Titan TTB910SDR User manual

Original Instructions_MNL_TTB910SDR_GB_V1_220119
400W Precision
File Belt Sander
TTB910SDR
EAN:5059340252926
WARNING: Read the instructions before using the product!

GB
IE
29
30
31
29
25
23
21
In more detail...
Product functions
Operation
Care and maintenance
Trouble shooting
Recycling and disposal
Guarantee
Declarations of conformity
20
02
03
11
13
Getting started...
Safety information
Your product
Before you start
These instructions are for your safety. Please read through them
thoroughly before use and retain them for future reference.
Let’s
get started...
02

03
Getting started...
GB
IE
TTB910SDR by TITAN Safety information
Safety warnings
General power tool safety warnings
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose
control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Unmodified
plugs and matching outlets will reduce risk of electric
shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators,ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
WARNING!Read all safety warnings,
instructions, illustrations and specifications
provided with this power tool. Failure to follow all
instructions listed below may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or
battery-operated (cordless) power tool.

04
Getting started...
GB
IE
Safety information
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as a dust
mask, non-skid safety shoes, hard hat or hearing
protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch is
in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch
TTB910SDR by TITAN

05
Getting started...
GB
IE
Safety information
on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result
in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control of
the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
4) Power tool use and care
a) Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power source and/or
remove the battery pack, if detachable, from the
power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting
the power tool accidentally.
TTB910SDR by TITAN

06
Getting started...
GB
IE
Safety information
Safety warnings
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use.Many accidents are caused
by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
h) Keep handles and grasping surfaces dry, clean and
free from oil and grease.Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
5) Service
a) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is
maintained.
TTB910SDR by TITAN

Getting started...
GB
IE
07
Safety information
WARNING! Contact with or inhalation of harmful /
toxic dusts arising from sanding lead-based painted
surfaces, woods and metals can endanger the
health of operator and bystanders!
>Take special care to guard against these dusts, including
the following:
•All persons entering the work area must wear an
appropriate dust mask specially designed for protection
against harmful / toxic dusts, in addition to using the
dust extraction facility, and keeping work area well
ventilated.
•Children and pregnant women must not enter the work
area.
•Do not eat, drink or smoke in the work area.
•Any pre 1960 building may have paint containing lead
on wood or metal surfaces. If you suspect workpiece
contains lead seek professional advice.
>Some wood and wood type products especially MDF
(Medium Density Fibreboard) can produce dust that can
be hazardous to your health. We recommend the use
of a dust mask with replaceable filters when using this
product in addition to using the dust extraction facility.
because the sanding surface may contact its own
cord. Cutting a "live" wire may make exposed metal
parts of the power tool "live" and could give the
operator an electric shock.
Vibration and noise reduction
To reduce the impact of noise and vibration emission,
limit the time of operation, use low-vibration and
TTB910SDR by TITAN
Belt sander and drum sander safety warnings
Hold the power tool by insulated gripping surfaces,

Safety information
Getting started...
GB
IE
08
Safety warnings
>Use correct attachments for the product and ensure they
are in good condition.
>Keep tight grip on the handles/grip surface.
>Maintainthisproductinaccordancewiththeseinstructions
and keep it well lubricated (where appropriate).
>Plan your work schedule to spread any high vibration
tool use across a longer period of time.
Emergency
Familiarise yourself with the use of this product by
means of this instruction manual. Memorise the safety
directions and follow them to the letter. This will help
to prevent risks and hazards.
>Always be alert when using this product, so that you can
recognise and handle risks early. Fast intervention can
prevent serious injury and damage to property.
>Switch off and disconnect from the power supply if
there are malfunctions. Have the product checked by a
qualified professional and repaired, if necessary, before
you operate it again.
Take the following points into account to minimise
the vibration and noise exposure risks:
>Only use the product as intended by its design and these
instructions.
>Ensure that the product is in good condition and well
maintained.
Residual risks
Even if you are operating this product in accordance
with all the safety requirements, potential risks of
low-noise operating modes as well as wear personal
protective equipment.
TTB910SDR by TITAN

