CEILING MOUNT SPEAKER
SYSTEM COMPONENTS
F-101 C/F-101 CM
High Ceiling Speaker
F-121 C/F-121 CM
Uniform Directivity Ceiling Speaker
AC-120 Dedicated Equalizer
DESCRIPTION
Two new speaker systems from TOA provide extensive
sound coverage for a variety of sound applications.
The F-101C/F-101 CM High Ceiling Speaker is designed to
provide full-range sound in areas with high ceilings at a low
cost.
The F-121 C/F-121 CM Uniform Directivity Ceiling Speaker
System is designed to provide a much wider dispersion
angle than standard ceiling speakers. Conventional 4" or 8"
ceiling mounted speakers have a severe sound quality and
intelligibility drop off outside the area directly underneath
the speaker. The F-121 C/F-121 CM Uniform Directivity
Ceiling Speaker is equipped with a specially designed
sound diffuser, housed in a mesh cone, and uses the AC-
120 Dedicated Equalizer that ensures optimal frequency
response. The F-121CM is transformer equipped with mul-
tiple line taps for loudness selection. This speaker provides
higher sound quality for low ceiling mounted speaker instal-
lations in public spaces, restaurants, offices, or shopping
malls while requiring fewer units.
TOA
FEATURES
F-101 C/CM High Ceiling Speaker
◆ 80Hz to 18,000 Hz (-10dB) frequency response for
smooth sound.
◆ Powerful 40 watts power handling capacity.
◆ Built-in circuitry automatically activates to alleviate
low/mid frequency excessive input damage.
◆ Self aligning support flange for easy, screw-in installation.
◆ 100/70V line matching transformer for high
impedance applications.
◆ Tuned, ported, bass-reflex type enclosure.
◆ Convenient 24" safety cable with spring clip.
F-121 C/F-121 CM Uniform Directivity Ceiling Speaker
◆ Can be used with AC-120 Dedicated Equalizer.
◆ Housed speaker diffuser designed to expand high
frequency dispersion.
◆ Self aligning support flange for easy, screw-in installation.
◆ Non-conducting grille to prevent dust or discolorization
from static electricity buildup.
◆ Built-in circuitry automatically activates to alleviate
low/mid frequency excessive input damage.
◆ 100/70V line matching transformer for high
impedance applications.
◆ Tuned, ported, bass-reflex type enclosure.
◆ Convenient 24" safety cable with spring clip.
AC-120 Dedicated Equalizer
◆ Built-in equalization filtering provides even sound quality bal-
ance and wide-area intelligibility for F-121 C/F-121 CM.
◆ Low cut switch removes low frequencies during announcements.
◆ Built-in 100Hz, 12dB/octave crossover for use when
F-121/F-121 CM is used with a FB-10 subwoofer.

F-101C/F-101CM
High Ceiling Speaker
SPECIFICATIONS
Model Number F-1O1C
Enclosure Bass-reflex type
Speaker
Full-range, 4.7" cone speaker
Nominal Impedance 8 ohms
Sensitivity 90dB (1W/1m)
Frequency Response 80-18,000Hz (-10dB)
Power Handling
Continuous Pink Noise: 40W
Capacity
Continuous Program: 120W
Finish Enclosure: Black
Front Grille: Off-white
Weight
Dimensions 5.5 Ibs.
Front Grille: 10.24" in diameter
Ceiling Hole: 8.58" in diameter
Ceiling Space: Over 6.3" max in height
Mountable ceiling tile thickness: .2"-1.4"
Model Number F-101 CM
Enclosure
Speaker
Rated Input
Bass-reflex type
Full-range, 4.7" cone speaker
100V taps at line: 20W (500W), 10W (1k Ω)
(Impedance) 5W (2k Ω), 3W(3.3k Ω), 1W (10 Ω)
70V:20W(250 Ω), 10W (500 Ω), 5W (1k Ω),
3W (1.7k Ω) , 1W (5k Ω)
Sensitivity 90dB (1W/1m)
Frequency Response 80-18000Hz (-10dB)
Finish Enclosure: Black
Front Grille: Off-white
Weight
Dimensions 6.2 Ibs.
