THOMSON 513630 User manual

www.thomsonsecurity.eu
V2
EN Wireless weather station
513630
Backlight
12h/24h
Alarm cloc
k
1
Calendar

WIRELESS WEATHER STATION
3EN
EN
www.thomsonsecurity.eu
TABLE OF CONTENTS
A - SAFETY INSTRUCTIONS 05
1 - OPERATING PRECAUTIONS 05
2 - MAINTENANCE AND CLEANING 05
3 - RECYCLING 05
B- PRODUCT DESCRIPTION 06
1 - CONTENTS OF THE KIT 06
2 - WEATHER STATION 06
3 - MAIN FUNCTIONS 07
C - CONFIGURATION 08
1 - QUICK START-UP 08
PAIRING THE SENSOR TO THE STATION 08
TIME AND DATE SETTING 08
ALARM SETTING 08
AUTOMATIC TIME SETTING 08
SETTING THE MEASUREMENT UNIT/MIN-MAX MEMORY 09
WEATHER FORECAST 09
D - TECHNICAL AND LEGAL INFORMATION 10
1 - TECHNICAL CHARACTERISTICS 10
2 - REPLACING THE BATTERIES 10
3 - WARRANTY 10
4 - HELP AND ADVICE 10
5 - DECLARATION OF CONFORMITY 11

WIRELESS WEATHER STATION
5EN
EN
www.thomsonsecurity.eu
A - SAFETY INSTRUCTIONS
1 - OPERATING PRECAUTIONS
• The weather station must not be installed
where the screen may be vulnerable to
scratching and dirt.
• The weather station is not designed for outside
use and should not be installed in locations
that are subject to extremes of humidity or
temperature.
• Do not expose the sensor to direct sunlight or
any reected light source.
• Do not daisy-chain extension cords and/or
multi-socket adapters.
• Do not install near acidic chemicals, ammonia
or sources of toxic gases.
2 - MAINTENANCE AND CLEANING
• Always unplug the product from the mains
before carrying out any maintenance.
• Never use abrasive or corrosive substances to
clean the products.
• Use a soft, slightly damp cloth.
• Never use an aerosol to spray the product as
this may damage the internal workings.
3 - RECYCLING
This logo indicates that electrical and
electronic waste must not be disposed of
with household waste. They are likely to
contain hazardous substances which are
dangerous to both health and the
environment. Return the equipment to
your local distributor or use the recycling collection
service provided by your local council.
It is forbidden to throw used batteries
into the dustbin. Batteries/accumulators
containing harmful substances are
marked with symbols (shown opposite)
which indicate that they cannot be
thrown away as ordinary waste. The corresponding
heavy metals are referred to as follows: Cd =
cadmium, Hg = mercury, Pb = lead. You can dispose
of these batteries/accumulators at local recycling
amenities (centres for sorting recyclable materials)
which are required to accept them. Keep batteries/
button cells/accumulators out of reach of children
and store them in a safe place not accessible to
them. as they could be swallowed by children or
pets. May be fatal if swallowed! In the event that a
battery is swallowed, consult a doctor or go to A&E
immediately. Never short-circuit the batteries, and
do not burn or recharge them. They may explode!
Pour en savoir plus :
www.quefairedemesdechets.fr

WIRELESS WEATHER STATION
EN 6
www.thomsonsecurity.eu
B - PRODUCT DESCRIPTION
1 - CONTENTS OF THE KIT
2 - WEATHER STATION
1x 1 3x 1
TIME
INDOOR
OUTDOOR
TODAYTEMP
88
8888
88
88
88
E
E
Hi
RH
M
PM
D
DAY
M
D
%
Lo
Z
z
TIME
INDOOR
OUTDOOR
TODAYTEMP
88
8888
88
88
88
E
E
Hi
RH
M
PM
D
DAY
M
D
%
Lo
Z
z
DC 4.5V
MODE ALARM
WAVE
LIGHT/SNZ
1
2
3
4
6
8
9
11
12
10
5
7
21
19
20
13 14 1615 1817
1Weather station
2Mains adaptor
3Temperature sensor
1Weather forecast
2Time
3Radio transmission icon
4Outside temperature
5Min/max outdoor temperature
6Time
7Inside temperature
8DCF77 indicator
9Alarm indicator
10 Date
11 Day of Week
12 Alarm postponement indicator
13 MODE button
14 ALERT button
15 UP button
16 DOWN button
17 WAVE button
18 Light/Snz button
19 Battery compartment (2 x LR03 AAA)
20 Socket for mains adaptor plug
21 Battery compartment (2 x LR03 AAA)
2x 1

