ThinkRF R5550 User manual
ThinkRF R5550
Real-Time Spectrum Analyzer
User Guide
Version 1.0
April 2019
Document no. 5-0038-190401
Copyright © 2019 ThinkRF Corporation, All rights reserved.
All product names are trademarks of their respective companies.
Important notice
The information in this
guide is furnished for
informational use only
and is subject to change
without notice. ThinkRF
Corporation assumes no
responsibility or liability
for any errors or
inaccuracies that may
appear in this document.
No part of this
publication may be
reproduced, published,
stored in an electronic
database, or transmitted,
in any form or by any
means, electronic,
mechanical, recording,
or otherwise, for any
purpose, without the
prior written permission
of ThinkRF Corporation.
Trademarks
ThinkRF, the ThinkRF
logo and R5550 are
trademarks of ThinkRF
Corporation.
All other brand or
product names are
trademarks or registered
trademarks of their
respective companies or
owners.
ThinkRF Corp
390 March Road
Kanata, ON K2K 0G
(613) 369-5104
HARDWARE WARRANTY AND LIMITATI N F LIABILITY
Read this warranty carefully before you use the product.
R5550 Real-Time Spectrum Analyzers are warranted for workmanship and materials
for a period of one (1) year from the date of shipment as identified by the Customer’s
packing slip or carrier waybill. ThinkRF reserves the right to void the warranty on any
equipment that has been altered or damaged due to Customer negligence,
unauthorized repair, misuse of equipment, evidence of physical or environmental
damage, transportation abuse or removal of any ThinkRF identification labels or
serial numbers.
It will remain the responsibility of the Customer, having obtained a Return Material
Authorization (RMA) and shipping instructions from ThinkRF, to return, at the
Customer's expense, the defective unit to ThinkRF’s repair facilities. ThinkRF will
incur shipping charges for the return of warranty repaired equipment. The RMA
number can be secured by calling ThinkRF Customer Service and Support (1-613-
369-5104). If the product does not fall within ThinkRF’s warranty period or the
product is found to be functioning as designed, then under the terms of ThinkRF’s
warranty policy, all costs of repairs and shipping will be charged directly to the
Customer. ThinkRF will warrant repaired units for a period of 90 days from date of
shipment from ThinkRF to the Customer. If the remaining period on the original
hardware warranty is greater than 30 days, then ThinkRF will honor this remaining
warranty period.
THINKRF EXPRESSLY DISCLAIMS ALL OTHER WARRANTIES AND
CONDITIONS, WHETHER EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION, WARRANTIES, CONDITIONS OR REPRESENTATIONS OF
WORKMANSHIP, MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE, DURABILITY, OR THAT THE OPERATION OF THE HARDWARE OR
LICENSED SOFTWARE WILL BE ERROR FREE. IN NO EVENT WILL THINKRF
BE LIABLE FOR INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES.
USE F PR DUCTS IN HIGH RISK ACTIVITIES
THINKRF PRODUCTS ARE INTENDED FOR STANDARD INDOOR COMMERCIAL
USE. WITHOUT THE APPROPRIATE NETWORK DESIGN ENGINEERING, THEY
MUST NOT BE USED FOR ANY “HIGH RISK ACTIVITY”, as described in this
paragraph. Customer acknowledges and agrees that the products supplied
hereunder are not fault-tolerant and are not designed, manufactured or intended for
use or resale as on-line control equipment in hazardous environments requiring fail
safe performance including but not limited to the operation of nuclear facilities,
aircraft navigation or communication systems, air traffic control, direct life support
machines, or weapons systems, in which the failure of products could lead directly to
death, personal injury, or severe physical or environmental damage, all of which are
examples of “High Risk Activity”. THINKRF AND ITS SUPPLIERS EXPRESSLY
DISCLAIM ANY EXPRESS OR IMPLIED WARRANTY OF FITNESS FOR HIGH
RISK ACTIVITIES.
GNU General Public License
This device contains free firmware: you can redistribute it and/or modify it under the
terms of the GNU General Public License as published by the Free Software
Foundation, either version 3 of the License, or (at your option) any later version. This
program is distributed in the hope that it will be useful, but WITHOUT ANY
WARRANTY; without even the implied warranty of MERCHANTABILITY or
FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License
for more details. GNU General Public License is available at
http://www.gnu.org/licenses/.
