Titan POWRTWIN PLUS DI Series User manual

PT6900 DI 120V
PT12000 DI 400V
PT6900 DI 230V
PT12000 DI GasPT6900 DI Gas
POWRTWIN™
PLUS DI
0921 • Form No. 0537856E / Doc. # 11214233
AIRLESS, HIGH-PRESSURE
SPRAYING UNIT
AIRLESS HOCHDRUCK-
SPRITZGERÄT
GROUPE DE PROJECTION À
HAUTE PRESSION
- GB - OPERATION MANUAL 2
- D - BETRIEBSANLEITUNG 30
- F - MODE D’EMPLOI 60
OPERATION MANUAL
Models:
PT6900 Plus DI (120V) 290029
PT6900 Plus DI (230V) 290033
PT6900 Plus DI (Gas) 290021
PT6900 Plus DI (Gas) 290035-MBV
PT6900 Plus DI (230V) 290061-MBV
PT12000 Plus DI (400V) 290034-MBV
PT12000 Plus DI (Gas) 290023

2 PowrTwin Plus DI
GB
Warning!
Attention: Danger of injury by injection!
Airless units develop extremely high spraying pressures.
Be safety conscious!
1
2
3
Never put your ngers, hands or any other parts of the body into
the spray jet!
Never point the spray gun at yourself, other persons or animals.
Never use the spray gun without safety guard.
Do not treat a spraying injury as a harmless cut. In case of injury
to the skin through coating materials or solvents, consult a doctor
immediately for quick and expert treatment. Inform the doctor
about the coating material or solvent used.
The operating instructions state that the following points must
always be observed before starting up:
1. Faulty units must not be used.
2. Secure Titan spray gun using the safety catch on the trigger.
3. Ensure that the unit is properly earthed.
4. Check allowable operating pressure of high-pressure hose and
spray gun.
5. Check all connections for leaks.
The instructions regarding regular cleaning and maintenance of
the unit must be strictly observed.
Before any work is done on the unit or for every break in work the
following rules must be observed:
1. Release the pressure from spray gun and hose.
2. Secure the Titan spray gun using the safety catch on the trigger.
3. Switch o unit.
Original Operating Manual

PowrTwin Plus DI 1
GB
Contents
Contents
Page
1. Safety regulations for Airless spraying...................................... 2
1.1 Explanation of symbols used.............................................................. 2
1.2 Electrical safety......................................................................................... 3
1.3 Gasoline engine safety.......................................................................... 4
1.4 Fueling (gas engine)............................................................................... 4
2. General view of application............................................................. 5
2.1 Application ................................................................................................ 5
2.2 Coating materials .................................................................................... 5
3. Description of unit................................................................................ 5
3.1 Airless process.......................................................................................... 5
3.2 Functioning of the unit......................................................................... 5
3.3 System diagram - gasoline PT units.................................................. 6
3.4 System diagram - electric PT units.................................................... 7
3.5 Technical data for PT units................................................................... 8
3.6 Airless Spray Tip Recommendation Chart...................................... 9
4. Operation................................................................................................10
4.1 Operating the swing cart....................................................................10
4.2 Setup..........................................................................................................11
4.3 Preparing a new sprayer.....................................................................12
4.4 Preparing to paint.................................................................................13
4.5 Painting.....................................................................................................14
4.6 Pressure relief procedure ...................................................................14
5. Cleanup....................................................................................................15
5.1 Special cleanup instructions for use with
ammable solvents ..............................................................................15
5.2 Cleaning the sprayer............................................................................15
5.3 Cleaning a clogged tip ........................................................................15
6. Maintenance..........................................................................................16
6.1 Daily maintenance................................................................................16
6.2 Maintaining the lter assembly........................................................16
6.3 Maintaining the hydraulic system...................................................18
6.4 Maintaining the uid section............................................................18
6.5 Basic engine maintenance.................................................................18
6.6 Replacing the motor brushes (120V electric convertokit)......19
6.7 Replacing the belt.................................................................................20
6.8 Servicing the hydraulic motor..........................................................22
6.9 Servicing the uid section..................................................................24
6.10 SAE O-ring tting installation ...........................................................26
Page
7. Troubleshooting .................................................................................27
7.1 Airless gun ...............................................................................................27