WIRELESS WEATHER STATION
7EN
EN
www.thomsonsecurity.eu
B - PRODUCT DESCRIPTION
3 - MAIN FUNCTIONS
- Coloured backlit screen
- Temperature and indoor humidity display
- Current/MIN/MAX/outdoor temperature display
- Displays the time in 12 and 24-hour format
- Radio clock (DCF77)
- Daily alarm
- Calendar
- Wireless external sensor

WIRELESS WEATHER STATION
EN 8
www.thomsonsecurity.eu
C - CONFIGURATION
1 - QUICK START-UP
These steps must be followed in order.
Insert 2 AAA LR03 batteries (not supplied) into the
station 19. Then insert the 2 AAA LR03 batteries (not
supplied) into the outdoor sensor, ensuring that the
polarity is respected 21.
PAIRING THE SENSOR TO THE STATION
Pairing is automatic once the batteries are inserted.
To force pairing, if required:
- On the station, press and hold the DOWN button
for 5 seconds. The indicator starts to  ash
- On the outdoor sensor, remove then reinsert the
batteries, positioning yourself near the weather
station.
TIME AND DATE SETTING
- Press and hold the MODE button until the year
starts  ashing. Using the UP and DOWN buttons,
set the year.
- Press the MODE button to con rm. The  gure to
the left of M  ashes on the lower right side of the
screen. Set the month using the UP and DOWN
buttons
- Press the MODE button to con rm. The  gure to
the left of D  ashes on the lower right side of
the screen. Set the Day using the UP and DOWN
buttons
- Press the MODE button to con rm. The letters M
and D  ash on the lower right side of the screen.
Set the display order using the UP and DOWN
buttons (month/day or day/month)
- Press the MODE button to con rm. The two
letters to the right of DAY  ash. Set the calendar
language using the UP and DOWN buttons (GE
= German / EN = English / FR= French / IS Italian
/ Sp = Spanish / DU = Netherlands / DA = Danish)
- Press the MODE button to con rm. The two
 gures under Time: 00  ash. Set the time zone
using the UP and DOWN buttons.
- Press the MODE button to con rm. 24h or 12h
 ashes. Set the display format for the hour using
the UP and DOWN buttons
- Press the MODE button to con rm then
set the hour using the UP and DOWN buttons.
- Press the MODE button to con rm then set the
minutes using the UP and DOWN buttons.
- Press the MODE button again
to con rm the settings.
ALARM SETTING
- Press and hold the ALARM button for 3 seconds:
The hour of the alarm  ashes
Set the hour of the alarm using the UP and
DOWN buttons
- Press the ALARM button to con rm. The minutes
 ash. Set the minutes of the alarm using the
UP and DOWN buttons
- Press the ALARM button to con rm. Zz 05
 ashes.
Set the duration of the alarm postponement in
minutes using the UP and DOWN buttons
- Finish the con guration by pressing quickly on the
ALARM button
- When the alarm goes off, pressing the Light/SNZ
button pauses the alarm and postpones it to the
pre-set time (Zz).
- When the alarm goes off, pressing the ALARM
button stops the alarm tone.
To set the alarm, press the ALARM button once. A
bell (9) appears between the hour and minutes
To turn off the alarm, press the ALARM button once.
The bell (9) disappears.
The tone lasts for approximately 1 minute.
AUTOMATIC TIME SETTING
To launch the automatic time setting for the station,
press the WAVE button once. The LED (8)  ashes.
The station switches to radio reception (for 7 minutes)
and attempts to pick up the DCF77 time signal to
automatically update the time and date.
Note: the time zone must be set correctly for a
correct display. If reception is insuf cient, please set
the station near a window.
Ensure that you leave a gap of 2.5 m between the
station and any source of interference (television,
router, microwaves, etc.)
The signal search can be cut off at any point
by pressing the WAVE button, if the signal is not
available.