Table of Contents
Preface ............................................................................................................................ 5
Audience ............................................................................................................................................ 5
Conventions ....................................................................................................................................... 5
Obtaining the Latest Documentation and Software ............................................................................ 5
Document Feedback .......................................................................................................................... 5
Obtaining Technical Assistance ......................................................................................................... 6
verview of the ThinkRF R5550 ................................................................................... 7
Getting Familiar with the ThinkRF R5550 .......................................................................................... 8
The Front Panel .......................................................................................................................... 8
The Rear Panel .......................................................................................................................... 8
The Underside ............................................................................................................................ 9
Installing the ThinkRF R5550 ...................................................................................... 10
Preventing Electrostatic Discharge Damage .................................................................................... 10
Unpacking the Box ........................................................................................................................... 10
Connecting the Antenna, Ethernet and Power Cables ..................................................................... 11
Selecting Where to Mount the R5550 .............................................................................................. 12
Connecting to the R5550 ............................................................................................. 13
Deciding on Your Network Topology and IP Address Allocation ...................................................... 13
Changing the Method of IP Address Allocation for the R5550 analyzer .......................................... 14
Connecting the R5550 Analyzer Directly to a Computer .................................................................. 14
Connecting to the R5550 Analyzer Across a Network ..................................................................... 16
Administration Console .............................................................................................. 18
Connecting via Your Web Browser .................................................................................................. 18
Configuring the R5550 Time ............................................................................................................ 18
Configuring the R5550 IP Address .................................................................................................. 20
Updating the R5550's Firmware ...................................................................................................... 20
Customizing the R5550 Calibration ................................................................................................. 22
Uploading a Custom Calibration File ........................................................................................ 23
Calibration File Source Selection .............................................................................................. 24
Restoring the Default Calibration Settings ................................................................................ 24
Restarting the R5550 ....................................................................................................................... 25
Reset to Factory Settings ........................................................................................... 26
Using the USB Console ............................................................................................... 27
Installing the USB Drivers on Your PC ............................................................................................ 2
Connecting to the USB Console ...................................................................................................... 2
To Configure the R5550 Analyzer's IP Address ............................................................................... 28
Status Indicator LEDs ................................................................................................. 30
Power-up Sequence ........................................................................................................................ 30
Power (PWR) Indicator LED ............................................................................................................ 30
Status (STS) Indicator LED .............................................................................................................. 30
10 MHz Reference (REF) Clock Source and Lock Indicator LED .................................................... 31
RF Chain PLLs LOCK Indicator LED ............................................................................................... 31
Ethernet LINK Status and ACT Indicator LEDs ................................................................................ 31
Hardware Reference .................................................................................................... 33
System Specifications ...................................................................................................................... 33
SMA Connectors .............................................................................................................................. 33
Ethernet RJ-45 Port Pinout .............................................................................................................. 34
GPIO Port Pinout ............................................................................................................................. 34
USB Console Port Pinout ................................................................................................................. 35
RJ-45 Straight-Through Ethernet Cable .......................................................................................... 36
RJ-45 Crossover Ethernet Cable ..................................................................................................... 36
Document Revision History ........................................................................................ 37
Preface
This preface describes the audience for, the organization of, and conventions used in this
document. It also identifies related documentation and explains how to access electronic
documentation.
Audience
This document is written for technical people who have basic understanding, familiarity
and experience with network test and measurement equipment.
Conventions
This section describes the conventions used in this document.
Note: This symbol means take note. Notes contain helpful suggestions or references to
additional information and material.
Caution: This symbol means be careful. In this situation, you might do something that
could result in equipment damage or loss of data.
Warning: This symbol means danger. You are in a situation that could cause bodily
injury. Before you work on any equipment, be aware of the hazards involved with
electrical circuitry and be familiar with the standard practices for preventing accidents.
btaining the Latest Documentation and Software
Please regularly visit our website's resource page at http://www.thinkrf.com/resources
to obtain the latest documentation and the latest releases of new firmware and software.
Document Feedback
Please send your comments about this document or our other documentation to
Thank you, we appreciate your comments.
btaining Technical Assistance
The ThinkRF Support website provides online documents for resolving technical issues
with ThinkRF products at http://thinkrf.com/documentation/.
For all customers who hold a valid end-user license, ThinkRF provides technical
assistance 9 AM to 5 PM Eastern Time, Monday to Friday. Contact us at
Before contacting Support, please have the following information available:
R5550 serial number which is located on the identification label on the R5550's
underside.
