Toa RM-200SF User manual

INSTALLATION MANUAL
INTEGRATED VOICE EVACUATION SYSTEM
VX-3000 SERIES
Thank you for purchasing TOA’s Integrated Voice Evacuation System.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

2
TABLE OF CONTENTS
Chapter 1 : NOTE
1. SAFETY PRECAUTIONS .......................................................................... 1-2
2. GENERAL DESCRIPTION ....................................................................... 1-5
3. SYSTEM FEATURES ................................................................................... 1-5
4. SYSTEM EXAMPLE ..................................................................................... 1-5
Chapter 2 : NOMENCLATURE AND FUNCTIONS
1. VX-3004F/3008F/VX-3016F VOICE EVACUATION
FRAME .................................................................................................................. 2-2
2. VX-015DA/030DA/050DA DIGITAL POWER AMPLIFIER
MODULE ............................................................................................................. 2-9
3. RM-200SF FIREMAN'S MICROPHONE ........................................ 2-10
4. RM-320F FIREMAN'S MICROPHONE EXTENSION ............ 2-13
5. RM-300X REMOTE MICROPHONE ................................................. 2-14
6. RM-210F REMOTE MICROPHONE EXTENSION ................... 2-17
7. RM-200RJ TERMINAL UNIT ................................................................. 2-18
8. SX-200EL END OF LINE UNIT ............................................................ 2-19
9. VM-300SV END OF LINE UNIT .......................................................... 2-19
Chapter 3 : INSTALLATION AND SETTING PROCEDURES
(HARDWARE)
1. VX-015DA, VX-030DA, AND VX-050DA DIGITAL POWER
AMPLIFIER MODULE ................................................................................ 3-2
1.1. Changing the Speaker Line Voltage .................................................................. 3-2
1.2. Replacing the Blade Fuse ................................................................................. 3-2
2. VX-3004F, VX-3008F, AND VX-3016F VOICE EVACUATION
FRAME ................................................................................................................. 3-3
2.1. Installing VX-015DA/030DA/050DA Digital Power Amplifier Module ................ 3-3
2.2. The Zones Allocation Setting ............................................................................ 3-5
2.3. The ID Number Setting ...................................................................................... 3-7
2.4. Setting the IP Address ...................................................................................... 3-8
3. RM-200SF AND RM-300X MICROPHONES ............................... 3-9
3.1. The ID Number Settings .................................................................................... 3-9

3
3.2. Adjusting Microphone Sensitivity
3.3. CPU Off Function (All-Zone Emergency Broadcast) Settings ......................... 3-13
3.4. Termination Setting .......................................................................................... 3-14
3.5. Using an External Microphone (RM-300X Only) ............................................. 3-15
3.6. Using an Auxiliary Input (RM-300X Only) ........................................................ 3-17
3.7. Compressor Function Setting ........................................................................... 3-19
3.8. Microphone Fault Detection Function Setting (RM-300X Only) ....................... 3-21
3.9. Installing the RM-200SF on a Wall ................................................................. 3-22
3.10. Installing the RM-320F on a Wall (RM-200SF only) ...................................... 3-26
3.11. RM-300X Extension with the Addition of the RM-210F ................................. 3-28
3.12. Installing the RM-300X on a Wall .................................................................. 3-29
3.13. Installing the RM-210F on a Wall (RM-300X Only) ....................................... 3-30
3.14. Creating Remote Microphone Name Labels ................................................. 3-32
3.15. Rack Mounting .............................................................................................. 3-35
4. CONNECTIONS ........................................................................................... 3-36
4.1. Removable Terminal Plug Connection ............................................................ 3-36
4.2. Input Equipment Connections ......................................................................... 3-37
4.3. Speaker Connection ....................................................................................... 3-53
4.4. Control Output Terminal Connections ............................................................. 3-56
4.5. Control Input Terminal Connections ............................................................... 3-57
4.6. Emergency Control Input Terminal Connections ............................................ 3-58
5. VX-3000F CONNECTION ...................................................................... 3-59
5.1. LAN Link Connector Connections ................................................................... 3-59
5.2. Sharing Standby Amplifier .............................................................................. 3-65
5.3. Speaker Selector Extension ........................................................................... 3-66
5.4. Analog Link Terminal Connections ................................................................. 3-67
6. SPEAKER LINE INITIAL SETTING ................................................. 3-68
6.1. Setting Items ................................................................................................... 3-68
6.2. OPEN/SHORT Criterion by Comparing the Current Value
with the Initial Value ........................................................................................ 3-68
6.3. Setting Procedures ......................................................................................... 3-69
Chapter 4 : APPENDIX
1. THE FIRMWARE VERSION CONFIRMATION ............................ 4-2
2. SPECIFICATIONS ......................................................................................... 4-4
2.1. VX-3004F Voice Evacuation Frame 4SS .......................................................... 4-4
2.2. VX-3008F Voice Evacuation Frame 8SS .......................................................... 4-6
2.3. VX-3016F Voice Evacuation Frame 16SS ........................................................ 4-8
2.4. VX-015DA Digital Power Amplifier Module 150 W ........................................... 4-10
2.5. VX-030DA Digital Power Amplifier Module 300 W .......................................... 4 -11
2.6. VX-050DA Digital Power Amplifier Module 500 W .......................................... 4-12
2.7. RM-200SF Fireman's Microphone ................................................................... 4-13
2.8. RM-320F Fireman's Microphone Extension .................................................... 4-14
2.9. RM-300X Remote Microphone ....................................................................... 4-15
2.10. RM-210F Remote Microphone Extension ...................................................... 4-16
2.11. RM-200RJ Terminal Unit ................................................................................ 4-16
2.12. VM-300SV End Of Line Unit ......................................................................... 4-17

