Titan TTB890SDR User manual

Original Instructions_MNL_TTB890SDR_GB_V01_220308
TTB890SDR
WARNING: Read the instructions before using the product!

02
EN
32
33
34
31
27
29
26
In more detail...
Product functions
Operation
Care and maintenance
Trouble shooting
Recycling and disposal
Guarantee
Declaration of conformity
25
02
03
15
17
Getting started...
Safety information
Your product
Before you start
These instructions are for your safety. Please read through them
thoroughly before use and retain them for future reference.
Let’s
get started...

03
Getting started...
EN
TTB890SDR Safety information
Safety warnings
General power tool safety warnings
Work area safety
>
>
>
WARNING Read all safety warnings, instructions,
illustrations and specifications provided with
this power tool. Failure to follow all instructions
listed below may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to
your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases
or dust. Power tools create sparks which may ignite the
dust or fumes.
Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
Electrical safety
>
>
Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfac-
es, such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body
is earthed or grounded.

04
Getting started...
EN TTB890SDR
Safety information
Personal safety
>
>
>
>
Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric
shock.
Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock
>
>
>
Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
Use personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask,
non-skid safety shoes, hard hat or hearing protection used
for appropriate conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or
energising power tools that have the switch on invites
accidents.

05
Getting started...
EN
TTB890SDR Safety information
Power tool use and care
>
>
>
>
>
Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations
Dress properly. Do not wear loose clothing or jewel-
lery. Keep your hair and clothing away from moving parts.
Loose clothes, jewellery or long hair can be caught in
moving parts.
If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
Do not let familiarity gained from frequent use of tools
allow you to become complacent and ignore tool safety
principles. A careless action can cause severe injury
within a fraction of a second.
>
>
>
Do not force the power tool. Use the correct power tool
for your application. The correct power tool will do the
job better and safer at the rate for which it was designed.
Do not use the power tool if the switch does not turn it
on and off. Any power tool that cannot be controlled with
the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or
remove the battery pack, if detachable, from the power
tool before making any adjustments, changing
accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool
accidentally.

06
Getting
started...
EN TTB890SDR
Safety information
Sander safety warnings
WARNING! Contact with or inhalation of harmful
/ toxic dusts arising from sanding lead-based
painted surfaces, woods and metals can endanger
the health of operator and bystanders!
>
>
>
>
>
Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by
poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind
and are easier to control.
Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpected situations.
Service
> Have your power tool serviced by a qualified repair
person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained.

07
Getting started...
EN
TTB890SDR Safety information
>Take special care to guard against these dusts, including
the following:
• All persons entering the work area must wear an
appropriate dust mask specially designed for protection
against harmful / toxic dusts, in addition to using the
dust extraction facility, and keeping work area well
ventilated.
• Children and pregnant women must not enter the work
area.
• Do not eat, drink or smoke in the work area.
• Any pre 1960 building may have paint containing lead
on wood or metal surfaces. If you suspect workpiece
contains lead seek professional advice.
>Some wood and wood type products especially MDF
(Medium Density Fibreboard) can produce dust that can
be hazardous to your health. We recommend the use
product in addition to using the dust extraction facility.
Vibration and noise reduction
To reduce the impact of noise and vibration emission,
limit the time of operation, use low-vibration and
low-noise operating modes as well as wear personal
protective equipment.
Take the following points into account to minimise the
vibration and noise exposure risks:
>Only use the product as intended by its design and these
instructions.
>Ensure that the product is in good condition and well
maintained.
>Use correct attachments for the product and ensure they
are in good condition.
>Keep tight grip on the handles/grip surface.

08
Getting started...
EN TTB890SDR
Safety information
Safety warnings
>Maintainthisproductinaccordancewiththeseinstructions
and keep it well lubricated (where appropriate).
>Plan your work schedule to spread any high vibration
tool use across a longer period of time.
Emergency
Familiarise yourself with the use of this product by
means of this instruction manual. Memorise the
safety directions and follow them to the letter. This
will help to prevent risks and hazards.
>Always be alert when using this product, so that you
can recognise and handle risks early. Fast intervention
can prevent serious injury and damage to property.
>Switch off and disconnect from the power supply if
there are malfunctions. Have the product checked by a
you operate it again.
Residual risks
Even if you are operating this product in accordance
with all the safety requirements, potential risks of
injury and damage remain. The following dangers
can arise in connection with the structure and design
of this product:
>Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
>Injuries and damage to property due to broken cutting
attachments or the sudden impact of hidden objects
during use.
>
objects.