The product version.
The firmware version running on the R5550.
Versions of ThinkRF software you are using, potentially including the API
libraries to third-party applications.
The operating system and version you are using.
verview of the ThinkRF R5550
verview of the ThinkRF R5550
The R5550 Real-Time Spectrum Analyzer (RTSA) is a high-performance software-
defined RF receiver, digitizer and analyzer. It is designed for stand-alone, remote,
distributed, and/or embedded real-time spectrum analysis, monitoring and intelligence
applications.
ThinkRF has patented software-defined RF receiver technology that provides industry
leading combined sensitivity, tuning range, instantaneous bandwidth and scan rate.
Additionally, the R5550 provides real-time sophisticated triggering, search and loss-less
capture of signals of interest using an integrated patented digital signal processing
engine.
The R5550 is ideal for monitoring, management and surveillance of transmitters, whether
they are in-building or spread across a geographic area. Applications include but are not
limited to spectrum analysis, 5G wireless technology, research, test and measurement,
spectrum monitoring and OEM integration.
The R5550 Real-Time Spectrum Analyzer provides Gigabit Ethernet for stand-alone,
remote and distributed applications. ThinkRF supports a rich set of industry-leading
standard protocols and APIs, enabling the R5550 to easily integrate into your new or
existing applications. Standard protocols include the Standard Commands for
Programmable Instruments (SCPI) protocol for controlling and obtaining status from the
R5550 and the VITA 49 Radio Transport (VRT) protocol for digitized data and its
associated context information. APIs are provided for interfacing and performing data
acquisition and spectral analysis with Python™, C/C++, MATLAB® and LabVIEW®
Applications can also be built within the PyRF development framework. PyRF is built on
the Python programming language and is open-source under BSD licensing. PyRF
handles the low-level details of real-time acquisition, signal processing and visualization,
and provides feature rich libraries, example applications and source code, all specific to
the requirements of signal analysis.
ThinkRF R5550 Real-Time Spectrum Analyzer User Guide 7
verview of the ThinkRF R5550
Getting Familiar with the ThinkRF R5550
This section provides information about the front and rear panels, connection ports and
identification label of the R5550 Real-Time Spectrum Analyzer.
Note: The type and placement of connectors and components on the panels and the
case may vary depending upon the product variant and version.
The Front Panel
The front panel of the R5550 (the left side of the picture above) contains the power
switch, status indicator LEDs and input connector for the RF antenna port.
The Rear Panel
The rear panel of the R5550 (the right side of the picture above) contains the power
input, 10 MHz reference clock I/O, hardware reset push-button, HIF output, analog I/Q
outputs, USB console (CNSL), Ethernet, and GPIO port.
8 ThinkRF R5550 Real-Time Spectrum Analyzer User Guide
verview of the ThinkRF R5550
The Underside
The underside of the ThinkRF R5550 provides an identification label, as illustrated in the
following page. The label on your product may vary depending on your product variant
and version. This product “Version” number is important for identifying which firmware
can be used to update your product.
ThinkRF R5550 Real-Time Spectrum Analyzer User Guide 9
Installing the ThinkRF R5550
Installing the ThinkRF R5550
Ensure that you read and understand the following information about safety and
electrostatic discharge before you unpack and install the R5550.
Warning: Only trained and qualified personnel should be allowed to install or replace this
equipment. Read the installation instructions before you connect the system to its power
source.
Preventing Electrostatic Discharge Damage
Electrostatic Discharge (ESD) is a single-event, rapid transfer of electrostatic charge
between two objects, such as an operator and a piece of electrical equipment. ESD can
occur when a high electrostatic field develops between two objects in close proximity.
ESD occurs when electronic components are improperly handled and is one of the major
causes of device failures in the semiconductor industry.
Electrostatic discharge is more likely to occur with the combination of synthetic fibers and
dry atmosphere. Always follow these steps to prevent ESD.
Warning: Never open the front or rear panels of the R5550 as personal injury may result
and opening the chassis will void the warranty. There are no user-serviceable parts
inside. Always contact ThinkRF support for service through the online support form at
http://www.thinkrf.com/support/.
Caution: To prevent ESD, wear an ESD-preventive wrist strap that you provide, ensuring
that it makes good skin contact.
Caution: Do not touch any exposed contact pins or connector shells of interface ports
that do not have a cable attached. If cables are connected at one end only, do not touch
the exposed pins at the unconnected end of the cable.
