Titan TTI885IPD User manual

Original Instructions_MNL_TTI885IPD_GB_V01_220216
TTI885IPD
WARNING: Read the instructions before using the product!
EN
V11221 / BX220IM
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 1 2021/12/23 10:31 PM

EN
02
31
32
33
30
28
27
24
In more detail...
Product functions
Operation
Care and maintenance
Troubleshooting
Recycling and disposal
Guarantee
Declaration of conformity
23
02
03
17
18
19
Getting started...
Technical and legal information
Your product
Technical
Before you start
These instructions are for your safety. Please read through them
thoroughly before use and retain them for future reference.
Let’s
get started...
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 2 2021/12/23 10:31 PM

TTI885IPD
Getting started...
03
EN
Safety information
Safety warnings
General power tool safety warnings
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-
operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b) Do not operate power tools in explosive
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause you
to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
of electric shock.
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 3 2021/12/23 10:31 PM
WARNING! Read all safety warnings,
instructions, illustrations and specifications
provided with this power tool. Failure to follow
all instructions listed below may result in electric
shock, fire and/or serious injury.

04
TTI885IPD
Getting started...
EN Safety information
Safety warnings
b) Avoid body contact with earthed or grounded
surfaces, as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
A moment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as a dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 4 2021/12/23 10:31 PM

TTI885IPD
Getting started...
05
EN
Safety information
c) Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool.
switch or energising power tools that have the switch
on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result
in personal injury.
e) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
4) Power tool use and care
a) Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 5 2021/12/23 10:31 PM

06
TTI885IPD
Getting
started...
EN Safety information
Safety warnings
c) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands
of untrained users.
e) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect
the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are
caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
h) Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 6 2021/12/23 10:31 PM

TTI885IPD
Getting started...
07
EN
Safety information
5) Battery tool use and care
a)
manufacturer. A charger that is suitable for one type
with another battery pack.
b)
battery packs. Use of any other battery packs may
c) When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
d) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or
burns.
e) Do not use a battery pack or tool that is damaged or
risk of injury.
f)
or excessive temperature.
temperature above 130 °C may cause explosion.
g) Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
Charging
range may damage the battery and increase therisk
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 7 2021/12/23 10:31 PM

08
TTI885IPD
Safety information
Getting started...
EN
Safety warnings
6) Service
a)
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
b) Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
Impact driver safety warnings
1. Hold power tool by insulated gripping surfaces,
when performing an operation where the fastener
may contact hidden wiring. Fastener contacting a
“live” wire may make exposed metal parts of the power
tool “live” and could give the operator an electric shock.
Additional safety warnings for battery pack
a) Battery pack needs to be charged before use.
Always refer to the charger’s instruction and charge it
properly.
b) Remove the battery pack from the product when
not in use.
c) Don’t maintain the battery pack on the charger
when not in use.
d) After extended periods of storage, it may be
necessary to charge and discharge the battery pack
several times to obtain the maximum performance.
e) Longer life and better performance can be obtained
if the battery is charged when the air temperature
is between 18°C and 24°C. Do not charge the battery
in air temperature below 5 °C or above 40 °C. This
is important as it can prevent serious damage to the
battery.
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 8 2021/12/23 10:31 PM

TTI885IPD
Getting started...
Safety information EN
9
f) Do not charge battery in a damp or wet location.
Following this rule will reduce the risk of electric shock.
g) Do not disassemble the battery and avoid
mechanical damage to the battery. Risk of short
circuit and fumes may be emitted. Ensure fresh air
and seek medical assistance in the event of discomfort.
h) When disposing of battery pack, keep the battery
pack of different electrochemical systems separate
from each other.
The following information applies to professional
users only but is good practice for all users:
ADDITIONAL SAFETY WARNING FOR
CONSTRUCTION DUST
The updated Control of Substances Hazardous to Health
Regulations 1st October 2012 now also targets to reduce
the risks associated with silica, wood and gypsum dusts.
Construction workers are one of the at- risk groups within
this because of the dust that they breathe: silica dust is
not just a nuisance; it is a real risk to your lungs!
Silica is a natural mineral present in large amounts
in things like sand, sandstone and granite. It is also
commonly found in many construction materials such as
dust (also known as Respirable Crystalline Silica or RCS)
during many common tasks such as cutting, drilling and
silica can lead to the development of:
• Lung cancer
• Silicosis
• Chronic Obstructive Pulmonary Disorder / Chronic
obstructive pulmonary disease (COPD)
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 9 2021/12/23 10:31 PM