Getting started...
GB
IE
09
Safety information
>Danger of injury and property damage caused by flying
objects.
WARNING! This product produces an
electromagnetic field during operation! This field
may under some circumstances interfere with
active or passive medical implants! To reduce
the risk of serious or fatal injury, we recommend
persons with medical implants to consult their
doctor and the medical implant manufacturer
before operating this product!
>
>
ADDITIONAL SAFETY WARNING FOR CONSTRUCTION
DUST
The updated Control of Substances Hazardous to Health
Regulations 1st October 2012 now also targets to reduce
the risks associated with silica, wood and gypsum dusts.
Construction workers are one of the at-risk groups within
this because of the dust that they breathe: silica dust is
not just a nuisance; it is a real risk to your lungs!
>Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
>Injuries and damage to property due to broken
attachments or the sudden impact of hidden objects
during use.
The following information applies to professional users
only but is good practice for all users:
injury and damage remain. The following dangers can
arise in connection with the structure and design of
this product:
TTB910SDR by TITAN

Safety information
Getting started...
GB
IE
10
Safety warnings
>Lung cancer Silicosis Chronic Obstructive Pulmonary
Disorder (Chronic obstructive pulmonary disease (COPD)
And breathing in fine particles of wood dust can lead to
the development of Asthma The risk of lung disease is
linked to people who regularly breathe construction dust
over a period of time, not on the odd occasion.
>
How to reduce the amount of dust?
Reduce the amount of cutting by using the best sizes
of building products.
Use a less powerful tool e.g. a block cutter instead of
angle grinder.
Using a different method of work altogether – e.g.
using a nail gun to direct fasten cable trays instead of
drilling holes first.
To protect the lung, the COSHH Regulations sets a limit
on the amount of these dusts that you can breathe (called
a Workplace Exposure Limit or WEL) when averaged over
a normal working day.
These limits are not a large amount of dust: when
compared to a penny it is tiny – like a small pinch of salt:
This limit is the legal maximum; the most you can breathe
after the right controls have been used.
3.
2.
1.
>Silica is a natural mineral present in large amounts in
things like sand, sandstone and granite. It is also
commonly found in many construction materials such as
concrete and mortar. The silica is broken into very fine
dust (also known as Respirable Crystalline Silica or RCS)
during many common tasks such as cutting, drilling
and grinding Breathing in very fine particles of crystalline
silica can lead to the development of:
TTB910SDR by TITAN

Getting started...
GB
IE
11
Safety information
•Arsenic and chromium from chemically treated timber.
Your risk from these exposures varies, depending upon how
often you do this type of work. To reduce your exposure to
these chemicals:
•Work in a well-ventilated area.
•Work with approved safety equipment, such as those dust
masks that are specially designed to filter microscopic
particles.
For more information please see the HSE website:
http://www.hse.gov.uk/construction or
http://www.hse.gov.uk/pubns/cis69.pdf
Warning: Some dust particles created by power
sanding, sawing, grinding, drill and other construction
jobs contain chemicals known to cause cancer, birth
defects or other reproductive harm. Some examples of
these chemicals are:
•Lead from lead-based paints.
•Crystalline silica from bricks and cement and other
masonry products.
VIBRATION
The European Physical Agents (Vibration) Directive has
been brought in to help reduce hand arm vibration
syndrome injuries to power tool users. The directive
requires power tool manufacturers and suppliers to provide
indicative vibration test results to enable users to make
informed decisions as to the period of time a power tool
can be used safely on a daily basis and the choice of tool.
Please always work with approved safety equipment,
such as those dust masks that specially designed to filter
out microscopic particles and use the dust extraction
facility at all time.
TTB910SDR by TITAN

Safety information
Getting started...
GB
IE
12
Safety warnings
The declared vibration emission value should be used as
a minimum level and should be used with the current
guidance on vibration.
Calculating the actual period of the actual period off use can
be difficult and the HSE website has further information.
The declared vibration emission been measured in
accordance with a standardised test stated above and may
be used to compare one tool with another tool.
The declared vibration emission value may also be used in
a preliminary assessment of exposure.
Warning: The vibration emission value during actual use
of the power tool can differ from the declared value depending
on the ways in which the tool is used dependant on the
following examples and other variations on how the tool is
used:
How the tool is used and the materials being cut or drilled.
And the tool is being used as intended by its design and
these instructions.
The tightness of the grip on the handles.
The use the correct accessory for the tool and ensuring it is
sharp and in good condition.
The tool being in good condition and well maintained.
While working with this power tool, hand/arm vibrations
occur. Adopt the correct working practices in order to
reduce the exposure to vibration. This tool may cause
hand-arm vibration syndrome if its use is not adequately
managed.
TTB910SDR by TITAN

