Uplus Lighting 250 LED BEAM User manual

User manual
250 LED BEAM
Please read the instructions carefully before use

2
TABLE OF CONTENTS
1. Safety Instructions……………………………………………………………………………3-4
Technical Specifications…………………………………………………………………………4
Control Menu ……………………………………………………………………………………5-6
DMX Channels …………………………………………………………………………………6-11
Trouble Shooting…………………………………………………………………………………11
Fixture Cleaning………………………………………………………… ………………………11
STATEMENT
The product has well capability and intact packing when leave factory. All of the user should
comply with warning item and manual, any misuse cause of the damages are not included in our
guarantee, and also can not be responsible for any malfunction & problem owing to ignore the
manual.

3
1.Safety Instructions
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction booklet.
•Unpack and check carefully there is no transportation damage before using the unit.
•Before operating, ensure that the voltage and frequency of power supply match the power
requirements of the unit.
•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
•The unit is for indoor use only. Use only in a dry location.
•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces. Be sure that no ventilation slots are blocked.
•Disconnect main power before replacement or servicing.
•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.
•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always
by taking its base.
•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher
than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand
during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before
replacing or serving.
•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit
by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always use the same type spare parts.
•DO NOT touch any wire during operation as high voltage might be causing electric shock.
Warning:
•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
Caution:
•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any
repairs yourself. In the unlikely event your unit may require service, please contact your nearest
dealer.
Installation:
•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly

4
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also
always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.
•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the
touch of people.
2.Technical Specifications
Light source: 250W LED white light module (The new generation of built-in light guide column
technology, perfect light concentration, super-bright brightness,)
Maximum power: 350W
Power supply: Wide voltage input switching power supply 100V-240V 50-60Hz
Color temperature: 6500K
Lamp life: 50000 hours
Control mode: DMX512 signal input, automatic operation
Channel mode: 16CH/20CH
X/Y scan: horizontal 540°, vertical: 270°
Color: 12 color +White
Fixed pattern: 14 fixed patterns + white light, dithering effect
Dimming: 0-100% linear dimming
Strobe: Synchronous pulse strobe, random pulse strobe
Prism disk: 8 prism
Beam angle: 2°
Focusing: the pattern can be adjusted freely
Display: color LCD display, Chinese and English display, reverse display
The system has an RDM function to remotely modify the address code.
Efficient heat pipe cooling system, no risk of lamp damage
Protection level: IP20
Dimension: 323*207*560 mm, NW:12.5KGS
NW: folding hooks version is 13.5kg

5
3.Control Menu
Menu Operation
On the base of the control panel offers a number of features, such as setting DMX fixture address,
switch the lamp, run the test program, the mode selection.
MAIN
SECOND
THIRD
Dmx Address
1 - 512
Fixture
Dmx Mode
STD/EXT
Run Mode
DMX/Host/Sound
Pan Invert
Close/Open
Tilt Invert
Close/Open
Manual
Color
0 - 255
Strobe
0 - 255
Dimmer
0 - 255
Fix gobo
0 - 255
⁞
⁞
Information
Time
Current Time：xxx H
Show Time：xxx H
Power Count：xxx
Sensor
Pan
Tilt
Temp
⁞
Software Version
Panel：Vx.xxx
Motor：Vx.xxx

6
4.DMX Channels
Model 1- CH16
Channel
Feature
DMX value
Function
CH 1
Color
0-4
white
5-9
white + color 1
10-14
color 1
15-19
color 1 + color 2
20-24
color 2
25-29
color 2+ color 3
30-34
color 3
35-39
color 3+ color 4
40-44
color 4
45-49
color 4+ color 5
50-54
color 5
55-59
color 5+ color 6
60-64
color 6
65-69
color 6+ color 7
70-74
color 7
75-79
color 7+ color 8
80-84
color 8
85-89
color 8+color 9
90-94
color 9
95-99
color 9+color 10
Factory
Password
0 - 255
Pan
0 - 255
Tilt
0 - 255
Dimmer
0 - 255
Color
0 - 255
FixGobo
0 - 255
⁞
⁞
Reset
XY reset
Off/Run
Motor reset
Off/Run
All Reset
Off/Run
Factory
Off/Run
Display
Language
CH/EN
Display Flip
Normal / Reverse
Display Mode
60s / Show