TTI885IPD
Getting
started...
EN
10
Safety information
Safety warnings
the development of Asthma. The risk of lung disease is
linked to people who regularly breathe construction dust
over a period of time, not on the odd occasion.
To protect the lung, the COSHH Regulations sets a limit
on the amount of these dusts that you can breathe (called
a Workplace Exposure Limit or WEL) when averaged
over a normal working day. These limits are not a large
amount of dust: when compared to a penny it is tiny – like
a small pinch of salt:
This limit is the legal maximum; the most you can breathe
after the right controls have been used.
HOW TO REDUCE THE AMOUNT OF DUST?
• Reduce the amount of cutting by using the best sizes
of building products.
• Use a less powerful tool e.g. a block cutter instead of
angle grinder.
• Using a different method of work altogether – e.g.
using a nail gun to direct fasten cable trays instead of
Please always work with approved safety equipment,
out microscopic particles and use the dust extraction
facility at all time.
For more information please see the HSE website:
http://www.hse.gov.uk/construction or http://www.hse.gov.
uk/pubns/cis69.pdf
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 10 2021/12/23 10:31 PM

TTI885IPD
Getting started...
EN
11
Safety information
WARNING! Some dust particles created by power
sanding, sawing, grinding, drilling and other
construction jobs contain chemicals known to
cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks and cement and
other masonry products.
• Arsenic and chromium from chemically treated
timber.
Your risk from these exposures varies, depending
upon how often you do this type of work. To reduce
your exposure to these chemicals:
• Work in a well-ventilated area.
• Work with approved safety equipment, such as
those dust masks that are specially designed to
VIBRATION
The European Physical Agents (Vibration) Directive
has been brought in to help reduce hand arm vibration
syndrome injuries to power tool users. The directive
requires power tool manufacturers and suppliers to
provide indicative vibration test results to enable users to
make informed decisions as to the period of time a power
tool can be used safely on a daily basis and the choice of
tool.
SEE TECHNICAL SPECIFICATIONS IN THE
INSTRUCTION MANUAL FOR THE VIBRATION
LEVELS OF YOUR TOOL.
The declared vibration emission value should be used
as a minimum level and should be used with the current
guidance on vibration.
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 11 2021/12/23 10:31 PM

TTI885IPD
Getting started...
EN
12
Safety warnings
the HSE website has further information.
The declared vibration emission value has been measured
in accordance with a standardised test and may be used
to compare one tool with another.
The declared vibration emission value may also be used
in a preliminary assessment of exposure.
WARNING! The vibration emission value during
actual use of the power tool can differ from the
declared value depending on the ways in which
the tool is used:
• How the materials are grinded, cut or drilled.
• If the tool is in good condition and well maintained.
• Use correct accessory for the tool and ensure it
is sharp and in good condition.
• The tightness of the gripping handles.
• The tool is being used as intended by its design
and these instructions.
While working with this power tool, hand/arm
vibrationsoccur.Adoptthecorrectworkingpractices
in order to reduce the exposure to vibration. This
tool may cause hand-arm vibration syndrome if its
use is not adequately managed.
Safety information
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 12 2021/12/23 10:31 PM