Getting started...
GB
IE
13
Safety information
All employees should be part of an employer’s health
surveillance scheme to help identity any vibration related
diseases at an early stage, prevent disease progression and
help employees stay in work.
Health surveillance
Helping to minimise your vibration exposure risk. ALWAYS
use sharp chisels, drills and blades.
Maintain this tool in accordance with these instructions and
keep well lubricated (where appropriate).
Avoid using tools in temperatures of 10ºC or less. Plan your
work schedule to spread any high vibration tool use
across a number of days.
Warning: Identify safety measures to protect the
operator that are based on an estimation of exposure in the
actual conditions of use (taking account of all parts of the
operating cycle such as the times when the tool is switched
off and when it is running idle in addition to the trigger time).
Note The use of other tools will reduce the users’ total
working period on this tool.
TTB910SDR by TITAN

Safety information
Getting started...
GB
IE
14
Symbols
On the product, the rating label and within these instructions you will find among
others the following symbols and abbreviations. Familiarize yourself with them to
reduce hazards like personal injuries and damage to property.
V~ Volt, (alternating voltage) mm Millimetre
Hz Hertz kg Kilogram
W Watt dB(A) Decibel (A-rated)
/min or min-1 Per minute m/s² Metres per seconds squared
Lock / to tighten or
secure. Unlock / to loosen.
Note / Remark. Caution / Warning.
Read the instruction
manual. Wear hearing protection.
Wear eye protection. Wear a dust mask.
Wear protective gloves. Wear protective, slip-
resistant footwear.
yyWxx Manufacturing date code; year of manufacturing (20yy) and week
of manufacturing (Wxx)
Switch the product off and disconnect it from the power supply
before assembly, cleaning, adjustments, maintenance, storage
and transportation.
This product is of protection class II. That means it is equipped
with enhanced or double insulation.
The product complies with the applicable European directives and
an evaluation method of conformity for these directives was done.
WEEE symbol. Waste electrical products should not be disposed
of with household waste. Please recycle where facilities exist.
Check with your Local Authority or local store for recycling advice.
TTB910SDR by TITAN
UK Conformity Assessed.

Getting started...
GB
IE
15
Your product
Your product
8765431 2 9 10
11
12
13
14
15
16
17b
1. Front roller
2. Sanding belt
3. Sanding arm
a. Spring*
b. Holder*
c. Support*
d. Pin*
4. Clamp lever
5. Tracking adjustment knob
6. Drive roller
7. Locking lever
8. Speed dial
9. Handle
10. Power cord with plug
11. Lock-on button
12. On/off switch
13. Rear hand guard
14. Motor housing
15. Air vents
16. Dust extraction outlet
17. Dust bag assembly
a. Dust bag
b. Connector
c. Frame*
d. Zipper*
NOTE: Parts marked with * are not shown in this overview. Please refer
to the respective section in the instruction manual.
TTB910SDR by TITAN
17a

Getting started...
GB
IE
16
Your product
Technical specification
General
> Rated voltage, frequency
> Rated power input
> Rated no load speed n0
> Protection class
> Weight
> Sanding belt dimensions
: 230 – 240 V~, 50 Hz
: 400 W
: 300 - 1700 m/min
: II
: approx. 2.0 kg
: approx. 9 x 457 mm
approx. 13 x 457 mm
Sound values
> Sound pressure level LpA :79.7 dB(A)
> Sound power level LWA :90.7 dB(A)
> Uncertainty KpA, KWA :3 dB(A)
Hand arm vibration values
> Hand arm vibration ah:3.467 m/s2
> Uncertainty K : 1.5 m/s2
The sound values have been determined according to noise test code given
in EN 62841-1 and EN 62841-2-4, using the basic standards EN ISO 3744
and EN ISO 11203.
The sound intensity level for the operator may exceed 80 dB(A) and ear protection
measures are necessary.
The declared vibration value has been measured in accordance with a
standard test method (according to EN 62841-2-4) and may be used for
comparing one product with another. The declared vibration value may also
be used in a preliminary assessment of exposure.
WARNING! Depending on the actual use of the product the vibration
values can differ from the declared total. Adopt proper measures to
protect yourself against vibration exposures. Take the whole work
process including times the product is running under no load or
switched off into consideration.
Proper measures include among others regular maintenance and care
of the product and accessories, keeping hands warm, periodical breaks
and proper planning of work processes.
RATING LABEL EXPLANATION
TTB910SDR = MODEL NUMBER
TT - Titan
B - 220-240 V~
910 - Sequential code
SDR - Sander
TTB910SDR by TITAN