7.2 Fluid section............................................................................................27
7.3 Hydraulic motors...................................................................................28
7.4 Spray patterns ........................................................................................29
Accessories and spare parts ........................................................................90
Spare parts list for the main assembly.................................................. 90/91
Spare parts list for the cart assembly .................................................... 92/93
Spare parts list for the hydraulic system.............................................. 94/95
Spare parts list for the hydraulic motor ............................................... 96/97
Spare parts list for the uid section....................................................... 98/99
Spare parts list for electric convertokit (120V)........................................100
Spare parts list for electric convertokit (400V)........................................101
Spare parts list for electric convertokit (230V).............................. 102/103
Spare parts list for gas convertokit .............................................................104
Spare parts list for the high-pressure lter ..............................................105
Spare parts list for belt guard assembly....................................................106
Spare parts list for bleed valve .....................................................................107
Spare parts list for bleed valve assembly, heavy materials................108
Connection diagram (230V).......................................................................110
Connection diagram (400V).......................................................................111
Accessories for PT units...............................................................................112
Gun manifold assemblies (optional) ..........................................................114
Warranty .............................................................................................................116

2 PowrTwin Plus DI
GB
Safety precautions
1. Safety regulations for Airless spraying
1.1 Explanation of symbols used
This manual contains information that must be read and understood
before using the equipment. When you come to an area that has one
of the following symbols, pay particular attention and make certain
to heed the safeguard.
This symbol indicates a potential hazard that
may cause serious injury or loss of life. Important
safety information will follow.
At
tention
This symbol indicates a potential hazard to you
or to the equipment. Important information that
tells how to prevent damage to the equipment or
how to avoid causes of minor injuries will follow.
Danger of skin injection
Danger of fire from solvent and paint fumes
Danger of explosion from solvent, paint fumes
and incompatible materials
Danger of injury from inhalation of harmful
vapors
i
Notes give important information which should
be given special attention.
HAZARD: INJECTION INJURY
A high pressure stream produced by this equipment
can pierce the skin and underlying tissues, leading to
serious injury and possible amputation.
Do not treat a spraying injury as a harmless cut. In
case of injury to the skin through coating materials
or solvents, consult a doctor immediately for quick
and expert treatment. Inform the doctor about the
coating material or solvent used.
PREVENTION:
• NEVER aim the gun at any part of the body.
• NEVER allow any part of the body to touch the uid stream.
DO NOT allow body to touch a leak in the uid hose.
• NEVER put your hand in front of the gun. Gloves will not
provide protection against an injection injury.
• ALWAYS lock the gun trigger, shut the uid pump o and
release all pressure before servicing, cleaning the tip guard,
changing tips, or leaving unattended. Pressure will not be
released by turning o the engine. The PRIME/SPRAY valve
or pressure bleed valve must be turned to their appropriate
positions to relieve system pressure.
• ALWAYS keep tip guard in place while spraying. The tip guard
provides some protection but is mainly a warning device.
• ALWAYS remove the spray tip before ushing or cleaning the
system.
• NEVER use a spray gun without a working trigger lock and
trigger guard in place.
• All accessories must be rated at or above the maximum
operating pressure range of the sprayer. This includes spray
tips, guns, extensions, and hose.
HAZARD : HIGH PRESSURE HOSE
The paint hose can develop leaks from wear, kinking
and abuse. A leak can inject material into the skin.
Inspect the hose before each use.
PREVENTION:
• Avoid sharp bending or kinking of the high-pressure hose. The
smallest bending radius amounts to about 20 cm.
• Do not drive over the high-pressure hose. Protect against
sharp objects and edges.
• Replace any damaged high-pressure hose immediately.
• Never repair defective high-pressure hoses yourself!
• Electrostatic charging of spray guns and the high-pressure
hose is discharged through the high-pressure hose. For this
reason the electric resistance between the connections of the
high-pressure hose must be equal to or lower than 1M.
• For reasons of function, safety and durability use only original
Titan high-pressure hoses.
• Before each use, check all hoses for cuts, leaks, abrasion
or bulging of cover. Check for damage or movement of
couplings. Immediately replace the hose if any of these
conditions exist. Never repair a paint hose. Replace it with
another earthed high-pressure hose.
• Make sure power cord, air hose and spray hoses are routed in
such a manner to minimize slip, trip and fall hazard.
HAZARD: EXPLOSION OR FIRE
Flammable vapors, such as solvent and paint vapors,
in work area can ignite or explode.
