TMG SD03-1036 User manual

3.6V
CORDLESS SCREWDRIVER
SD03-1036

2
1
23
6
4
9
12
1
2
3
8
10
11
14
3
5
8
9
5
13
7
4
8
14
5a 1 12
b c
13

3
Important!
When using equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating manual with
due care. Keep this manual in a safe place, so that
the information is available at all times. If you
give the equipment to any other person, give
them these operating instructions as well.
We accept no liability for damage or accidents
which arise due to non-observance of these
instructions and the safety information.
1. Safety information
General safety instructions for electric tools
Caution!
Read all safety regulations and instructions.
Any errors made in following the safety
regulations and instructions may result in an
electric shock,re and/or serious injury.
Keep all safety regulations and instructions
in a safe place for future use.
The term “electric tool” used in the safety
instructions refers to electric tools operated from
the mains power supply (with a power cable)
and to battery operated electric tools (without a
power cable).
1. Workplace safety
a) Keep your work area clean and well
illuminated. Untidy or unlit work areas can result
in accidents.
b) Do not operate the electric tool in
an environment where there is a risk of
liquids, gases or dust. Electric tools produce
sparks which could set the dust or vapours alight.
c) Keep the electric tool out of the reach of
children and other persons. If there is a
distraction, you may lose control of the appliance.
2. Electrical safety
a) The connector plug from this electric tool
never be altered in any way. Never use adapter
plugs together with earthed electric
tools. Unaltered plugs and correct sockets
reduce the risk of an electric shock.
b) Avoid bodily contact with earthed surfaces
such as pipes, heating, ovens and
fridges. The risk of electric shock is increased
if your body is earthed.
c) Keep the tool out of the rain and away
from moisture. The ingress of water into an
electric tool increases the risk of an electric
shock.
d) Do not use the cable to carry the electric
tool, to hang it up or to pull it out of the
socket. Keep the cable away from heat,
oil, sharp edges and moving parts of the
appliance. Damaged or entangled cables
increase the risk of an electric shock.
e) If you are working outdoors with an electric
tool, only use extension cables which
Using specially designed outdoor extension
cables, the risk of electric shock is reduced.
f) If operation of the electric tool in a damp
environment can not be avoided, use a
earth-leakage circuit-breaker. The earthleakage
circuit-breaker reduces the risk of an
electric shock.
3. Safety of persons
a) Be careful, watch what you are doing and
use an electric tool sensibly. Do not use
of drugs, alcohol or medication. A moment
of inattention when using the electric tool can
result in serious injuries.
b) Wear personal protection equipment
GB

4
and always wear safety goggles. Wearing
personal protection (such as dust masks,
non-slip safety shoes, safety helmet or ear
protection, depending upon the type and use
of the electric tool) reduces the risk of injury.
c) Make sure that the appliance cannot start
up accidentally. Ensure that the electric
it to the power supply and/or insert the
battery, or pick up or carry the tool. If your
tool or if you connect the appliance to the
mains when it is switched on, this can lead to
accidents.
d) Remove keys and wrenches before
switching on the electric tool. A tool or key
which comes into contact with rotating parts
of the appliance can lead to injuries.
e) Avoid abnormal working postures. Make
sure you stand squarely and keep your
balance at all times. In this way, you can
control the electric tool better in unexpected
circumstances.
f) Wear suitable work clothes. Do not wear
loose clothing or jewellery. Keep hair, clothes
and gloves away from moving parts.
Loose clothing, jewellery or long hair can get
trapped in moving parts.
g) If vacuuming devices and draining devices
are correctly attached and correctly used.
The use of a dust extraction system can reduce
the danger posed by dust.
4. Usage and treatment of the electric tool
a) Do not overload the appliance. Use the
correct tool for your work. You will be able
to work better and more safely within the given
performance boundaries.
b) Do not use an electric tool with a defective
switch. An electric tool that cannot be
repaired.
c) Pull the plug out of the socket and/or
remove the battery before making any
adjustments to the appliance, changing
accessories or put the appliance down. This
safety measure prevents starting the electric
tool unintentionally.
d) Keep unused electric tools out of the
reach of children. Do not allow people
who are not familiar with the appliance or
who have not read these instructions to
use the appliance. Electric tools are dangerous
if they are used by inexperienced people.
e) Clean your electric tool carefully. Check
whether moving parts are functioning
properly and not jamming, whether parts
are broken or damaged enough that the
Have damaged parts repaired before
using the appliance. Many accidents are
caused by badly maintained electric tools.
f) Keep your cutting tools sharp and clean.
Carefully maintained cutting tools with sharp
cutting edges will jam less and are easier to
control.
g) Make sure to use electric tools, accessories,
attachments, etc. in accordance with
these instructions. Take the conditions in
your work area and the job in hand into
account. Using electric tools for any purpose
other than the one for which they are intended
can lead to dangerous situations.
5. Using and handling the cordless tool
you insert the battery. Inserting a battery
into an electric tool that is switched on can
cause accidents.
b) Only charge the batteries in chargers that
are recommended by the manufacturer.
GB