Getting started...
GB
IE
17
Before you start
Unpacking
> Unpack all parts and lay them on a flat, stable surface
> Remove all packing materials and shipping devices, if applicable.
> Make sure the delivery contents are complete and free of any damage. If you
find that parts are missing or show damage do not use the product but contact
your dealer. Using an incomplete or damaged product represents a hazard to
people and property.
> Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
WARNING! The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts! There
is a danger of choking and suffocation!
You will need
(items not supplied)
Suitable personal protective equipment
(items supplied)
Sanding arm (3)
Spring (3a)
Tracking adjustment knob (5)
Dust bag assembly (17)
Sanding belt (13 x 457 mm,
60# x 3, 80# x 3, 120# x 3) (2)
Setup
WARNING! The product must be fully assembled before operation!
Do not use a product that is only partly assembled or assembled with
damaged parts!
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Do not connect the product to power supply before it is completely
assembled!
TTB910SDR by TITAN

Getting started...
GB
IE
18
Before you start
Sanding arm assembly
> Place the spring (3a) in the holder
(3b) and keep it in position.
> Align the pin (3d) with the spring
and attach the sanding arm (3)
onto the support (3c).
> Secure the connection by
tightening the tracking adjustment
knob (5) (Fig. 1).
3d
3a
3c
3b
3
5
Fig. 1
Sanding belt
Choosing the right sanding belt
Sanding belts are available with different grain sizes (grit). The grain size is
indicated with a number on the reverse of the sanding belt, the higher the number
the finer the grain size
coarse < P100 removal of paint and varnish, preparation of rough surfaces
fine > P180 finishing, cleaning plaster and water stain from wood
> Only use suitable sanding belts in terms of application and size.
> Replace worn or damaged sanding belts immediately.
> Start with a coarse sanding belt and finish with a fine-grained one to achieve a
satisfactory result.
> Do not use the same sanding belt on different materials, e. g. do not use the
sanding belt that has been used for sanding metal to sand wood. Small metal
particles remaining in the sanding belt will lead to scratches.
Attaching
> Pull the clamp lever (4) backward all the way out (Fig. 2, step 1).
TTB910SDR by TITAN

Getting started...
GB
IE
Before you start
19
> Pay attention to the rotational direction indicated on the inside of the sanding
belt (2). Align the sanding belt (2) in accordance with the direction indicated on
the product housing and slide it over the front roller (1) and the drive roller (6)
(Fig. 2, step 2).
> Press the clamp lever (4) back in. Slightly pull on the sanding belt (2) to test if
it sits properly in place (Fig. 3).
14
6
2
2.
1.
4
2
Fig. 2 Fig. 3
Belt position
> Make sure the on/off switch (12) is in its off position. Then connect the plug with
a suitable socket.
> Hold the product securely and press the on/off switch (12) then release it.
The sanding belt rotates for a short period to check the correct position.
NOTE: Refer to “Product functions / Operation” for more information
about operating this product!
> Whilst the sanding belt is running, adjust the tracking adjustment knob (5) to
align the sanding belt to the centre of the rollers (1, 6).
> Turn the tracking adjustment knob (5) clockwise to adjust the sanding belt (2)
to the right (Fig. 4).
> Turn the tracking adjustment knob (5) anticlockwise to adjust the sanding belt
(2) to the left (Fig. 5).
TTB910SDR by TITAN

Before you start
Getting started...
GB
IE
20
Sanding belt
2
5
2
5
Fig. 4 Fig. 5
> Disconnect the product from the power supply before performing further
assembly and adjustment.
Removing/Replacing
> Pull the clamp lever (4) backward
all the way out and remove the
sanding belt (2) (Fig. 6).
> Attach a new sanding belt (2) as
required.
4
2
2.
1.
Fig. 6
Dust extraction
WARNING! Attach the dust bag or a dust extraction device when using
this product to sand wood in order to keep the working area clean!
Wear a dust mask when operating this product! Dust can be harmful to
health! Especially dust and chips of wood that has been treated, e.g.
with a wood preservative or stain!
WARNING! Do not use the dust bag when sanding metal! The hot
metal particles could cause residual wood dust or the bag itself to catch
fire
TTB910SDR by TITAN