Chapter 1
NOTE

1-2
Chapter 1 NOTE
1. SAFETY PRECAUTIONS
• Beforeinstallationoruse,besuretocarefullyreadalltheinstructionsinthissectionforcorrectandsafe
operation.
• Besuretofollowalltheprecautionaryinstructionsinthissection,whichcontainimportantwarningsand/or
cautions regarding safety.
• Afterreading,keepthismanualhandyforfuturereference.
• Thisequipmentisnotsuitableforuseinlocationswherechildrenarelikelytobepresent.
• Anequipmentinstallerandthepersoninchargeofmaintenancearerequiredtofullyunderstandthefunctions
and structure of this unit, then be aware of electrical and mechanical risks before work.
Before starting work, he or she should take possible measures to prevent occurrence of such risks.
 BesuretocontactyournearestTOAdealerifyouneedtoconrmunclearpointsaboutrisksourcesofthis
unit.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury and property
damage which could result from mishandling. Before operating your product, read this manual rst and
understand the safety symbols and messages so you are thoroughly aware of the potential safety hazards.
When Installing the Unit
• Donotexposetheunittorainoranenvironmentwhereitmaybesplashedbywaterorotherliquids,asdoing
somayresultinreorelectricshock.
• Sincetheunitisdesignedforindooruse,donotinstallitoutdoors.Ifinstalledoutdoors,theagingofparts
causes the unit to fall off, resulting in personal injury. Also, when it gets wet with rain, there is a danger of
electric shock.
• (ApplicabletoVX-3004F,VX-3008F,VX-3016F,VX-015DA,VX-030DA,VX-050DA,RM-200SF,RM-300X,
and VX-3000DS only)
 Usetheunitonlywiththevoltagespeciedontheunit.Usingavoltagehigherthanthatwhichisspecied
mayresultinreorelectricshock.
• (ApplicabletoVX-3000DSonly)
Do not cut, kink, otherwise damage nor modify the power supply cord. In addition, avoid using the power cord
in close proximity to heaters, and never place heavy objects -- including the unit itself -- on the power cord,
asdoingsomayresultinreorelectricshock.
• (ApplicabletoRM-200SF,RM-300X,RM-320F,andRM-210Fonly)
Avoid installing or mounting the unit in unstable locations, such as on a rickety table or a slanted surface.
Doing so may result in the unit falling down and causing personal injury and/or property damage.
• (ApplicabletoRM-200SF,RM-300X,RM-320F,andRM-210Fonly)
Install the unit only in a location that can structurally support the weight of the unit and the mounting bracket.
Doing otherwise may result in the unit falling down and causing personal injury and/or property damage.
When the Unit is in Use
• Shouldthefollowingirregularitybefoundduringuse,immediatelyswitchoffthepower,disconnectthepower
supply plug from the AC outlet and contact your nearest TOA dealer. Make no further attempt to operate the
unitinthisconditionasthismaycausereorelectricshock.
· If you detect smoke or a strange smell coming from the unit
· If water or any metallic object gets into the unit
· If the unit falls, or the unit case breaks
· (Applicable to VX-3000DS only)
If the power supply cord is damaged (exposure of the core, disconnection, etc.)
· If it is malfunctioning (no tone sounds)
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
WARNING

