Timberwolf TPS35 Operating instructions

EN
W415-1477 / A / 10.19.16
FR
PG
49
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
INSTALLATION AND
OPERATING INSTRUCTIONS
1.18F
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
Phone [phone] • Fax [phone] • www.timberwolffireplaces.com • ask@timberwolffireplaces.com
$10.00
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
!
WARNING
CERTIFIED FOR CANADAAND UNITED STATES USING ANSI/CSAMETHODS.
SAFETY INFORMATION
!WARNING
PLEASE READ ENTIRE MANUAL
BEFORE YOU INSTALL OR USE THIS
PELLET BURNING APPLIANCE.
If the appliance is not properly installed,
a house fire may result causing personal
injury or loss of life.
- Authorities having jurisdiction (such as
municipal building department, fire department, fire
prevention bureau, etc.) should be consulted before
installation to determine the need to obtain a permit.
- Contact local building or fire officials about
restrictions and installation inspection
requirements in your area.
- This appliance is hot while in operation. Keep
children, clothing and furniture away. Contact may
cause skin burns.
- Do not start a fire with chemicals or fluids such as
gasoline, engine oil, etc...
- Do not burn trash or garbage, lawn clippings /
waste, rubber, waste petroleum products, paints
or paint thinners / solvents, plastic, materials
containing asbestos, construction debris, railroad
ties, manure or animal remains, salt water driftwood
or salted materials, unseasoned wood, coloured
paper, cardboard, plywood or particleboard.
TPS35
PELLET STOVE
TPI35
PELLET INSERT
MODEL TPS35/TPI35 MEET THE 2015 U.S ENVIRONMENTAL PROTECTION AGENCY (E.P.A.) PELLET FUEL EMISSION LIMITS FOR PELLET APPLIANCES SOLD
AFTER MAY 15, 2015, 40 C.F. R. PART 60. THESE STOVES HAVE BEEN TESTED AND LISTED BY INTERTEK TESTING SERVICES TO STANDARDS: ASTM E 1509,
ULC/ORD C1482M-90, ULC S627 AND ULC S628.
FOR INDOOR USE ONLY

W415-1477 / A / 10.19.16
2
EN
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
TABLE OF CONTENTS
1.0 INSTALLATION OVERVIEW 3
1.1 STOVE 3
1.2 INSERT 4
2.0 INTRODUCTION 5
2.1 DIMENSIONS 6
2.1.1 STOVE 6
2.1.2 INSERT (COMPLETE WITH FLASHING) 6
2.2 SPECIFICATIONS 7
2.3 GENERAL INSTRUCTIONS 7
2.4 GENERAL INFORMATION 8
2.4.1 FUEL 8
2.4.2 PELLET SPECIFICATIONS 9
2.4.3 CORN SPECIFICATIONS 9
2.4.4 SAFETY FEATURES 10
2.4.5 EPA COMPLIANCE 10
2.5 RATING PLATE INFORMATION 10
3.0 INSTALLATION PLANNING 11
3.1 INSTALLATION OPTIONS 11
3.2 APPLIANCE PLACEMENT 11
3.3 LEVELLING THE APPLIANCE 11
3.4 MINIMUM CLEARANCE TO COMBUSTIBLES 12
3.4.1 STRAIGHT INSTALLATION 12
3.4.2 CORNER INSTALLATION 12
3.5 FLOOR PROTECTION REQUIREMENTS INSTALLATION 13
3.6 OUTSIDE AIR 13
3.7 MOBILE HOME 13
4.0 VENTING 14
4.1 TYPE OF VENT 14
4.2 PELLET VENT INSTALLATION 14
4.3 VENTING THE PELLET APPLIANCE 14
4.4 PELLET VENT TERMINATION 15
4.5 VENT TERMINAL CLEARANCES 15
4.6 STOVE VENTING INSTALLATION EXAMPLES 16
4.6.1 HORIZONTAL TERMINATION (THROUGH WALL) 16
4.6.2 VERTICAL RISE HORIZONTAL TERMINATION (THROUGH WALL) 16
4.6.3 VERTICAL TERMINATION 17
4.6.4 CLASS A CHIMNEY RETROFIT 17
4.6.5 HEARTH MOUNT INSTALLATION 18
4.7 INSERT VENTING INSTALLATION EXAMPLES 19
4.7.1 TYPICAL EXISTING MASONRY INSTALLATION 19
4.7.2 FACTORY BUILT FIREPLACE 20
5.0 FRAMING (INSERT ONLY) 21
5.1 INSTALLATION INTO A COMBUSTIBLE ENCLOSURE 22
5.2 MINIMUM ENCLOSURE CLEARANCES 23
5.3 MINIMUM CLEARANCE TO COMBUSTIBLES 23
5.4 INSERT MINIMUM MANTEL CLEARANCES 24
5.5 MINIMUM STOVE ALCOVE INSTALLATION REQUIREMENTS 24
6.0 FINISHING 25
6.1 VIEWING DOOR INSTALLATION 25
6.2 DOOR HANDLE INSTALLATION 26
6.3 DECORATIVE INSET 26
6.4 FLASHING INSTALLATION 27
7.0 WIRING DIAGRAM 28
8.0 OPERATING INSTRUCTIONS 29
8.1 PROPER PELLET LOADING 29
8.2 PRE-START CHECK 29
8.3 MANUAL APPLIANCE LIGHTING 29
8.4 LIGHTING INSTRUCTIONS 30
8.5 REMOTE CONTROL 30
8.6 CONTROL ADJUSTMENT 31
8.7 THERMOSTAT INSTALLATION 32
8.8 SHUTDOWN INSTRUCTIONS 32
9.0 NORMAL OPERATING SOUNDS 32
10.0 MAINTENANCE 33
10.1 DAILY MAINTENANCE 33
10.1.1 ASH DISPOSAL 33
10.1.2 BURN POT INSPECTION 33
10.1.3 CARE OF GLASS 33
10.1.4 HEAT EXCHANGER TUBES CLEANING 34
10.1.5 PELLET PILE UP MAINTENANCE 34