Unpacking the Box
The following table lists the items that come with your R5550 analyzer. If any of the items
are missing or damaged, please contact your ThinkRF customer service representative.
10 ThinkRF R5550 Real-Time Spectrum Analyzer User Guide
Installing the ThinkRF R5550
ThinkRF R5550 Shipping Box Contents:
•R5550 Real-Time Spectrum Analyzer
•Power adapter and cable
•Straight-through Ethernet cable
•USB console cable
•Antenna
•Precautions & Quickstart Guide
Note: The antenna is included for your convenience and only intended to perform
adequately across a limited frequency range.
Connecting the Antenna, Ethernet and Power Cables
Caution: Never connect a transmitter directly to the receiver with a cable.
Caution: Do not over-tighten the antenna connector on the jack. Using a wrench, pliers
or even your hand to over-tighten the antenna can cause permanent damage to the
receiver. See SMA Connectors section for the torque recommendation.
1. Screw the antenna on to the R5550 "RF IN" antenna input SMA jack. Carefully
turn the antenna screw by hand until it encounters resistance. See System
Specifications for the maximum allowable input and cautions.
2. Connect one end of the Ethernet cable to the R5550's Ethernet port and the
other end to an Ethernet port on your router or PC.
3. Connect the R5550 analyzer to its power adapter.
Warning: Use only the power adapter provided with the unit.
4. Plug the power adapter into a power outlet.
5. Push the power switch towards the power symbol to power the unit on.
Note: See Administration Console section for description of the R5550 status.
ThinkRF R5550 Real-Time Spectrum Analyzer User Guide 11
Installing the ThinkRF R5550
Selecting Where to Mount the R5550
Caution: To prevent damage to the R5550 radio receiver, do not install or operate the
R5550 within 2 feet (60 cm) of devices such as Wi-Fi access points that transmit more
than +15 dBm power.
12 ThinkRF R5550 Real-Time Spectrum Analyzer User Guide
Connecting to the R5550
Connecting to the R5550
The R5550 analyzer is a network device and typically all communications with the R5550
analyzer are via a Gigabit Ethernet connection, either directly to a computer or across an
IP network. The R5550 analyzer's Gigabit Ethernet connection provides control and
status of the R5550 using SCPI commands and data using the VRT protocol.
This section provides instruction for different methods of connecting to the R5550 via its
Ethernet port and obtaining its IP address.
Deciding on Your Network Topology and IP Address Allocation
Note: To connect with the R5550 analyzer via its Ethernet port, you must decide on both
the topology of your network connection and how your R5550 obtains its IP address.
As illustrated in the following picture, the R5550 supports any IP network topology
connected via its Ethernet port including:
a direct connection to a computer across an RJ-45 Ethernet cable as per the
Connecting the R5550 Analyzer Directly to a Computer section;
a connection across a routed local network, whether on the same subnet or
across different subnets or across a routed wide-area network such as the
Internet, as per the Connecting to the R5550 Analyzer Across a Network section.
The R5550 analyzer also supports different methods of obtaining its IP address including:
dynamic IP address allocation via the Dynamic Host Configuration Protocol
(DHCP), which is applicable to a routed network topology that has a DHCP
server;
dynamic IP address allocation via the Automatic Private IP Addressing (APIPA)
protocol (otherwise known as Auto-IP), which is applicable for where a DHCP
server is not available. This method allows a direct connection to a computer that
supports Auto-IP or to a local network using a switch. With Auto-IP, a host
13 ThinkRF R5550 Real-Time Spectrum Analyzer User Guide
Connecting to the R5550
network device randomly assigns itself a link-local address in the 169.254.x.y
subnet when it fails to contact a DHCP server. Many operating systems (OSs),
including Windows, support Auto-IP;
static IP address allocation, which is applicable to any network topology.
Changing the Method of IP Address Allocation for the R5550 analyzer
This section provides the instruction for re-configuring one IP address allocation type to
another.
Note: The R5550 analyzer is configured for dynamic IP address allocation by factory
default.
If your R5550 analyzer is configured for dynamic IP allocation, then it may be
reconfigured for static IP address allocation using either its web administration or USB
console. Using the administration console in this scenario requires first a connection to
the R5550 via its Ethernet port, which in turn requires dynamic allocation of its IP either
by DHCP or Auto-IP.