09
Getting started...
EN
TTB890SDR Safety information
WARNING!Thisproduct produces an electromagnetic
circumstances interfere with active or passive medical
implants! To reduce the risk of serious or fatal injury, we
recommend persons with medical implants to consult
their doctor and the medical implant manufacturer
before operating this product!
WARNING! Some dust created by power sanding,
sawing, grinding, drilling and other construction
activities contains chemicals known to cause
cancer, birth defects or other reproductive harm.
Some examples of these chemicals are:
• Lead from lead-based paint
• Crystalline silica from bricks and cement and
other masonry products
• Arsenic and chromium from chemically treated
timber
Your risk from these exposures varies, depending
upon how often you do this type of work. To reduce
your exposure to these chemicals:
• Work in a well-ventilated area.
• Work with approved protective equipment,
such as those dust masks that are specially
>
ADDITIONAL SAFETY WARNING FOR CONSTRUCTION
DUST
The updated Control of Substances Hazardous to Health
Regulations 1st October 2012 now also targets to reduce
the risks associated with silica, wood and gypsum dusts.
The following information applies to professional users only
but is good practice for all users:

>Lung cancer Silicosis Chronic Obstructive Pulmonary
Disorder (Chronic obstructive pulmonary disease (COPD)
And breathing in fine particles of wood dust can lead to
the development of Asthma The risk of lung disease is
linked to people who regularly breathe construction dust
over a period of time, not on the odd occasion.
Getting
started...
EN TTB890SDR
Safety information
10
>
How to reduce the amount of dust?
Reduce the amount of cutting by using the best sizes
of building products.
These limits are not a large amount of dust: when
compared to a penny it is tiny – like a small pinch of salt:
This limit is the legal maximum; the most you can breathe
after the right controls have been used.
To protect the lung, the COSHH Regulations sets a limit
on the amount of these dusts that you can breathe (called
a Workplace Exposure Limit or WEL) when averaged over
a normal working day.
1.
Safety warnings
>
>
Construction workers are one of the at-risk groups within
this because of the dust that they breathe: silica dust is
not just a nuisance; it is a real risk to your lungs!
Silica is a natural mineral present in large amounts in
things like sand, sandstone and granite. It is also
commonly found in many construction materials such as
concrete and mortar. The silica is broken into very fine
dust (also known as Respirable Crystalline Silica or RCS)
during many common tasks such as cutting, drilling
and grinding Breathing in very fine particles of crystalline
silica can lead to the development of:

11
Getting started...
EN
TTB890SDR Safety information
• Arsenic and chromium from chemically treated timber.
Your risk from these exposures varies, depending upon how
often you do this type of work. To reduce your exposure to
these chemicals:
• Work in a well-ventilated area.
• Work with approved safety equipment, such as those dust
masks that are specially designed to filter microscopic
particles.
Please always work with approved safety equipment,
such as those dust masks that specially designed to filter
out microscopic particles and use the dust extraction
facility at all time.
For more information please see the HSE website:
http://www.hse.gov.uk/construction or
http://www.hse.gov.uk/pubns/cis69.pdf
Use a less powerful tool e.g. a block cutter instead of
angle grinder.
Using a different method of work altogether – e.g.
using a nail gun to direct fasten cable trays instead of
drilling holes first.
3.
2.
Warning: Some dust particles created by power
sanding, sawing, grinding, drill and other construction
jobs contain chemicals known to cause cancer, birth
defects or other reproductive harm. Some examples of
these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks and cement and other
masonry products.

