Thomas 1060 User manual

USER’S
GUIDE
Double
tank mixer
Ref. 1060/2169/1168
7877/7876
THOMAS APICULTURE
French designer and manufacturer
Of beekeeping equipment
ZA de l’Évangile
321, rue Bernard de la Rochefoucauld
45450 Fay-aux-Loges –France
Tél: [phone]
Fax : [phone]
E-mail : [e-mail]
www.thomas-apiculture.com
Non-contractual

Double tank mixer : User’s Guide 2/6
- Version du 10/06/2020 -
Technical Definition
Stainless steel
Capacity / Weight :
Ref. 1060 : 100 kg/ 75 kg
Ref. 2169 : 200 kg/ 90 kg
Ref. 1168 : 400 kg/ 250 kg
Ref. 7877 : 600 kg/ 310 kg
Ref. 7876 : 1000 kg/ 330 kg
Speed : 35 rpm
Motor :
Ref. 1060: Single phase 220 V –2370 W
Ref. 2169: Single phase 220 V –2370 W
Ref. 1168: Triple phase 380 V+N –4750W
Ref. 7877: Triple phase 380 V+N –4750W
Ref. 7876: Triple phase 380 V+N –5100W
The double tank mixer allows the re-melting of
previously skinned crystallized honey, the
mixing of liquid honeys and the production of
creamy honey by seeding and directed
crystallization.
Thanks to its electric heating system, the device
liquefies the honey to facilitate mixing.
SAFETY PRECAUTIONS
CAUTION : Before connecting the appliance to the power supply, make sure that the electrical
installation complies with current standards (protection by earth leakage circuit breaker, earth
wire, etc.).
Check the supply voltage.
Before using the unit for the first time, clean it to remove any residual chips or filings.
Use edible oil to fill the oil bath (not included, to be ordered separately). Never use water: risk of
damage to the immersed heaters (1).
Never operate the appliance without oil.
Never replace the vent or seal completely the vent cap: too high an oil level can damage the tank
and the welds.
Never heat without oil or honey.
Do not the device heat for a long time without surveillance (for example over night).

- Version du 10/06/2020 -
OPERATING PRINCIPLE
Entirely made of stainless steel, the double tank mixer consists of an Archimedes' screw (2) which
stirs the honey in an ascending or descending direction and ensures a remelting and a homogeneous
mixing of the product in a minimum of time.
The heating of the apparatus is ensured by an immersed heater (1) controlled by an electronic
temperature regulator (3).
The appliance is equipped with a safety contact, located under the crossbar, to stop the rotation of
the screw when the stainless steel lid (4) is opened.
The mixer also has a flat sloped base allowing the honey to flow completely through an outlet 40/49
located at the bottom of the appliance.
Double tank mixer : User’s Guide 3/6
Oil filling
Hole (5)
Stainless steel
half lid (4)
Geared motor
Immersed
Heater (1)
Honey draining
vane (10)
Command box
Glass plug
for checking
the oil level
programmable
cycle time delay
temperature probe
displayl

- Version du 10/06/2020 -
USAGE GUIDE
Filling the water bath
Unscrew the vent plug and pour the edible oil into the filler elbow (5) until the oil level indicator
is reached.
For those who have an oil pump, filling can be carried out via the drain valve located under the
unit.
The mixer is sold without oil (ref. 840).For 100 kg mixer, provide 50 L of oil, For 200 kg mixer,
provide ~60 L of oil, For 400 kg mixer, provide ~150 L of oil, For 600 kg mixer, provide ~200 L of
oil, For a 1000 kg mixer, provide ~220 L of oil.
Draining the oil bath
Unscrew the plug on the outlet valve, turn the water bath drain valve and let the oil drain into a
container.
Start-up
Connect the unit to the power supply.
Set the POWER button (6) to "ON".
Set the ON/OFF button (7) to "ON", the indicator light will light up to indicate when the unit is
heating up. When the desired temperature is reached, the indicator light will go out.
Pour the honey into the tank.
Set the electronic controller (3) to the desired temperature (see also the enclosed controller
manual):
- Press the SET key for more than 2 seconds.
- The temperature value is displayed and the °C LED flashes.
- Change this value using the ▲ou ▼buttons within 10 seconds to reach the
desired temperature.
- To store the new value, press the SET button again or wait 10 seconds to
restart the operation.
Press the rotation direction invertor (8) to turn the mixer screw.
Rotate this knob again to change the direction of rotation.
To stop the machine, turn the ON/OFF knob (7) to OFF and then turn the power switch (6) to
OFF.
In case of emergency, press the emergency stop button (9) and unlock it by turning it slightly to
the right.
Collect the honey by opening the honey outlet valve (10).
Double tank mixer : User’s Guide 4/6

- Version du 10/06/2020 -
Double tank mixer : User’s Guide 5/6
MAINTENANCE
CAUTION : Disconnect the machine from the power supply before any work is carried out.
Protect electrical equipment when cleaning.
Clean with hot water.
The double tank mixer is a seasonal equipment but must operate regularly throughout the
year (at least a few minutes per month).
Store preferably in a dry room.
Rotation
direction invertor
(8)
Digital thermostat
(3)
Emergency stop
switch
(9)
ON/OFF switch
(+ indicating light)
(7)
POWER switch
(6)

- Version du 10/06/2020 -
Frequent Questions
CAUTION : Unplug the machine before any work is carried out.
Problem Possible solution
The mixer does not start
- Check that the unit is connected to the power supply.
- Check the power supply (power failure).
- Check that the circuit breaker button inside the control
box is set to ON.
- Check the condition of the fuses.
The mixer does not heat up
- Check that the ON/OFF button (7) is in the ON position.
- Check the setting of the digital thermostat (3).
- Check that the emergency stop button (9) is unlocked
(turn it slightly to the right).
The endless screw does not turn
- Check that the cover (4) is closed properly and press the
safety contact.
- Check the condition of the circuit breaker inside the box.
- Check that the direction of rotation inverter (8) is not set
to 0.
- Check that the emergency stop button (9) is unlocked
(turn it slightly to the right).
Double tank mixer : User’s Guide 6/6

If the problems are still there,
please contact us :
Customer Service :
02 38 46 88 00
From 8:00 am to 12:00 am
And from 2:00 pm to 5:30 pm
From Monday to Friday
[email protected]
Technical Help:
08 99 25 66 20 (cost: 0,05€/min)
High season 12H/24 and 6 days /7
(Monday - Saturday 8:00 am –8:00 pm)
Off season 8H/24 et 5 days /7
(Monday –Friday from 8:00 to 12:00
And from 1:30 pm to 6:00 pm)
[e-mail]