W415-1477 / A / 10.19.16
3
EN
1.0 INSTALLATION OVERVIEW
Door, see “FINISHING - INSTALLING
THE VIEWING DOOR” section.
Venting, see “GENERAL VENTING”
and “INSTALLATION” sections.
Floor, see “INSTALLATION PLANNING -
FLOOR PROTECTION REQUIRE-
MENTS” section.
See “OUTSIDE AIR”
section.
Handle, see “DOOR
HANDLE INSTALLATION”
section.
Rating plate, see
“RATING PLATE
INFORMATION”
section.
1.1 STOVE
10.1.6 BURN POT CLEANING 35
10.2 BI-WEEKLY (OR EVERY 10 BAGS OF PELLETS) 35
10.2.1 VACUUM FIREBOX 35
10.3 SEMI-ANNUALLY (OR EVERY TON OF PELLET) 36
10.3.1 HOPPER CLEANING 36
10.3.2 SOOT AND FLY ASH FORMATION 36
10.3.3 VERTICAL EXHAUST DUCT CLEANING 36
10.3.4 EXHAUST BLOWER CLEANING 37
10.3.5 SEAL CHECK 37
10.3.6 VENT CLEANING 38
10.4 JAMMED AUGER 38
11.0 REPLACEMENT PARTS 39
12.0 TROUBLESHOOTING 41
13.0 WARRANTY 44
14.0 SERVICE HISTORY 45
15.0 NOTES 46

W415-1477 / A / 10.19.16
4
EN
1.2 INSERT
Door, see “FINISHING -
INSTALLING THE VIEW-
ING DOOR” section.
Venting, see “VENTING” and
“INSTALLATION” sections.
Handle, see “DOOR
HANDLE INSTALLATION”
section.
Rating plate, see
“RATING PLATE
INFORMATION”
section.
Flashing, see “FLASHING
INSTALLATION” section.

W415-1477 / A / 10.19.16
5
EN
2.0 INTRODUCTION
3.8C
!
WARNING
• THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED.
• Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to
operating instructions could cause fire or injury. Contact the local building or fire authority and follow their guidelines. Notify
your insurance company of this appliance as well.
• Never try to repair or replace any part of the appliance unless instructions are given in this manual. All other work should be
done by a trained technician.
• Risk of burns. The appliance should be turned off and cooled before servicing.
• Do not operate without fully assembling all components.
• Do not install damaged, incomplete or substitute components.
• Risk of cuts and abrasions. Wear protective gloves and safety glasses during installation. Sheet metal edges may be sharp.
• Children and adults should be alerted to the hazards of high surface temperature and should stay away to avoid burns or
clothing ignition. Toddlers, young children and others may be susceptible to accidental contact burns. Aphysical barrier is
recommended if there are at risk individuals in the house. To restrict access to an appliance or stove, install an adjustable
safety gate to keep toddlers, young children and other at risk individuals out of the room and away from hot surfaces.
• Clothing or other flammable material should not be placed on or near the appliance.
• Due to high temperatures, the appliance should be located out of traffic and away from furniture and draperies.
• Ensure you have incorporated adequate safety measure to protect infants/toddlers from touching hot surfaces.
• Even after the appliance is out, the glass and/or screen will remain hot for an extended period of time.
• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children from hot surfaces.
These screens and guards must be fastened to the floor.
• Any safety screen or guard removed for servicing must be replaced prior to operating the appliance.
• It is imperative that the control compartments, burners and circulating blower and its passageway in the appliance and venting
system are kept clean. The appliance and its venting system should be inspected before use and at least annually by a
qualified service person. More frequent cleaning may be required due to excessive lint from carpeting, bedding material, etc.
The appliance area must be kept clear and free from combustible materials, gasoline and other flammable vapors and liquids.
• Under no circumstances should this appliance be modified.
• Do not use this appliance if any part has been under water. Immediately call a qualified service technician to inspect the
appliance and to replace any part of the control system which has been under water.
• Do not operate the appliance with the glass door removed, cracked or broken. Replacement of the glass should be done by a
licensed or qualified service person. The viewing door and ashpan must be closed and latched during operation.
• Do not strike or slam shut the appliance glass door.
• Only doors / optional fronts certified with the unit are to be installed on the appliance.
• Keep the packaging material out of reach of children and dispose of the material in a safe manner. As with all plastic bags,
these are not toys and should be kept away from children and infants.
• If the appliance is not properly installed, a house fire may result. Do not expose the appliance to the elements (ex. rain, etc.)
and keep the appliance dry at all times. Wet insulation will produce an odour when the appliance is used.
• The chimney must be sound and free of cracks. Clean your chimney a minimum of twice a year and as required.
• The heater is designed and approved for pelletized wood fuel only. Any other type of fuel burned in this heater will void the
warranty and safety listing. D
o not burn trash or garbage, lawn clippings / waste, rubber, waste petroleum products, paints
or paint thinners / solvents, plastic, materials containing asbestos, construction debris, railroad ties or treated wood, manure
or animal remains, salt water driftwood or salted materials, unseasoned wood, coloured paper, cardboard, plywood or
particleboard.
• Do not start a fire with chemicals or fluids such as gasoline, engine oil, etc.
• Ashes must be disposed in a metal container with a tight lid and placed on a non-combustible surface well away from the
home or structure.
• Your appliance requires periodic maintenance and cleaning. Failure to maintain your appliance may lead to smoke spillage in
your home.
• The exhaust system must be completely straight and properly installed. It is recommended that the pellet vent joints be sealed
with a minimum 500°F (260°C) silicone sealant. Install according to the vent manufacturer’s instructions.
• Ensure clearances to combustibles are maintained when building a mantel or shelves above the appliance. Elevated
temperatures on the wall or in the air above the appliance can cause melting, discolouration or damage to decorations, a T.V.
or other electronic components.
• During a power outage this appliance will not operate. If a power outage does occur, check the appliance for smoke spillage
and open a window if any smoke spills into the room.
• Keep foreign objects out of the hopper.
• Disconnect the power cord before performing any maintenance. NOTE: Turning the pellet feed to “OFF” does not
disconnect all power to the heater.
• Do not throw this manual away. This manual has important operating and maintenance instructions that you will need at a
later time. Always follow the instructions in this manual.
• At no point should you use firewood or firelogs in this appliance. The use of which could cause a house fire.
• This appliance must be connected to a standard 115 V, 50Hz grounded electrical outlet. Do not use an adapter plug or sever
the grounding prong. Do not route the electrical cord underneath, in front of, or over the appliance.
• When installed in a mobile home, the appliance must be bolted to the floor, have outside air, and NOT BE INSTALLED IN THE
BEDROOM (per H.U.D. requirements). Check with local building officials.

