Titon SR700 User manual

EN
Product User Manual
Single Room Heat Recovery Ventilation Controller Unit
Single Room Heat Recovery Ventilation Fan Unit
ventilation systems
SR700 SRHRV Fan TP600
SRC1 Controller TP590

2
Warnings, Safety Information and Guidance
Important Information
Read these instructions fully before the installation of this
appliance
1. Installation of the appliance and accessories must be carried out
by a qualied and suitable competent person and be carried out
in clean, dry conditions where dust and humidity are at minimal
levels.
2. This manual covers the installation of the Single Room Heat Re-
covery Ventilation (SRHRV) Fan Unit and SRC1 Controller Unit.
3. All wiring must conform to current I.E.E. Wiring Regulations and all
applicable standards and Building Regulations.
4. Inspect the appliance. If damaged, it must be replaced by the
manufacturer or their service agent in order to avoid a hazard.
5. The appliance must be connected to a local all pole isolation
switch with a contact separation of at least 3mm.
6. The SRC1 Controller Unit is suitable for 220-240V ~ 50-60Hz single
phase with a fuse rating of 3A.
7. Control & communication cable - Titon recommends the use of
unshielded CAT5e cable to comply with EMC directives.
8. Control & communication cables should not be placed within
50mm or on the same metal cable tray as any mains lighting or
power cables.
9. The unit must be stored in a clean and dry environment.
10. Do not install the appliance in areas where the following may be
present or occur:
o Excessive moisture, oil or grease laden atmosphere;
o Corrosive or ammable gases, liquids or vapours;
o Ambient temperatures above 40°C or below -5°C;
o Humidity levels above 90%;
o A wet environment.

3
11. The appliance is not suitable for installation to the exterior of the
dwelling.
12. This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appli-
ance in a safe way and understand the hazards involved. Children
should be supervised to ensure that they do not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
13. Ensure that external grilles are located away from any ue outlet,
in accordance with relevant Building Regulations.
14. The unit must not be connected to a tumble dryer or a cooker
hood.
15. Precautions must be taken to avoid the back-ow of gases into the
room from an open ue appliance.
16. Ensure ducting is free from debris and blockages before switching
on the units.
17. Before cleaning, power down the ventilation system and wait suf-
cient time for the Fans to stop rotating before starting cleaning.

4
Contents
When this document is viewed
as a PDF the headings & sub
headings on this page are hyper
links to the content. Additionally the page
numbers in this document are hyper links
back to this contents page.
Warnings, Safety Information and Guidance
Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Information
Dimensions & Component Identication . . . . . . . . . . . . . 6
Controller Operation
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Heat Recovery Mode . . . . . . . . . . . . . . . . . . . . . . . . . 9
Cross Ventilation Mode . . . . . . . . . . . . . . . . . . . . . . . 9
Fan Speeds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Timed Intensive Ventilation . . . . . . . . . . . . . . . . . . . 9
Sleep Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Sensor Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Filter Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Other Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Sensor Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Maintenance
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
SRHRV Fan Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Diuser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Wiring Aperture Cover. . . . . . . . . . . . . . . . . . . . . . . 11
Air Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Heat Cells . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Foam Fly Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Vent Tube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Reassembly after Cleaning. . . . . . . . . . . . . . . . . . . 12
Replacement Filters. . . . . . . . . . . . . . . . . . . . . . . . . 12
SRC1 Controller Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Service Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

5
Product Information
Designed to be used in pairs and in conjunction with a SRC1 the SR700s create a balanced
decentralised ventilation system with heat recovery. As part of a system multiple units provide
continual air circulation for your home, extracting stale moist air and replacing it with warmed fresh
air from outside.
The system provides an easily installed and maintainable solution for removing internal
condensation and eliminating mould growth within the home. Unlike regular extractor fans that
waste 100% of heat that passes through them from the home, the SR700 system will recover up to
94%, based on in house testing, of wasted heat. When used as part of a whole house system it can
be used to recover heat or provide continuous fresh air without heat recovery.
SRHRV System Layout