7
CH 1
Color
100-104
color 10
105-109
color 10+color 11
110-114
color 11
115-119
color 11+color 12
120-124
color 12
125-129
color 12+White
130-189
FAST ROTATION - SLOW ROTATION
190-194
STOP
195－255
SLOW ROTATION - FAST ROTATION
CH 2
Strobe
0-3
close
4-103
strobe from slow to fast
104-107
Opening
108-207
Pulse strobe from fast to slow
208-212
Opening
213-251
random slow to fast
252-255
opening
CH 3
Dimmer
0-255
dimming
CH 4
Gobo
0-4
white
5-9
Gobo 1
10-14
Gobo 2
15-19
Gobo 3
20-24
Gobo 4
25-29
Gobo 5
30-34
Gobo 6
35-39
Gobo 7
40-44
Gobo 8
45-49
Gobo 9
50-54
Gobo 10
55-59
Gobo 11
60-64
Gobo 12
65-69
Gobo 13
70-74
Gobo 14
75-78
White
79-86
Gobo 1 Jitter
87-94
Gobo 2 Jitter
95-102
Gobo 3 Jitter
103-110
Gobo 4 Jitter
111-118
Gobo 5 Jitter
119-126
Gobo 6 Jitter
127-134
Gobo 7 Jitter
135-142
Gobo 8 Jitter
143-150
Gobo 9 Jitter
151-158
Gobo 10 Jitter
159-166
Gobo 11 Jitter
167-174
Gobo 12 Jitter
175-182
Gobo 13 Jitter

8
CH 4
Gobo
183-190
Gobo 14 Jitter
191-220
FAST ROTATION - SLOW ROTATION
221-225
Stop
226-255
SLOW ROTATION - FAST ROTATION
CH 5
Prism
0－127
Reserve
128-255
prism Insert
CH 6
Prism Rot
0－127
Rotation
128－190
FAST ROTATION - SLOW ROTATION
191－192
stop
193－255
SLOW ROTATION - FAST ROTATION
CH 7
7Colors
0－127
Reserve
128-255
7Colors Insert
CH 8
Frost
0－127
white
128-255
Frost Insert
CH 9
Foucs
0－255
Foucs，Linear
CH 10
Pan
0－255
Pan
CH 11
Pan fine
0－255
Pan fine
CH 12
Tilt
0－255
Tilt
CH 13
Tilt fine
0－255
Tilt fine
CH 14
P/T Speed
0－255
P/T Speed
CH 15
Reset
0－249
Reserve
250－255
All Reset
CH 16
Reserve
0－255
Reserve
Model 2- CH20
Channel
Feature
DMX value
Function
CH 1
Color
0-4
white
5-9
white + color 1
10-14
color 1
15-19
color 1 + color 2
20-24
color 2
25-29
color 2+ color 3
30-34
color 3
35-39
color 3+ color 4
40-44
color 4
45-49
color 4+ color 5
50-54
color 5
55-59
color 5+ color 6
60-64
color 6
65-69
color 6+ color 7
70-74
color 7
75-79
color 7+ color 8
80-84
color 8