PREVENTION:
• Use equipment only in well ventilated area. Keep a good
supply of fresh air moving through the area to keep the air
within the spray area free from accumulation of ammable
vapors. Keep pump assembly in well ventilated area. Do not
spray pump assembly.
• Electric models only - Do not use materials with a ashpoint
below 38º C (100º F). Flashpoint is the temperature at which a
uid can produce enough vapors to ignite.
• Gas models only - Do not ll fuel tank while engine is running
or hot; shut o engine and allow to cool. Fuel is ammable
and can ignite or explode if spilled on a hot surface.
• Eliminate all ignition sources, such as pilot lights, cigarettes,
portable electric lamps and plastic drop cloths (potential static
arc).
• Keep work area free of debris, including solvent, rags and
gasoline.
• Do not plug or unplug power cords, or turn power or light
switches on or o when ammable vapors are present.
• Ground equipment and conductive objects in work area.
Make sure the grounding cable (not equipped) is connected
from the grounding lug to a true earth ground.
• Use only grounded hoses.
• Hold spray gun rmly to the side of a grounded pail when
triggering into pail.
• If there is static sparking or if you feel a shock, stop operation
immediately.

PowrTwin Plus DI 3
GB
Safety precautions
• Know the contents of the paint and solvents being sprayed.
Read all Material Safety Data Sheets (MSDS) and container
labels provided with the paints and solvents. Follow the paint
and solvent manufacturer’s safety instructions.
• Do not use a paint or solvent containing halogenated
hydrocarbons. Such as chlorine, bleach, mildewcide,
methylene chloride and trichloroethane. They are not
compatible with aluminum. Contact the coating supplier
about compatibility of material with aluminum.
• Keep a re extinguisher in work area.
HAZARD: HAZARDOUS VAPORS
Paints, solvents, and other materials can be harmful
if inhaled or come in contact with body. Vapors can
cause severe nausea, fainting, or poisoning.
PREVENTION:
• Wear respiratory protection when spraying. Read all
instructions supplied with the mask to be sure it will provide
the necessary protection.
• All local regulations regarding protection against hazardous
vapors must be observed.
• Wear protective eyewear.
• Protective clothing, gloves and possibly skin protection cream
are necessary for the protection of the skin. Observe the
regulations of the manufacturer concerning coating materials,
solvents and cleaning agents in preparation, processing and
cleaning units.
HAZARD: GENERAL
This product can cause severe injury or property
damage.
PREVENTION:
• Follow all appropriate local, state, and national codes
governing ventilation, re prevention, and operation.
• Pulling the trigger causes a recoil force to the hand that is
holding the spray gun. The recoil force of the spray gun is
particularly powerful when the tip has been removed and
a high pressure has been set on the airless pump. When
cleaning without a spray tip, set the pressure control knob to
the lowest pressure.
• Use only manufacturer authorized parts. User assumes all
risks and liabilities when using parts that do not meet the
minimum specications and safety devices of the pump
manufacturer.
• ALWAYS follow the material manufacturer’s instructions for
safe handling of paint and solvents.
• Clean up all material and solvent spills immediately to prevent
slip hazard.
• Wear ear protection. This unit can produce noise levels above
85 dB(A).
• Never leave this equipment unattended. Keep away from
children or anyone not familiar with the operation of airless
equipment.
• Do not spray on windy days.
• The device and all related liquids (i.e. hydraulic oil) must be
disposed of in an environmentally friendly way.
1.2 Electric Safety
Electric models must be earthed. In the event of an electrical short
circuit, earthing reduces the risk of electric shock by providing an
escape wire for the electric current. This product is equipped with
a cord having an earthing wire with an appropriate earthing plug.
Connection to the mains only through a special feed point, e.g.
through an error protection insallation with INF < 30 mA.
DANGER — Work or repairs at the electrical
equipment may only be carried out by a skilled
electrician. No liability is assumed for incorrect
installation. Switch the unit o. Before all repair
work, unplug the power plug from the outlet.
Danger of short-circuits caused by water ingressing into the electrical
equipment. Never spray down the unit with high-pressure or high-
pressure steam cleaners.
Work or repairs at the electrical equipment:
These may only be carried out by a skilled electrician. No liability is
assumed for incorrect installation.
Operating Temperature
This equipment will operate correctly in its intended ambient, at a
minimum between +10°C and +40°C.
