Toolshop 241-9932 User manual

SAVE THIS MANUAL
You will need this manual for safety instructions, operating procedures and warranty.
Put it and the original sales receipt in a safe dry place for future reference.
For questions about this product, Please call 1-866-915-8626
Operator’s Manual
241-9932
VARIABLE SPEED REVERSIBLE DRILL

2
IMPORTANT SAFETY INSTRUCTIONS
WARNING: When using electric tools, machines or equipment, basic safety
precautions should always be followed to reduce the risk of fire, electric
shock, and personal injury.
READ ALL INSTRUCTIONS BEFORE USING THIS TOOL
1. KEEP WORK AREA CLEAN. Cluttered areas invite injuries.
2. CONSIDER WORK AREA ENVIRONMENT. Don’t use power tools in damp,
wet, or poorly lit locations. Don’t expose your tool to rain. Keep the work area
well lit. Don’t use tools in the presence of flammable gases or liquids.
3. KEEP CHILDREN AND BYSTANDERS AWAY. All children should be kept
away from the work area. Don’t let them handle machines, tools or extension
cords.
Visitors can be a distraction and are difficult to protect from injury.
4. GROUNDED TOOLS must be plugged into an outlet that itself is properly
installed and grounded. Grounding provides a low-resistance path to carry
electricity to ground away from the operator, should the tool malfunction elec-
trically. Do not remove the grounding prong from the plug or alter the plug in
any way. If in doubt as to whether the outlet is properly grounded according
to code, check with a qualified electrician.
5. OBSERVE PROPER PRECAUTIONS REGARDING DOUBLE INSULA-
TION. This tool is double insulated. It is equipped with a polarized plug.
One blade is wider than the other, so it will fit into a polarized outlet only one
way. If you have difficulty inserting the plug, try reversing it. If it still doesn’t
fit , do not alter the plug; have a qualified electrician install a polarized outlet.
6. GUARD AGAINST ELECTRIC SHOCK. Prevent body contact with grounded
surfaces: pipes, radiators, ranges, and refrigerator enclosures. When your
body is grounded the risk of electric shock increases. When working wher-
ever “live” electrical wires may be encountered, try to ascertain whether
there is a danger of shock. Even so, DO NOT TOUCH ANY METAL PARTS
OF THE TOOL while using it. Hold the tool only by the plastic grip to prevent
electric shock if you contact a live wire.
7. DO NOT ABUSE THE CORD. Never carry your tool by the cord or pull on
the cord to unplug it. Protect the cord from potential sources of damage:
heat, oil & solvents, sharp edges, or moving parts. Replace damaged cords
immediately.
8. WHEN WORKING OUTDOORS, USE AN OUTDOOR-RATED EXTENSION
CORD. An extension cord rated for outdoor use must be marked “W-A” or
“W”.
9. DO NOT EXPOSE ELECTRICAL POWER TOOLS TO MOISTURE. Rain or
wet conditions can cause water to enter the tool and lead to electric shock.
10. ENSURE THE EXTENSION CORD YOU USE IS OF SUFFICIENT GAUGE
FOR ITS LENGTH.
11. STORE IDLE EQUIPMENT. Store equipment in a dry area to inhibit rust.
Equipment also should be in a high location or locked up to keep out of
reach of children.
12. DON’T FORCE THE TOOL. It will do the job better and more safely at the
rate for which it was intended.
13. USE THE RIGHT TOOL. Don’t force a small tool or attachment to do the
work of a larger industrial tool. Don’t use a tool for a purpose for which it was
not intended.
14. DRESS PROPERLY. Don’t wear loose clothing or jewelry; they can be
caught in moving parts. Protective, non-electrically conductive gloves and
non-skid footwear are recommended when working. Wear protective hair
covering to contain long hair and keep it from harm.
!
Recommended Minimum Wire Gauge for Extension Cords
Amps from Tool Nameplate 25’ length 50’ length 75’ length 100’ length 150’ length 200’ length
0-5 amps 16 ga. 16 ga. 16 ga. 14 ga. 12 ga. 12 ga.
5.1-8 amps 16 ga. 16 ga. 14 ga. 12 ga. 10 ga. Do Not Use
8.1-12 amps 14 ga. 14 ga. 12 ga. 10 ga. Do Not Use Do Not Use
12.1-15 amps 12 ga. 12 ga. 10 ga. 10 ga. Do Not Use Do Not Use
15.1-20 amps 10 ga. 10 ga. 10 ga. Do Not Use Do Not Use Do Not Use