1-3
Chapter 1 NOTE
• Topreventareorelectricshock,neveropennorremovetheunitcaseastherearehighvoltagecomponents
inside the unit.
(Applicable to VX-3004F, VX-3008F, VX-3016F, RM-200SF, RM-300X, and VX-3000DS only)
 Referallservicingtoqualiedservicepersonnel.
• Donotplacecups,bowls,orothercontainersofliquidormetallicobjectsontopoftheunit.Iftheyaccidentally
spillintotheunit,thismaycauseareorelectricshock.
• (ApplicabletoVX-3004F,VX-3008F,VX-3016F,VX-015DA,VX-030DA,VX-050DA,VX-3000DSonly)
 Donotinsertnordropmetallicobjectsorammablematerialsintheventilationslotsoftheunit’scover,asthis
mayresultinreorelectricshock.
• (ApplicabletoVX-3000DSonly)
Do not touch a power supply plug during thunder and lightning, as this may result in electric shock.
• Whenreplacingthefuse,besuretousethesuppliedone.Usinganyotherfusethansuppliedmaycausere
or electric shock.
VX-015DA: Blade 10 A
VX-030DA: Blade 20 A
VX-050DA: Blade 30 A
VX-3000DS: AC T8A H, AC T6.3A L, and Blade 35 A
• (ApplicabletoVX-3000DSonly)
Handle or use the batteries properly.
 Doingotherwisemaycauseleakageorexplosionofthebatteries,resultinginare,personalinjury,damage
to peripheral equipment, or contamination of environment.
When Installing the Unit
• (ApplicabletoVX-3000DSonly)
Never plug in nor remove the power supply plug with wet hands, as doing so may cause electric shock.
• (ApplicabletoVX-3000DSonly)
When unplugging the power supply cord, be sure to grasp the power supply plug; never pull on the cord itself.
Operatingtheunitwithadamagedpowersupplycordmaycauseareorelectricshock.
• (ApplicabletoVX-3004F,VX-3008F,VX-3016F,VX-015DA,VX-030DA,VX-050DA,andVX-3000DSonly)
Do not block the ventilation slots in the unit’s cover. Doing so may cause heat to build up inside the unit and
resultinre.
(Applicable to VX-015DA, VX-030DA, and VX-050DA only)
Also, periodically clean the ventilation slots of dust.
• Avoidinstallingthe unit inhumid or dustylocations,in locations exposed to thedirectsunlight,near the
heaters,orinlocationsgeneratingsootysmokeorsteamasdoingotherwisemayresultinreorelectric
shock.
• (ApplicabletoVX-3004F,VX-3008F,VX-3016F,VX-015DA,VX-030DA,VX-050DA,RM-200SF,RM-300X,
and VX-3000DS only)
Note correct polarity (positive and negative orientation) when connecting the power supply cord. Reversed
polarity connections will cause damage to the unit.
• (ApplicabletoVX-3004F,VX-3008F,VX-3016F,andVX-3000DSonly)
System units (except remote microphones) are designed exclusively to be mounted in an equipment rack.
Besureobservethefollowinginstructionswhenrack-mountingtheunit.Failuretodosomaycauseareor
personal injury.
· Installtheequipment rackonastable,hardoor.Fixitwithanchor boltsortakeotherarrangementsto
prevent it from falling down.
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
CAUTION

1-4
Chapter 1 NOTE
· Rack-mounting screws are not supplied with the unit. Prepare them that are appropriate for the equipment rack .
· (Applicable to VX-3000DS only)
When connecting the unit’s power cord to an AC outlet, use the AC outlet with current capacity allowable to
the unit.
• (ApplicabletoVX-3000DSonly)
When connecting multiple appliances to a single power socket through a multi-outlet power strip, a total
current consumption of the appliances must not exceed the allowable current capacity of the power socket.
 Failuretoobservethisinstructionmayresultinareorelectricshock.
• (ApplicabletoVX-3000DSonly)
When 2 or more AC power cords are connected to a multi-outlet power strip, never remove the power strip
from a power source.
When the Unit is in Use
• (ApplicabletoVX-3004F,VX-3008F,VX-3016F,VX-015DA,VX-030DA,andVX-050DAonly)
Do not operate the unit for an extended period of time with the sound distorting. Doing so may cause the
connectedspeakerstoheat,resultinginare.
• (ApplicabletoRM-200SFandRM-300Xonly)
 UsethespeciedACadapterfortheunit.Notethattheuseofotheradaptermaycauseare.
• (ApplicabletoVX-015DA,VX-030DA,andVX-050DAonly)
Contact your TOA dealer as to the cleaning. If dust is allowed to accumulate in the unit over a long period of
time,areordamagetotheunitmayresult.
• (ApplicabletoVX-3000DSonly)
 Makesuretoobservethefollowinghandlingprecautionssothatareorpersonalinjurydoesnotresultfrom
leakage or explosion of the battery.
· Donotshort,disassemble,heatnorputthebatteryintoare.
· Avoid using both new and old batteries together.
· Never charge batteries of the type which are not rechargeable.
· Do not solder a battery directly.
· Besuretousethespeciedtypeofbatteries.
· Note correct polarity (positive and negative orientation) when connecting a battery to the unit.
· Avoid locations exposed to the direct sunlight, high temperature and high humidity when storing batteries.
• (ApplicabletoRM-200SF,RM-300X,RM-320F,andRM-210Fonly)
Have the unit checked periodically by the shop from where it was purchased. Failure to do so may result
in corrosion or damage to the unit or its mounting bracket that could cause the unit to fall, possibly causing
personal injury.