Relative Humidity
The equipment will operate correctly within an environment at 50%
RH, +40°C. Higher RH may be allowed at lower temperatures.
Measures shall be taken by the Purchaser to avoid the harmful eects
of occasional condensation.
Altitude
This equipment will operate correctly up to 2100 m above mean sea
level.
Transportation and Storage
This equipment will withstand, or has been protected against,
transportation and storage temperatures of -25°C to +55°C and for
short periods up to +70°C.
It has been packaged to prevent damage from the eects of normal
humidity, vibration and shock.

4 PowrTwin Plus DI
GB
General view of application
1.3 Gasoline Engine Safety
1. Gas engines are designed to give safe and dependable service
if operated according to instructions. Read and understand
the engine manufacturer’s Owner’s Manual before operating
the engine. Failure to do so could result in personal injury or
equipment damage.
2. To prevent re hazards and to provide adequate ventilation,
keep the engine at least 1 meter (3 feet) away from buildings
and other equipment during operation. Do not place
ammable objects close to the engine.
3. People who are not operating the device must stay away from
the area of operation due to a possibility of burns from hot
engine components or injury from any equipment the engine
may be used to operate.
4. Know how to stop the engine quickly, and understand the
operation of all controls. Never permit anyone to operate the
engine without proper instructions.
5. Gasoline is extremely ammable and is explosive under
certain conditions.
6. Refuel in a well-ventilated area with the engine stopped. Do
not smoke or allow ames or sparks in the refueling area or
where gasoline is stored.
7. Do not overll the fuel tank. After refueling, make sure the
tank cap is closed properly and securely.
8. Be careful not to spill fuel when refueling. Fuel vapor or
spilled fuel may ignite. If any fuel is spilled, make sure the area
is dry before starting the engine.
9. Never run the engine in an enclosed or conned area. Exhaust
contains poisonous carbon monoxide gas; exposure may
cause loss of consciousness and may lead to death.
10. The muer becomes very hot during operation and remains
hot for a while after stopping the engine. Be careful not to
touch the muer while it is hot. To avoid severe burns or re
hazards, let the engine cool before transporting it or storing it
indoors.
11. Never ship/transport sprayer with gasoline in the tank.
DO NOT use this equipment to spray water or acid.
Attention
Do not lift by cart handle when loading or unloading.
Device is very heavy. Three-person lift is required.
1.4 Fueling (gas engine)
Gasoline is extremely flammable and is explosive
under certain conditions.
Attention
Do not overll the gas tank. Overlling can cause
the gas cap to become clogged with any particles
in the gasoline which can cause a vaccum. Read
the gas engine’s instruction manual for fueling
instructions.
Fuel Specications
• Use automotive gasoline that has a pump octane number of
86 or higher, or that has a research octane number of 91 or
higher. Use of a lower octane gasoline can cause persistent
“pinging” or heavy “spark knock” (a metallic rapping noise)
which, if severe, can lead to engine damage.
iIf “spark knock” or “pinging” occurs at a steady
engine speed under normal load, change brands of
gasoline. If spark knock or pinging persists, consult
an authorized dealer of the engine manufacturer.
Failure to do so is considered misuse, and damage
caused by misuse is not covered by the engine
manufacturer’s limited warranty.
Occasionally you may experience light spark knock
while operating under heavy loads. This is no
cause for concern, it simply means your engine is
operating eciently.
• Unleaded fuel produces fewer engine and spark plug deposits
and extends the life of the exhaust system components.
• Never use stale or contaminated gasoline or an oil/gasoline
mixture. Avoid getting dirt, dust, or water in the fuel tank.
Gasolines Containing Alcohol
If you decide to use a gasoline containing alcohol (gasohol), be
sure its octane rating is at least as high as that recommended by
the engine manufacturer. There are two types of “gasohol”: one
containing ethanol, and the other containing methanol. Do not use
gasohol that contains more than 10% ethanol. Do not use gasoline
containing methanol (methyl or wood alcohol) that does not also
contain co-solvents and corrosion inhibitors for methanol. Never
use gasoline containing more than 5% methanol, even if it has co-
solvents and corrosion inhibitors.
iFuel system damage or engine performance
problems resulting from the use of fuels that contain
alcohol is not covered under the warranty. The
engine manufacturer cannot endorse the use of
fuels containing methanol since evidence of their
suitability is incomplete at this time.
