Foodservice Equipment
Job ________ Item# ________
1400 Toastmaster Drive, Elgin IL 60120-9272 USA - Tel: [phone] - Fax: [phone] - www.toastmastercorp.com
Form 901 Rev 0 (02/05)
Application
The Toastmaster Countertop Gas
Charbroiler is the most economical
and flexible Countertop Charbroiler
in the food service industry. It offers
unsurpassed performance,
combining a proven control system
with Toastmaster quality and
durability. Available in three different
sizes: 24", 36", and 48".
Standard Features
•Stainless steel front including
top rail.
•Aluminized steel rear and sides.
•4” steel legs.
•3/4” rear gas connection.
•With full crumb tray.
• Wide or narrow branding by
inverting grates. (1/4” or 1/8”)
• Narrow grates have drain
channels.
Electrical
None required.
Heating
U shaped burner is controlled by
independent control of flame. One
standing pilot services each burner.
A 3/4 “ rear connection is standard.
Area over burners is covered by
stainless steel radiant. Each burner
is rated for 35,000 BTU/hr for
natural gas and 30,000 BTU/hr for
propane gas. The TMDC has one U
shaped burner per 12” of
charbroiler. TMDC24 - 2 burners,
TMDC36 -3 burners, TMDC48 - 4
burners. Dual branding cast iron
grates are reversible, allowing for a
1/4” or 1/8” brand.
Countertop Gas Charbroiler
Models TMDC24, 36 & 48
COUNTERTOP GAS CHARBROILER - MODELS TMDC24, 36 & 48
TMDC24
Controls
One front panel mounted control
knob per burner, to allow adjustable
flame height. One burner per 12” of
charbroiler.
Warranty
Product warranty includes one year
parts and labor. (USA only)
Approximate Weights
TMDC24 - 205 lbs. shipping.
TMDC36 - 255 lbs. shipping.
TMDC48 - 310 lbs. shipping.
Cleanability
!Stainless steel front for durability
and easy cleanup.
!Easy access to grease drawer.

INTENDED FOR COMMERCIAL USE ONLY. NOT FOR HOUSEHOLD USE.
Toastmaster, in line with its policy to continually improve its product, reserves the right to change materials or specifications without notice. Such
revisions do not entitle the buyer to corresponding changes, improvements, additions, or replacements for previously purchased equipment.
