INSTRUCTION MANUAL
CLEAN ROOM CEILING SPEAKER PC-5CL
Thank you for purchasing TOA’s Clean Room Ceiling Speaker.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
1. SAFETY PRECAUTIONS
• Before installation or use, be sure to carefully read
all the instructions in this section for correct and
safe operation.
• Be sure to follow all the precautionary instructions
in this section, which contain important warnings
and/or cautions regarding safety.
• After reading, keep this manual handy for future
reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below
are used in this manual to prevent bodily injury and
property damage which could result from mishandling.
Before operating your product, read this manual rst
and understand the safety symbols and messages
so you are thoroughly aware of the potential safety
hazards.
Indicates a potentially hazardous situation which,
if mishandled, could result in death or serious
personal injury.
WARNING
Indicates a potentially hazardous situation which,
if mishandled, could result in moderate or minor
personal injury, and/or property damage.
CAUTION
WARNING
When Installing the Unit
• Install the unit only in a location that can structurally
support the weight of the unit and the mounting
bracket. Doing otherwise may result in the unit
falling down and causing personal injury and/or
property damage.
• Be sure to tighten screws when mounting the
speaker. If not tightened, the screws may come off
due to a vibration, etc. and the speaker may fall,
resulting in personal injuries.
CAUTION
When the Unit is in use
• Do not operate the unit for an extended period of
time with the sound distorting. Doing so may cause
the connected speakers to heat, resulting in a re.

URL: https://www.toa.jp/
133-01-00328-00
Traceability Information for Europe
Manufacturer:
TOA Corporation
7-2-1, Minatojima-Nakamachi, Chuo-ku, Kobe, Hyogo, Japan
Authorized representative:
TOA Electronics Europe GmbH
Suederstrasse 282, 20537 Hamburg, Germany
2. INSTALLATION
Step 1. Make a 98 mm diameter hole in a ceiling. (It is
possible to use the supplied pattern paper for a 98
mm diameter hole.)
Step 2. Attach the supplied rubber gasket to the panel.
Step 3. Connect the input cable to the speaker cable.
100 V Line COM HOT
5 W (2 kΩ) White Black
70 V Line COM HOT
2.5 W (2 kΩ) White Black
Step. 4. Using the four supplied tapping screws, secure the
speaker to the ceiling.
Note
Ensure that the ceiling surface is strong (equivalent
to the plywood thicker than 5 mm) enough to hold
the screws.
330932
9
ø116
ø108
ø98
(mounting hole diameter)
4 – ø3.5
Rubber gasket
Punching net
Black
(100 V Line: 5 W, 70 V line: 2.5 W)
White (COM)
Unit: mm
3. SPECIFICATIONS
Rated Power 5 W
Rated Impedance 100 V line: 2 kΩ (5 W), 70 V line: 2 kΩ (2.5 W)
Sensitivity 87 dB (1 W, 1 m)
Frequency Response 150 Hz – 20 kHz
Enclosure Completely sealed type
Speaker Component 8 cm cone-type (vibration section : high molecular substance)
Operating Temperature –20 to +55 °C
Dust Particle Prevention No dust particle is produced by the method set out in JIS B-9926.
Finish Panel: Alloy-coated ABS resin
Enclosure: ABS resin, off-white
Punching net: Stainless steel
Exposed xing screw: Stainless steel
Dimensions ø116 x 104 (d) mm
Weight 620 g
Dimensions for Fixing Holes ø98 mm
Note: The design and specications are subject to change without notice for improvement.
• Accessories
Rubber gasket (chloroprene rubber) .................... 1
Tapping screw (3 x 16) .......................................... 4
Pattern paper ........................................................ 1
