TKB Home
TKB Home Thermostat - Touchpanel
SKU: TKBETZ96
Quickstart
This is a Z-Wave Device for Europe. To run this device please connect it to your mains power supply.
Important safety information
Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law. The manufacturer, importer,
distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material. Use this
equipment only for its intended purpose. Follow the disposal instructions. Do not dispose of electronic equipment or batteries in a fire or near open heat sources.
What is Z-Wave?
Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section.
Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and
every mains powered node can act as a repeater for other nodes (meshed network) in case the receiver is not
in direct wireless range of the transmitter.
This device and every other certified Z-Wave device can be used together with any other certified Z-Wave
device regardless of brand and origin as long as both are suited for the same frequency range.
If a device supports secure communication it will communicate with other devices secure as long as this
device provides the same or a higher level of security. Otherwise it will automatically turn into a lower level of
security to maintain backward compatibility.
For more information about Z-Wave technology, devices, white papers etc. please refer to www.z-wave.info.
Product Description
The new thermostate of TKB Home ist a digital thermostat which is designed for electric floor heating or water heating systems. The color touch LCD display is 4.3
inches in size and it supports four different languages. For creating your comfort temperatur you can use the five modes to define the desired temperatur depending on
your lifestyle. Using the 5+1+1 programmable function you use the on/off settings which allow different temperatures per day.
You can adjust your settings using the three different sensors: Ambient (built-in sensor) for controlling air temperatur, Floor Sensor for controlling the temperatur using
the floor probe and another Floor Sensor for conrolling the room temperatur.
Features:
Thermostat for electric floor heating (max. 16A) or water heating (max. 3A) systems
Colour touch LCD Display (4.3 inches)
Adjustable modes: comfort, economy, party, holiday, program mode control
Programmable per day (5+1+1 mode)
External and internal sensors
Four languages: English, French, German, Dutch
Power supply: 230VAC, 50/60Hz
Consumption: 1.5A
Current load: max. 16A
Wireless technology: Z-Wave

07-10-2020 09:54
Pagina 2 van 2http://manuals-backend.z-wave.info/make.php?lang=en&sku=TKBETZ96&cert=
Prepare for Installation / Reset
Please read the user manual before installing the product.
In order to include (add) a Z-Wave device to a network it must be in factory default state. Please make sure to reset the device into factory default. You can do this
by performing an Exclusion operation as described below in the manual. Every Z-Wave controller is able to perform this operation however it is recommended to use
the primary controller of the previous network to make sure the very device is excluded properly from this network.
Safety Warning for Mains Powered Devices
ATTENTION: only authorized technicians under consideration of the country-specific installation guidelines/norms may do works with mains power. Prior to the
assembly of the product, the voltage network has to be switched off and ensured against re-switching.
Inclusion/Exclusion
On factory default the device does not belong to any Z-Wave network. The device needs to be added to an existing wireless network to communicate with the
devices of this network. This process is called Inclusion.
Devices can also be removed from a network. This process is called Exclusion. Both processes are initiated by the primary controller of the Z-Wave network. This
controller is turned into exclusion respective inclusion mode. Inclusion and Exclusion is then performed doing a special manual action right on the device.
Quick trouble shooting
Here are a few hints for network installation if things dont work as expected.
1. Make sure a device is in factory reset state before including. In doubt exclude before include.
2. If inclusion still fails, check if both devices use the same frequency.
3. Remove all dead devices from associations. Otherwise you will see severe delays.
4. Never use sleeping battery devices without a central controller.
5. Dont poll FLIRS devices.
6. Make sure to have enough mains powered device to benefit from the meshing
Technical Data
Dimensions 0.1299900x0.0533000x0.0904900 mm
Weight 199 gr
EAN 6959174411300
Frequency Europe - 868,4 Mhz
Maximum transmission power 5 mW
Explanation of Z-Wave specific terms
Controller — is a Z-Wave device with capabilities to manage the network. Controllers are typically Gateways,Remote Controls or battery operated wall
controllers.
Slave — is a Z-Wave device without capabilities to manage the network. Slaves can be sensors, actuators and even remote controls.
Primary Controller — is the central organizer of the network. It must be a controller. There can be only one primary controller in a Z-Wave network.
Inclusion — is the process of adding new Z-Wave devices into a network.
Exclusion — is the process of removing Z-Wave devices from the network.
Association — is a control relationship between a controlling device and a controlled device.
Wakeup Notification — is a special wireless message issued by a Z-Wave device to announces that is able to communicate.
Node Information Frame — is a special wireless message issued by a Z-Wave device to announce its capabilities and functions.
