TimTam PowerMassager PRO User manual

MODERN RECOVERY
FOR ALL
PRO
Manual

The PowerMassager PRO is an ultra-modern therapy device taking modern recovery to the next
level of recovery performance. For an optimal recovery experience, the PRO has 3 Preset Deep Tissue
levels and a total of 5 massage modes. Outfitted with Antimicrobial Plastic Surfaces to offer non
cross contamination between users; the PRO offers a 175-degree adjustable head for total self-body
use. Embedded in the PRO is a LED Display for battery level and temperature gauge used for our
built-in heat technology accessory to increase recovery. We are able to offer all this with a whisper
quieter sound profile.
SPECIFICATIONS
MASSAGE MODES:
For Warmup, Recovery, Neck or Lumbar
modes, attach the desired tip and power
on. Press and cycle through the
massage modes until you find the desired
massage mode.
ACTIVATE HEAT
To initiate the heating function, attach the red
colored tip and power the device on. Press
and hold the button for 2 seconds until you
see the ball icon appear on the LED screen.
Within 2 minutes it will heat the Warmup Tip to
99°F .
TURN ON
To power the device, insert the battery
into it and press the button once,
which is located on the grip of the handle.
The LED screen will illuminate indicating
it has powered on.
DEEP TISSUE SPEEDS
The PowerMassager™ Pro has 3 Deep Tissue
speeds delivering up to 2,800 strokes per
minute. Click the button to cycle through
each of the 3 speed levels (1000,2000,2800 SPM).
TURN OFF
To power down the device, press and hold
the button for 3 seconds, or simply
remove the battery.
PRO
ACTIVATE VIBRATION
To initiate the vibration function, attach the
larger silver colored tip and power the device on.
Press and hold the icon for 2 seconds until
you see the ball icon appear on the LED screen.
Instantly you will hear and see the tip vibrate.
v
The PowerMassager™ Pro shaft can be
rotated up to 175 degrees of articulation,
allowin g you to target all areas of your
body easily. By pushing the red logo
portion of the dial directly above the shaft
you can then move the shaft into the
desired position. Once you find the right
massage point, release the button to lock
the arm in place.
The PowerMassager™ Pro has a built-in temperature sensor
allowing you to obtain baseline personal data pre, during and
post treatment! Locate the thermometer sensor icon on the
outside handle side of the grip. Power on the device, then
press the front of device against your skin and press and hold
the temp sensor button for 3 seconds and release. It will
measure and report the temperature of the area measured on
the LED screen. Optimal skin temperature is above 90
degrees, when the warmup tip you're using during therapy no
longer feels warm, you are approaching optimal muscle
temperature for safe workout or recovery!
ARTICULATING ARM Temperature Sensor
175 Degree Rotation
20mm Shaft
Skin Temperature
Sensor F°
Auto Warming Round Tip
(Included)
60 htz Vibrating Tip
(Optional Accessory)
Led Screen
Companion App
Available Late 2019
Antibacterial Plastics
3 Speeds - 1000,
2000, 2800 SPM
Bluetooth
Connectivity
Quiet Brushless Motor
5 Programs - Deep
Tissue, Warmup,
Recovery, Neck, Back
175 Degree Rotation
20mm Shaft
Skin Temperature
Sensor F°
Auto Warming Round Tip
(Included)
60 htz Vibrating Tip
(Optional Accessory)
Led Screen
Companion App
Available Late 2019
Antibacterial Plastics
3 Speeds - 1000,
2000, 2800 SPM
Bluetooth
Connectivity
Quiet Brushless Motor
5 Programs - Deep
Tissue, Warmup,
Recovery, Neck, Back
175 Degree Rotation
32mm Shaft
Muscle Temperature Sensor F°
Auto Warming Round Tip (Included)
60 htz Vibrating Tip (Optional Accessory)
LED Display
Companion App Available Late 2019
Antibacterial Plastics
12v Li-ion Battery
3 Speeds -
Accessory Button
Temperature
Sensor Button
1000, 2000, 2800 SPM
Wireless Connectivity
Quiet Brushless Motor
5 Programs -
Deep Tissue, Warmup, Recovery, Neck, Back
Secure Compartment for GPS Locator

MASSAGER SAFETY
SET UP AND USAGE
By using the device on yourself you will quickly discover the pressure that
achieves the desired result on the body. Do not apply excessive pressure
when using the PowerMassager™ Pro.
*** Please use caution when using or receiving treatment from someone
else. Become familiar with the features and the pressure required.
Everyone has different pain thresholds. In most cases you can let The
PowerMassager™ Pro do the work without adding any pressure!
Prior to massage do not turn on the PowerMassager before attaching the
desired accessory tip to it. Additionally, position the massager toward you with
the tip facing you and adjust the arm to the desired position to get the optimal
massage point. If you are using a powered tip follow proper protocol before
starting your session with The PowerMassager Pro.
PRESSURE
Designed with a one touch trigger and a 175 degree articulating arm, The
TimTam PowerMassager™ Pro is designed for 100% self use. Below are 3
ideal grip areas in which by using these areas in conjunction with the
articulating head; you will be able to access your body.
Designed with a one touch trigger, The TimTam PowerMassager™ Pro
was designed for 90% Self Use. This allows for a user to grip from different
areas of the product allowing you to access your body. Below are 3 ideal grip
areas in which by using these areas in conjunction with the articulating
head; you will be able to access the majority of your body.
HAND PLACEMENT