Before buying gasoline from an unfamiliar station, try
to nd out if the gasoline contains alcohol. If it does,
conrm the type and percentage of alcohol used. If
you notice any undesirable operating characteristics
while using a gasoline that contains alcohol, or one
that you think contains alcohol, switch to a gasoline
that you know does not contain alcohol.

PowrTwin Plus DI 5
GB
Description of unit
2. General view of application
2.1 Application
Priming and nal coating of large areas, sealing, impregnation,
construction sanitation, façade protection and renovation, rust
protection and building protection, roof coating, roof sealing,
concrete sanitation, as well as heavy corrosion protection.
Examples of objects to be sprayed
Large-scale construction sites, underground construction, cooling
towers, bridges, sewage treatment plants and terraces.
2.2 Coating materials
Processible coating materials
i
Pay attention to the Airless quality of the coating
materials to be processed.
Latex paint, dispersion paints, re protection and thick lm materials,
zinc dust and micaceous iron ore paints, Airless spray primer,
sprayable glue, anti-corrosive agents, thick coating materials and
bitumen-like coating materials.
No other materials should be used for spraying without Titan’s
approval.
Filtering
In spite of the high-pressure lter, ltering of the coating material is
to be recommended in general (except when processing airless joint
ller).
Stir coating material before commencement of work.
iMake sure when stirring with motor-driven agitators
that no air bubbles are stirred in. Air bubbles disturb
when spraying and can, in fact, lead to interruption
of operation.
Viscosity
It is possible to work with high-viscosity coating materials with the
devices.
If highly viscous coating materials cannot be sucked up, they must be
diluted in accordance with the manufacturer’s instruction.
Two-component coating material
The appropriate processing time must be adhered to exactly. Within
this time rinse through and clean the unit meticulously with the
appropriate cleaning agents.
Coating materials with sharp-edged additional materials
These have a strong wear and tear eect on valves, high-pressure
hose, spray gun and tip. The durability of these parts can be reduced
appreciably through this.
3. Description of unit
3.1 Airless process
The main area of application are thick layers of highly viscous coating
material for large areas and a high consumption of material.
A piston pump takes in the coating material by suction and conveys it
to the tip. Pressed through the tip at a pressure of up to a maximum
of 228-248 bar (22.8-24.8 MPa, 3300-3600 PSI), the coating material is
atomised. This high pressure has the eect of micro ne atomisation
of the coating material.
As no air is used in this process, it is described as an AIRLESS process.
This method of spraying has the advantages of nest atomisation,
cloudless operation and a smooth, bubble-free surface. As well as
these, the advantages of the speed of work and convenience must be
mentioned.
3.2 Functioning of the unit
The following section contains a brief description of the technical
construction for better understanding of the function.
iThis manual gives information for both electric
motor and gasoline engine PowrTwin Plus DI
models.
TITAN PowrTwin Plus DI (PT) are high-pressure spraying units driven
by either a gasoline engine or electric motor.
The gasoline engine or electric motor (g. 1, item 1) drives the
hydraulic pump (3) by means of a V-belt which is under the belt cover
(2). Hydraulic oil ows to the hydraulic motor (4) and then moves the
piston up and down in the material feed pump (5).
The inlet valve is opened automatically by the upwards movement
of the piston. The outlet valve is opened when the piston moves
downward.
The coating material ows under high pressure through the high-
pressure hose to the spray gun. When the coating material exits from
the tip it atomises.
The pressure control valve (6) controls the volume and the operating
pressure of the coating material.
