Titan Connected x User manual

SMART WATCH ACTIVITY TRACKER

User Manual

Catalogue

1 Packing List2 Product Detials3 Working Condition4 Waterproof Level5 Watch Battery6 Charging Instructions7 Wear Watch8 Install APP9 Bind Watch10 Time Calibration11 Operating Instructions12 Shortcut Menu13 Menu One14 Menu Two

（1）Alarm clock interface （2）Sleep Interface(1) Heart Rate Interface(2) Weather Interface(3) Activity Data(4) Missed Calls(5) SMS Interface(6) Social Notiﬁcation

��01

��03��04

��

��06

��08��09

��10

��

��12

��16

��17��

�

��20��

�

��22��

�

��24��

�

��25

��26��

��

��02

��11

15 Menu Three

（1） Remind Interface （2）Stopwatch Interface （3）Countdown Interface （4）Schedule Interface

16 Clean Watch 17 Troubleshooting18 Precautions19 FCC Statement

（3） Music Control （4）Remote Camera （5）Search for the Mobile Phone （6）Setting Interface

��30��31��32

��

��36��37��38��39

��41��42

��31

��40

１. Packing ListA：Smart watchB：User manualC：Charging dockD：Charging cableACBD

2. Product DetailsTouch ScreenUp KeyDown KeyPhysicalWatch HandsChargingContact SurfaceUSB Charger Port

Charge LampHeatRate Lenses

3. Working ConditionWorking temperature-10°C~55°CWorking humidity0~100%

4. Waterproof LevelThe watch can withstand the pressure equivalent to 30 meters water depth, suitable for daily use, is not recommended to wear when swimming in the pool or shallows, can not be used for diving, does not support bathing and sauna.

5. Watch Battery（1） The smart part can be used for about 3 days when the watch is fully charged.（2） If the watch shows low battery power, the smart part function will be automatically turned oﬀ, but the watch hands can continue to operate normally for about 30 days.Notice：The smart part can be used for about 3 days and is estimated based on the average use of the watch.The actual length of use varies depending on how much the notiﬁcation is reminded and how long the heart rate is on.

（1） Connect the USB cable to the USB power adapter.（2） Connect the other end of the USB cable to the charging dock. （3） Plug the USB power adapter into a power outlet.（4） Press the back of the watch into the charging cradle to charge the watch.Notice：1） Before using the watch for the ﬁrst time, fully charge the watch before using it, and it takes about two hours to complete the charging. When using a computer USB port, etc., as the charging source for the watch, it may take up to 3 hours to fully charge the watch.2） Use the charger only on a ﬂat desk, away from implanted devices.6. Charging Instructions

3） If there is an obstacle between the watch and the charging dock, the watch may not charge properly.4） When the battery is low, please charge it in time. After the watch is charged, please disconnect the charging power.5） When the battery is low, please charge it in time. After the watch is charged, please disconnect the charging power. To avoid damage to your watch, please use the original factory-installed charging accessories.6） Do not use if the charging device is damaged.7） Unplug the charging device when cleaning your watch, during a thunderstorm, or when it will not be used for a long time.8） Do not attempt to disassemble or modify your watch, charging cable or charging dock.9） Do not twist or pinch the charging cable.10） Do not attempt to remove or replace the battery or watch by yourself. The substances contained in this product and the battery may cause harm to the environment or human health. Please dispose of it properly.

7. Wearing the Watch

(1) Wear the watch on your wrist, just behind the wrist bone and fasten it well using the buckle.(2) The watch must be comfortably tight on your wrist such that there is no gap between the watch and your wrist. This is important so that the Heart Rate sensor, which is at the back of the watch, is always in contact with your skin.(3) To change or replace the strap (watch band), ﬂip your watch to the rear side. You will see a slider near the case-to-strap joint. Slide this spring bar to releasing it.

8. Installing the mobile APPApple App Store (iOS users)Use the Search tab to look for “Titan Connected X” App. Download the App and let it install. The Titan Connected X App supports iOS 9.0 and aboveGoogle Play Store (Android users)Use the Search tab to look for “Titan Connected X” App. Download the App and let it install. The Titan Connected X App supports Android 6.0 and aboveNote: Please grant the necessary permissions that the App requests, in order to make use of all the features of the watch.

9. Pairing the Watch(1) Turn on your phone's Bluetooth and open the APP on your phone.Note：1) If you are a new user, you need to create a new account.2) If you have registered an account, log in using the APP with your email address and password.(2) After logging in, follow the instructions on the APP to scan the watch with the QR code to bind the watch.Note：In the Pairing process, the watch needs to be near the mobile phone.(3) When the connection is successful, the watch and mobile device will prompt "Pairing successful" after the binding is completed.(4) After the binding is successful, your watch screen will guide you step by step through the setup process.(5) If the binding fails, the APP will remind you to reoperate the binding.

10. Time Calibration((1) After the watch is successfully paired to the App, follow the instructions on the App to scan the watch for time calibration(2) Ensure that the watch ﬁts into the outline that is shown on the app screen and your camera is pointing exactly on your watch(3) When the time calibration is complete, click the "Home" button to return to the main interface of the App(4) If you notice an error in the time, you can always go to the Settings option in the App and do the calibration again (also if your time zone changes).

ClickSwipe left

11. Opearting Construction

(2) Key describtion Up key：Turn on the screen; return to the home page; turn on the standby mode; long press for 5 seconds to turn on/oﬀDown key：Light the screen; return to the previous layer; long press to display the pairing QR codeUp key + down key：Long press the two buttons at the same time for 8 seconds to power oﬀ (1) Touch screen operationDouble clickSwipe rightLong pressSwipe upSwipe down

Note: 1) If you restart the watch, the activity data will not be deleted.2) By default, if the watch is operated without any human on any interface, the screen will be darkrn after 5 seconds and will be automatically turned oﬀ after 10 seconds.You can change this setting from the settings option in the app. 3) Watch on any interface, if there is no operation within 2 minutes, will automatically return to the main time interface (except stopwatch, countdown, etc.)

Click the menu icon to enter the icon function.20°

Partly Cloudy84% Double click on any interface to return to the previous layer.Long press the watch face, swipe left or right to select the replacement watch face.

Swipe left to access the menu one.Swipe right to access menu three.Swipe up to access the shortcut menu.Swipe down to access the message center.(The watch pointer turns to show 9:15)

(1) Flight modeWhen the icon is , the ﬂight mode is oﬀ and Bluetooth is not connected; when the icon is , the ﬂight mode is on; when the icon is , the ﬂight mode is oﬀ and Bluetooth is connected.(2) Vibration settingsWhen the icon is , vibration is enabled (default); when the icon is , the silence is turned on.(3) Brightness adjustmentClick , slide the screen to left or right to increase or decrease the screen brightness.(4) Settings buttonClick , enter into the watch setting.12. Shortcut Menu

20°

Partly Cloudy84%

(1) Heart rate interface13. Menu One1) Swipe to the menu one on the watch, click the icon on the screen, and then click the screen to start the heart rate monitoring. The green light appears on the back of the watch and the heart rate begins to be measured.108 BPM

5 min ago
