USER MANUAL
Raised toilet seat / with lid
Product code: KING-10-20 / KING-10L-20
KING-15L-20
Dear Customers,
Thank you for purchasing our product. We hope that the equipment you have selected will
meet your expectations. We would like to share some important information with you.
Timago International Group is a Polish company which distributes medical, rehabilitation and
orthopaedic products to pharmacies and medical stores.
Our mission is to ensure your comfort by offering safe, functional, and high-quality products.
We have many years of experience in this sector. Timago products reach a wide range of
users in Poland and throughout Europe through our distributors (medical retailers).
Timago’s company culture promotes openness to your needs. Our goal is to promote safe
and correct use of our products for treatment and rehabilitation in order to improve comfort
and quality of life.
We invite you to access our website for more information: timago.com.

2

3
1. Introduction
Prior to use of our products you should inspect the equipment for any defects which may
have occurred during transport. If this happens, please contact your retailer.
Then, please read this instruction which includes important information for the user.
Please contact us if you have any questions concerning the use of the equipment. Our
advisors will provide you with any information you require on an ongoing basis.
Please note that if you have questions other than those concerning the use of our products,
you should contact your doctor, nurse or physical therapist.
2. Characteristics
Toilet seat is made of durable plastic material. It is equipped with modern mounting system
with anti-sliding protection and fits to majority of toilet bowls. Ergonomically designed
surface of the toilet seat results in equal distribution of pressure force on the user’s body.
The slight downward incline of the toilet seat promotes correct posture and reduces flexing
of the hip and knee joints. There are two cut outs at the front and back which facilitate
performing hygienic activities in sitting position. The surface is easy to clean and resists
stains and smells. The models KING-10L-20 / KING-15L-20 are equipped with lid.
The set includes:
•toilet seat
•bracket with adjustment knob and anti-sliding protection – 2 pcs
•lid (models KING-10L-20 / KING-15L-20)
Elements of the toilet seat:
a. front skirt
b. bracket
c. anti-sliding protection
d. adjustment knob
e. front and back cut outs
f. lid
g. hinges of lid

4
3. Application
Raised toilet seat is ancillary equipment which helps the user to perform hygienic activities.
The raised toilet seat is recommended to people with reduced mobility who have difficulties
in sitting and standing up when using the toilet and for patients after hip operation.
4. Assembly and general recommendations for use
Note! Follow the information contained in this manual while assembly and adjustment.
Users with reduced mobility may need help from a third person who has appropriate skills.
Note! Do not use the toilet seat when you notice any visible or perceptible damage
(e.g. crack) as this may cause an accident.
ASSEMBLY
•Insert brackets with adjustment knobs into the slots of the raised toilet seat. Set the
brackets wider than the width of the toilet bowl.
•Lift the toilet seat and place raised toilet seat directly on the toilet bowl positioning
the brackets towards the back part of the toilet bowl and the front skirt against the
outer part of the front of the toilet bowl.
•Turn the adjustment knobs clockwise until perceptible resistance so that the seat
does not move from side to side.
Note! The side-locks have been especially designed for easy assembly, therefore,
the resistance indicates that the locks are already mounted.
Note! Before use, ensure that the raised toilet seat is correctly assembled.

5
5. Technical data
Inner seat dimensions 21 x 26 cm
Outer seat dimensions 36.5 x 40.5 cm
Height 10 cm / 15 cm
Weight KING-10-20
Weight KING-10L-20 / KING-15L-20
1.00 kg
1.40 kg
Maximum capacity 225 kg
Colour white
6. Notes and recommendations
•Patients with reduced mobility require help from a third person.
•Do not exceed maximum capacity of the raised toilet seat (225 kg).
•Do not stand on the raised toilet seat.
•The lid in KING-10L-20 / KING-15L-20 may not serve as a seat.
•Do not lean on the raised toilet seat for standing up and sitting down.
•Do not attach any objects to the raised toilet seat as it may cause an accident.
•Only one person can use the raised toilet seat during hygienic activities.
•Remove all potential obstacles in the bathroom and make sure that the floor is flat.
Slippery floor should be secured with e.g. anti-slip mats.
•Do not make any repairs or modifications by yourself. Any repairs should be done by
qualified personnel of the manufacturer.
•Do not store raised toilet seat in rooms in the temperature below zero and in the
open air.
NOTE! Timago International Group does not bear responsibility of improper use of the
raised toilet seat, failure to comply safety regulations and misuse.
7. Maintenance
•Clean the raised toilet seat regularly using only water and mild detergents. Dry
thoroughly.
•The seat can be immersed in water or sanitized in an autoclave at 85oC for 1 minute.

6
•Do not use for cleaning: strong polishing agents and detergents, abrasive agents,
bleach, petrol or solvents (it may cause product damage, visible defects and in
consequence - loss of warranty rights).
•At least once every three months check:
-condition of brackets and adjustment knobs
8. Warranty information
All products distributed by our company are under a warranty, the terms of which are
described in the warranty card received at the time of purchase.
Please, keep in mind that for warranty purposes, the proof of purchase (receipt or invoice)
should be retained.
As a user friendly company, we only supply products which have been thoroughly tested
with respect to materials, quality and functionality.
Please contact us if you have any questions concerning our servicing procedure.
9. Labels
Reference number Manufacturer
LOT number Manufacture date
Serial number
Representative in Euro-
pean Union
Note
Please read the
instruction
The Manufacturer checked for compliance with
essential medical devices requirements.
10. Recommended products
•Products offered by Timago International Group include:
•Orthoses and joint stabilizers
•Manual and special-use wheelchairs
•Walkers and rollators
•Crutches and canes

7
•Rehabilitation beds
•Ancillary and sanitary equipment
•Anti-decubitus equipment and accessories
•Stabilizing and immobilizing belts
•Electro-medical equipment
•Disposable medical equipment
Our complete line of products is available from our distributors.
Learn more at: timago.com.

8
Manufacturer:
LM GLOBAL Design Limited
Suite 74, Guinness Enterprise
Centre, Taylor’s Lane,
D8 Dublin, Ireland
Issue II, date 09.04.2018
