TIME LED 781234 User manual

Installation and Operating Instructions
INS-781234-V1
Read and follow instructions before operating your driver.
Save this manual for future reference.
Package includes:
1 x Ambient 40W LED 12V Driver
1 x Manual
TIME LED is part of Pitacs Limited. For customer support contact:
Bradbourne Point, Bradbourne Drive, Tilbrook, Milton Keynes, Buckinghamshire MK7 8AT
T: [phone] F: [phone] E: [e-mail] W: www.timeled.co.uk
015
015
Ambient 40W LED 12V Driver
Safety:
• This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS 7671) and
current Building Regulations. If in any doubt, consult a qualified electrician.
• Please isolate mains prior to installation or maintenance
• Check the total load on the circuit (including when this product is fitted) does not exceed the rating of the circuit
cable, fuse or circuit breaker
• Do not overload this product or subject it to conditions outside its rating
• Please note the IP (Ingress Protection) rating of this luminaire when deciding the location for installation
• This product is IP20 rated

Full Technical specification available upon request. Contact [e-mail] for PDF.
Ambient 40W LED 12V Driver
Cleaning:
• Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may damage the driver.
Warning:
• This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance testing.
Irreparable damage will occur if this instruction is not followed.
Warranty:
• This product is warranted to be free of defects in materials, design and workmanship for 1 year from the date of
purchase (conditions apply, please see TIME LED website for further details). If a suspected fault should develop in this
time, please contact us via the address on the front.
Recycling Advice:
Waste Electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check
with your local authority or retailer for recycling advice.
Product Code 781234
Size (mm) 160x20x58
Watts 40W
Input Frequency 50Hz
Voltage 170-265V
Hertz 50Hz
Current 3.33A
Power 40W
Power Factor (PF) 0.9
Material PC
IP Rating IP20
Warranty 1 Year
Installation:
• Provide power to the required point of installation.
• Connect the LED driver to the mains supply, ensuring the correct polarity is observed: Live = brown, Neutral = blue.
• Connect a suitable LED load to the secondary side of the driver, ensuring the correct polarity is observed: Red to
positive (+) and Black to negative (-).
• Ensure cable strain relief is securing the cables eectively.
• Switch on power supply and check for correct operation.