W415-1477 / A / 10.19.16
6
EN
2.1 DIMENSIONS
2.1.1 STOVE
2.1.2 INSERT (COMPLETE WITH FLASHING)
* A and B are adjustable, see "SPECIFICATIONS" section.
A *
B *
30 5/16"
770mm
21 1/4" 540mm
19 11/16" 500mm 23 1/2" 597mm
24 1/4" 616mm
25 7/8" 657mm
17"
432mm
11 5/8"
295mm
CENTRE OF
AIR INTAKE
CENTRE OF
EXHAUST
38 3/8" 975mm
29 3/8"
746mm 20 13/16"
529mm
7 1/8"
181mm
CENTRE OF
EXHAUST
1 7/8"
47mm
CENTRE OF
AIR INTAKE
8 1/2" 220mm
CENTRE OF AIR INTAKE
5 5/8" 143mm
CENTRE OF EXHAUST 1 1/4"
32mm
38 3/8" 975mm
21 1/4 540mm

W415-1477 / A / 10.19.16
7
EN
2.2 SPECIFICATIONS
ALL WIRING SHOULD BE DONE BY A QUALIFIED ELECTRICIAN AND SHALL BE IN COMPLIANCE
WITH LOCAL CODES. IN THE ABSENCE OF LOCAL CODES, USE THE CURRENT CSA C22.1
CANADIAN ELECTRIC CODE (IN CANADA) OR THE ANSI/NFPA NO. 70 NATIONAL ELECTRIC CODE
IN THE UNITED STATES.
DO NOT CONNECT THIS APPLIANCE TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE. DO
NOT CONNECT TO ANY AIR DISTRIBUTION DUCT OR SYSTEM.
PROVIDE ADEQUATE CLEARANCE FOR SERVICING AND OPERATING THE APPLIANCE.
PROVIDE ADEQUATE VENTILATION.
NEVER OBSTRUCT THE FRONT OPENING OF THE APPLIANCE.
OBJECTS PLACED IN FRONT OF THE APPLIANCE MUST BE KEPT A MINIMUM OF 48” (1219.2mm)
FROM THE FRONT FACE OF THE APPLIANCE.
!
WARNING
AB
Adjustable Flashing 11" (279mm) to
13" (330mm) 10 1/2" (267mm) to 12 1/2" (317mm)
Electrical Rating 115 Volts, 3.6 Amps, 60Hz
Watts During Ignition Sequence 400 (approximately)
Watts During Operation 180 (approximately)
Weight Stove 158 lbs (1003kg) / Insert 140 lbs (889kg)
Exhaust Collar 3" (76mm)
Intake Collar 2" (51mm)
Hopper Capacity 45 Pounds (20kg)
Burn Rate 1.5 to 4.5 (Pounds Per Hour) / 0.7 to 2 (Kilograms Per Hour)
BTU/Hr 12750 to 38250
Approximate Maximum Heating Capacity (in square feet)* 800 to 2000 Sq. Feet / 74 to 186 Sq. Meters
Maximum Burn Time on Low Burn** 30 Hours
* Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside temperature. It is
also affected by the fuel size, quality, and moisture level.
** Small pellets will increase or decrease the stated burn rates and burn times. Differences of plus or minus 20%
depending on fuel quality may occur.
2.3 GENERAL INSTRUCTIONS

W415-1477 / A / 10.19.16
8
EN
2.4 GENERAL INFORMATION
Thank you for purchasing a Wolf Steel Ltd. PelletAppliance. This appliance is designed for use with Pelletized
Wood Only.
Please read this entire manual before installation and use of this pellet fuel-burning room appliance. Failure to
follow these instructions could result in property damage, bodily injury or even death.
Keep this manual handy for future reference.
This Pellet Appliance, when installed, must be electrically grounded in accordance with the local codes, or in
the absence of local codes, use the current CSA C22.1 Canadian Electrical Code in Canada or the ANSI/NFPA
70 National Electrical Code in the United States.
This appliance will not operate using natural draft or without a power source for the blower systems and fuel
feed system.
These appliances are equipped with levelling screws that penetrate the front corners of the firebox. If these
screws are missing it will have a negative influence on the performance of this appliance. Ensure that the
levelling screws are tightened into position.
The protective wrap on plated parts is best removed when the assembly is at room temperature but this can be
improved if the assembly is warmed, using a hair dryer or similar heat source.
If the appliance is installed directly on carpeting, vinyl tile or other combustible material other than wood
flooring, the appliance shall be installed on a non-combustible hearth pad extending the full width and depth.
4.5B
2.4.1 FUEL
This appliance is designed to burn wood pellet fuel. In addition, a corn/wood pellet mixture with a maximum
50% corn can be burned. Burning any other fuel, that is not approved for use with this appliance, will void the
warranty.
Important: The corn/wood pellet mixture needs to be mixed evenly before being put into the hopper.

W415-1477 / A / 10.19.16
9
EN
If the fuel does not comply to
this standard the appliance
may not operate as designed.
We recommend the use of
premium grade (1% ash
content) for longer appliance
life and less frequent cleaning.
Inorganic Fines (fine
particles) 1% maximum through a 1/8" (3.2mm) screen
Bulk Density 38 pound per cubic foot minimum
Size 1/4" (6.4mm) to 5/16" (8mm) diameter, 1/2" - 1 1/2" (13mm
- 38mm) long maximum
Ash Content No more than 2%
Moisture Content 8% maximum
Chlorides 300 parts per million by weight
Trace Metals Less than 100mg/kg
Heat Content Approximately 8200 BTU/Hr per pound minimum
Construction Waste Not to contain any waste materials
2.4.2 PELLET SPECIFICATIONS
P.F.I. PELLET STANDARDS:
Pellet quality is important, please read the following:
Your Wolf Steel Ltd. Pellet Appliance has been designed to burn premium hard or soft wood pellets only. Do
not use any other type of fuel such as fire logs or fire starting pellets, as this will void the warranties stated in
this manual.
The performance and heat output of the pellet appliance is directly related to the quality and moisture of the
pellets. Store pellets in a cool dry area to prevent moisture absorption. 64.1
!
WARNING
IT IS IMPORTANT TO SELECT AND USE ONLY PELLETS THAT ARE DRY AND FREE OF DIRT
OR ANY IMPURITIES SUCH AS HIGH SALT CONTENT. DIRTY FUEL WILL ADVERSELY AFFECT
THE OPERATION AND PERFORMANCE OF THE APPLIANCE AND WILL VOID THE WARRANTY.
THE PELLET FUEL INSTITUTE (P.F.I.) HAS ESTABLISHED STANDARDS FOR WOOD PELLET
MANUFACTURERS. WE RECOMMEND THE USE OF PELLETS THAT MEET OR EXCEED THESE
STANDARDS. ASK YOUR DEALER FOR A RECOMMENDED PELLET TYPE.
2.4.3 CORN SPECIFICATIONS
Use only clean-shelled corn with a moisture content less than 15% and approximate fuel value of 7,000 BTU/
lb (16,200 kJ/kg). Do not attempt to burn corn with higher moisture content or burn lesser grade fuels. Do not
burn other types of agricultural pellets or by-products (alfalfa, cherry pits, olive pits, nut shells, etc.) as they
are not permitted to be burned in this appliance.
Corn must be clean and free of debris. Never burn corn right from the field. Damage caused by dirty corn is
not covered by the Lifetime Limited Warranty. Ask for screened corn only. Stalk parts, excessive fines and
cob remnants will clog the air flow holes in the burn plate. Check the corn for foreign objects.
Use only a maximum 50% corn to pellet mixture.

