TIME LED 781302 User manual

Installation and Operating Instructions
INS-781302-V1
Read and follow instructions before operating your RGB LED Controller with Remote.
Save this manual for future reference.
Package includes:
1 x Ambient RGB LED Lighting Controller
1 x Remote
1 x CR2032 Battery For Remote
1 x Manual
TIME LED is part of Pitacs Limited. For customer support contact:
Bradbourne Point, Bradbourne Drive, Tilbrook, Milton Keynes, Buckinghamshire MK7 8AT
T: [phone] F: [phone] E: [e-mail] W: www.timeled.co.uk
015
015
Ambient RGB LED Lighting Controller With Remote
Safety:
• Installation of this LED controller should only be carried out by a qualified electrician or competent person to the
latest Building and current IEE Wiring Regulations (BS7671).
• Please isolate mains prior to installation/maintenance.
• Check the total load on the circuit (including when this product is fitted) does not exceed the rating of the circuit
cable, fuse or circuit breaker.
• Please note the IP (Ingress of Protection) rating of this product when deciding the location for installation.
• This product is IP20 rated, for internal use only.

Full Technical specification available upon request. Contact [e-mail] for PDF.
Ambient RGB LED Lighting Controller
With Remote
Cleaning:
• Do not use any chemical or abrasive cleaners.
• Clean product with a soft, dry cloth.
Warranty:
• This product is warranted to be free of defects in materials, design and workmanship for 1 year from the date of
purchase (conditions apply, please see TIME LED website for further details). If a suspected fault should develop in this
time, please contact us via the address on the front.
Recycling Advice:
Waste Electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check
with your local authority or retailer for recycling advice.
Product Code 781302
Driver Size
Remote Size
49x21x36
84x51x7
Cable Length 13cm
Voltage 12-24V
Working Temperature -20 to +60°C
Maximum Wattage 72W (12V)
144W (24V)
Max Load 2A for each colour
Lifespan 7500 Hours
Material PC
IP Rating IP20
Warranty 1 Year
1.Specifications:
Operation Instructions of Controller
Working temperature: -20-60C
RC.size:84x51X7mm
Supply voltage: DC12V
Connecting Mode: Common anode
Adopt IR remoter to control the led controiler ,which has 24 buttons,the function of each button as the table below:
II. Control Method:
Output: Three CMOS drain-open output
Max load current: 2 A each color
III. Panel specification and connecting drawing as follows:
IV. Warning:
1. Supply vlotage of this product is DC12~24V never connect AC220V.
2. Never connect two wires directly in case of short circuit.
3. Lead wire should be connected correctly according to colors that connecting diagram offers.
4. Warranty of this product is one year, in this period we guarantee replace ment or repairing with no charge, but
exclude the artif:cial situation of damaged or overload working.
Brightness + (Speed up) Brightness - (Speed down) Off On
Static red
Static orange
Static dark yellow
Static yellow
Static straw yellow
Static green
Static Pea green
Static cyan
Static light blue
Static sky blue
Static green
Static Pea green
Static cyan
Static light blue
Static sky blue
Static white
7 color jumpy change
All fade out&fade in
7color fade change
3 base colr jumpy
DC12~24V
POWER
SIGNAL
IR Sensor
OUTPUT
G
G
RR
B
B
IR.size:60x35x21mm
Remote Interface:
Installation:
FLASH
W
ON
B
OFF
GR
STROBE
FADE
SMOOTH
Mode Settings
Power On
Power O
Brightness
Adjustments
Red Hue Variations White Colour Temperature
Green Hue Variations Blue Hue Variations
• Supply voltage of this product is DC12~24V DO NOT connect AC220V.
• Never connect two wires directly in case of short circuit.
• The lead wire should be connected according to the above the diagram.
DC 12V OR DC 24V