TTI885IPD
Getting started...
EN
13
WARNING! Identify safety measures to protect
the operator that are based on an estimation of
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it
is running idle in addition to the trigger time).
Note:
• The use of other tools will reduce the users’ total
working period on this tool.
• Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades.
• Maintain this tool in accordance with these
instructions and keep well lubricated (where
appropriate).
• Avoid using tools in temperatures of 10 ºC or
less. Plan your work schedule to spread any
high vibration tool use across a number of days.
Health surveillance
All employees should be part of an employer’s health
surveillance scheme to help identity any vibration related
diseases at an early stage, prevent disease progression
and help employees stay in work.
Vibration and noise reduction
To reduce the impact of noise and vibration emission,
limit the time of operation, use low-vibration and
low-noise operating modes as well as wear personal
protective equipment.
Take the following points into account to minimise the
vibration and noise exposure risks:
a) Only use the product as intended by its design and
these instructions.
b) Ensure that the product is in good condition and well
maintained.
Safety information
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 13 2021/12/23 10:31 PM

TTI885IPD
Getting
started...
EN
14
Safety warnings
c) Use correct attachments for the product and ensure
they are in good condition.
d) Keep tight grip on the handles/grip surface.
e) Maintain this product in accordance with these
instructions and keep it well lubricated (where
appropriate).
f) Plan your work schedule to spread any high vibration
tool use across a longer period of time.
g) Prolonged use of the product exposes the user
to vibrations that can cause a range of conditions
collectively known as hand-arm vibration syndrome
diseases such as carpal tunnel syndrome. To reduce
this risk when using the product, always wear protective
gloves and keep your hands warm.
Emergency
Familiarise yourself with the use of this product by
means of this instruction manual. Memorise the
safety directions and follow them to the letter. This
will help to prevent risks and hazards.
a) Always be alert when using this product, so that
you can recognise and handle risks early. Fast
intervention can prevent serious injury and damage to
property.
b) Switch the product off and remove the battery pack
if there are malfunctions. Have the product checked
before you operate it again.
Safety information
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 14 2021/12/23 10:31 PM

TTI885IPD
Getting started...
EN
15
Residual risks
Even if you are operating this product in accordance
with all the safety requirements, potential risks of
injury and damage remain. The following dangers
can arise in connection with the structure and design
of this product:
a) Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
b) Injuries and damage to property due to broken cutting
attachments or the sudden impact of hidden objects
during use.
c)
objects or poor power tool accessories.
WARNING! This product produces an
may under some circumstances interfere with
active or passive medical implants! To reduce
the risk of serious or fatal injury, we recommend
persons with medical implants to consult their
doctor and the medical implant manufacturer
before operating this product!
Safety information
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 15 2021/12/23 10:31 PM

TTI885IPD
Getting started...
EN
16
Safety information
Symbols
others the following symbols and abbreviations. Familiarise yourself with them to
reduce hazards like personal injuries and damage to property.
V Volt, (direct current voltage) mAh Milliampere per hour
/min or
min-1
Per minute °C Degree Celsius
g Gram kg Kilogram
mm Millimetre m Metre
cm Centimeter n0No-load speed
dB(A) Decibel (A-rated) m/s² Metres per second squared
Lock / to tighten or secure. Unlock / to loosen.
Read the instruction
manual.
Note / Remark.
Caution / Warning.
xxWyy Manufacturing date code; year of manufacturing (20xx) and week of
manufacturing (Wyy)
Wear hearing protection. Wear eye protection.
Wear a dust mask. Wear protective gloves.
Wear protective, slip-resistant footwear.
Switch the product off and remove battery pack before assembly,
cleaning, adjustments, maintenance, storage and transportation.
WEEE symbol. Waste electrical products should not be disposed of
with household waste. Please recycle where facilities exist. Check with
your Local Authority or local store for recycling advice.
Crossed out dust bin. Batteries and battery packs should not be
disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or local store for recycling advice.
Do not dispose of battery packs in rivers or immerse in water.
injury.
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 16 2021/12/23 10:31 PM

TTI885IPD
Getting started...
EN
17
Safety information / Your product
max. 45°C
Do note expose battery packs to heat in excess of 45 ºC. Do not charge
or store the battery pack in temperatures below 0 °C (32 °F) and above
45 °C (113°F).
The product complies with the applicable European directives and an
evaluation method of conformity for these directives was done.
UK Conformity Assessed.
Your product
9d 9
9b
9c
9a 10
1
2
3
4
5
6
7
8
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 17 2021/12/23 10:31 PM

