Soundoff Signal Pinnacle EPL7000 Series User manual

Please see reverse for Technical Specifications
ELECTRICAL CONNECTION:
Follow diagram below for electrical
connections:
RED WIRE: Connect through a switch
and fuse to 10-16Vdc.
BLACK WIRE: Connect to a good reliable
ground (-).
PATTERN CHANGE:
Connect BLACK WIRE to ground. Touch
the WHITE WIRE to 10-16Vdc and hold
for 1-2 seconds. The mini lightbar will
advance one flash pattern and flash the
new pattern each time this is done.
INSTALLATION:
1) Determine a clean, flat location
(typically roof) on the vehicle to
mount the PINNACLE Mini Lightbar.
The PINNACLE Mini Lightbar comes
with two (2) steel brackets which
should be used to permanently
mount the light bar to a vehicle roof
or similar horizontal surface.
2) Position the bar with brackets
attached and mark hole centers.
Center punch or drill pilot holes for
a 1/4” sheet metal screw (customer
supplied).
3) Place a locking washer over the
screw and securely fasten the
brackets to the mounting surface.
The screws and holes should
be calked with a silicone based
material to prevent leakage. DO NOT
OVERTIGHTEN!
4) Make electrical connections.
Caution: Do not install this product
or route any wires in the air bag
deployment zone. Refer to your vehicle
Owner’s Manual for the location of any
air bag deployment zones.
RED BLACK
WHITE
5 AMP
FUSE
+12 Vdc
PINNACLE
LIGHTBAR
EPL7000 MINI LIGHTBAR
PERMANENT MOUNT
EPL7PD(x)C Low Bracket (shown)
EPL7HD(x)A
EPL7HD(x)C High Bracket
EPL7HD(x)A
•HIGH CURRENT interconnects must be properly terminated. Poor crimp quality can cause heat
build-up and fire. Follow crimp connector manufacturer instructions.
•DO NOT install this product or route any wires in the Air Bag Deployment Zone. Refer to vehicle
Owner’s Manual for deployment zones.
•Do NOT use system to disconnect headlights, brake lights or other safety equipment.
•Unit may become hot to touch during normal operation.
•Failure to properly install connectors, fuses or wiring may cause vehicle failure or fire.
•Installation must only be performed by trained technician. Installer must determine vehicle wiring
configuration and proper integration of system.
•Use proper wire gauge. All power wires connecting to positive (+) or negative (-) battery terminal
or local chassis ground (-) must be sized to supply at least 125% of max. current and properly fused at
power source.
•Install protective grommets when routing wire through firewall or metal.
WARNING

PMB3BKT Replacement Permanent Mount Bracket (each)
PMB3BRKT Replacement Permanent Mount Bracket (kit)
PMB3TDC EPL7000 Replacement Clear Dome
Replacement Parts & Accessories:
TECHNICAL SPECIFICATIONS
Overall Dimensions: 14.25”L x 8.27”W x 2.93”H
Flash Patterns: 28 flash patterns
Input Voltage Range: 10 - 16 Vdc
Current Consumption: 2 Amps (Avg) - 4 Amps (Max)
# of LEDs: 24 Generation 3 LEDs
Operating Temperature: -40º to +65º C
Cord Length: 300”
Flash Patterns
Alternating Patterns
FPM
(Flashes per Minute)
1. Warp Alternating
2. Quad “
3. Quad2 “
4. Quint “
5. Double2 “
6. Warp 1, 2, 3 “
7. Progressive “
8. Q-Switch™ “
9. Intercycle “
10. Warp Whole Bar
11. Quad “
12. Quad2 “
13. Quint “
14. Double2 “
15. Warp 1, 2, 3 “
16. Progressive “
17. Warp Diagonal
18. Quad “
19. Quad2 “
20. Quint “
21. Double2 “
22. Warp 1, 2, 3 “
23. Progressive “
24. Q-Switch “
25. Intercycle “
26. Rotator “
27. Cycle 1 Random
28. Cycle 2 “
EPL7000 MINI LIGHTBAR
PERMANENT MOUNT
EPL7PD(x)C Low Bracket (shown)
EPL7HD(x)A
EPL7HD(x)C High Bracket
EPL7HD(x)A

Please see reverse for Technical Specifications
ELECTRICAL CONNECTION:
Follow diagram below for electrical
connections:
RED WIRE: Connect through a switch
and fuse to 10-16Vdc.
BLACK WIRE: Connect to a good reliable
ground (-).
PATTERN CHANGE:
Connect BLACK WIRE to ground. Touch
the WHITE WIRE to 10-16Vdc and hold
for 1-2 seconds. The mini lightbar will
advance one flash pattern and flash the
new pattern each time this is done.
INSTALLATION:
1) Determine a clean, flat location
(typically roof) on the vehicle to
mount the PINNACLE Mini Lightbar.
The PINNACLE Mini Lightbar comes
with two (2) steel brackets which
should be used to permanently
mount the light bar to a vehicle roof
or similar horizontal surface.
2) Position the bar with brackets
attached and mark hole centers.
Center punch or drill pilot holes for
a 1/4” sheet metal screw (customer
supplied).
3) Place a locking washer over the
screw and securely fasten the
brackets to the mounting surface.
The screws and holes should
be calked with a silicone based
material to prevent leakage. DO NOT
OVERTIGHTEN!
4) Make electrical connections.
Caution: Do not install this product
or route any wires in the air bag
deployment zone. Refer to your vehicle
Owner’s Manual for the location of any
air bag deployment zones.
RED BLACK
WHITE
5 AMP
FUSE
+12 Vdc
PINNACLE
LIGHTBAR
EPL7000 MINI LIGHTBAR
PERMANENT MOUNT
EPL7PF(x)C Low Bracket (shown)
EPL7PF(x)A
EPL7HF(x)C High Bracket
EPL7HF(x)A
•HIGH CURRENT interconnects must be properly terminated. Poor crimp quality can cause heat
build-up and fire. Follow crimp connector manufacturer instructions.
•DO NOT install this product or route any wires in the Air Bag Deployment Zone. Refer to vehicle
Owner’s Manual for deployment zones.
•Do NOT use system to disconnect headlights, brake lights or other safety equipment.
•Unit may become hot to touch during normal operation.
•Failure to properly install connectors, fuses or wiring may cause vehicle failure or fire.
•Installation must only be performed by trained technician. Installer must determine vehicle wiring
configuration and proper integration of system.
•Use proper wire gauge. All power wires connecting to positive (+) or negative (-) battery terminal
or local chassis ground (-) must be sized to supply at least 125% of max. current and properly fused at
power source.
•Install protective grommets when routing wire through firewall or metal.
WARNING

