TLW K01-0102 User manual

Product Name: Galaxy IP44 Rated COB LED Cabinet Light 2.6W
With Round Surface Mounting Spacer
Product Code: K01-0102
Kit Contents
▪LED cabinet light with micro connector
▪Round surface mounting spacer
▪Screws for surface mounting spacer
Important Safety Information
The rated inputting voltage must be 9 -16V DC. You should use a driver to convert the mains voltage to e 9-
16V DC.
The luminaire shall under no circumstances be covered with insulating material.
During normal use, the object lighted muse not exceed a temperature of 95ºC.
Installation should be carried out by a qualified electrician.
This product may contain substances that can be hazardous to the environment if not disposed of properly.
Electrical and electronic equipment should never be disposed of with household waste.
Installation
1
2
Cut out diameter is 56mm for cabinet
light.
If you are putting the cable through the
mounting surface, a 8mm diameter hole
is required for the plug and cable.
Alternatively you can use the cable groove
to surface mount the cable.
3
4
Fix the round surface spacer B (see
diagram) on the mounting surface by
two screws.
Lead the cable through the hole or
groove and fix the K01-0100 C into
the round surface spacer B (see
diagram).

Product Name: Galaxy IP44 Rated COB LED Cabinet Light 2.6W
With Round Surface Mounting Spacer
Product Code: K01-0102
Other Information
Specifications:
K01-0100 is a low voltage LED cabinet light, which is 2.6W in wattage and 9-16V DC in rated voltage.
Put the cabinet light in the mounting
surface.
Each light is fitted with a 2m cable c/w
micro plug. Plug the micro plug into the
driver’s connector block (driver may not
be supplied with lights)
Connect driver to 240V power supply
(driver may not be supplied with lights)
5
6
7