Front Grille: 10.24" in diameter
Ceiling Hole: 8.58" in diameter
Ceiling Space: Over 6.3" max in height
Mountable ceiling tile thickness: .2"-1.4"
APPEARANCE AND DIMENSIONAL DIAGRAM
*F-101C and F-121C transformer not included
F-101C/F-101 CM POLAR RESPONSE
F-101 C/F-101 CM FREQUENCY RESPONSE
OVERLOAD PROTECTION
To prevent damage from excessive low frequencies, the
F101C has a built-in overload protection circuit. During oper-
ation, if the overload circuit senses excessive low frequency,
it will attenuate the low frequency output of the speaker.
Once activated, the protection circuit will reset in approxi-
mately 10 seconds after turning the system volume down to
prevent reoccurrence.
ARCHITECT’S AND ENGINEER’S
SPECIFICATIONS
The speaker shall be the compactly designed TOA bass-reflex
full-range ceiling mount speaker, the F1O1C at 8 ohms low
impedance/F-101 CM with 70V/100V high impedance line
transformer. The speaker shall provide smooth frequency
response and high power handling capacity.
The F-101C/F-101 CM shall have a ceiling mount assembly
incorporating a 4.7" full-range speaker. Sensitivity shall be
90dB (1W, 1m) with a frequency response of 80Hz to
18,000Hz (-10dB).
Power handling capacity for the F-101C 8Ω impedance unit
shall be 40W continuous pink noise or 120W continuous pro-
gram.
The F-101 C/F-101 CM shall have 5 transformer taps. The taps
shall be 20W, 10W, 5W, 3W and 1W. The F-101C also shall
have a built-in protective circuit that prevents low-mid fre-
quency overload by reducing only the low-mid frequency sig-
nals.
The enclosure shall be a tuned, ported, bass-reflex type mold-
ed from a flame-resistant polymer. It shall incorporate four
spring swing arms and two spring-loaded clips to facilitate
easy installation of both the enclosure and front grille, respec-
tively. It shall include a 24" safety cable with spring clip for
easy anchoring to support structure. It shall also accommo-
date separately supplied T-bars and is sized to fit inside an
appropriate metal back can, if desired.
The finish shall consist of an off-white front grille. Front grille
dimensions shall be 10.24" outer diameter. The ceiling hole
shall be 8.58" in diameter.
Required ceiling space shall be at least 6.30" in height, and
ceiling tile thickness shall range from .02"-1.4".
The assembly’s weight shall not be more than 5.5 Ibs. for the
F-101C and 6.2 Ibs. for the F-101CM with a transformer.

F-121C/F-121CM Uniform Directivity Ceiling Speaker
SPECIFICATIONS
Model Number F-121C
Enclosure Bass-reflex type
Speaker
Full-range, 4.7" cone speaker
Nominal Impedance 8Ω
Sensitivity 90dB (1W/1m)
Frequency Response
80-18,000Hz (-10dB) (70-18,000 Hz w/AC-120)
Power Handling Continuous Pink Noise Input: 40W
Capacity Continuous Program: 120W
Finish Enclosure: Black
Front Grille: Off-white
Weight
5.6Ibs.
Dimensions
Front Grille: 10.24" in diameter
Ceiling Hole: 8.58" in diameter
Ceiling Space: Over 6.3" max in height
Mountable ceiling tile thickness: .2"-1.4"
Model Number F-121 CM
Enclosure Bass-reflex type
Speaker Full-range, 4.7" cone speaker
Rated Input
100V taps at line: 20W (500 Ω) , 10W (1k Ω)
(Impedance) 5W (2k Ω) , 3W (3.3k Ω) , 1W (10 Ω)
70V:20W(250 Ω), 10W (500Ω), 5W (1k Ω) ,
3W (1.7k Ω) , 1W (5k Ω)
Sensitivity 90dB (1W/1m)
Frequency Response
80-18000Hz (-10dB) (70-18,000 Hz w/AC-120)
Finish Enclosure: Black
Front Grille: Off-white
Weight 6.2Ibs.