1-5
Chapter 1 NOTE
2. GENERAL DESCRIPTION
The TOA VX-3000 Series Integrated Voice Evacuation System is designed for both general and emergency
purpose broadcasts.
ItiscomprisedoftheVoiceEvacuationFrame,DigitalPowerAmpliermodules,PowerSupplyunit,Emergency
PowerSupply,andauser-speciednumberofRemoteMicrophones.
The VX-3000 system allows 3 types of broadcasts to be made: General-purpose broadcast such as general
paging and BGM, Emergency broadcast that the emergency messages are to be broadcast by an automatic
announcement device or remote microphone, All-zone emergency broadcast* that is to be made available even
during system malfunctions or failures.
The dedicated software is used to perform all necessary settings related to the entire system operation and
functionsincludingsystemcongurations,input-to-outputsignalrouting,functionassignmenttotheoperation
keys, operation of the control terminals, and selection of the failure detection points.
* Available when an analog link is connected.
3. SYSTEM FEATURES
• VX-3000systemisavoiceevacuationsystem.
• Decentralizedcongurationispossiblevianetwork.
• VX-3000systemisconstructedupto128ABzonesor512zonesassystem.
• SpeakerSelectorfunctionisimplemented,thenVX-3000systemisabletocovermanyzones.
• Ageneralbroadcastforasoundqualityregulatingfunctionispossibletodigitalizeallsound.
• Ageneralbroadcastingispossiblebylatitudesettingofcontrolinput/outputandpriorities.
4. SYSTEM EXAMPLE
LAN
VX-3000 System
VX-3000 System
1A
1B
4A
4B
VX-3004F
BGM unit
RM-300X RM-210F RM-200SF RM-320F
VX-015DA/030DA/050DA
VX-3000DS

Chapter 2
NOMENCLATURE AND FUNCTIONS

2-2
Chapter 2 NOMENCLATURE AND FUNCTIONS
1. VX-3004F/3008F/VX-3016F VOICE EVACUATION FRAME
VX-3004F, VX-3008F, and VX-3016F are collectively referred to as "VX-3000F" in this manual.
• TheVX-3000FisaunitdesignedtocontroltheVoiceevacuationannouncementsoftheVX-3000seriesvoice
evacuation system.
• Ithasaudioinputterminalsandcanoutputtheampliedaudiosignalstothespeakerlineswhentheoptional
powerampliermodulesaremounted.
• Compatiblewithnetwork,thesystemcanbeconguredindistributedarrangement.
[Front]
Amplifier section Fault status section
[Amplifier section] [Fault status section]
9
10
11
12
13
14
15
16
17
18
19
20 21 22 23
1
2
3
5
6
7
8
4
VX-3004F
VX-3008F
Amplifier section Fault status section
1
2
3
5
6
7
8
[Amplifier section] [Fault status section]
9
10
11
12
13 14
15
16
17
18
19
20 21 22 23
4

2-3
Chapter 2 NOMENCLATURE AND FUNCTIONS
1. Power indicator (Green)
Lights when the power is supplied.
Flashes in standby state.
2. RUN indicator (Green)
Normallyashescontinuously.Goesoffwhilein
a CPU off state (p. 3-13). Also goes off while in
standby state*1.
*1A state during power failures or a state that the
unit is internally initialized after power-on
3. Emergency indicator (Red)
Lights when the VX-3000 system is in an
emergency condition or while in a CPU off state
(p. 3-13).
4. CPU off indicator (Red)
Lights while in a CPU off state (p. 3-13).
5. LAN A indicator (Green)
Lights when the LAN link A connector (49) on the
rearpanelisconnected,andashesduringLAN
communications.
6. LAN B indicator (Green)
Lights when the LAN link B connector (49) on the
rearpanelisconnected,andashesduringLAN
communications.
7. RS link A indicator (Green)
Lights when the RS link A connector (50) on
the rear panel is connected, and ashes while
communications are being performed via the RS
link A connector.
8. RS link B indicator (Green)
Lights when the RS link B connector (50) on
the rear panel is connected, and ashes while
communications are being performed via the RS
link B connector.
 9.Amplierpeakindicators(Red)
Showtheinputsignalstatetothepoweramplier
whenthepowerampliermoduleisinstalled.
The indicator corresponding to the module slot
port will light if the input signal level exceeds +0.5
dB*2.
Itremainsunlitwhennopowerampliermodule
is installed.
10.Ampliersignalindicators(Green)
Showtheinputsignalstatetothepoweramplier
whenthepowerampliermoduleisinstalled.
The indicator corresponding to the module slot
port will light if the input signal level exceeds - 25
dB*2.
Itremainsunlitwhennopowerampliermodule
is installed.
VX-3016F
[Amplifier section] [Fault status section]
9
10
11
12
13
14
15
16
17
18
19
20 21 22 23
1
2
3
5
6
7
8
4
Amplifier section Fault status section
*20 dB = 1 V