CHARGING
AC Charger: 100-240V 50/60 Hz- .8A -15VDC-1A
Rechargeable Lithium Ion battery 2000 mah
AC wall charger (15 VDC- 1A)
*The TimTam PowerMassager™ Pro should only be used
with the provided, certified TimTam charger with the correct
safety sensor so it will function properly.
CHARGING INSTRUCTIONS
Use a towel or soft cloth to wipe any moisture from unit.
Store in a cooler area.
Keep unit away from heat sources, liquids, and inexperienced individuals.
MAINTENANCE , CLEANING AND STORAGE
12
3 4
5 6
Connect the prong adaptor to the charging port.
Insert battery onto the base while connecting
the cable to the back of it.
Fully charge before first use. LED lights illuminate to
show battery level and indicate active charging.
Unit may be recharged at any time and at any
battery level. It is not recommended to fully
deplete the battery level. Recharge the unit
regularly to best prolong battery life.
Plug into the proper rated outlet.
Lay the prong adaptor on the snap in points of the
charger and twist to lock into place.
To release prongs from the
adaptor, press the button on
the bottom left and twist the
prongs to the left at the same time.
Red on the Left = Charging Green on the Right= Fully Charged
LED lights will remain illuminated when fully charged
while adaptor is plugged into the outlet.

WARNINGS AND CAUTION
Please consult with a licensed health professional before you use the PowerMassager™ as
use of the product could cause complications if you have certain preexisting conditions
such as but not limited to headaches, joint issues, implanted devices, surgery, pregnancy
and diabetes. It is highly advised that children should be supervised when using the Power-
Massager™.
Do not attempt to disassemble or assemble the PowerMassager™ as this could increase
the risk of electric shock, fire, or exposure to battery chemicals and also render the product
defective.
Store the PowerMassager™ in a cool, dry place. Storing in areas with higher temperatures
or an area that has direct exposure to direct sunlight, may render the product defective.
Keep away from liquid as this could potentially render the product defective if it came in
contact with it.
After intense use, allow a cool down phase of 20 minutes before reusing.
Do not leave the charger plugged in after the battery has been fully charged as this may
lead to reduction of useful life or damage to the battery.
Unplug the charger from the outlet when not in use. Additionally, make sure the charger
cable is easily visible so that it will not be stepped on or subjected to damage or stress. Be
sure to replace damaged charger immediately.
The TimTam PowerMassager™ should be charged indoors in a well ventilated, dry location.
Charging outdoors near location that has the potential of becoming a wet surface or expos-
ing the charger to moisture, rain, snow or heat may damage it. Furthermore, do not use the
battery or charger in the presence of potentially flammable locations as this could generate
a fire.
Do not slam the product on any surface as this could render the product defective.
Excess Weight on the Tim Tam PowerMassager™ may damage or break the unit during
normal intended use.
Please keep your fingers away from the metal shaft in between the massage tip and the
plastic body when the TimTam is powered on.
1
2
3
4
5
6
7
8
9
10
11

WARRANTY
If you did not purchase your product directly from TimTam, please contact the appropriate TimTam business entity,
dealer or retailer, from whom you directly purchased the product for warranty and return authorization procedures.
The TimTam PowerMassager™ has a 1 year warranty if purchased from www.timtam.tech or our official Amazon
store. An additional, extended warranty is available for select items on our website and can be purchased when
placing your order. If you purchased from a different seller, contact them for warranty support.
Email [email protected] to find out if your item(s) is eligible for an extended warranty. TimTam will repair or
replace the product, or necessary components, free of charge if Tim Tam All New fails due to a defect in material or
workmanship.
To have it repaired or replaced under the warranty, it must be reviewed to ensure there is a valid warranty. Upon
confirmation, TimTam will email you a return authorization form and instructions on sending the product to TimTam.
Warranty will be voided if damage was caused by misuse or abuse, accidents such as liquids including but not limited
to water or lotions, attachment of any foreign accessories, unauthorized repairs or modifications, improper use of
electrical power supply, loss of power, variation in line voltage, dropped product, deterioration of the delivered prod-
uct resulting from abnormal storage and/or safeguarding conditions on the client’s premises, damage exceeding the
cost of the product; malfunction or damage of an operating part from failure to adhere to our recommended
maintenance, or failure to provide the dated proof of purchase.
To obtain warranty service on your product, email [email protected] with the following information:
The product that is not working.
If you purchased the product at www.timtam.tech, the email used to purchase the product.
Pictures and or Video explaining what the issue is.
This warranty provided herein shall be the sole and exclusive warranty. There shall be no other warranties expressed
or implied, including any implied warranty of merchantability or fitness, or any other obligation on the part of the
company with respect to products covered by this warranty. TimTam shall have no liability for any incidental, conse-
quential or special damages. In no event shall this warranty require more than the repair or replacement of any part
or parts which is found to be defective within the effective warranty period. No refunds will be given. If replacement
parts for defective materials are not available, TimTam reserves the right to make product substitutions in lieu of
repair or replacement.
This warranty does not extend to the purchase of opened, used, repaired, repackaged and/or resealed products,
including but not limited to sale of such products on Internet auction sites and/or sales of such products by surplus
or bulk resellers. Any and all warranties or guarantees shall immediately cease and terminate as to any products or
parts thereof which are repaired, replaced, altered, or modified without the prior express and written consent of
TimTam.
This warranty provides you with specific legal rights, however some states and countries do not allow a limitation of
damages, so the foregoing limitation may not apply to you.
This warranty is initiated and executed by
TT Therapeutics LLC
9119 Highway 6 South Suite 230 Box 186 Missouri City, TX 77459
[email protected]
COMPLIANT
