TOOL WAREHOUSE HMWT-1000 User manual

THANK YOU FOR PURCHASING OUR SCISSOR LIFT TABLE
HYDRAULIC SCISSOR
LIFTING TABLE
HMWT-1000

Warnings
1. Read and understand the enre owners manual before aempng assembly or operaon.
2. Read and understand the warnings posted on the machine and in this manual. Failure to
comply with all ohese warnings may cause serious injury.
3. Replace the warning labels ihey become obscured or removed.
4. Do not use this scissor litable for other than its intended use. If used for other purposes, w
e disclaim any real or implied warranty and holds itselarmless from any injury that may r
esulrom that use.
5. Check damaged parts before further use ohe tool. a guard or other parhas damaged
should be carefully checked to determine that will operate properly and perform its
intended funcon Check for alignment of moving parts, binding of moving parts, breakage
of parts, mounng and any other condions that may affects operaon. a guard or other
parhas damaged should be properly repaired or replaced.
6. Do not allow anyone to sit or ride on the scissor litable. Serious injury could occur ihe
tool ps over.
7. Do not load scissor libeyond its rated capacity.
8.Secure load before raising or moving scissor li. Do noransport load in the raised posion
9. Use only on smooth, level finished floors
10. Press release lever fully to allow load to descend in a controlled manner; keep hands and fe
et clear oable when lowering load.
Familiarize yourself with the following safety noces used in this manual:
WARNING
This means thaf precauons are not heeded, it may resuln serious injury or possibly
e
ven death.
Note: Because of our policy of connuous improvement, we reserve therigho change
specificaons material at any me and without prior noce, withouncurring obligaons.
INSTRUCTION MANUAL
HYDRAULIC SCISSOR LIFT TABLE
HMWT-1000

Introduction
Thank you for purchasing a CYT-B hydraulic scissor lift table. Your lift table is made of high
quality steel and was designed to give you a durable, reliable and easy to use product. With
proper maintenance, your pallet truck will give you years of trouble free operation
Before attempting to use your new hydraulic lift table, we recommend you read this manual and
familiarize yourself with the details of operation
Unpacking
Open container and check for shipping damage Report any damage immediately to
distributor and shipping agent. Read the instruction manual thoroughly for assembly your
maintenance and safety instructions
Contents of the shipping Container
To save transportation cost, some parts are packed separately besides the scissor lift table as
follows:1 Scissor Lift Table, 1 Handle Assembly, 1 Foot Pedal, 1 Owner's Manual.
Assembling Scissor Lift Table
Before assembly, please prepare the necessary assembly tools, such as handle, screw driver, etc
1. As shown in Fig. 1, put the handle on the vehicle seat, adjust the position, and lock and fix it with
washer 12 (Part 4), spring washer Φ 12 (Part 5) and hexagon head bolt m12x25 (Part 6).
2. Install foot pedal parts: as shown in Fig. 2, insert foot lever (Part 1) into foot joint hole, and bolt
m10x30 (Part 2) and nut (Part 3) are locked and fixed
Fig. 1 Fig. 2

Operang Scissor LiTable
To raise the table: Fig. 3
1. Lock the brake on the casters.
2. The table can be raise by pumping the foot pedal.
3. Then, pump the pedal repeatedly unl the table
reaches the height you desire. Please
refer to Figure 3.
To lower the table
1. Lock the brake on the casters
2. Push down the descent lever unl the table reaches the height you desire. This
allows the table to lower in a slow. Controllable manner.
3. Before loading, always lock the caster brakes.
NOTE: During transit, air may have seeped into the pump. To bleed air out of the
hydraulic system, raise and lower the table severalmes to work any air bubbles out of
the pump.
SPECIFICATIONS:
Model HMWT-1000
Capacity 1000kg
Height of
table
TH max. 1800mm
TH min. 600mm
Table D
im
Length (TL) 1300mm
Width(TW) 800mm
Height(TH) 55mm
Packing size(L*W*H) 1480*820*650(mm)
Weight 300kg

Troubleshooting
Possible problems could arise in the operation of your hydraulic pallet truck. Their p
robable cause（s）and corrective action（s）follow：
Trouble
Probable Cause
Remedy
Table will not
rise.
No oil in reservoir.
Replenish reservoir
Release Plug or steel ball is not seating
Clean Release Plug
0r steel ball or
replace.
Steel ball is not seating.
Clean or replace steel
ball
Relief valve is not adjusted properly
Adjust the Relief
Adjusting Screw.
Table will not
remain elevated.
Release Plug or steel ball is not seating
Clean or replace Release
Plug or steel ball.
O-ring is worn out.
Replace O-ring.
Table will not
lower
O-ring is worn out.
Replace O-ring.
Release plug is clogged.
Replace Release plug.
Oil leaks from
lowering valve.
Washer Il is worn out.
Replace Washer II
Oil leaks from
pump cylinder.
U-packing is worn out.
Replace U-packing
Maintenance
1. Each friction part must be filled with No. 2 lubricating oil once a month;
2. Check the movement and friction of the wheel to ensure the normal state of the
wheel;
3. Check whether the rear wheel brake is effective;
4. Check the hydraulic cylinder for oil leakage.
Safety notice
1. The load of platform truck shall not exceed its rated load;

2. It is forbidden to use the vehicle to carry people;
3. It is strictly forbidden to drop the goods onto the platform truck from a height;
4. Brake the foot brake before lifting the platform to prevent accidents caused by the
plat form vehicle moving at will;
5. Only use platform vehicle on smooth and flat ground;
6. Hands and feet cannot reach under the platform when the platform is lowered;
7. Our company will not be responsible for any injury that may be caused if the above
warning is not followed.
8、Waste disposal
The waste generated from the use of this vehicle should be treated according to the lo
cal laws and regulations
