Safavieh PAT6730 User manual

MODEL # PAT6730
Product Dimension: 60.63”Wx34.65”Dx15”H
NOTICE
Please make sure that you have all parts indicated
before you begin assembly of this item.
CARE AND MAINTENANCE
Store outdoor furniture indoors or cover well when it is not in use.
Dust regularly with small brush or vacuum.Spills should be taken care of
immediately before they harden or stain with a slightly dampened sponge.
PIECE DESCRIPTION PICTURE QUANTITY
Part List and Hardware List
1X
1X
Allen key
4 X
Allen bolt
1 X
4 X
Allen nut
1 X
1 X
Bolt extra
Seat
Front leg
Rear leg
Wrench
1 X
O U T D O O R
M6x50
M6x80
M6x90
A
B
C
D1
D2
D3
D4
D5
Warning : Do not torque bolts / screws
Warning : Do not stand on the lounger
Weight capacity : 600 lbs.

Before beginning the assembly of the product,make sure all parts are present.
Compare the parts with package contents list and hardware contents list.
If any parts are missing or damaged,do not attempt to assemble the product.
Tool required for assembly (included): Allen key and Wrench.
1
Step1: attach the rear leg (A) to the seat (C) as shown on the picture by using the Allen bolt (D1) and Allen
nut (D2).Tighten all with the Allen key (D4) and Wrench (D5). Repeat the assembling of the front leg (B) in
the same way as the rear leg (A).Tighten all bolts and screws again before use.
.
D2
D2 D2
D5
D4
