Beok Controls TOL43-AC Series User manual

VIII. Operation Instruction
3.Two pipe or four pipe for choice.
4.3 Fan speed+auto, timer switch for daily or week.
.5 With daily programmable function, 4 period settings.
6.Selectable 80mmx80mm hidden box.
Accuracy
Sensing Element
Power Consumption
Power Supply
Current Load
External Material
Dimension
Ambient Temp.
Storage Temp.
±1℃
NTC
<0.5W
AC85~260V, 50/60HZ
3A
PC+ABS (flame retardant）
86x86x13.3mm
0-45℃,5-95％RH(Non-condensing）
-5~55℃
Set Temp. Range 10℃ - 40℃
I. Product Summary:
II. Technical Parameter:
IV. User Interface Explanation
2.Blue or white back light for customer choose.
TOL43-AC Series thermostats are designed to control the fans and valves
in air conditioner applications via comparison of the room temperature and
setting temperature as reaching the aim of comfort and saving energy.
Installation Box 80x80mm
V. Model Definition
AC 2: Two pipe, for air conditioning
AC 4: Four pipe, for air conditioning
1. Setting Power on/off
Press to turn on/off the power.
2. Setting Temperature
Press to set the temperature.
3. Setting the System Mode
Then go into day programmable setting.
Press M , 1 (for example) will flash in the position of 1234567.
4. Setting the Fan Speed
Press to select the fan speed.
In auto mode, the fan will run according to the comparison of room
temperature and set temperature.
Press M , mm will flash in the position of hh: mm.
Press to adjust the minute.
5. Setting the Day Program Schedules.
Press to adjust the hour.
Press M , period 1 and mm will flash.
Press to adjust the minute.
Press to confirm the setting;
Press M , period 2 and hh will flash.
7.Precise comfort control keeps temperature within1°C of the level you set.
1.Square LCD display, more clear to see.
TOL43-AC LCD SCREEN THERMOSTAT
VII.Wiring Digram
III. Main Functions and Characteristics
For example: TOL43-AC2
VI. Model Spec
TOL43-AC2
TOL43-AC4
Spec
2 Pipe
4 Pipe
Factory default is 26 ℃.
Press M to select heating, cooling or ventilation.
Factory Default is ventilation.
is Low speed(Factory default);
is Mid speed;
is High speed;
is Auto speed.
Press and hold M for 3 sec., hh will flash in the position of hh: mm.
Press to adjust the hour.
The above is the steps to set real time.
Press to adjust the week.
Press M , period 1 and hh will flash.
Press to adjust the hour.
Press M , period 2 and mm will flash.
Press to adjust the minute.
Press to confirm the setting;
Press M , period 3 and hh will flash.
Press to adjust the hour.
Press M , period 3 and mm will flash.
Press to adjust the minute.
Press to confirm the setting;
Press M , period 4 and hh will flash.
Press to adjust the hour.
Press M , period 4 and mm will flash.
Press to adjust the minute.
Press to confirm the setting;
Press M , loop will display in the screen.
One day programmable setting is finished.
Fan Speed
3 Fan speed+Auto
3 Fan speed+Auto
Daily
Programmable Timer Switch
√
√
√
√

IX. Installation Instruction
This product is suitable for standard 80*80mm wall box.
1.Connect the line of power and valve into the terminals. Fix the wall plate
into the wall box by a screwdriver.
2.Connect the lines with the LCD board.
3.Connect the LCD board into the wall plate.
NOTICE: The installation wire should be 1.5-2.5mm .
LCD Screen Thermostat
X. ATT:
Thank you for buying this product!
Please read this manual for complete instructions on installing and
operating your thermostat. If you require further assistance, please
feel free to contact us.
In the box you will find:
Thermostat
User Manual
Screws
Dryer
Our Service:
We offer the warranty of 24 months from the sales day.
During the warranty, if it is belong to the quality issue, we will fix or
replace them for you by free after test them.
If it is not quality problem or beyond the warranty time, we will
charge for the after-sales service.
TOL43-AC
TOL43-AC
√
√
√
√
Model
6. Setting the Regular Boot
Press M for more than 3 seconds, after setting the time, press
until and “hh” twinkling. Press to adjust the hours.
After the adjustment of hours, press M until the “mm” twinkling, press
to adjust the minutes. After the completion of all adjustments ,press
to confirm, then does not twinkle, Regular boot setup is complete.
The operation of canceling Regular boot is the same, press M to the
state of Regular boot, then pressing ,the is twinkling, Regular boot
has been canceled.
7. Setting the Off Timer
After the setting of Regular boot, press M again, until and “hh” twinkling,
press to adjust the hours. After the adjustment of hours is complete,
press until the “mm” twinkling, press to adjust the minutes.
After the completion of all adjustment, press to confirm, then does
not twinkling, Off timer setup is complete.
The operation of canceling Off timer is the same, press M to the state of
Off timer, then pressing , the is twinkling, Off timer has been canceled.
The setting of the third period and forth period are same with the first and
second period, the icons are (on, off/into the room, out of the house)
8. Setting the Circulation of Timer Switch
After setting the time of timer switch, press the M ,there will be “LooP",
then press ,week display area will displays the day of the week, or
the transformation of “12345" “123456",or “1234567".
If the screen only displays the day of the week, then the timer switch setting
is valid only for the day. If it displays “12345",then the timer switch is valid
from Monday to Friday, and Saturday and Sunday will be invalid.
If it displays “123456",then the timer switch is valid from Monday to Saturday,
and Sunday will be invalid. If it displays “1234567",then the timer switch
is valid everyday.
2
9.Advanced Setting Mode
Temperature Adjustment
(Attn: Only when your room temperature is different with actual temperature, you do this operation.)
In power-on status, press about 7 seconds, then “XX X” will display
on the bottom of the screen. For Example: “26 5” means temp is 26.5℃
then you can press to modify the temperature.
It will confirm automatically after correct temp twinkling 7 seconds.
Fan Coil Controlling Mode Setting
(You can select the fan coil In control & Out of control.)
In “F00” mode, when room temperature reaches to the setted temp, the fan coil stops working.
In power-on status, press about 7 seconds, “XX X” will display on the bottom
of the screen, then continue to press once again, “F00” or “F01” will display.
Press to choose “F00” or “F01”
In “F01” mode, when room temperature reaches to the setted temp, the fan coil goes on working.