2-4
Chapter 2 NOMENCLATURE AND FUNCTIONS
11.Amplieroperateindicators(Green)
The indicator corresponding to the module slot
port will light or go off depending on the operation
state of the power amplier when the power
ampliermoduleisinstalled.
Operating status Indicator status
In-use Lit
Standby Unlit
DC fuse blowout Unlit
Protection* activated Unlit
* The built-in protection circuit operates if some
irregularitiesoccurinsidetheampliersuchas
abnormal temperature rise or fan failure.
Itremainsunlitwhennopowerampliermodule
is installed.
12.Amplierpowerindicators(Green)
The indicator corresponding to the module slot
port will light or go off depending on the operation
state of the power amplier when the power
ampliermoduleisinstalled.
Operating status Indicator status
In-use Lit
Standby Lit
DC fuse blowout Unlit
Protection* activated Lit
* The built-in protection circuit operates if some
irregularitiesoccurinsidetheampliersuchas
abnormal temperature rise or fan failure.
Itremainsunlitwhennopowerampliermodule
is installed.
13. Zone fault indicators (Yellow)
Lightsorasheswhenthespeakerlinesurveillance
function detects 3 types of failures: poor insulation
(ground fault), overload (line short), and cable
disconnection.
14. Fuse fault indicator (Yellow)
Lights or ashes when DC fuse blowout are
detected.
15. Power fault indicator (Yellow)
Lights or ashes when failures are detected in
Power Supply Manager.
16. CPU fault indicator (Yellow)
Lights while in a CPU off state (p. 3-13) or when a
failure is detected in the VX-3000F.
17. General fault indicator (Yellow)
Lights while in a CPU off state (p. 3-13) Lights or
asheswhenafailureisdetectedinthesystem.
18. Unit fault indicator (Yellow)
Lightsorasheswhenafailureisdetectedinthe
unit.
19. Network fault indicator (Yellow)
Lights or ashes when failures are detected in
communications with the other VX-3000F.
It also ashes or lights at network setting and
whenacongurationerroroccurs.
20.
Emergency microphone fault indicator (Yellow)
Lights or ashes when failures are detected in
Emergency Microphone.
21. Fault ACK key
The buzzer will sound and Fault indicator will
asheswhenafailureisdetectedinthesystem.
Press this key to stop the buzzer and switches the
Faultindicatorfromashingtosteadyon.
22. Fault reset key
Pressing this key resets the failure information
(the buzzer and fault indicators) for the system.
23. Lamp test key
Used to test each indicator on the front panel of
the VX-3000F Voice Evacuation Frame.
All indicators remain lit and the buzzer sounds as
long as this key is pressed.

2-5
Chapter 2 NOMENCLATURE AND FUNCTIONS
24. Audio input volume controls
Adjust the input volume of each input channel.
Rotating the control fully counterclockwise mutes
the input sound source connected to that channel.
25. Module slots
Accommodate the VX-015DA, VX-030DA, or VX-
050DA, Digital Power Amplier Module. Up to 4
modules can be installed to the VX-3004F, up to 3
to the VX-3008F, and up to 2 to the VX-3016F.
26. Reset key
Pressing this key reactivates the VX-3000F.
27. ID switch
Sets the VX-3000F's ID number (device number).
28. DA control link connector
Connect this connector to the DA control link
connectoroftheinstalleddigitalpoweramplier
module.
29. DIP switch
[VX-3004F]
•Switches1–6
These switches are not used.
•Switch7
Used when conrming the rmware version.
(See p. 4-2.)
•Switch8
Used to set the IP address. (See p. 3-8.)
[VX-3008F]
•Switches1–3
Used to allocate speaker lines. (See p. 3-5.)
•Switches4–6
These switches are not used.
•Switch7
Used when conrming the rmware version.
(See p. 4-2.)
•Switch8
Used to set the IP address. (See p. 3-8.)
[VX-3016F]
•Switch1
Used to place the unit in 2 channel mode
operation. (See p. 3-5.)
•Switches2–6
These switches are not used.
•Switch7
Used when conrming the rmware version.
(See p. 4-2.)
•Switch8
Used to set the IP address. (See p. 3-8.)
Note
By default, switches 1 – 7 are set to OFF, and
switch 8 to ON.
30. Impedance initialize key
Press this key to acquire the initial value of the
speaker line impedance as failure detection is
executed on the basis of the impedance change.
31. DA output link connector
Connect this connector to the DA output link
connectoroftheinstalleddigitalpoweramplier
module.
24 25
26 27 28 28 28 2829 30 31 313131
[Front panel detached]