2
4
5
631

6 PowrTwin Plus DI
GB
Description of unit
3.3 System diagram - gasoline PT units
1 Extractable handle
2 Hydraulic motor
3 Handle for swiveling the material feed pump
4 Ball valve: horizontal position – hydraulic motor switched o
vertical position – hydraulic motor switched on
5 Oil cup for separating oil (separating oil prevents increased
wear and tear of the packings)
6 High-pressure lter
7 High-pressure hose outlet
8 Bleed hose
9 Suction tube
10 Relief valve handle: Turn left for circulation k
Turn right for spray p
11 V-belt under the belt cover
12 Pressure control knob
13 Oil measuring stick
14 Gasoline engine
1
7
9
9
8
11
PT12000 DI
13
12
14
10
8
5
4
6
2
3

PowrTwin Plus DI 7
GB
Description of unit
3.4 System diagram - electric PT units
1 Extractable handle
2 Hydraulic motor
3 Handle for swiveling the material feed pump
4 Ball valve: horizontal position – hydraulic motor switched o
vertical position – hydraulic motor switched on
5 Oil cup for separating oil (separating oil prevents increased
wear and tear of the packings)
6 High-pressure lter
7 High-pressure hose outlet
8 Bleed hose
9 Suction tube
10 Relief valve handle: Turn left for circulation k
Turn right for spray p
11 V-belt under the belt cover
12 Pressure control knob
13 Oil measuring stick
14 Electric motor (120V / 230V / 400V)
15 ON/OFF swtich (PT6900 DI • 120V)
16 ON/OFF switch (PT6900 DI • 230V)
17 ON/OFF switch (PT12000 DI • 400V)
18 Control lamp that shows unit operational (230V)
19 Control lamp that shows unit operational (400V)
20 Power Cord (120V)
21 Power Cord (230V • 400V)
1
21
7
9
9
8
11
PT12000 DI
13
12
14 16 18
15
20
17
19
10
8
5
4
6
2
3

8 PowrTwin Plus DI
GB
Description of unit
3.4 Technical data for PT units
PT6900 Plus DI
(120V) PT6900 Plus DI (230V) PT6900 Plus DI (gas) PT12000 Plus DI (400V) PT12000 Plus DI (gas)
Gasoline engine, power
Honda -------- -------- 163cc, 4.8 Hp -------- 270cc, 8.5 Hp
Fuel Capacity
-------- -------- 0.83 US gal (3.1 l) -------- 1.6 US gal (6.06 l)
Voltage
~ 115V, 50/60 Hz 230 V~, 50 Hz -------- 400 V~, 50 Hz, V3~ --------
Capacity
2.4 kW 3.1 kW -------- 5.5 kW --------
Power Cord
3 x 2.5 mm – 6 m 3 x 2.5 mm – 6 m -------- 5 x 2.5 mm – 6 m --------
Fuse Protection
16 A 16 A -------- 16 A --------
Max. operating pressure
22.8 MPa (228 bar, 3300 PSI) 24.8 MPa (248 bar, 3600 PSI)
Max. sound pressure level
80 dB (A)* 92 dB (A)* 92 dB (A)* 88 dB (A)* 98 dB (A)*
Max. size of tip with a spray gun
1-gun 0.035” – 0.89 mm 0.041” – 1.04 mm 0.050” – 1.27 mm 0.059” – 1.50 mm 0.059” – 1.50 mm
2-gun 0.023” – 0.58 mm 0.029” – 0.73 mm 0.033” – 0.84 mm 0.040” – 1.01 mm 0.040” – 1.01 mm
3-gun 0.017” – 0.43 mm 0.021” – 0.53 mm 0.023” – 0.58 mm 0.034” – 0.86 mm 0.034” – 0.86 mm
4-gun -------- 0.017” – 0.43 mm 0.019” – 0.48 mm 0.030” – 0.76 mm 0.030” – 0.76 mm
5-gun -------- -------- -------- 0.026” – 0.66 mm 0.026” – 0.66 mm
6-gun -------- -------- -------- 0.024” – 0.61 mm 0.024” – 0.61 mm
Max. volume ow
1.25 gal (4.7 l)/min 1.75 gal (6.6 l)/min 2.25 gal (8.5 l)/min 3.15 gal (11.9 l)/min 3.15 gal (11.9 l)/min
Weight
205 lbs (93 kg) 205 lbs (93 kg) 190 lbs (86 kg) 220 lbs (100 kg) 194 lbs (88 kg)
Max. viscosity
50.000 mPa·s 65.000 mPa·s
Dimensions L x W x H
43” x 25” x 34” (1090 x 660 x 866 mm) 46” x 27” x 34” (1168 x 686 x 866 mm)
Max. temperature of the coating material
109ºF (43° C)
Filter insert (standard equipment)
50 mesh, 18 in2
Hydraulic oil lling quantity
5.9 l (1.56 gal) CoolFlo
Max. tire pressure
0.2 MPa (2 bar, 30 PSI)
Special high-pressure hose
DN 6 mm, 15 m (50’ x 1/4”), connection thread NPSM 1/4
* Place of measurement: 1 m distance from unit and 1.60 m above reverberant oor, 120 bar (12 MPa) operating pressure.
