DVI
OUT 1
STEP 4: Connect the DVI and KVM cables between the
Source CPU and the VelocityKVM Transmitter using the
cables supplied in KIT-000005-R. Ensure the CPU is turned
ON.
STEP 3: Connect the destination DVI and KVM devices to
the VelocityKVM Receiver using standard cables. Ensure
the devices are turned ON.
2
VELOCITY-28_Manual_QSG
Source CPU
DVI IN 2
Fiber-Optic Cables:
L1: Data Tx to Rx and Video 1 Primary
L2: Data Rx to Tx
L3: Video 1 Secondary
L4: Video 2
STEP 2: *
8
Extend Distribute Innovate

QUICK START GUIDE
STEP 5: If desired, connect your optional local keyboard &
mouse by inserting the PS/2 or USB HID connectors into the
VelocityKVM-34 Transmitter’s local devices receptacles.
Ensure all system functions are operating properly. USB HID or PS2 Keyboard/Mouse
USB HID or PS2 Keyboard/Mouse
QUICK START GUIDE
Velocitykvm-34
Velocitykvm-34
Multi-Mode Fiber Extension System –Four DVI Displays
Multi-Mode Fiber Extension System –Four DVI Displays
3
4
5
USB 2.0 Option
Audio IN/OUT
Stereo 3-D
USB 2.0 Option
Audio OUT ►
DVI IN 1
STEP 1: Connect the five Multi-Mode Fiber-Optic Cables
between the Transmitter and Receiver units (up to 1000
meters) as shown; L1 to L1, L2 to L2, etc.
◄ Audio IN
PS/2 Keyboard
PS/2 Mouse
USB HID (Kybd/Mouse)
USB 1.1 (Kybd/Mouse)
Stereo Emitter IN
*STEP 2: Ensure that
the POWER ON/OFF
switch is in the OFF
position (0) on both the
Tx and Rx units.
Connect the supplied
AC Power Cords to
both units and plug
each into a standard
AC supply. Turn both
switches ON (1).
DVI OUT 1
STEP 4: Connect the DVI and KVM cables between the Source
CPU and the VelocityKVM-34 Transmitter using the cables
supplied in KIT-000005-R. Ensure the CPU is turned ON.
STEP 3: Connect the destination DVI and KVM devices to
the VelocityKVM-34 Receiver using standard cables.
Ensure the devices are turned ON.
2
VELOCITY-34_Manual_QSG
Source CPU
DVI IN 2
Fiber-Optic Cables:
L1: Data Tx to Rx and Video 1
L2: Data Rx to Tx
L3: Video 2
L4: Video 3
L5: Video 4
STEP 2: *
DVI IN 3
DVI OUT 2 DVI OUT 3
DVI IN 4
1
DVI OUT 4
DVI OUT 1DVI OUT 2 DVI OUT 3
DVI OUT 4
9
Extend Distribute Innovate

QUICK START GUIDE
STEP 5: If desired, connect your optional local keyboard &
mouse by inserting the PS/2 or USB HID connectors into the
VelocityKVM Transmitter’s local devices receptacles.
Ensure all system functions are operating properly.
USB HID or PS2 Keyboard/Mouse
USB HID or PS2 Keyboard/Mouse
QUICK START GUIDE
Velocitykvm-35
Velocitykvm-35
Multi-Mode Fiber Extension System –Three DVI Displays
Multi-Mode Fiber Extension System –Three DVI Displays
14
5
USB 2.0 Option
Audio IN/OUT
Stereo 3-D
USB 2.0 Option
Audio OUT ►
DVI IN 1
STEP 1: Connect the 4 Multi-Mode Fiber-Optic Cables
between the Transmitter and Receiver units (up to 1000
meters) as shown.
Audio
◄IN
PS/2 Keyboard
PS/2 Mouse
USB HID (Kybd/Mouse)
USB 1.1 (Kybd/Mouse)
Stereo Emitter IN
*STEP 2: Ensure that
the POWER ON/OFF
switch is in the OFF
position (0) on both the
Tx and Rx units.
Connect the supplied
AC Power Cords to
both units and plug
each into a standard
AC supply. Turn both
switches ON (1).
DVI OUT 1
STEP 4: Connect the DVI and KVM cables between the
Source CPU and the VelocityKVM Transmitter using the
cables supplied in KIT-000005-R. Ensure the CPU is turned
ON.
STEP 3: Connect the destination DVI and KVM devices to
the VelocityKVM Receiver using standard cables. Ensure
the devices are turned ON.
2
VELOCITY-35_Manual_QSG
Source CPU
DVI IN 2
Fiber-Optic Cables:
L1: Data Tx to Rx and Video 1
L2: Data Rx to Tx
L3: Video 2
L4: Video 3
STEP 2: *
DVI IN 3
DVI OUT 2 DVI OUT 3
3
10
Extend Distribute Innovate