2-6
Chapter 2 NOMENCLATURE AND FUNCTIONS
[Rear]
VX-3004F
VX-3008F
VX-3016F
32 33 33 3334 34 34 343335 3535 35 36
37 38 39 40 41 4342
44 45 46
47 48 49 50
44
45
3632 33 35 33 35 33 3534 34 34
37 38 39
46
47 48 49 50 51 52
42
41 43 40
45
44
37 38 39 51 52
42 3632 33 35 33 3534 34
46
47 48 49 50
41 41 43
40

2-7
Chapter 2 NOMENCLATURE AND FUNCTIONS
32. DC power input terminal
Connect an optional DC power supply unit to
this terminal. Select the DC power supply source
with consideration given to the current power
consumption of the system the VX-3000F is to be
connected to.
(See the Instruction Manual attached to the VX-
3000DS.)
33. Fuse
When an amplier module is installed, its fuse
can be checked.
Youcanreplacethefusewiththeampliermodule
installed to the VX-3000F. (See p. 2-9.)
34.Ampliermodelnumberindicationwindow
Whenapowerampliermoduleisinstalled,you
can check its model number.
35.AmplierDCpowerinputterminal
Whenapowerampliermoduleisinstalled,you
can check its power input terminals. (See p. 2-9.)
36. Audio input terminals
Electronically-balanced47kΩ,–20dB*/–60dB*,
Terminal connectors. LINE or MIC input can be
selected, and the phantom power supply turned
on and off. (See the separate Setting Software
Instructions,"UnitCongurationSetting.")
* 0 dB = 1 V
37. Signal ground terminal
Hum noise may be generated when external
equipment is connected to the unit. Connecting
this terminal to the signal ground terminal of the
external equipment may reduce the hum noise.
Note: This terminal is not for protective ground.
38.Standbyamplieroutputconnector
WhenastandbyamplierissharedbymultipleVX-
3000F units, connect this connector to the standby
amplierinputconnectorofotherVX-3000F.
39.Standbyamplierinputconnector
When making the VX-3000F with no standby
ampliersharethestandbyamplierinstalledto
other VX-3000F, connect this connector to other
VX-3000F'sstandbyamplieroutputconnector.
40. MAC address
This is the MAC address* for the unit. Since
the relationship of each unit location to its MAC
address is established when setting the network
attributes, keep track of this relationship for later
use.
* The unit’s MAC address consists of 12
hyphenated alphanumeric characters.
41. Speaker output terminals
Connect speakers to these outputs.
42. ATT/Control output terminals
These terminals permit the VX-3000 system to
control other connected external equipment.
Alternatively, these terminals become attenuator
control outputs by setting.
43. Emergency control input terminal
Connect to an automatic re alarm system and
activate emergency broadcasts, play back/stop
automatic emergency announcements and reset
emergency broadcasts.
Two isolated voltage inputs which activates when
the polarity of the applied voltage (24 V DC is kept
applied to this terminal under normal condition) is
reversed.
44. DS link connectors
Connects this connector to the DS LINK IN
connector of the VX-3000DS.
45. Analog link output connector
Connect this connector to the analog link input
connector of the other VX-3000F.
46. Analog link input connector
Connect this connector to the analog link output
connector of the other VX-3000F.
47. Control output connectors
These RJ45 connectors permit the VX-3000
system to control other connected external
equipment.
48. Control input connectors
These RJ45 connectors receive activation signals
from external equipment to enable external VX-
3000 system control.
Alternatively, these connectors become EOL
inputs by setting.
33 34 35

2-8
Chapter 2 NOMENCLATURE AND FUNCTIONS
49. LAN link connectors
Use switching hubs to connect between the LAN
link connector of the VX-3000F. Connect each
of the LAN Links A and B to the same switching
hub*, or to different switching hubs* that have
beenconnectedinstarconguration.
Also, it is possible to interconnect the VX-3000F
units directly using the LAN link connectors A and
B without using switching hubs.
* Contact your TOA dealer for more information
on switching hubs.
Notes
• BesuretoconnectbothconnectorsofAandB.
• After connection completion, press the Reset
key to reactivate the VX-3000F.
50. RS link connectors
Connect the RM-200SF Fireman's Microphone
or RM-300X Remote Microphone to these
connectors.
51. Extension output connectors
Connect these connectors to the Extension input
connector of the VX-3000F in SS mode (with no
built-inDigitalPowerAmplier)forzonenumber
expansion by the VX-3008F or VX-3016F.
52. Extension input connectors
Connect these connectors of the VX-3008F or
VX-3016F set to SS mode to the Extension output
connector of the VX-3000F in normal mode.

