Titanium Strength XR6255 User manual

HD Power Rack
Model #: XR6255
OWNER’S MANUAL
Caution: Read all precautions and
instructions in this manual before using
this equipment. Save this manual for
future reference.
!

Contents
Assembly Instructions
Contents
Before You Begin
Assembly Steps
1
2
3-6
Parts & Hardware List 7
Page 1

Before Your Begin
Assembly Instructions
Page 2
This exercise equipment is built for optimum safety. Be sure to read the entire
manual before you assemble or operate your equipment. Please note the following
safety precautions:
1. Keep children and pets away from the equipment at all times. Do not leave
children unattended in the same room with the equipment.
2. Only one person at a time should use the equipment.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal
symptoms STOP the workout at once.
CONSULT A PHYSICIAN IMMEDIATELY.
4. Position the equipment on a clear, level surface. DO NOT use the bench
near water or outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT
wear robes or other clothing that could become caught in the equipment.
7. Use the equipment only for its intended use as described in this manual.
DO NOT use attachments not recommended by the manufacturer.
8. Before using the equipment, always do stretching exercises to properly warm up.
9. Never operate the equipment if the equipment is not functioning properly.
Tools Required
Tools Required : Allen Wrentch Set / Socket Wrentch Set
Adjustable Wrentch / Crescent Wrench
Rubber Mallet / Tape Measure
ASSEMBLY REQUIRES AT LEAST THREE PERSONS

Assembly Instructions
Page 3
STEP 1
1
2
2x
3
4
5
H10-2
x6
W10
8x
H10-2
28
17
6x
N12
4x
H12-18
x4
W12
x8

Assembly Instructions
Page 4
STEP 2
6
2x
H12-3
x4
W12
12x
H12-17
8x
BW12
8x
N12
8x
7
2x
20
8x
26
2x
25
6x
19
8x
H10-2
x8
W10
x8

Assembly Instructions
Page 5
STEP 3
8
9
10
2x
27
4x
N12
8x
H12-18
x4
H12-17
x6
W12
x16
BW12
x2
W10
4x 4x
H10-2

Assembly Instructions
Page 6
STEP 4
18 x4
15
11
14
13
16
22
12
21
P10-4
6x
F6-2
A6-1
x6
242x
23 x2
18 x8
24 x4
x2
x2 x8
W10
4x 4x
H10-2

Assembly Instructions
Page 7
Parts & Hardware List
Part# Discription Qty Remark
1 Right Base 1
2 Left Base 1
3 Right Rear Support 1
4 Left Rear Support 1
5 Bottom Cross Frame 1
6 Front Upright Frame 2
7 Rear Upright Frame 2
8 Top Cross Frame 1
9 Top Rear Cross Frame 1
10 Top Side Frame 2
11 Right J-Hook 1
12 Left J-Hook 1
13 Right Handle 1
14 Left Handle 1
15 Right Spotting Arm 1
16 Left Spotting Arm 1
17 Bottom Rubber Band Hook 6
18 Plastic Cover 12 Pre-assembled
19 Dia 48mm Inner Cap 8 Pre-assembled
20 Plate Bumper Ring 8
21 Dia 30mm Inner Cap 2 Pre-assembled
22 Spotting Arm Cover 2 Pre-assembled
23 J-Hook Cover 2 Pre-assembled
24 Magnet 6 Pre-assembled
25 Plate Storage Holder 6
26 Short Plate Storage Holder 2
27 Top Rubber Band Hook 4
28 Bar Storage Holder 1
A6-1 Allen Bolt M6x10 6 Pre-assembled
F6-2 Flat Head Bolt M6x15 8 Pre-assembled
P10-4 Positioning Bolt M10x30 6 Pre-assembled
H10-2 Hex Head Bolt M10x20 24
H12-3 Hex Head Bolt M12x25 4
H12-17 Hex Head Bolt M12x95 14
H12-18 Hex Head Bolt M12x100 8
W10 M10 Washer 24
BW12 M12 Big Washer 10
W12 M12 Washer 36
N12 M12 Nut 20

We warrants this product to be free from defects in workmanship and
materials under normal use and conditions for a period of
1 year FROM THE
DATE OF ORIGINAL PURCHASE. This Limited Warranty is not transferable
and is available only for the original purchaser of the product. The company’s
obligation under this warranty is limited to replacing or repairing the product,
at the discretion of the company.
This Limited Warranty is void if the product is:
Damaged through improper use, negligence, abuse, misuse, transportation
damage, act of nature, or accident, include failure to follow the assembly and or
operation instructions supplied with the product.
Used in commercial or rental applications.
Modified or repaired by anyone not authorized by the company.
This Limited Warranty does not cover expendable items including but not limited to:
Batteries, light bulbs, fuses, accessories, and other items that experience wear as a
result of normal use.
Limited Warranty