QUICK START GUIDE USB HID or PS2 Keyboard/Mouse
USB HID or PS2 Keyboard/Mouse
QUICK START GUIDE
Velocitykvm-38
Velocitykvm-38
Multi-Mode Fiber Extension System –Two Dual-Link DVI Displays
Multi-Mode Fiber Extension System –Two Dual-Link DVI Displays
3
4
5
USB 2.0 Option
Audio IN/OUT
Stereo 3-D
USB 2.0 Option
Audio OUT ►
STEP 1: Connect the five Multi-Mode Fiber-Optic Cables
between the Transmitter and Receiver units (up to 1000
meters) as shown; L1 to L1, L2 to L2, etc.
◄ Audio IN
PS/2 Keyboard
PS/2 Mouse
USB HID (Kybd/Mouse)
USB 1.1 (Kybd/Mouse)
Stereo Emitter IN
*STEP 2: Ensure that
the POWER ON/OFF
switch is in the OFF
position (0) on both the
Tx and Rx units.
Connect the supplied
AC Power Cords to
both units and plug
each into a standard
AC supply. Turn both
switches ON (1).
STEP 4: Connect each of the Dual-Link DVI and KVM cables
between the Source CPU and the VelocityKVM-38 Trans-
mitter using the cables supplied in KIT-000005-R. Ensure
the CPU is turned ON.
STEP 3: Connect the destination Dual-Link DVI and KVM
devices to the VelocityKVM-38 Receiver using standard
cables. Ensure the devices are turned ON.
2
VELOCITY-38_Manual_QSG
Source CPU
DVI IN 1 Dual-Link
Fiber-Optic Cables:
L1: Data Tx to Rx and Video 1 Primary
L2: Data Rx to Tx
L3: Video 1 Secondary
L4: Video 2 Primary
L5: Video 2 Secondary
STEP 2: *
1
DVI OUT 1
Dual-Link
DVI OUT 2
Dual-Link
DVI IN 2 Dual-Link
Local Dual-Link
DVI OUT 1
(optional)
Local Dual-Link
DVI OUT 2
(optional)
DVI OUT 1
Dual-Link
DVI OUT 2
Dual-Link
STEP 5: If desired, connect your optional local keyboard &
mouse by inserting the PS/2 or USB HID connectors into the
VelocityKVM-38 Transmitter’s local devices receptacles
and connect the optional local Dual-Link DVI displays to
the Transmitter’s Dual-Link DVI OUT Ports 1 & 2. Ensure all
system functions are operating properly.
11
Extend Distribute Innovate

12
Extend Distribute Innovate

Technical Specifications
Each Thinklogical™ Velocity KVM system is designed to the following specifications:
Copper Connectors
Transmitter
Video System 4,5,8 DVI-D (2); System 24,34 DVI-D (4)
Audio MIC 3.5mm Jack
Audio LINE 3.5mm Jack
Serial Port DB9 Female
USB 1.0 (HID) USB B
USB 1.1 USB B
USB 2.0 USB B
USB Local Kybd. USB A
USB Local Mouse USB A
PS2 Keyboard MiniDIN 6 Female
PS2 Mouse MiniDIN 6 Female
PS2 Local Kybd. MiniDIN 6 Female
PS2 Local Mouse MiniDIN 6 Female
Stereo Emitter 3D BNC Female
Software Updates USB B (3)
Fiber Connectors LC, SC or ST for Multi-mode
Receiver
Video System 4, 5, 8 DVI-D (2); System 24,34 DVI-D (4)
Audio MIC 3.5mm Jack
Audio LINE 3.5mm Jack
Serial Port DB9 Male
USB 1.0 (HID) USB A (4)
USB 1.1 USB A (4)
USB 2.0 USB A (4)
PS2 Keyboard MiniDIN 6 Female
PS2 Mouse MiniDIN 6 Female
Stereo Emitter 3D BNC Female
Software Updates USB B
Fiber Connectors LC, SC, or ST for Multi-mode
Electrical Cables (supplied with system)
CBL000009-002MR, DVI-D M to M: -4, -5, -24(2), -28, -34(4), -35 (3)
CBL000022-002MR, HD15 to DVI-D: -5
CBL000023-002MR, DVI-D Male to Male, Dual-Link: -8, -28, -38 (2)
KIT-000005-R, Audio Kit, 6FT: 1 each -4, -5, -8, -24, -28, -34, -35, -38
AC Power cords (model determined by destination)
KIT-000005-R Audio Kit contains the following:
CBL000006-006FR 6 pin MiniDIN Male to Male Cable, 6FT (2)
CBL000015-006FR USB A-B Cable, 6FT (2)
CBL000016-006FR 3.5mm Male to 3.5mm Male Plug, 6FT (2)
CBL000017-006FR DB9 Male to DB9 Female Cable, 6FT (1)
CBL000018-006FR BNC Male to BNC Male Cable, 50Ω, 6FT (1)
Video Resolution
DVI –D All Single-Link and Dual-Link Resolutions
Optical Cable
Fiber Type: 50 or 62.5 micron, Multi-mode
Required: 1, 2, 3, 4 or 5 depending upon application.
(Not supplied, but available through Thinklogical™)
Optical Distance
Up to 50 meters with Type OM1
Up to 350 meters with Type OM2
Up to 1000 meters with Type OM3
Operating Temperature and Humidity
0° to 50°C (32° to 122 °F), 5% to 95% RH, non-condensing
Dimensions
Height: 1.72” (4.4cm) ± .039”; .100cm
Depth: 18.02” (45.8cm)* ± .039”; .100cm
Width: 17.49” (44.5cm) ± .039”; .100cm
Weight
Weight: 11 lbs (4.99kg) each
Shipping Weight: 27 lbs (12.25 kg) Transmitter and Receiver
Supply Voltage
100-240 VAC, 47-63 Hz, Universal AC power supply
Power Consumption: 40 Watts per unit
Compliance: Approvals for US, Canada, and European Union
Warranty: 12 months from date of purchase. Extended warranties available.
Copyright © 2011. All rights reserved. Printed in the U.S.A. All trademarks and service marks are the property of their respective owners.
Visit us online at www.thinklogical.com for more
product information, current updates and the
complete line of Thinklogical™ products.
13 Extend Distribute Innovate
PHONE: [phone]
WEBSITE: www.thinklogical.com
EMAIL: [email protected]
PHONE: [phone]
WEBSITE: www.thinklogical.com
EMAIL: [email protected]