2-9
Chapter 2 NOMENCLATURE AND FUNCTIONS
2. VX-015DA/030DA/050DA DIGITAL POWER AMPLIFIER MODULE
• TheVX-015DA,VX-030DA,andVX-050DAareDigitalpowerampliermodulesusedfortheVX-3000system.
• Theyaremoduletypeswith1channelofclass-Ddigitalpoweramplier,whichcontributestoenergy-saving
and light weight design.
• TheVX-015DA,VX-030DA,andVX-050DAalsofeaturestandbymodetobesetforreducingstandbypower
consumption.
• TheyrequireVX-3000FcontrolunitandVX-3000DSpowersupplyunit.
Module lineup includes the following 3 models different in rated output.
VX-015DA :150 W
VX-030DA :300 W
VX-050DA :500 W
1. DA control link connector
Connect this connector to the DA control link
connector of the VX-3000F to which this module is
installed using the supplied harness.
2. Fixing screw
Fixes the module to the VX-3000F.
3. Model number indication
4. DA output link connector
Connect this connector to the DA output link
connector of the VX-3000F to which this module is
installed using the supplied harness.
5. Filter
Dustprooflter.
Removeandcleanthelterperiodically.
Ifthelterbecomesclogged,heatwillbetrapped
inside the module.
6. Fuse
Use a blade fuse described below depending on
thepoweramplier'sratedoutput.
VX-015DA : 10 A
VX-030DA : 20 A
VX-050DA : 30 A
7. DC power input terminal
Connect an optional DC power supply unit to this
terminal. (See the Instruction Manual attached to
the VX-3000DS.)
8. Output voltage selection switch
Usedtoselectpoweramplier'sratedoutputvoltage.
[Rear]
6 7
[Left Side]
8
1
234
Appearance with
a filter detached
Appearance with
a filter attached
5
[Front]

2-10
Chapter 2 NOMENCLATURE AND FUNCTIONS
3. RM-200SF FIREMAN'S MICROPHONE
• TheRM-200SFFireman’sMicrophonefeatures3functionkeys,1emergencykey,1talkkey,andtheindicator
lamps associated with these keys. Functions are assigned to the function keys using the VX-3000 Setting
Software.
• Speciallydesignedforbothemergencyandgeneralpurposebroadcastapplications,theFireman’sMicrophone
can be used for push-button zone selection and microphone broadcasts.
• VX-3000settingsoftwarepermitsdesiredfunctionstobeassignedtoindividualFunctionkeys(equippedwith
2 LED indicators).
• Upto4RM-320FRemoteMicrophoneExtensionunitscanbeusedwitheachRM-200SFRemoteMicrophone.
•Upto2RM-200SFFireman’sMicrophonescanbeconnectedwithinaVX-3000F.
• TheCPUswitchenablesall-zoneemergencybroadcastsfromtheRM-200SFFireman’sMicrophone,even
when the CPU malfunctions.
•FailuresofEmergencybuttonsandsignal(bothcontrolandaudio)pathbetweenthemicrophone(including
the internal microphone element) and the VX-3000F are automatically detected.
[Front]
1. Power indicator (Green)
Lights when the power is turned on.
2. Emergency key
Assign emergency activation function to this key
using the VX-3000 Setting Software.
Lights when the VX-3000F is in an emergency
condition.
3. Monitor speaker
Used to monitor current broadcasts.
4. Monitor speaker volume control
Adjusts the volume of the built-in Monitor speaker
(3).
5. Microphone volume control
Adjusts the input sensitivity of the Hand-held
Microphone.
6. Microphone hanger
Used to hold the unit's Hand-held Microphone.
7. CPU switch
Normally set to ON. (Factory-preset: ON)
Setting this switch to OFF in combination with
the DIP switch (20) setting on the bottom surface
allows the all-zone emergency broadcast to be
made using a hand-held microphone by way of
analog transmission not via the CPU control.
8. Indication label insert slot
The label can be printed using the VX-3000
Setting Software. (See the separate Setting
Software Instructions, "PRINTING LABELS FOR
REMOTE MICROPHONES.")
9. Failure indicator (Yellow/Red)
Flashes yellow if some problem within the system
is detected.
This indicator will light yellow if the signal to the
VX-3000F or VX-3000F to which the RM-200SF
is connected is interrupted for 5 seconds or more.
Lights red when the unit is placed in reset state by
pressing the Reset Switch (11).
FIREMAN'S MICROPHONE
RM-200SF
MIC SP CPU
OFF ON
1
2
3
4
5
6
7 8
9
10
11 12
13
14
15
16
17
[Hand-held microphone]
18