WIRELESS WEATHER STATION
9EN
EN
www.thomsonsecurity.eu
C - CONFIGURATION
SETTING THE MEASUREMENT UNIT/MIN-MAX
MEMORY
- Press the DOWN button to alternate between
Celsius and Fahrenheit
- Pressing and holding the DOWN button for 3
seconds erases the MIN/MAX values saved.
WEATHER FORECAST:
The weather station displays the weather using an
integrated atmospheric pressure sensor.
It can display 4 different statuses:
Sun Clouds/clearing
Very cloudy Rainy
Information: The weather forecast that measures
humidity and temperature may be distorted if the
weather station is installed in an area that is either
too hot or too cold, and the measured data is too
high compared to the current surrounding data.

WIRELESS WEATHER STATION
EN 10
www.thomsonsecurity.eu
D - TECHNICAL AND LEGAL INFORMATION
1 - TECHNICAL CHARACTERISTICS
Weather station
Power supply
- The station operates with 2 LR3 batteries (not included) and/or
a 4.5 V mains transformer (included)
- The sensor operates with 2 LR3 batteries (not included)
Frequency 433.92 MHz
Range between the sensor and the station 60 m in open air.
Range of indoor temperatures 0°C (32°F) ~ 50°C (122°F)
Range of outdoor temperatures -20°C (-4°F) ~ 60°C (140°F)
Humidity measurement range 20% RH ~ 95% RH
Temperature measurement unit Celsius (°C) or Fahrenheit (°F).
Station dimensions 120 x 120 x 24.5 mm
Sensor dimensions 92 x 40 x 23 mm
Materials ABS
2 - REPLACING THE BATTERIES
The battery life is one to two years under normal
operation. Use 2 alkaline LR06 AA batteries for
the station and 2 alkaline LR03 AAA batteries
for the outdoor sensor, ensuring that the indicated
polarity is respected.
3 - WARRANTY
• This product is under warranty for parts and
labour for 2 years from the date of purchase.
Proof of purchase must be retained for the
duration of the warranty period.
• The warranty does not cover damage caused
by negligence, knocks or accidents.
• to be opened or replaced by non-Avidsen
employees.
• The warranty will be void if the device is
tampered with.
4 - HELP AND ADVICE
• If, despite the care we have taken in designing
our products and drafting these instructions,
you do encounter difculties when installing
your product or you have any questions, we
recommend you contact one of our specialists
who will be glad to help.
• If you encounter operating problems during
the installation or a few days afterwards,
it is essential that you are in front of your
installation when contacting us, so that one of
our technicians can diagnose the source of the
problem, as it will probably be the result of a
setting that is incorrect or an installation that
is not to specication. If the problem is caused
by the product itself, the technician will give
you an RMA number so that you can return the
unit to the shop. Without this RMA number, the
shop may refuse to exchange the product.

WIRELESS WEATHER STATION
11 EN
EN
www.thomsonsecurity.eu
D - TECHNICAL AND LEGAL INFORMATION
Contact our After Sales Service team technicians
on:
0,35 € / min
0 892 701 369
Monday to Friday, 9AM to 12PM and 2PM to 6PM.
Avidsen undertakes to keep a stock of spare parts
for this product throughout the contractual warranty
period.
5 - DECLARATION OF CONFORMITY
Per the RED directive
Avidsen declares that the following equipment:
Weather station 513630
Complies with the 2014/53/EU directive and its
conformity has been assessed pursuant to the
applicable standards in force:
EN62479:2010
EN301 489-1 V1.9.2:2011-09
EN301 489-3 V1.6.1:2013-08
EN300 220-1 V2.4.1:2012-05
EN300 220-2 V2.4.1:2012-05
Chambray les Tours, date: 01/03/2017
Alexandre Chaverot, CEO

is aTECHNICOLOR S.A. brand used under licence by:
Avidsen France S.A.S - 32, rue Augustin Fresnel
37170 CHAMBRAY LES TOURS - France