5
A charger that is designed for a certain type
other types of battery.
c) Use only the correct batteries in the electric
tools. The use of other batteries may
d) Keep unused batteries away from paper
clips, coins, keys, nails, screws and other
metallic objects that could cause a short
circuit between the contacts. A short circuit
between the battery contacts may cause
from the battery. Avoid contact with it. If
in your eyes, also seek medical advice.
or burns.
6. Service
a) Have your electric tool repaired only by
trained personnel using only genuine
spare parts. This will ensure that your electric
tool remains safe to use.
Hold the equipment by the insulated handles
when carrying out work during which the
screw or the plug-in tool could strike
concealed power cables. Contact with a live
cable may also make the metal parts of the
equipment live and cause an electric shock.
Important.
Read the instructions for use before
starting the machine.
Wear safety goggles.
Wear ear protection.
Wear good quality, strong gloves.
Always use breathing apparatus when
machining materials which generate
dust.
End of life machines contain valuable
materials and therefore they should not
be placed in household waste.
We would ask you to play your part in
protecting resources and help protect
the environment by returning this
machine to a return point (if one is
available) when it reaches the end of its
life.
Description of symbols
Pay attention to all the signs and symbols shown
in these instructions and on your tool.
Make a note of these signs and symbols. If you
interpret the signs and symbols correctly, your
work with the machine will be safer and better.
GB

6
2. Layout
1. Bit chuck
2. Lamp
3. Locking button
4. Battery capacity indicator
5. Handle
6. Charging control lamp
7. Charging connection
9. Clockwise/Counter-clockwise selector switch
10. Battery charger
11. Charging cable
12. Locking sleeve
3. Proper use
The cordless screwdriver is designed for
tightening and undoing screws.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or
injuries of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or
industrial applications. Our warranty will be
voided if the machine is used in commercial,
trade or industrial businesses or for equivalent
purposes.
4. Technical data
Motor power supply: 3.6 V DC
Idling speed: 210 min-1
Clockwise/Counter-clockwise: Yes
Charge voltage for rechargeable battery: 5.5 V DC
Charge current for rechargeable battery: 600 mA
Battery charger supply voltage:
100-240 V~ / 50/60 Hz
Charging time: 3-5 hours
Battery type: Li-Ion/1.3 Ah
Weight: 415 g
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
LpA sound pressure level 57.5 dB(A)
KpA uncertainty 3 dB
LWA sound power level 68.5 dB (A)
KWA uncertainty 3 dB
The impact of noise can cause damage to
hearing.
Total vibration values (vector sum of three
directions)
determined in accordance with EN 60745.
Screwing without hammer action
Vibration emission value ah<2,5 m/s2
K uncertainty = 1,5 m/s2
Important!
The vibration value changes according to the
area of application of the electric tool and
circumstances.
5. Before starting the equipment
Be sure to read the following information before
time:
1. Charge the battery pack with the charger
supplied.
2. Only ever use screwdriver bits which are
suitable for the purpose and in faultless
condition.
3. Always check for concealed electric cables and
gas and water pipes when drilling and screwing
in walls.
6. Operation
6.1 Charging the battery (Fig. 1)
The battery is protected from exhaustive
GB
13. Work light switch button
14. Work light