W415-1477 / A / 10.19.16
10
EN
2.4.4 SAFETY FEATURES
2.4.5 EPA COMPLIANCE
We suggest that our woodburning hearth products
be installed and serviced by professionals who are
certified in the U.S. by the National Fireplace
Institute® (NFI) as NFI Woodburning Specialists or
who are certified in Canada by
Wood Energy Technical
Training (WETT).
HIGH LIMIT SWITCH: Your appliance is equipped with a high limit switch. In the event that the temperature
of the appliance approaches an unsafe operating temperature, this switch will shut down the pellet feed,
which will eventually shut down the unit. If this happens, it is important to find out why the unit overheated.
Contact your local dealer.
LOW LIMIT SWITCH: This switch will automatically shut down the appliance if the fire goes out or fails to
light within 15 minutes.
HOPPER DOOR INTERLOCK: Your appliance is equipped with a micro switch in the hopper assembly that
shuts-off the auger when the hopper door is opened. Closing the door switches the auger back on, allowing
pellets to feed again.
VACUUM SWITCH: This switch will sense lack of air flow through the appliance and shut down the pellet
feed. This lack of flow could be caused by a blocked vent.
POWER FAILURE: In the event of a power failure, the appliance will shut down. Once power is restored, the
appliance will re-start, unless the convection air temperature has gone above the high limit switch setting. If
this happens, contact your local dealer.
2.5 RATING PLATE INFORMATION
U.S. ENVIROMENTALPROTECTION AGENCY Certified to comply with July 1992 Particulate Emission Standards
MODEL TPS35 LISTED PELLET FUELBURNING ROOM HEATER TESTED TO:ASTM E 1509, ULC/ORD C1482-M90, ULC S627
TPS35
Straight Installation Corner Installation
MINIMUM CLEARANCES TO COMBUSTIBLE
SIDE 6” CORNER 2” MIN 1.5 LB/HR
MAX 4.5 LB/HR
Floor
Protection
Through Wall Installation
3”
6”
- INSTALLAND USE ONLYIN ACCORDANCE WITH THE
MANUFACTURER’S INSTRUCTIONSAND LOCAL
BUILDING CODES.
- MINIMUM CEILING HEIGHT: 7FT (2.13M) HEARTH
Floor Protection
6”
2”
2”
Tee
WOLFSTEELLTD.
24 NAPOLEON ROAD, BARRIE, ON, L4M 0G8 CANADA
ATTENTION : L'APPAREILEST CHAUD LORSQU’IL FONCTIONNE. NE PASTOUCHER. TENIR
LES ENFANTS, LES VÊTEMENTS ET LES MEUBLES À L’ÉCART. LE CONTACT PEUT CAUSER
DES BRÛLEURS DE PEAU.
Installation de coin
DÉGAGEMENTS MINIMAUX AUX MATÉRIAUX COMBUSTIBLES
CÔTÉ 6” COIN 2”
ARRIÈRE 3” PLAFOND 48”
IDÉBIT D’ALIMENTATION
MIN. 1.5 LB/H
MAX. 4.5 LB/H
3” 2”
Tee
6”
Floor
Protection
6”
Protection de
plancher
Protection de
plancher
Évents à Travers le Mur
Coude
45°
Protection de
plancher
Évents Verticaux Intérieurst
Protection de
plancher
Évents Verticaux Intérieurs
Té
3”
6”
45°
2”
2”
6”
2”
2”
3” 2”
6”
6”
6” 6”
9700539 (WSL)
4001657 (NGZ)
4001658 (NAC)
4001659 (WUSA)
U.S. Environmental Protection Agency:
U.S. Environmental Protection Agency:
Certifié conforme à la norme d’ émanation de particles de
Certifié conforme à la norme d’ émanation de particles de
2015.Non approuvé pour la vente après le 15 mai, 2020
2015.Non approuvé pour la vente après le 15 mai, 2020
: 40 CFR Part 60, Subpart AAA.
: 40 CFR Part 60, Subpart AAA.
3.3 Grammes par heure.
3.3 Grammes par heure.
Certified to comply with 2015 particulate emissions standards.
to comply with 2015 particulate emissions standards.
40 CFR Part 60, Subpart AAA.
0, Subpart AAA.
3.3 Grams Per Hour
3.3 Grams Per Hour
MANUFACTURE DATE: / DATE DE FABRICATION:
YEAR: 2016 2017 2018
MONTH: 2019 2020
243658710912111
HOT WHILE IN OPERATION. DO NOT TOUCH. KEEP CHILDREN,CLOTHINGAND FURNITURE AWAY.
- KEEP VIEWING ANDASH REMOVAL DOORSTIGHTLY CLOSED DURING OPERATION.
- CONTACT LOCALBUILDING AND FIRE OFFICIALS ABOUTRESTRICTIONS AND
INSTALLATION INSPECTION INYOUR LOCAL AREA.
- SUITABLE FOR USE IN MOBILE HOMES WHEN USED WITH OUTSIDEAIR
INSTALLATION KIT.
- REFER TO INSTALLATION INSTRUCTIONS OR LOCAL BUILDING CODES WHEN
PASSING EXHAUST SYSTEM THROUGH COMBUSTIBLE WALLOR CEILING.
-FUEL: FOR USE WITH PELLET FUEL ONLY.
- INSTALLER ET UTILISER CONFORMÉMENTAUX INSTRUCTIONS DU FABRICANT ETAUX CODES
DU BÂTIMENT LOCAUX.
- HAUTEUR DE PLAFOND MINIMALE 7 PI. (2,13 m)
BASE DE PROTECTION/PROTECTION DE PLANCHER COMBUSTIBLE : SI INSTALLÉ SUR UN
PLANCHER COMBUSTIBLE, L’APPAREIL DOIT ÊTRE PLACÉ SUR UNE PLAQUE PROTECTRICE
INCOMBUSTIBLE S’ÉTENDANT SUR 6” À L’AVANT.
- NE PAS RACCORDER CETAPPAREILÀ LA CHEMINÉE D’UN AUTREAPPAREIL.
- REMPLACER LA VITRE PAR UNE VITRE EN CÉRAMIQUE SEULEMENT.
DANGER : RISQUE DE SECOUSSE ÉLECTRIQUE. DÉBRANCHER L’ALIMENTATION ÉLECTRIQUE
AVANT DE PROCÉDER À L’ENTRETIEN.
- GARDER LA PORTE VITRÉE ET LAPORTE DU TIROIR À CENDRES BIEN FERMÉES DURANT LE
FONCTIONNEMENT.
- CONTACTER LESAUTORITÉS LOCALES DU BÂTIMENT ET DU SERVICE DES INCENDIESAU
SUJET DES RESTRICTIONS ET DES INSPECTIONS D’INSTALLATION DANS VOTRE RÉGION.
- PEUT ÊTRE INSTALLÉ DANS UNE MAISON MOBILE SI INSTALLÉ CONJOINTEMENT AVEC UNE
PRISE D’AIR EXTÉRIEUR.
- SE RÉFÉRER AUX INSTRUCTIONS D’INSTALLATION OU AUX CODES DU BÂTIMENT LOCAUX
LORSQUE LE SYSTÈME D’ÉVACUATION TRAVERSE UN MUR OU UN PLAFOND COMBUSTIBLES.
-COMBUSTIBLE : POUR USAGE AVEC DES GRANULES SEULEMENT.
W385-2035 / A
Interior Vertical Vent
ELECTRICAL RATING
120V 3.6A 60HZ
Through Wall Vents Interior Vertical Vent
CARACTÉRISTIQUES ÉLECTRIQUES
120 V 60 Hz
Installations à Travers le Mur
Installation en Coin
Protection de
plancher
EXTENSION / COMBUSTIBLE FLOOR PROTECTION:
IF INSTALLED ONA COMBUSTIBLE FLOOR, UNIT MUST
BE PLACED ON ANON-COMBUSTIBLE FLOOR PROTECTOR
EXTENDING 6” IN FRONT.
- DO NOT CONNECT THIS UNIT TO ACHIMNEY FLUE
SERVING ANOTHER APPLIANCE.
- REPLACE GLASS WITH ONLY CERAMIC GLASS.
DANGER: RISK OF ELECTRICAL SHOCK. DISCONNECT
POWER BEFORE SERVICING UNIT.
THIS WOOD APPLIANCE NEEDS PERIODIC INSPECTIONAND REPAIR FOR PROPER OPERATION.
CONSULTTHE OWNER’S MANUAL FOR FURTHER INFORMATION. ITIS AGAINST UNITED STATE
FEDERAL REGULATIONS TO OPERATE THIS WOOD APPLIANCE IN A MANNER INCONSISTENT
WITH THE OPERATING INSTRUCTIONS INTHE OWNER’S MANUAL.
CET APPAREIL AU BOIS DOIT FAIRE L’OBJECT D’UNE INSPECTION ET D’UN ENTRETIEN
PÉRIODIQUES POUR UN FONCTIONNEMENT ADÉQUAT. CONSULTEZ LE MANUEL
D’INSTRUCTIONS POUR PLUS D’INFORMATION. LES RÈGLEMENTS FÉDÉRAUX DE L’ÉTATS-UNIS
INTERDISENT D’UTILISER CET APPAREIL DE CHAUFFAGE D’UNE MANIÈREALLANT À
L’ENCONTRE DES INSTRUCTIONS DE FONCTIONNEMENT CONTENUES DANS CE MANUEL.
For rating plate location, see
“INSTALLATION OVERVIEW”
section.
This illustration is for reference
only. Refer to the rating plate
on the appliance for accurate
information.
NOTE: The rating plate must
remain with the appliance
at all times. It must not be
removed.
SAMPLE
SAMPLE
VIROMENTALPROTECTION AGENCY Certified to comply withROMENTALPROTECTION AGENCY Certified to comply with
1482-M90, ULC S6482-M90, U
PLE
CorneCo
S TO COMBUSTIBLEIBLE
CORNER 2”CORNE
M
IN 1.5 LB
/
H
RMIN 1.5 LB/HR
M
AX 4.
5
LB
/
HR
MAX 4.5 LB/HR
on
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
D.D.
OAD, BARRIE, ON, L4M 0G8 CANADAOAD, BARRIE, ON, L4M 0G8 CANADA
MP
DÉGAGEMENTS MINIMDÉGAGEMENT
CÔTÉ 6”CÔTÉ 6”
ARRIÈRE 3”ARRIÈRE 3”
PL
LE
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
LE
LE
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
LE
LE
LE
LE
LE
LE
LE
LE
LE
LE
LE
LE
LE
LE
L
L
LE
L
L
L
E
E
L
L
L
L
L
L
L
L
L
LE
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
Fl
oor
P
r
o
t
ec
ti
on
LE
E
Protection dePtti d
plancherplancher
MP
MP
MP
MP
MP
MP
MP
3”
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
MP
P
P
P
P
P
P
P
P
P
P
P
3”
P
P
P
2
”
P
P
P
P
P
CertifieCertif
40 CFR PartCFR Pa
TURE DATE: / DATE DE FABRICATION:TE: / DATE DE FABRICATION:
SA
2
0
1
7
SA
2
0
1
8201
A
2
0
1
92019
A
22
22
33
4
66
8
S
S
S
SA
SA
SA
SA
SA
SA
SA
SA
A
A
A
A
A
A
HOT WHILE IN OPERATION. DO NOT TOUCH. KEEHOT WHILE IN OPERATION. DO NOT TOUCH. KE
RICECE
ON ÉLECTRIQUEE
RMÉES DURANT LEMÉE
CE DES INCENDIES AUE DES INCENDIES A
N DANS VOTRE RÉGION.DANS VOTRE RÉGION.
CONJOINTEMENT AVEC UNENJOINTEMENT AVEC UNE
X CODES DU BÂTIMENT LOCAUXBÂTIMENT LOCAUX
MUR OU UN PLAFOND COMBUSTIBLES.ND COMBUSTIBLES.
SEULEMENT.
I
nter
i
or
V
ert
i
ca
l
V
en
tInterior
Through Wall Ventsgh Wall Ven
Installations à Travers leInstallations à Travers
Protection deProtection de
P
r
otectio
n
deProtection d
Protection d
plancherplancher
p
l
anc
h
e
rplancher
plancher
E INSPECTION ET D’UN ENTRETIENINSPECTION ET D’UN ENTRETIEN
ÉQUAT. CONSULTEZ LE MANUELQUAT. CONSU
N. LES RÈGLEMENTS FÉDÉRAUX DE L’ÉTATS-UNISLES RÈGLEMENTS FÉDÉRAUX DE L’ÉTATS-UNIS
CHAUFFAGE D’UNE MANIÈREALLANT ÀAUFFAGE D’UNE MANIÈR
NCTIONNEMENT CONTENUES DANS CE MANUEL.NEMENT CONTENUES DANS CE MANUEL.