If your R5550 is configured for static IP allocation, then it may be reconfigured for
dynamic IP address allocation using its administration or USB console or via a hardware
reset. Using the hardware reset to reconfigure to dynamic IP allocation is the simplest
method and is described in the section. Using the administration console requires a
connection to the R5550 via its Ethernet port.
Connection to the R5550 using dynamic or static IP allocation is described in the
following sections. The console usage is described in the Administration Console or To
Configure the R5550 Analyzer's IP Address section.
Connecting the R5550 Analyzer Directly to a Computer
This section provides instruction on connecting the R5550 analyzer directly to a computer
via their Ethernet ports using an Ethernet cable.
In order to connect directly to a R5550, the host PC might require a spare Ethernet
interface that is not otherwise used as its primary network connection. For example, you
may use a wireless connection for primary network connectivity or obtain a second
Ethernet card or USB adapter to connect to the R5550.
For this overview, the ThinkRF S240 Real-Time Spectrum Analysis Software is used to
connect to the R5550 analyzer. The latest version of this software can be found at http://
www.thinkrf.com/resources.
To connect the R5550 directly to your computer:
1. Decide on whether you will be using static or dynamic IP allocation. Regardless
of which method you choose, both your PC's and the R5550 Ethernet interface
must be configured for the same method of IP allocation. If necessary, configure
your R5550 to your chosen method of IP allocation following the instruction in the
section.
ThinkRF R5550 Real-Time Spectrum Analyzer User Guide 14
Connecting to the R5550
2. Connect the provided Ethernet cable to both your PC's and the R5550 Ethernet
ports.
3. Power up the R5550 and wait a minute for it to complete booting.
4. Check to ensure that either your PC's or the R5550 LINK indicator is illuminated.
If it is not then your PC may not support automatic crossover on its Ethernet
connection and you may require an RJ-45 crossover Ethernet cable as specified
in the section.
5. If you're using static IP allocation then skip to the next step. Otherwise, check the
STS LED for the Auto-IP setup completion (take a minute or longer).
Note: While the R5550 is searching for a DHCP server, the STS LED blinks yellow slowly
until it obtains an IP address either via DHCP or Auto-IP. The STS LED blinks in a green
heartbeat pattern if it has set up successfully to using an Auto-IP address.
Verify the host PC's IP configuration using the PyRF Discovery Tool. With a
Windows OS, open a Command window and type ipconfig to show the IP
addresses assigned to each interface. The Ethernet interface should show a
169.254.x.y address as seen in the following picture as an example.
6. Use the PyRF Discovery tool or the S240 Real-Time Spectrum Analysis Software
(as shown in the following figure), both provided by ThinkRF, to determine the
assigned IP address of the R5550. In order for the Discovery tool to locate the
R5550, both your computer and the R5550 must be configured for the same
subnet. If you are using Auto-IP dynamic IP allocation, then they will both be on
the same 169.254.x.y subnet. If you are using static IP and the Discovery tool
cannot locate the R5550, then you need to have prior knowledge of its static IP
address or use the USB console.
15 ThinkRF R5550 Real-Time Spectrum Analyzer User Guide
Connecting to the R5550
7. The assigned IP address may now be used to communicate with the R5550
analyzer.
Note: Link-local addresses used for Auto-IP are non-routable, so communications is
limited to devices within the local subnet. This restriction may be an issue when running
virtual machines (e.g. Mac Parallels, VirtualBox, etc.) that may be connected through
virtual routers to the host PC's physical network interface.
Note: After obtaining a link-local address, the R5550 continues to request a DHCP
address. If a DHCP server responds at a later time, the link-local address is overwritten
with the offered IP address. This new address is retained until the network cable is
physically unplugged or the R5550 is restarted.
Connecting to the R5550 Analyzer Across a Network
This section provides instruction on connecting the R5550 to a computer across a routed
local network whether on the same subnet or across different subnets or across a routed
wide-area network such as the Internet.
To connect the R5550 across a network:
1. Decide on whether you will be using static or dynamic IP allocation. Both your PC
and the R5550 do not need to be configured for the same method of IP
allocation; although to locate your R5550 using the ThinkRF Discovery tool
requires that they be on the same subnet. If necessary, configure your R5550 to
your chosen method of IP allocation following the instruction in the section. If you
are using dynamic IP allocation then your router or your network must support a
DHCP server.
2. Connect the provided Ethernet cable to both your router's and the R5550
Ethernet ports.