2-11
Chapter 2 NOMENCLATURE AND FUNCTIONS
10. CPU indicator (Red)
Lights red when any one of the CPU switches
on the RM-200SFs connected within the system
is set to OFF or when the all-zone emergency
broadcasts is being made by any one of the RM-
300Xs connected within the system.
11. Reset switch
Used to reactivate the RM-200SF unit.
Holding down both this switch and the R3 key
of the Function keys (14) for 2 seconds or more
causes the Failure Indicator (9) to light red,
placing the RM-200SF in reset state.
12. Status indicators (Red/Yellow/Green)
Light, ash, or go off depending on the current
operation state of function keys, failure state or
emergency state. (See the separate Operating
Instructions, "INDICATOR STATUS OF REMOTE
MICROPHONES.")
13. Selection indicators (Green)
Light or go off depending on the current operation
state of function keys. (See the separate Operating
Instructions, "INDICATOR STATUS OF REMOTE
MICROPHONES.")
14.Functionkeys(R1–R3)
Positioned in top-down order (R1, R2, R3).
Pressing a specic function key executes the
function that has been assigned to that key by
the VX-3000 Setting Software. Assignment of
functionstospecickeysisdoneusingtheVX-
3000 Setting Software. (See the separate Setting
Software Instructions, "RM Event Settings.")
15. Microphone indicator (Green)
Lights or goes off depending on the current
operation state of the Talk key.
16. Broadcast Status Indicator (Yellow/Green)
Lights, ashes, or goes off depending on the
current operation state of the Talk key.
17. Talk key
Press this key to broadcast a voice announcement.
It must be pressed continuously for the duration
of the broadcast.
Thetalkkeyoperationmethodisxedto"PTT,"
and can not be changed.
18. Microphone
Used for voice announcements.
EXTENSION
19
19. RM-320F connection terminal
Connect the RM-320F Remote Microphone
Extension unit to this terminal. (See p. 2-13.)
[Side]

2-12
Chapter 2 NOMENCLATURE AND FUNCTIONS
[Wall mount bracket unit (Accessory)]
23
24
[Rear]
8
7
6
5
4
3
2
1
TERMINATION
CPU OFF
LEVEL METER
COMMUNICATION
UNIT ID
OnOff
DIP SWITCH
20 21 22
20. DIP switch
Used for setting the RM-200SF unit.
•Switches1–3[UNITID]
Set the RM-200SF's device number (ID number).
(See p. 3-9.)
•Switch4[COMMUNICATION]
Sets the RM communication function. (See
p. 3-14.)
•Switch5[LEVELMETER]
Changes a broadcast status indicator (12) into
an output signal level indicator. (See p. 3 -11.)
•Switch6[CPUoff]
Sets whether the CPU off function (all-zone
emergency broadcasts) is enabled or disabled.
(See p. 3-13.)
•Switch7
Not used. Normally set to OFF .
•Switch8[TERMINATION]
Sets the termination of the RM communication
line (Control communication lines between the
VX-3000F and the RM-200SF). Normally set to
OFF.
Note
By default, switches 1 – 5 and 7 are set to OFF,
and switches 6 and 8 to ON.
21. USB terminal
Not used.
22. Extension connector
Connect this connector to the extension connector
(23) of the Wall Mount Bracket Unit (accessory).
(See p. 3-25.)
23. Extension connector
Connect the cable extending from the RM-200SF
to this connector. (See p. 3-25.)
24. Screw terminal block
•Audiomonitorline[MONITORIN]
Connect the audio monitor input line from the
VX-3000F to the RM-200SF.
•RMcommunicationline[DATA]
Connect the control communication line between
the VX-3000F and the RM-200SF.
•Audiooutputline[AUDIOOUT]
Connect the audio signal output line from the
RM-200SF to the VX-3000F.
•DCpowerinput[DCIN24V]
Used to supply DC power from the VX-3000F to
t he R M -2 0 0 SF.
•Shield[SHIELD]
Used for the control line through which the
VX-3000F system conrms the RM-200SF's
connection.
Be sure to connect at least one of two terminals
to the VX-3000F.