6
Packaging Contents
Inspect the units when taking delivery. Check the units for damage and that all accessories have
been supplied.
SRC1 Controller Unit
Package supplied with:
SRC1 Controller Unit x 1;
Product User Manual x 1.
Install / Commissioning leaet x 1.
Dimensions & Component Identication
Fan Unit
711 34.5 Ø220.4
Ø180
Controller Unit
80
60.8
80 12 36

7
1
2
3
4
4
5
6
6
9
7
8
10
11
No. Component
1 Diuser*
2 Bezel
3 Wiring Aperture Cover
4 Spring Steel Clip
5 Air Filter
6 Heat Cell
No. Component
7 Fan with Connectors
8Vent Tube
9 Foam Strip Seal positions (not supplied)
10 Foam Fly Screen
11 External Louvre
SRHRV Fan Unit ‑Components
*Front face may have protective lm. If present, please remove.

8
Controller Operation
Introduction
The controller has 2 modes of operation, Heat Recovery- which is the default and Cross Ventilation.
These are selected via the buttons on the left hand side of the controller. LEDs 1 and 2 indicate the
currently selected mode.
Controller
Increase
Speed
Cross
Ventilation
Decrease
Speed
Heat
Recovery
Humidity protection
Cross ventilation
Heat recovery
Error
Reduced speed
Medium speed
Intensive speed

9
Heat Recovery Mode
In Heat Recovery Mode the Supply and Extract fans change directions at regular intervals, warming
the Heat Cell when extracting from the property and recovering the stored heat when supplying air
to the property. This is the default operating mode.
Cross Ventilation Mode
In warm weather when heat recovery is not required Cross Ventilation mode simply supplies air to
one side of the property and extracts from the other to create a cooling ow of air. By default Cross
Ventilation is continuous, but it may have a timer congured by the installer (4, 8, 12 or 24 Hours).
If a timer has been selected this will be indicated by LED 1 slowly ashing and once the timer has
expired the controller will return to Heat Recovery mode. A second press of the Cross Ventilation
button switches from timer to continuous.
Fan Speeds
By default the fans run at Nominal level which is indicated by LED 6. For normal use there are 2
other speeds, Intensive and Reduced which can be selected using the up and down arrows on the
right hand side of the controller. LEDs 5 and 7 will indicate when these speeds have been selected.
Additionally there is another speed – Humidity Protection which is below Reduced Speed and is
indicated by LED 4 being dimly lit. It is only recommended to use this level when the property is
unoccupied. In some installations the fans can be switched o by pressing the down arrow whilst at
Humidity Protection Speed; all LEDs are extinguished except LED 4 which ashes slowly. This is not a
default setting.
Timed Intensive Ventilation
The up and down arrows have additional functions; pressing and holding the up arrow for 2 seconds
puts the unit into Intensive ventilation for a timed period which by default is 1hour. LED 7 ashes to
indicate the unit is running on the timer and once the timer has expired the previously selected level
is returned to. Timed Intensive ventilation can be cancelled by pressing the down arrow.
Sleep Mode
Pressing and holding the down arrow for 2 seconds puts the fans into Sleep Mode; all fans will stop
for a period which by default is 1 hour. This is indicated by LED 4 slowly ashing; after the timer has
expired the fans restart at the previously selected level. Sleep Mode can be cancelled by pressing
the up arrow. In some installations Sleep Mode may set the fans to Humidity Protection rather than
stopping them. Sleep Mode can also be a Switched External Digital Input if one has been installed
and congured. Operating the switch puts the unit into Sleep Mode; a second switch operation
before the timer has expired brings the controller out of Sleep Mode.