VIBRATION
The European Physical Agents (Vibration) Directive has
been brought in to help reduce hand arm vibration
syndrome injuries to power tool users. The directive
requires power tool manufacturers and suppliers to provide
indicative vibration test results to enable users to make
informed decisions as to the period of time a power tool
can be used safely on a daily basis and the choice of tool.
Getting
started...
EN TTB890SDR
Safety information
12
The declared vibration emission value should be used as
a minimum level and should be used with the current
guidance on vibration.
Calculating the actual period of the actual period off use
can be difficult and the HSE website has further information.
The declared vibration emission been measured in
accordance with a standardised test stated above and
may be used to compare one tool with another tool.
The declared vibration emission value may also be used
in a preliminary assessment of exposure.
Warning: The vibration emission value during actual
use of the power tool can differ from the declared value
depending on the ways in which the tool is used
dependant on the following examples and other variations
on how the tool is used:
How the tool is used and the materials being cut or drilled.
Safety warnings

And the tool is being used as intended by its design and
these instructions.
The tightness of the grip on the handles.
The use the correct accessory for the tool and ensuring it is
sharp and in good condition.
The tool being in good condition and well maintained.
13
Getting started...
EN
TTB890SDR Safety information
All employees should be part of an employer’s health
surveillance scheme to help identity any vibration related
diseases at an early stage, prevent disease progression
and help employees stay in work.
Health surveillance
While working with this power tool, hand/arm vibrations
occur. Adopt the correct working practices in order to
reduce the exposure to vibration. This tool may cause
hand-arm vibration syndrome if its use is not adequately
managed.
Helping to minimise your vibration exposure risk. ALWAYS
use sharp chisels, drills and blades.
Maintain this tool in accordance with these instructions and
keep well lubricated (where appropriate).
Avoid using tools in temperatures of 10ºC or less. Plan your
work schedule to spread any high vibration tool use
across a number of days.
Warning: Identify safety measures to protect the operator
that are based on an estimation of exposure in the actual
conditions of use (taking account of all parts of the operating
cycle such as the times when the tool is switched off and when
it is running idle in addition to the trigger time). Note The use of
other tools will reduce the users’ total working period on this tool.

Getting
started...
EN TTB890SDR
Safety information
14
Symbols
others the following symbols and abbreviations. Familiarize yourself with them to
reduce hazards like personal injuries and damage to property.
V~ Volt, (alternating voltage) mm Millimetre
Hz Hertz kg Kilogram
W Watt dB(A) Decibel (A-rated)
/min or min-1 Per minute m/s² Metres per seconds squared
Lock / to tighten or
secure.
Unlock / to loosen.
Note / Remark. Caution / Warning.
Read the instruction
manual.
Wear hearing protection.
Wear eye protection. Wear a dust mask.
Wear protective gloves. Wear protective, slip-
resistant footwear.
yyWxx Manufacturing date code; year of manufacturing (20yy) and week of
manufacturing (Wxx)
Switch the product off and disconnect it from the power supply
before assembly, cleaning, adjustments, maintenance, storage and
transportation.
This product is of protection class II. That means it is equipped with
enhanced or double insulation.
The product complies with the applicable European directives and
an evaluation method of conformity for these directives was done.
WEEE symbol. Waste electrical products should not be disposed of
with household waste. Please recycle where facilities exist. Check
with your Local Authority or local store for recycling advice.
UK Conformity Assessed.

Getting started...
EN
TTB890SDR Your product
15
Your product
1. Speed dial
2. Gripping surface
3. Air vents
4. On/off switch
5. Handle
6. Power cord with plug
7. Vacuum adaptor
a. Tongue
8. Dust bag assembly
a. Dust bag
b. Tongue
c. Connector
9. Dust extraction outlet
a. Groove*
10. Base plate
11. Clamp lever (x 2)
12. Clamp bar (x 2)
13. Sanding paper
(60# x1, 120# x 1, 240# x 1)
14. Hole punch
NOTE: Parts marked with * are not shown in this overview. Please
refer to the respective section in the instruction manual.
7
7a
8a
13 14
8b
8c
1 2 3 4 5 6
9
1011
12