7
discharge.
An integrated protective circuit automatically
Warning! Do not press the ON/OFF switch any
more if the protective circuit has actuated. This
may damage the battery.
1. Check that your mains voltage is the same as
that marked on the rating plate of the battery
charger. Plug the battery charger in the plug
socket and connect the charging cable to the
charging connection. The charging process
starts as soon as the charging cable is
connected to the charging adapter.
2. The red LED (6) will come on to indicate that
the battery pack is being charged.
3. When the charging control lamp (6)
all three lights lit, said charging is complete.
Important! The handle may become a little warm
during the charging process. This is normal.
If the battery pack fails to charge, please check
whether there is voltage at the socket-outlet
and check for proper contact with the charging
contacts in the battery charger.
If the battery still fails to charge, send
the battery charger
and the screwdriver
to our customer services department.
Timely recharging of the battery pack will help it
serve you well for a long time. You must recharge
the battery pack when you notice that the power
of the screwdriver drops.
Never allow the battery pack to become fully
discharged. This will cause it to develop a defect.
6.2 Changeover switch (Fig. 2/Item 9)
The slide switch above the ON/OFF switch is for
setting the direction of rotation of the cordless
screwdriver and for preventing the cordless
screwdriver from being switched on
inadvertently.
You can select between clockwise and
counterclockwise rotation. Change the direction
of rotation only when the equipment is at a
standstill. If you fail to observe this point, the
gearing may become damaged. When the slide
switch is in the middle position, the ON/OFF
switch is blocked.
6.3 ON/OFF switch (Fig. 2 / Item 8)
screwdriver on. Release the ON/OFF switch to
6.4 LED lamp
The LED lamp (2)and(14) can be used in poor lighting
conditions to illuminate the area where you want
to screw.
Button(8)control the LED lamp(2) ON/OFF
Button(13)control the LED lamp(14) ON/OFF
Don't put the light point-blank you and other
people's eyes
6.5 Angle setting (Fig. 3/Item 3)
angle settings. To do so, press the locking button
(3) and move the screwdriver into the desired
position (Press the release button and by turning
the handle (5) to the right). Then release the
locking button (3).
Important. Before you switch on the
screwdriver, make sure that it is correctly
locked in the angle position in question.
6.6 Battery capacity indicator (Fig. 4/Item 8)
press the button auf ON/Switch.
The battery capacity indicator (4) indicates the
charge state of the battery on 3 colored LEDs.
All LEDs illuminate:
The battery is fully charged.
GB

8
6.7 Changing the tool (Fig. 5)
Important! Set the changeover switch to its
centre position whenever you carry out any work
(for example changing the tool, maintenance
work, etc.) on the cordless screwdriver.
Pull back and hold the locking sleeve (12).
Insert the bit (a) into the bit chuck (1) and let go
of the locking sleeve (12).
Check that it is secure by attempting to pull the
tool apart again.
6.8 Screwdriving
We recommend using self-centering screws (e.g.
Torx screws, recessed head screws) designed for
reliable working. Be sure to use a bit that matches
the screw in shape and size. Set the torque, as
described elsewhere in these operating
instructions, to suit the size of screw.
7. Cleaning and maintenance
Always pull out the mains power plug before
starting any cleaning work.
7.1 Cleaning
Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it
with compressed air at low pressure.
We recommend that you clean the device
Clean the equipment regularly with a moist
cloth and some soft soap. Do not use cleaning
agents or solvents; these could attack the plastic
parts of the equipment. Ensure that no water can
seep into the device.
7.2 Maintenance
There are no parts inside the equipment which
require additional maintenance.
8. Disposal and recycling
The unit is supplied in packaging to
prevent its being damaged in transit.
This packaging is raw material and can
therefore be reused or can be returned to
the raw material system.
The unit and its accessories are made of various
types of material, such as metal and plastic.
Defective components must be disposed of as
special waste. Ask your dealer or your local
council.
GB
The yellow and red LED illuminate:
The battery has an adequate remaining charge.
Red LED:
The battery is empty, recharge the battery.