W415-1477 / A / 10.19.16
11
EN
3.0 INSTALLATION PLANNING
Check with local building officials for any permits required for installation of this pellet appliance and notify your
insurance company before proceeding with installation.
Before installing we recommend placing the appliance outside and load 5 lbs (2.3k) of pellets inside the hop-
per. Plug the appliance in and let it run on HIGH until the pellets run out. This will cure the paint and burn off
most of the oils on the steel, thereby minimizing any smell inside the home. 68.1A
READ ENTIRE MANUAL BEFORE YOU INSTALL OR USE THIS APPLIANCE. FAILURE TO FOLLOW THE
INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
USE ONLY WOLF STEEL APPROVED OPTIONAL ACCESSORIES AND REPLACEMENT PARTS WITH
THIS APPLIANCE. USING NON-LISTED ACCESSORIES AND REPLACEMENT PARTS (BLOWERS,
DOORS, LOUVRES, TRIMS, GAS COMPONENTS, VENT COMPONENTS, ETC.) COULD RESULT IN A
SAFETY HAZARD AND WILL VOID THE LIMITED LIFETIME WARRANTY.
!
WARNING
3.1 INSTALLATION OPTIONS
Stove model:
To install in a Residential or Mobile Home see "MOBILE HOME INSTALLATION" section. For alcove
installations see "ALCOVE INSTALLATION REQUIREMENTS" section. For horizontal vent or vertical vent see
"VENTING" section. Outside air, see "OUTSIDE AIR" section.
Insert model:
To install as an insert into an existing masonry appliance or factory built appliance see "VENTING" section. To
install into a combustible enclosure, see "INSTALLATION INTO A COMBUSTIBLE ENCLOSURE" section.
Have an authorized dealer install the appliance. If you install the appliance yourself, have your dealer review
your installation plans and/or installation.
Draw out a detailed plan of the installation including dimensions and verify the dimensions with the
requirements listed in this manual.
You may wish to adjust the appliance position slightly to ensure the vent does not intersect with a framing
member. Appliance must be positioned so that no combustibles are within, or can swing within (e.g. drapes,
doors), 4 feet (1.2m) of the front of the appliance. 67.1B
3.2 APPLIANCE PLACEMENT
3.3 LEVELLING THE APPLIANCE
Move the appliance close to its final position. This appliance is equipped with levelling screws located on the
base. Level using the levelling screws. Levelling the appliance will eliminate rocking or excessive noise when
the fan is in operation. Once the appliance is level, move it partially into place to allow for all connections to be
made. It is not practical to level the appliance once it has been installed. Determine the required depth prior to
installing the appliance and adjust the levelling screws accordingly. 67.2

