Toa DM-1200 User manual

INSTRUCTION MANUAL
MICROPHONE
DM-1200
DM-1200D
GENERAL DESCRIPTION
The TOA DM-1200 series microphones re unidirection l microphones provided consistently cle r sound reinforcement
suited for h nd-held speech use. This microphone body is rigidly constructed of diec st-zinc, nd designed to reduce
switching nd h ndling noises. In ddition, the DM-1200D comes with remote control function to ctiv te mplifier's
power or chime unit. Refer to the mplifier's instruction m nu l for det ils of the remote function nd connection.
APPEARANCE
DM-1200 DM-1200D
CIRCUIT DIAGRAMS
DM-1200
DM-1200D
Phone Plug 5-Pin DIN Plug
5-Pin DIN Plug
SPECIFICATIONS
St nd rd Accessory
unb l nced
b l nced
-55 dB (1 kHz 0 dB=1 V/P )
50Hz~12kHz
1-core shielded c ble
10m (32.8ft.)
Phone plug
2-core shielded plus 2-core c ble
5m (16.4ft.)
5-pin DIN plug
265 g (0.58 Ib.) (without connection c ble)
39.5X163 mm (
1.6X6.4 in.)
Short-off circuit type, slide switch
None | Slide switch (interlocked with t lk switch)
Body: Zinc-diec st, p inted Met llic Gr y
He d: Aluminum-diec st nd Zinc pl ted steel wire, p inted Met llic Gr y
Microphone holder (W5/16",W5/8",W3/8")
*Specific tions re subject to ch nge without notice.
TOA Corpor tion
Model
Type
Directivity
R ted Imped nce
R ted Sensitivity
Frequency Response
Connection C ble
C ble Length
Termin l of C ble
Weight
Dimensions
T lk Switch
Remote Switch
Finish
DM-1200
DM-1200D
Moving coil microphone
Unidirection l

*Ple se see the reverse side for English m nu l.
DM-1200
DM-1200D
DM-1200 DM-1200D
Phone Plug
5-Pin DIN Plug
DM-1200
Phone Plug
DM-1200D
5-Pin DIN Plug
DM-1200
DM-1200D
-55 dB (1 kHz 0 dB=1 V/P )
50 Hz~12 kHz
10m 5 m
265 g
39.5X163
(W5/16",W5/8",W3/8")
TEL [phone]
DM-1200
DM-1200D
96C
60
TEL
This w rr nty is v lid only in J p n.
No.