10
Sensor Operation
If room sensors have been installed these will control the fan level depending on the environmental
parameter being measured. If the fan speed is being controlled by the sensor this will be indicated
by LEDs 5, 6 or 7 ashing quickly. The up arrow can be used to increase the ventilation rate above
the sensor determined level. The down arrow can be used to temporary override the sensor for 1
hour. After the hour has elapsed the fans will return to a level determined by the sensor readings.
Filter Timer
After 6 months of operation LED 3 – the warning Led will be constantly illuminated to indicate the
lters in the fan units require cleaning or replacing. Once the lters have been cleaned/replaced the
timer can be reset by pressing and holding down the up and down arrows together for 5 seconds.
LEDs 5, 6 and 7 will ash 3 times to indicate the timer has been reset and the warning LED will be
cleared.
Other Warnings
LED 3 is also used to indicate errors which may occur with the controller. The number of times the
LED ashes followed by a pause indicates the type of error, these are detailed below:
Number Error Error LED Indication Recommended Action
1Filter Timer expired LED ON Replace/Clean Filters & Reset Timer.
2 Self test failed 2 x FLASH - PAUSE Contact the installer.
3 Sensor Communication
Error
3 x FLASH - PAUSE Check wiring to the sensor(s), contact
the installer.
4 Controller temperature
too high
4 x FLASH - PAUSE Contact the installer.
Sensor Options
Sensor type Surface mount Flush mount
Relative humidity (RH) sensor TP610 TP614
Carbon dioxide (CO) sensor TP611 TP615
Combined relative humidity (RH) & Carbon dioxide (CO) sensor TP612 TP616
Volatile organic compound (VOC)/ Air quality sensor TP613 TP617

11
Maintenance
Cleaning
Routine cleaning and lter changes are all that are normally required to keep the SRHRV System
working eciently.
Before cleaning ,power down the ventilation system and wait sucient time for the Fans to stop
rotating before starting cleaning.
SRHRV Fan Unit
Diuser
Remove Diuser before cleaning with a soft cloth damped with mild soapy water. To remove the
Bezel, un-clip the three legs that hold the Diuser to the Bezel.
Wiring Aperture Cover
Remove Wiring Aperture Cover before cleaning. To remove the Wiring Aperture Cover rst remove
the Diuser then using a screwdriver, place the tip in the indicated aperture and gently rotate.
Air Filter
Inspect every 6-12 months depending on environmental conditions. Remove loose debris using
a dry soft brush and a vacuum cleaner; do not use water. For replacement lters see Replacement
Filter section. Used lters should be dispose of as household waste.
Heat Cells
Remove the Heat Cell prior to cleaning. To access the Internal Heat Cell rst remove the Diuser,
Wiring Aperture Cover, Air Filter. To remove the Heat Cells use the wire handle and pull Heat Cell out
of the Vent Tube. Second Heat Cell can be pulled out in the same way after removing the Fan. Heat
Cells should be cleaned using a dry soft brush and a vacuum cleaner.

12
Fan
To remove the Fan carefully slide the Fan out of the Vent Tube, do not pull on the blades or wire.
Disconnect the Communication Cable before removing Fan. Fan should only be cleaned with a soft
dry brush.
Foam Fly Screen
Inspect every 6-12 months depending on environmental conditions. Remove loose debis as required
by rinsing with warm water. Ensure parts are fully dried before retting. For replacement lters see
Replacement Filter section. Used lters should be dispose of as household waste.
Vent Tube
Wipe down the interior of the Vent Tube with a soft cloth damped with mild soapy water.
Reassembly after Cleaning
Ensure that all components are thoroughly dry before reassembly. Refer to diagram on page 7. Note
When retting Fan into unit Fan Label must face into the dwelling.
Replacement Filters
Description Part Number
Air Filter G2 XP2010838
Air Filter G3 XP2010311
Foam Fly Screen XP2010320
Replacement lters are available from Titon Sales
SRC1 Controller Unit
Cleaning
Wipe down the exterior with a soft cloth damped with mild soapy water.

13
Notes

14
Service Record
Serviced By Company Date Notes

15
Serviced By Company Date Notes

MARKETING DIVISION
894 The Crescent, Colchester Business Park,COLCHESTER, CO4 9YQ
Tel : [phone] Fax: [phone]
Email: [e-mail] Web: www.titon.com
©2017 TITON DO 5483 Iss 04
In the event of any queries please contact the system installer.
Ensure this booklet is passed to the householder once
installation & commissioning of the ventilation system is
complete.
This Product Manual must be kept in the Home Information Pack
and used as a service record.