W415-1477 / A / 10.19.16
12
EN !
WARNING
2” (51mm)
Floor
Protection
6”
(152mm)
6”
(152mm)
6”
(152mm)
3”(76mm)
Floor
Protection
3”(76mm)
6”
(152mm)
6”
(152mm)
6”
(152mm)
Floor Protection
45°
2”
(51mm)
2” (51mm)
Floor Protection
45° 45°
Elbow
2” (51mm)
2”
(51mm)
3.4 MINIMUM CLEARANCE TO COMBUSTIBLES
Through the Wall Installations complete
with outside air
Interior Vertical Vents
3.4.1 STRAIGHT INSTALLATION
DO NOT INSTALL INTO ANY AREA HAVING LESS THAN 48" (1219mm) (CEILING TO APPLIANCE
BOTTOM, EXCLUDING HEARTH HEIGHT).
Through the Wall Vents complete with outside air Interior Vertical Vents
NOTE: If interior vertical pellet vent is used, the clearance to the back wall is determined by the
upward-turning elbow or "Tee". It will vary in depth depending on the brand of pellet vent used [it is
approximately 5" (127mm)]. Before placing the appliance, connect the elbow or "Tee" and allow for the
minimum 3" (76mm) clearance to the combustible wall.
3.4.2 CORNER INSTALLATION

W415-1477 / A / 10.19.16
13
EN
3.5 FLOOR PROTECTION REQUIREMENTS INSTALLATION
29.4A
Installation into a manufactured home or mobile home should be installed in
accordance with the Manufactured Home Construction and Safety Standard,
Title 24 CFR, Part 3280, in the United States or the Mobile Home Standard,
CAN/CSA Z240 MH Series, in Canada.
The appliance must be grounded to the steel chassis of the mobile home
(Some states do not require this; check with your local building department).
!
WARNING
DO NOT INSTALL IN A SLEEPING ROOM.
THE STRUCTURAL INTEGRITY OF THE MANUFACTURED HOME FLOOR, WALL, AND CEILING ROOF
MUST BE MAINTAINED.
3.6 OUTSIDE AIR
Available from your Authorized Dealer (114KT)
Outside air must not be drawn from an enclosed space (garage, unventilated crawl space).
NOTE: Wolf Steel Ltd. strongly suggests using outside air for all residential installations, especially for
those that are energy efficient, air-tight homes.
Outside air supply must not be over 15' (4.6m) long.
Outside air vents must be made with 1 3/4" (45mm) diameter or larger metal or aluminum duct with a metal
screen attached to the end to keep out rodents (P.V.C. or other materials may not be used).
The outside air inlet must not be above or within 12" (305mm) of the chimney termination, must have a rain
cap or down-turned elbow to prevent the water from entering and be located so that it will not become
plugged by snow or other material.
Outside air is required for all combustible built-in enclosure installations.
STOVE
ILLUSTRATED
The appliance must be installed on a non-combustible floor protector extending the full depth of the
appliance and extending a minimum 6" (152mm) in front and on either side (minimum .018" thick - 26 gauge)
of the fuel loading and ash removal openings.
The floor protector must extend under and 2" (51mm) beyond each side and back of a "Tee" (if used).
NOTE: Floor protection is required for spark and ash shielding, but not for limiting floor temperatures
from the radiant heat of the appliance. The appliance was designed and safety tested so that without
any protection, the floor would not overheat.
Refer to local building codes for suitable floor protection materials.
3.7 MOBILE HOME