Dimensions
Front Grille: 10.24" in diameter
Ceiling Hole: 8.58" in diameter
Ceiling Space: Over 6.3" max in height
Mountable ceiling tile thickness: .2"-1.4"
APPEARANCE AND DIMENSIONAL DIAGRAM
*F-101C and F-121C transformer not included
F-121C/F121 CM POLAR RESPONSE
OVERLOAD PROTECTION
To prevent damage from excessive low frequencies, the
F121C has a built-in overload protection circuit. During oper-
ation, if the overload circuit senses excessive low frequency,
it will attenuate the low frequency output of the speaker.
Once activated, the protection circuit will reset in approxi-
mately 10 seconds after turning the system volume down to
prevent reoccurrence.
ARCHITECT’S AND ENGINEER’S
SPECIFICATIONS
The speaker shall be the compactly designed TOA bass-
reflex, wide-dispersion, ceiling mount speaker, the F121C at 8
ohms low impedance/F-121 CM with 70V/100V high imped-
ance line transformer. The speaker shall provide smooth fre-
quency response, high power handling capacity, and, due to
the unique diffuser incorporated into the grille, extremely wide
high frequency dispersion.
The F-121 C/F-121 CM shall have a ceiling mount assembly
incorporating a 4.7" full-range speaker. Sensitivity shall be
90dB (1W, 1m) with a frequency response of 80Hz to
18,000Hz (-10dB).
Power handling capacity for the F-121C/F-121CM 8
Ωunit
shall be 40W continuous pink noise or 120W continuous program.
The transformer taps on the F-121 C/F-121 CM shall be 20W,
10W, 5W ,3W and 1W. The F-121C also shall have a built-in
protective circuit that prevents low-mid frequency overload by
reducing only the low-mid frequency signals.
The enclosure shall be a tuned, ported, bass-reflex type mold-
ed from a flame-resistant polymer. It shall incorporate four
spring-loaded clips to facilitate easy installation of both the
enclosure and front grille, respectively. It shall include a 24"
safety cable with spring clip for easy anchoring to support
structure. It shall also be sized to accommodated mounting
within a separately supplied standard metal back can if
desired.
The 10.24" diameter ceiling grille/diffuser shall have a non-
conducting off-white finish to prevent discoloration or dust
build-up due to static.
The bass-reflex enclosure shall mount in ceiling tiles up to 1.4"
and shall not extend above the tile more than 6.3". The
assembly’s weight shall not be more than 5.6 Ibs for the
F-121C or 6.2 Ibs. for the F-121 CM with a transformer.
F-121C/F121CM FREQUENCY RESPONSE
F-121C/F121CM FREQUENCY RESPONSE

AC-120 Equalizer
SPECIFICATIONS BLOCK DIAGRAM
Model Number AC-120
Power Requirements AC Mains, 50/60Hz
Power Consumption 9W
Distortion
Hum & Noise
Channel Input
Channel Output
Low Frequency
Output
Low cut
Finish
Weight
Less than 0.05% (+4B*, 1kHz)
Less than -94dB* (20Hz-20kHz)
Nominal Input Level: +4dB*, 10KΩ, electronically
balanced, 1/4" jack
Max Output Level: +20dB*
Nominal Output Level: +4dB*, 600KΩ,
electronically balanced, 1/4” jack
Max Output Level: +20dB*
Filter Cutoff Frequency: 100Hz, 12db/oct
Nominal Output Level: +4dB*, 600KΩ
electronically balanced, 1/4" jack
Max Output Level: +20dB*
Filter Cutoff Frequency: 100Hz, 12dB/oct
100Hz, 6dB cut (only with F-121C)
Panel: Aluminum in Black
8.2 Ibs.
Dimensions
*odB=0.775V RMS
19"(W) x 1.37"(H) x 11.71"(D)
**Specifications are subject to change without notice
APPEARANCE AND DIMENSIONAL DIAGRAM
TOA