TTI885IPD
Getting
started...
EN
18
Your product
1. Tool holder
2. Sleeve
3. Air vents
4. Forward / reverse
rotation control
5. On/off switch
6. Handle
7. Belt clip
8. Work light
9. Battery pack
a) Batery capacity
indicators
b) Battery capacity
button
c) Release button
d) Battery docking
port
10. Charger
NOTE: Parts marked with * are not shown in this overview. Please
refer to the respective part in the instruction manual.
General
> Rated voltage : 18 V
> Rated no load speed n0:0-2200 min-1
> Bit holder/ Tool socket : Hex, 63.5mm
> Weight : approx. 1.4kg
(Including battery pack)
Battery pack
> Model no. : TTI801BAT
> Cell : Li-Ion, 2 pcs
> Capacity : 2000 mAh
> Voltage : 18 V
> Weight : approx. 0.4 kg
Charger for battery pack
> Model no. : TTB804CHR
> Rated output : 21.4V d.c., 2.4 A
Usable battery pack (sold separately)
> Model no. : TTI802BAT TTI803BAT
> Capacity : 4000 mAh 5000 mAh
Usable charger (sold separately)
> Model no. : TTB805CHR
> Rated output : 21.4V d.c., 4 A
> Ambient temperature range for charger
and battery use : 5 °C to 40 °C
Sound values
> Sound pressure level LpA :88.3 dB(A)
> Sound power level LWA :99.3 dB(A)
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 18 2021/12/23 10:31 PM

TTI885IPD
Getting started...
EN
19
> Uncertainty KpA, KWA :3 dB(A)
Hand arm vibration values
> Impact tightening of fasteners of the
maximum capacity of the tool ah:9.06 m/s2
> Uncertainty K : 1.5 m/s2
The sound intensity level for the operator may exceed 80 dB(A) and ear protection
measures are necessary.
The declared vibration total values and the declared noise emission values
have been measured in accordance with a standard test method (EN 62841-1 /
EN 62841-2-2) and may be used for comparing one tool with another; they may
also be used in a preliminary assessment of exposure.
WARNING! The vibration and noise emissions during actual use of the
power tool can differ from the declared values depending on the ways
in which the tool is used especially what kind of workpiece is processed;
and need to identify safety measures to protect the operator that are
based on an estimation of exposure in the actual conditions of use
(taking account of all parts of the operating cycle such as the times
when the tool is switched off and when it is running idle in addition to
the trigger time).
Rating label explanation
Unpacking
1.
2. Remove all packing materials and shipping devices if applicable.
3. Make sure the delivery contents are complete and free of any damage. If
contact your dealer. Using an incomplete or damaged product represents a
hazard to people and property.
4. Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 19 2021/12/23 10:31 PM
TTI885IPD = Model number
TT = TITAN
I = 18V Lithium-Ion
885 = Serial Number
IPD = Cordless Impact Driver

TTI885IPD
Getting started...
EN
20
Before you start
Unpacking
WARNING! The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts! There
is a danger of choking and suffocation!
You will need
(items not supplied)
Suitable personal protective equipment
(items supplied)
Battery pack (9)
Charger (10) and its manual
NOTE: The accessories required depend on the intended application.
Ask your dealer for advice.
Assembly
WARNING! The product must be fully assembled before operation!
Do not use a product that is only partly assembled or assembled with
damaged parts!
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Do not connect the battery pack (9) to the product before it is completely
assembled!
Driver bits
Different driver bits can be used with this product depending on the screw/bolt
head.
WARNING! Always use driver bits according to the intended use! For
example, never use a slotted driver bit for crosshead screws!
Observe the technical requirements of this product (see section
Driver bits and screws/bolts become hot during use! Handle them
carefully! Wear protective gloves when handling driver bits and screws/
bolts in order to avoid injuries like burns!
MNL_18V IMPACT DRIVER_MID18-LI_IMGB_V1_211224.indd 20 2021/12/23 10:31 PM