W415-1477 / A / 10.19.16
14
EN
4.0 VENTING
4.1 TYPE OF VENT
4.2 PELLET VENT INSTALLATION
4.3 VENTING THE PELLET APPLIANCE
Must be an approved 3" (76.2mm) or 4" (102mm) diameter Type "L" or "PL" vent, vented to the outside or
connect the vent to a factory built type "A" chimney using an adaptor; and/or stainless steel chimney liner for
masonry appliance installations. Use 4" (102mm) diameter vent if vent or liner height is over 15' (4.6m) or if
installation is over 4,000' (1219m) above sea level.
Use an approved wall thimble when passing the vent through walls and a ceiling support / firestop spacer
when passing the vent through ceilings (maintain a 3" (76mm) clearance to any combustibles).
7.5D
The vent must have a support bracket every 5’ (1.5m)when on
the exterior wall. To achieve optimum performance, keep vent
runs as short as possible, especially on horizontal installations.
MAXIMUM VENTING: Maximum venting height is 33’ (10.1m)
Maximum horizontal without vertical rise is 5’ (1.5m) straight
off the back of the appliance. Use no more than 180° of
elbows (two 90° elbows, or two 45° elbows and one 90°
elbow, etc), excluding the tee and the termination.
VENT INSTALLATION: Termination must exhaust above
the air inlet elevation, and parallel or above the exhaust
output of the pellet appliance. It is recommended that at
least 3’ (0.9m) of vertical pipe be installed to create some
natural draft. This is to help prevent the possibility of smoke
or odour entering the home during the appliance shut down
or in the event of a power outage. Horizontal sections must
have a 1/4” (6.4mm) rise every 12” (304.8mm) of travel if
longer than 3’ (0.9m).
The pellet vent connections must be sealed with HI-Temp
RTV Silicone and screwed together with at least 3 3/8”
(85.7mm) long stainless steel screws. Seal each vent
section by injecting a liberal amount of 500°F (260°C) RTV
silicone sealant into the gap. We recommend sealing the
outside of the vent connections to permit easier access
when servicing.
5’ (1.5m)
10’ (3.1m)
15’ (4.6m)
20’ (6.1m)
33’ (10.1m)
30’ (9.1m)
25’ (7.6m)
0
5’
(1.5m) 10’ (3.1m)
0
Use 4”
(101.6mm)
diameter “L”
vent if venting
in this shaded
region.
Use 3” (76.2mm)
or 4” (101.6mm)
diameter “L”
vent if venting
in this shaded
region.
!
WARNING
PELLET VENT MUST MAINTAIN A MINIMUM 3" (76.2mm) CLEARANCE TO ANY COMBUSTIBLE (INSTALL
VENT AT CLEARANCES SPECIFIED BY THE VENT MANUFACTURER, CHIMNEY LINER EXCLUDED).
DO NOT CONNECT THE PELLET VENT TO A VENT OR CHIMNEY SERVING ANY OTHER APPLIANCE OR
HEATER.
DO NOT INSTALL A FLUE DAMPER IN THE EXHAUST VENTING SYSTEM OF THIS UNIT.

W415-1477 / A / 10.19.16
15
EN
4.4 PELLET VENT TERMINATION
The vent termination must have an approved cap (to prevent water from entering) or a 45° downturn.
If the termination is located on a windy side of the house, a shield is recommended to prevent soot from
building up on the side of the house.
Horizontal terminations must protrude 12" (305mm) from the wall, vertical terminations require a minimum 24"
(610mm) above the highest point that it penetrates through the roof.
Depending on pellet quality, vent configuration and air settings, black soot may occur on the terminal wall.
4.5 VENT TERMINAL CLEARANCES
CLEARANCES
A12” (30.5cm) Clearance above grade, veranda porch, deck or balcony. (Including vegetation and mulch)
B9” (22.9cm)* Clearance beside or below any windows or doors that open.
12” (30.5cm)* Clearance above any window or door that opens.
C18”
(45.7cm) Vertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (0.6m) from the center line of the terminal.
D0” (0mm) Clearance to an outside corner wall.
E3” (75mm) Clearance to an inside combustible corner wall or protruding combustible obstructions (vent chase, etc.)
F9” (22.9cm) Clearance to a non-mechanical air supply inlet to the building or a combustion air inlet to any other appliance.
G3’ (0.9m) Clearance to a mechanical air supply inlet.
H7’ (2.1m) ** Clearance above a paved sidewalk or paved driveway located on public property.
I12” (30.5cm)** Clearance under a veranda, porch, deck or balcony.
J24” (61cm) Clearance above the roof.
K2’ (0.6m) Clearance from an adjacent wall including neighbouring buildings.
L
3’ (0.9m) within a
height of 15 feet
(13.7m) above the
meter / regulator
assembly
Clearance to each side of center line extended above natural gas or propane meter / regulator assembly or
mechanical vent.
* Recommended to prevent condensation on windows and thermal breakage
** This is a recommended distance. For additional requirements check local codes.
A
J
D
K
I
H
E
C
B
G
F
E
B
L
12.7C
NOTE: Illustration dimensions are to the center of
the exhaust exit point of the vent.

