Cinderella CLASSIC Guide

www.cinderellaeco.com
Maintenance
Maintenance
To ensure optimal operation of your Cinderella, be
prepared to set aside some time for preventative
maintenance. Good maintenance means lower
operating costs and longevity. In the following,
additional instructions, you will find some simple
measures that we recommend be carried out one or
two times a year or every 1000th incineration.
Clean the air pipes
Check inlet and outlet air pipes by disconnecting the toilet from
the pipes. Make sure that both inlet air and exhaust air pipes
and valves are cleaned free of dirt, dust or anything else that
may impede air ow. Use ordinary pipe cleaning brushes when
cleaning the pipes. Remove pipe cap and bottom lid from the
T-bend and clean the hole.
Emptying notications Emptying the ash container
The following procedure is recommended:
1Make sure that the incineration process has nished, and that
the toilet is cold. The fan must be o
3Turn the ash container so that the handle points straight out.
Red and yellow lights will now indicate that the ashtray is out of
position
6
Pour hot water in the insert and leave it for about 30 minutes.
Clean with a brush. (Do not use sharp tools.) Wipe the outside of
the insert
2Remove the front over at the bottom front of the toilet
4Pull the ash container out and towards you
5Remove the insert (the inner bowl) and empty the ashes
7Put the insert back in the ash container
8Pour 1 liter of water into the insert before placing it back into the
toilet
9Replace the ash container and push it all the way in
11 Replace the front cover
10 Turn the handle rmly to the left until it stops. Red and yellow
lights will go out
12
Open and close the toilet lid. Start an incineration process without
putting in a bowl liner or paper. The water in the insert will begin
to boil and the water vapor will clean the catalyst.
emptying the ash container.
seconds 3 short beeps are heard. This is easily solved by
indicates «toilet locked, container full» and every 10
the yellow and red lights are lit constantly. The display
be used for a while, but it will eventually lock. Thereafter,
are heard when the toilet lid is opened. The toilet can still
indicates ”empty the ash container” and 3 short beeps
Yellow and red lights ash alternately. The display
CINDERELLA COMFORT & GAS MODEL
seconds 3 short beeps are heard.
the yellow and red lights are lit constantly, and every 10
be used for a while, but it will eventually lock. Thereafter,
are heard when the toilet lid is opened. The toilet can still
Yellow and red lights ash alternately, and 3 short beeps
CINDERELLA CLASSIC MODEL
Cinderella indicates when you should empty the ashtray:

www.cinderellaeco.com
Cleaning
Cleaning Check your battery
Clean the catalyst
1Open the toilet lid (the fan will start)
3
Use damp paper and any ordinary cleaning agent (Note: Be sure not to
use chlorine-based or ammable agents). Carefully wipe the entire bowl
and the ”wings” and drop the paper into the incineration chamber
2Press the start button. The wings of the toilet bowl, which open to give
access to the incineration chamber, will open and remain open until
the toilet lid is closed
4When the cleaning process is done, close the toilet lid. The fan will stop
when the toilet is reset
1Check that the toilet has been connected to 230 V for at least
2 days
3Open and close the toilet lid
2Pull out the plug
4
5
6
Press the start button
If you hear the toilet bowl leaves open and close, the
battery is OK
If not, it is time to replace the battery
1Unplug and disconnect the toilet from the inlet and outlet air pipes
3At the back of the toilet, where the vent pipe is located, you will nd a
smaller pipe in the middle. This is the catalyst pipe
2Remove the ash container
4Scrape the catalyst pipe carefully with a knife. Vacuum
at the same time so that no dirt falls into the pipe
When performing a normal cleaning of your Cinderella (or if
someone forgets to use the bowl liner) do the following:
(NOTE: be sure this is only performed when the toilet is cold,
and the fan has stopped):
Cinderella has a built-in battery that is activated auto-
matically, should you lose access to electricity, in order to
power the fan while the toilet is hot. The life expectancy
of the battery is estimated at 4-5 years under optimal
conditions. If the power is o for longer periods, the
battery life is reduced. Test your battery as follows:
The catalyst ensures odorless incineration. Under normal conditions,
the ash should have a grayish color, with no paper residue. To avoid
poor incineration quality or odor, the catalyst should be ushed
through with water. In order to accomplish this, you should be able
to lift the Cinderella yourself or have someone to do it with you.
The rest of your maintenance routine requires that you have access to a place
where you can spill some water, for example in the garden, the bathtub or shower.
Find a stable surface on which the toilet can be
placed. Angle the toilet with the front down. The
front edge of the toilet should be about 20 cm
above ground level. Insert a funnel into the end of
the exhaust pipe. Pour 5-10 liters of hot water (tap
water hot) into the funnel. Make sure that the water
does not run over the edge of the exhaust pipe.
Keep ushing water through the system until you
see that the water owing out is completely clear,
with no color. Reassemble the toilet and start an
incineration cycle without putting in a bowl liner or
paper. This will dry the catalyst.