Getting started...
EN TTB890SDR
Your product
16
General
> Rated voltage, frequency : 220 – 240 V~, 50 Hz
> Rated power input : 300 W
> Rated no load speed n0:6000 – 11000 min-1
> Protection class : II
> Weight : approx. 2.2 kg
> :hook & loop, or clamp
> Base plate dimension : approx. 115 x 230 mm
Sound values
>Sound pressure level LpA :79.9 dB (A)
>Sound power level LWA :90.9 dB (A)
>Uncertainty KpA , KWA :3 dB (A)
Hand arm vibration values
>Hand arm vibration ah:16.95 m/s 2
>Uncertainty K : 1.5 m/s2
RATING LABEL EXPLANATION
TTB890SDR = Model number
TT = TITAN
B = 220-240V ~
890 = Serial Number
SDR = 1/2 sheet sander
The sound values have been determined according to noise test code given in
EN 62841-1, using the basic standards EN ISO 11203 and EN ISO 3744.
The sound intensity level for the operator may exceed 80 dB(A) and ear
protection measures are necessary.
The declared vibration value and noise value has been measured in accordance
with a standard test method (according to EN 62841-2-4) and may be used for
comparing one product with another. The declared vibration value and noise
value may also be used in a preliminary assessment of exposure.
WARNING! The vibration and noise emissions during actual use of the
power tool can differ from the declared values depending on the ways
in which the tool is used especially what kind of workpiece is
processed; and need to identify safety measures to protect the operator
that are based on an estimation of exposure in the actual conditions of
use (taking account of all parts of the operating cycle such as the times
when the tool is switched off and when it is running idle in addition to
the trigger time).

Getting started...
EN
TTB890SDR Before you start
17
Unpacking
>
> Remove all packing materials and shipping devices, if applicable.
> Make sure the delivery contents are complete and free of any damage. If you
your dealer. Using an incomplete or damaged product represents a hazard to
people and property.
> Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
WARNING! The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts! There
is a danger of choking and suffocation!
You will need
(items not supplied)
Suitable personal protective equipment
(items supplied)
Vacuum adaptor (7)
Dust bag assembly (8)
Sanding paper (13)
Hole punch (14)
Setup
WARNING! The product must be fully assembled before operation!
Do not use a product that is only partly assembled or assembled with
damaged parts!
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Do not connect the product to power supply before it is completely
assembled!

Getting
started...
EN TTB890SDR
Before you start
18
Sanding paper
Choosing the right sanding paper
Sanding papers are available with different grain sizes (grit). The grain size is
indicated with a number on the back side of the sanding paper, the higher the
coarse < P100 removal of paint and varnish, preparation of rough
surfaces
> P180
> Only use suitable sanding papers in terms of application and size. Do not use
the papers that are bigger than the base plate of the product.
> Replace worn or damaged sanding papers immediately.
>
a satisfactory result.
> Do not use the same sanding paper on different materials, e. g. do not use the
sanding paper that has been used for sanding metal to sand wood. Small metal
particles remaining in the sanding paper will lead to scratches.
>
extraction.
Hook-and-loop system
With the hook-and-loop system, sanding papers are simply pressed on the base
plate and removed by pulling off.
Attaching
> Align the hole pattern of the sanding
paper (13) with the one in the base
plate (10) before attaching the
sanding paper (13) to the plate to
satisfactory result.
> Slightly press the sanding paper (13)
Fig. 1
10
13

Getting started...
EN
TTB890SDR Before you start
19
Removing / Replacing
> Grip one corner of the sanding paper (13) and pull it off the base plate (10)
(Fig. 2).
> Attach a new sanding paper as required.
Fig. 2
Clamp system
With the clamp system, standard non hook-and-loop type sanding paper can be
held by clamp bars (12) at the front and rear of the product.
Attaching
> Pull the clamp lever (11) upwards to disengage it (Fig. 3, step 1).
> Press the clamp lever (11) downwards along the base plate (10) to open the
clamp bar (12) (Fig. 4, step 2).
Fig. 3 Fig. 4
1.
2.
10
13
2.
11
12
10
1.
11

Getting started...
EN TTB890SDR
20
Before you start
Sanding paper
> Align one end of the sanding paper (13) to one of the clamp bars (12) and hold
it in position (Fig. 5).
Fig. 5
> Pull the clamp lever (11) upwards along the base plate (10) and then press it
down to engage it (Fig. 6).
Fig. 6
> Tighten the sanding paper (13) and
clamp bar (12) (Fig. 7).
Fig. 7
13
13
12
1.
10
11
2.
12
13