PMB3BKT Replacement Permanent Mount Bracket (each)
PMB3BRKT Replacement Permanent Mount Bracket (kit)
PMB3TDC EPL7000 Replacement Clear Dome
Replacement Parts & Accessories:
TECHNICAL SPECIFICATIONS
Overall Dimensions: 14.25”L x 8.27”W x 2.93”H
Flash Patterns: 28 flash patterns
Input Voltage Range: 10 - 16 Vdc
Current Consumption: 2 Amps (Avg) - 4 Amps (Max)
# of LEDs: 24 Generation 3 LEDs
Operating Temperature: -40º to +65º C
Cord Length: 125.75”
Flash Patterns
Alternating Patterns
FPM
(Flashes per Minute)
1. Warp Alternating
2. Quad “
3. Quad2 “
4. Quint “
5. Double2 “
6. Warp 1, 2, 3 “
7. Progressive “
8. Q-Switch™ “
9. Intercycle “
10. Warp Whole Bar
11. Quad “
12. Quad2 “
13. Quint “
14. Double2 “
15. Warp 1, 2, 3 “
16. Progressive “
17. Warp Diagonal
18. Quad “
19. Quad2 “
20. Quint “
21. Double2 “
22. Warp 1, 2, 3 “
23. Progressive “
24. Q-Switch “
25. Intercycle “
26. Rotator “
27. Cycle 1 Random
28. Cycle 2 “
EPL7000 MINI LIGHTBAR
PERMANENT MOUNT
EPL7PF(x)C Low Bracket (shown)
EPL7PF(x)A
EPL7HF(x)C High Bracket
EPL7HF(x)A

Please see reverse for Technical Specifications
INSTALLATION:
1) Detemine a clean, flat location
(typically the roof) on the vehicle to
mount the PINNACLE Mini Lightbar.
The PINNACLE Mini Lightbar comes
equipped with four magnetic feet. It
is the responsibility of the installer
and end user to determine whether
it is safe to use magnetic mounting
hardware for your application.
A Permanent Mount version
(EPL7PD(x)C) is available.
Note: The magnetic character of roof
steel varies from vehicle to vehicle.
Be sure that your vehicle is capable
of providing enough magnetic force
to safely secure the PINNACLE Mini
Lightbar to the roof.
2) A Protective Film has been provided
with the PINNACLE Mini Lightbar kit
that can be applied to the bottom of
each magnet. This film will protect
the paint of the vehicle. Apply one
donut shaped decal to the bottom of
each magnetic foot. Be sure to cover
the magnet entirely for maximum
protection to the paint finish.
Note: Protective film can reduce the
magnetic force by as much as 10%.
EPL7000 PINNACLE MINI
LIGHTBAR MAGNET MOUNT
EPL7SAM+(x)C
OPERATION:
Electrical Connections
& Flash Pattern Selection:
See diagram at left for Power ON ( ),
Power OFF ( ) and Pattern SELECT
( ) switch positions. Turn the light
on by pressing the Power ON button. To
change the flash pattern press and hold
the PATTERN SELECT button for one
to two (1-2) seconds. The PINNACLE
Mini Lightbar will advance one (1) flash
pattern and flash the new pattern each
time this is done. The PINNACLE Mini
Lightbar features non-volatile memory
and will recall last pattern used.
Selected pattern will remain the default
once turned off and can be changed
by changing the flash pattern before
powering off.
Power ON
Power OFF
Pattern SELECT
EPL7SAM+(x)A
•HIGH CURRENT interconnects must be properly terminated. Poor crimp quality can cause heat
build-up and fire. Follow crimp connector manufacturer instructions.
•DO NOT install this product or route any wires in the Air Bag Deployment Zone. Refer to vehicle
Owner’s Manual for deployment zones.
•Do NOT use system to disconnect headlights, brake lights or other safety equipment.
•Unit may become hot to touch during normal operation.
•Failure to properly install connectors, fuses or wiring may cause vehicle failure or fire.
•Installation must only be performed by trained technician. Installer must determine vehicle wiring
configuration and proper integration of system.
•Use proper wire gauge. All power wires connecting to positive (+) or negative (-) battery terminal
or local chassis ground (-) must be sized to supply at least 125% of max. current and properly fused at
power source.
•Install protective grommets when routing wire through firewall or metal.
WARNING