W415-1477 / A / 10.19.16
16
EN
Floor
Protection
Minimum
Outside Air
(Recommended)
6”(152mm)
Minimum
3”(76mm)
Minimum
Wall
Thimble
Maximum
Wall Thimble
Outside Air
(Recommended)
Floor
Protection
6”(152mm)
Minimum
3”(76mm)
2”(51mm)
17”(432mm)
11 5/8”(295mm)
17”
(432mm)
11 5/8”(295mm)
12”(305mm)
5’(1.5m)
4.6 STOVE VENTING INSTALLATION EXAMPLES
4.6.1 HORIZONTAL TERMINATION (THROUGH WALL)
4.6.2 VERTICAL RISE HORIZONTAL TERMINATION (THROUGH WALL)

W415-1477 / A / 10.19.16
17
EN
Outside air (Recommended)
(Installation showing inlet of out-
side air in ventilated crawl space)
Ceiling Support Vent must maintain
3”(76mm) clearance to
combustibles.
Vertical Cap
Roof Flashing
Storm Collar
Floor Protection
3”(76mm)
2”(51mm)
24”(610mm)
4.6.3 VERTICAL TERMINATION
Class A Chimney
Ceiling Support
Outside air
(Recommended)
(Installation show-
ing inlet of outside
air in ventilated
crawl space)
Vent must maintain
3”(76mm) clearance to
combustibles.
Roof Flashing
Storm Collar
Floor Protection
Vertical Cap
3”(76mm)
2”(51mm)
4.6.4 CLASS A CHIMNEY RETROFIT

W415-1477 / A / 10.19.16
18
EN
Floor Protection
Clean-out
tee
Outside Air (Recommended)
Fl
oo
r Pr
o
t
ec
ti
on
e
nd
ed
)
o
ut
Outsid
e
Ai
r
(R
ec
om
me
Storm Collar
Vertical Cap
S
torm
C
ollar
Chimney Cap
Bring outside air to the stove
Pellet
Liner
Flue Cover
Pellet
Vent
6”(152mm)
MIN
4.6.5 HEARTH MOUNT INSTALLATION
For installation instructions See "TYPICAL EXISTING MASONRY" section.

W415-1477 / A / 10.19.16
19
EN
4.7 INSERT VENTING INSTALLATION EXAMPLES
4.7.1 TYPICAL EXISTING MASONRY INSTALLATION
!
WARNING
Prior to installation:
When installing the insert into a masonry fireplace, do not
remove any bricks or masonry. Do not weaken the structure,
or reduce the protection for combustible materials to less then
that required by the National Building Code. Bolted or screwed
together pieces (smoke shelf / deflectors) may be removed,
but must be able to be re-installed if the appliance is removed.
External trim pieces, which do not affect the operation of the
fireplace, may be removed provided they are available to be re-
installed in event the appliance is removed.
A warning label must be attached to the back wall of the fireplace
stating that “This fireplace has been altered to accommodate a
fireplace insert and must be re-inspected by a qualified person
prior to re-use as a fireplace”.
Non-combustible floor protection must cover the flooring
underneath, as well as extend a minimum of 6” (152.4mm) in
front and to both sides of the appliance.
Clean all ashes out of the inside of the fireplace. Make sure
that the chimney and fireplace are free of cracks, loose mortar,
creosote deposits, blockage or other signs of deterioration.
If necessary, have any repair work done by a qualified
professional before installing the appliance.
A. Remove the fireplace damper or fasten it permanently open.
B. Measure the throat of the fireplace and mark this shape on a piece of 24 (0.511mm) gauge sheet meta
l
(flue cover). Cut a hole sized for the pellet liner to lie directly below the fireplace flue opening. Allow 2”
(50.8mm) of material for a flange on all sides and cut to these measurements. Bend down the flanges.
If you have never done this before, it might be a good idea to make a cardboard pattern and test it first.
Fasten this flue cover in position as high as possible with two masonry screws per side through the
flanges into the fireplace.
C. If you plan on connecting outside air it is recommended to do so at this time.
D. Install floor protection if necessary.
E. Connect the pellet vent with a clean out tee to the back of the insert. Refer to manufacturer’s
installation instructions to see “REAR TO TOP VENT CONVERSION INSTRUCTIONS” section and th
e
“GENERAL VENTING” section.
F. Run a liner down the chimney and connect to tee.
G. Position the insert in it’s final location.
H. Pull the excess length of liner out through the top of the chimney. Trim the excess liner, install the cap
and cap the chimney.
DO NOT REMOVE BRICKS OR MORTAR FROM THE FIREPLACE.
Storm Collar
Vertical Cap
Outside Air
(Recommended)
o
rm
C
olla
r
S
t
o
rtical
Cap
Ver
Cover Plate
Flue
Cover
Pellet
Liner
62.3B

W415-1477 / A / 10.19.16
20
EN
4.7.2 FACTORY BUILT FIREPLACE
Prior to installation:
Do not weaken the structure or reduce the protection for
combustible materials to less then that required by the National
Building Code. Bolted or screwed together pieces (smoke shelf /
deflectors) may be removed, but must be able to be re-installed
if the appliance is removed.
External trim pieces, which do not affect the operation of the
fireplace, may be removed provided they are available to be re-
installed in event the appliance is removed.
A warning label must be attached to the back wall of the
fireplace stating that “This heater has been altered to
accommodate a fireplace insert and must be re-inspected by a
qualified person prior to re-use as a factory built fireplace”.
Non-combustible floor protection must cover the flooring
underneath, as well as extend a minimum of 6” (152.4mm) in
front and to both sides of the appliance.
Clean all ashes out of the inside of the fireplace. Make sure
that the chimney and fireplace are free of cracks, loose mortar,
creosote deposits, blockage or other signs of deterioration.
If necessary, have any repair work done by a qualified
professional before installing the appliance.
A. Remove the fireplace damper or fasten it permanently
open.
B. Measure the throat of the fireplace and mark this shape on a piece of 24 (0.511mm) gauge sheet meta
l
(flue cover). Cut a hole sized for the pellet liner to lie directly below the fireplace flue opening. Allow 2”
(50.8mm) of material for a flange on all sides and cut to these measurements. Bend down the flanges.
If you have never done this before, it might be a good idea to make a cardboard pattern and test it first.
Fasten this flue cover in position as high as possible with two masonry screws per side through the
flanges into the appliance.
C. If you plan on connecting outside air it is recommended to do so at this time.
D. Install floor protection if necessary.
E. Connect the pellet vent with a clean out tee to the back of the insert. Refer to manufacturer’s
installation instructions to see “REAR TO TOP VENT CONVERSION INSTRUCTIONS” section and th
e
“GENERAL VENTING” section.
F. Run a liner down the chimney and connect to tee.
G. Position the insert in it’s final location.
H. Pull the excess length of liner out through the top of the chimney. Trim the excess liner, install the cap
and cap the chimney.
Roof
Flashing
Storm
Collar
Floor Protection
Vertical
Cap
The smoke
shelf, damper
and baffles may
be removed
Do not remove any part that would
alter the integrity in any way.
80.1A