9
CH 1
Color
85-89
color 8+color 9
90-94
color 9
95-99
color 9+color 10
100-104
color 10
105-109
color 10+color 11
110-114
color 11
115-119
color 11+color 12
120-124
color 12
125-129
color 12+White
130-189
FAST ROTATION - SLOW ROTATION
190-194
STOP
195－255
SLOW ROTATION - FAST ROTATION
CH 2
Strobe
0-3
close
4-103
strobe from slow to fast
104-107
Opening
108-207
Pulse strobe from fast to slow
208-212
Opening
213-251
random slow to fast
252-255
opening
CH 3
Dimmer
0-255
dimming
CH 4
Gobo
0-4
white
5-9
Gobo 1
10-14
Gobo 2
15-19
Gobo 3
20-24
Gobo 4
25-29
Gobo 5
30-34
Gobo 6
35-39
Gobo 7
40-44
Gobo 8
45-49
Gobo 9
50-54
Gobo 10
55-59
Gobo 11
60-64
Gobo 12
65-69
Gobo 13
70-74
Gobo 14
75-78
White
79-86
Gobo 1 Jitter
87-94
Gobo 2 Jitter
95-102
Gobo 3 Jitter
103-110
Gobo 4 Jitter
111-118
Gobo 5 Jitter
119-126
Gobo 6 Jitter
127-134
Gobo 7 Jitter
135-142
Gobo 8 Jitter
143-150
Gobo 9 Jitter
151-158
Gobo 10 Jitter

10
CH 4
Gobo
159-166
Gobo 11 Jitter
167-174
Gobo 12 Jitter
175-182
Gobo 13 Jitter
183-190
Gobo 14 Jitter
191-220
FAST ROTATION - SLOW ROTATION
221-225
Stop
226-255
SLOW ROTATION - FAST ROTATION
CH 5
Prism
0－127
Reserve
128-255
prism Insert
CH 6
Prism Rot
0－127
Rotation
128－190
FAST ROTATION - SLOW ROTATION
191－192
stop
193－255
SLOW ROTATION - FAST ROTATION
CH 7
7Colors
0－127
Reserve
128-255
7Colors Insert
CH 8
Frost
0－127
white
128-255
Frost Insert
CH 9
Foucs
0－255
Foucs，Linear
CH 10
Pan
0－255
Pan
CH 11
Pan fine
0－255
Pan fine
CH 12
Tilt
0－255
Tilt
CH 13
Tilt fine
0－255
Tilt fine
CH 14
P/T Speed
0－255
P/T Speed
CH 15
Reset
0－249
Reserve
250－255
All Reset
CH 16
Reserve
0－255
Reserve
CH 17
Reserve
0－255
Reserve
CH 18
Color speed
0－255
Fast to Slow
CH 19
Gobo speed
0－255
Fast to Slow
CH 20
Focus speed
0－255
Fast to Slow

11
5.Trouble Shooting
F ollo w ing a r e a few c o mm on p r oble m s th a t m a y occu r d uring ope r a tion . He r e a r e s o m e s ug g es tion s fo r
ea s y tr ou b leshooting :
A. The un it does no t work , no li ght a n d t he f a n d o es no t w o r k
1. Check th e c on nect ion of p owe r a nd m a in fu s e .
2. M eas ure th e m a ins volt a ge on th e m a i n co nn e ct o r .
3. Check th e pow er on LED .
B. N o t responding t o D MX c on t ro ll er
1. D M X LED s h ou ld b e on. If no t, che ck D M X co n nectors, ca b l es to s ee if link p r ope r ly .
2. If th e D M X LE D i s on a nd no r espons e t o th e c h a nn el, che ck th e a dd r ess s etti ng s a nd D M X p ol a r ity .
3. If y ou h a ve i nter m ittent D M X s ig n a l p r oble m s , che ck th e p ins on c onn ecto r s or on
PCB of th e u nit or the p r ev iou s on e.
4. Tr y to us e a no th er D M X co ntroller .
5. Check if th e D M X ca b le s r un ne a r or run a lon g s id e t o h ig h volta ge c a b les th a t m a y c a us e d a m a ge or
in terfer ence to D M X inter face circui t.
C . One of the cha nn el s is no t w o r k ing w el l
1. Th e s tep p er moto r m ig h t b e dam a g ed or the c a b le c on nect ed to th e PCB is b r oken.
2. Th e m oto r ’ s d r ive IC on th e PCB m ig h t b e o ut of co ndition
6.Fixture Cleaning
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,
smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
