Application
The Toastmaster Countertop Gas
Fryer is the most economical and
flexible Countertop Fryer in the food
service industry. It offers
unsurpassed performance,
combining a proven control system
with Toastmaster quality and
durability.
Standard Features
•Stainless steel tank and door.
•Tube-type fry pot permits over
50% more heat to be
transferred to the fat.
•Quick recovery eliminates
waiting between loads.
•Large cold zone captures food
particles, reduces flavor
transfer and extends oil life.
•Wide spacing between tubes-
permits easy access for
cleaning.
•1” full port, front drain valve-
allows for quick draining.
•Single unit combination gas
shut off valve, pressure
regulator and pilot ignition
system.
•100% safety shut off.
•3/4” gas connection.
•Includes two twin plated wire
mesh baskets with plastic-
coated heat resistant handles.
•25 lbs. shortening capacity.
Electrical
None required.
Heating
Each cast iron burner rated 16,660
BTU/hr TCGF12 : 3 burners, total of
50,000 BTU/hr hour.
Countertop Gas Fryer
Model TCGF12
COUNTERTOP GAS FRYER - MODEL TCGF12
TCGF12
Controls
Includes manual shut off, 100%
safety shut off pilot gas valve, pilot
adjustment and 175oF to 375oF
adjustable thermostat. High limit
control automatically shuts down
main burner and pilot if oil
temperature exceeds 475oF.
Equipped with cast iron burners.
Frypot
16 gauge, type 304 stainless steel
frypot. 2” wide by 4” tall oval
shaped heat tubes run front to
back. Front access, quick opening
1” full port drain valve.
Warranty
Product warranty includes one year
parts and labor. (USA only)
Approximate Weights
TCGF12 - 117 lbs. shipping.

INTENDED FOR COMMERCIAL USE ONLY. NOT FOR HOUSEHOLD USE.
Toastmaster, in line with its policy to continually improve its product, reserves the right to change materials or specifications without notice. Such
revisions do not entitle the buyer to corresponding changes, improvements, additions, or replacements for previously purchased equipment.