3. Power up the R5550 and wait a minute for it to complete booting. The sequence
of connecting and powering on are inconsequential.
4. Check to ensure that either your router's or the R5550's LINK indicator is
illuminated.
5. If your R5550 is behind a firewall or a router with firewall capability, then your
network's DHCP server is likely assigning private IP addresses (e.g. 192.168.x.x,
10.x.x.x, 1 2.x.x.x), and the firewall is likely providing some form of network
address translation (NAT) function. If this is the case and if you require access to
the R5550 from outside your firewall, then you will likely have to configure the
firewall to allow port forwarding on port 3 000 and 3 001. If necessary, consult
with your network administrator.
6. Use the PyRF Discovery tool or the S240 Real-Time Spectrum Analysis Software
both provided by ThinkRF, to determine the R5550's assigned IP address. In
order for the Discovery tool to locate the R5550, both your computer and the
R5550 must be configured for the same subnet. If you are using DHCP then you
may have to query your router's allocation tables to determine the IP that is
allocated to your R5550 MAC address. If you are using static IP and the
ThinkRF R5550 Real-Time Spectrum Analyzer User Guide 16
Connecting to the R5550
Discovery tool cannot locate the R5550, then you need to have prior knowledge
of its static IP address or use the USB console. If necessary, consult with your
network administrator.
7. The assigned IP address may now be used to communicate with the R5550.
17 ThinkRF R5550 Real-Time Spectrum Analyzer User Guide
Administration Console
Administration Console
This section provides instruction on connecting to the R5550 via its web-based
Administration Console. The Administration Console provides the ability to:
obtain status information from the R5550;
change date and time configuration;
change IP configuration;
upgrade the R5550 software/firmware;
upload customized calibrations settings;
and/or restart the R5550.
All of these functions may be performed via the network either locally or remotely.
Connecting via Your Web Browser
Connect to the R5550 Administration Console by entering the IP address of your R5550
into a web browser's web address dialog. The IP address is shown in the S240 software
as the connected device. The following "Status" web page should appear providing
information on the R5550.
Configuring the R5550 Time
The time on the R5550 analyzer can be set manually or as per host PC's time or via an
NTP server.
ThinkRF R5550 Real-Time Spectrum Analyzer User Guide 18
Administration Console
Note: The R5550 analyzer stores its time based on the Coordinated Universal Time
(UTC) and otherwise has no notion of local time-zones. Conversely, the web dialog
translates and displays the R5550 time based on the local time-zone setting of the PC.
1. Click on the "Time Configuration" link in the left column menu of the
administrative console web page. The following "R5550 Device Time
Configuration" web page should appear.
2. Select the time synchronization source.
3. If “Enter time manually” is selected then enter the date and time based on your
local time-zone.
4. If “Use current PC time” is selected then the data and time fields will be
populated automatically.
5. If “NTP” is selected, enter at least one NTP server IP address and select whether
the time be synced just this one time or continuously. If “continuously” is
selected, the R5550's time is synchronized to the NTP server on a continuous
and regular basis, the regularity of which is optimally determined automatically.
6. Click the “Apply” button.
19 ThinkRF R5550 Real-Time Spectrum Analyzer User Guide
Administration Console
Configuring the R5550 IP Address
The R5550 provides options for selecting whether the R5550 IP address is obtained
dynamically using DHCP or is set manually to a static address.
Caution: Please note that if the R5550 IP address is set to static IP then the only way to
communicate with the R5550 is via that IP address. If you mistakenly enter the wrong IP
address and/or subnet mask, or forget the IP address, then you can change the IP
configuration Using the USB Console or Restarting the R5550.
1. Click on the "IP Configuration" link in the left column menu of the administrative
console. The following "R5550 Device IP Configuration" web page should
appear. Once the “Apply” is clicked, the new configuration will take effect
immediately and the current configuration and web page will no longer be valid.
Updating the R5550's Firmware
This section will step you through updating the R5550 firmware. The firmware install file
contains firmware images associated with the R5550 FPGA, Linux operating system and
the embedded application. The process of updating will copy the new images to the
R5550 in addition to and without erasing the current installed images. The new install will
only take effect upon the R5550 being restarted.
Note: Updating firmware might over-write any user-defined calibrated values, see
Customizing the R5550 Calibration for more information.
ThinkRF R5550 Real-Time Spectrum Analyzer User Guide 20