3
ALWAYS CHECK THE SPEED RATING OF ACCESSORIES. This tool will
spin accessories at up to 3,000 /min. Accessories not rated for speeds this high
will very likely fly apart and could cause serious injury.
15. USE EYE PROTECTION. Use a full-face mask if the work you’re doing
produces metal filings, dust or wood chips. Goggles are acceptable in other
situations. Wear a clean dust mask if the work involves creating a lot of fine
or coarse dust.
16. SECURE WORK. Use clamps or a vise to hold the work. It’s safer than using
your hands and it frees both hands to operate the tool.
17. DON’T OVERREACH. Keep proper footing and balance at all times. Do not
reach over or across machines that are running.
18. MAINTAIN TOOLS WITH CARE. Keep tools sharp and clean for better and
safer performance. Follow instructions for lubricating and changing accessories.
For safe performance,Keep handles dry, clean and free from oil and grease.
19. AVOID UNINTENTIONAL STARTING. Be sure the switch is in the OFF posi-
tion before plugging in.
20. ALWAYS CHECK AND MAKE SURE TO REMOVE ANY ADJUSTING KEYS
OR WRENCHES before turning the tool on. Left attached, these parts can fly
off a moving part and result in personal injury.
21. DO NOT USE THE TOOL IF IT CANNOT BE SWITCHED ON OR OFF.
Have your tool repaired before using it.
22. DISCONNNECT THE PLUG FROM POWER BEFORE MAKING ANY AD-
JUSTMENTS. Changing attachments or accessories can be dangerous if
the tool could accidentally start.
23. STAY ALERT. Watch what you are doing & use common sense. Don’t operate
any tool when you are tired.
24. CHECK FOR DAMAGED PARTS. Before using this tool, any part that is
damaged should be carefully checked to determine that it will operate prop-
erly and perform its intended function. Check for alignment of moving parts,
binding of moving parts, breakage of parts, mountings, and other conditions
that may affect its operation. Inspect screws and tighten any ones that are
loose. Any part that is damaged should be properly repaired or replaced by
an authorized service center unless otherwise indicated elsewhere in the in-
struction manual. Have defective switches replaced by an authorized service
center. Don’t use the tool if switch does not turn it on and off properly.
25. REPLACEMENT PARTS. When servicing, use only identical replacement
parts.
26. SERVICE AND REPAIRS should be made by qualified repair technicians at
an authorized repair centre. Improperly repaired tools could cause serious
shock or injury
IMPORTANT SAFETY INSTRUCTIONS
SAFETY PRECAUTIONS FOR ELECTRIC DRILL
Voltage: 120 volts AC, 60Hz.
Current rating: 4.0 Amp
No load speed:0-3,000/min
3/8”keyless chuck
Convenient above-the-trigger reverse switch
Lock-on button
SPECIFICATIONS

4
Operating the keyless chuck
RUNNING THE DRILL
1. Plug in the tool.
2. Depress the variable speed trigger switch to turn the tool on. The farther the switch is
depressed, the faster the drilling speed.
3. To maintain the maximum drilling speed, depress the lock-on button with your thumb
after fully depressing the variable speed trigger switch.
4. To disengage the lock-on button, squeeze the trigger.
To change the chuck rotation direction, move the rotation direction switch above the
trigger to the other side. Setting the direction switch to the right causes the drill to
turn clockwise, for normal drilling. The direction switch moved to the left will cause
the drill to run in reverse (counterclockwise) direction, backing drill bits and screws
out screws out of their holes.
Warning: Turn off your drill at once, unplug and inspect it for serious problems if:
Moving parts get stuck
Speed drops to an abnormally low level
The motor housing gets hot
Sparks or odours emit from the casing
Metal Drilling
Use a sharp drill bit especially designed to cut the material you are working on. It is
recommended you use a cutting fluid on the metal surface to avoid heat
buildup.slowly, or not at all.
•
Center the rotation direction knob to prevent the motor accidentally starting.
•
Note there are two rings on the chuck. Turning the endmost knurled ring of the
chuck clockwise by hand while with the other hand, holding the second ring
(closer to the rear of the tool) to prevent the motor turning; closes the jaws of
the chuck. Turning that same endmost knurled ring counter-clockwise opens
the jaws.
•
Open the jaws to accept a bit and then close the jaws so they clamp the bit
tightly.
A. Keyless Chuck
B. Lock-on Button
C. Variable speed--On/Off Trigger
D.
E.
Direction Lever(Forward / Reverse)
Belt Clip
FUNCTION DESCRIPTION
OPERATING PROCEDURES
Warning: Turn off your drill at once, unplug and inspect it for serious problems if:
 Moving parts get stuck
 Speed drops to an abnormally low level
 The motor housing gets hot
 Sparks or odors emit from the casing
!
A
B
C
D
E

5






Keep the vents clear of dust and debris. This will help prevent possible
electrical shorts and ensure proper cooling.
Keep the tool housing clean, free of oil and grease by using mild soap and
a damp (not wet) cloth.
Inspect the cord regularly and have it replaced by an authorized repair
facility if it is damaged.
Lubrication for this tool is done at the factory and should not be necessary
again under normal use.
An authorized repair centre should do any repairs, modification, or
maintenance that involve disassembling the tool.
Any damage to the tool should be corrected at an authorized repair centre.
MAINTENANCE
PARTS LIST
Please refer to the schematic drawing on page 6.
ITEM DESCRIPTION ITEM DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Screw
Chuck
Output spindle
Bearing
Retaining sping
Columnar pin
Gear
Retaining sping
Copper bush
Bearing
Armature
Carbon brush holder
Carbon brush
Contactor
15
16
17
18
19
20
21
22
23
24
25
26
27
Carbon brush cover
Right housing
Screw
Label
Bearing
Stator
Grip
Cord and plug
Cord sheathing
Cord clamping
Switch
Left housing
Label

SCHEMATIC DRAWING
6
!
WARNING: Repairs should be made by an authorized repair centre. Do not open or
disassemble this power tool.

TOOL SHOP®
1-YEAR LIMITED WARRANTY:
For questions / comments, technical assistance or repair parts –
Please call toll free at: 1-866-915-8626
(M-F 8am – 5pm EST)
SAVE YOUR RECEIPTS. THIS WARRANTY IS VOID WITHOUT THEM.
VARIABLE SPEED REVERSIBLE DRILL WARRANTY
This TOOL SHOP® brand power tool carries a 1-Year Limited Warranty to the
original purchaser. If, during normal use, this TOOL SHOP® tool fails due to a
defect in material or workmanship within one (1) year from the date of
purchase, simply bring this tool with your original sales receipt back to your
nearest MENARDS® retail store. At its discretion, TOOL SHOP® agrees to
have the tool replaced with the same or similar TOOL SHOP® product free of
charge, within the stated warranty period, when returned by the original
purchaser with original sales receipt. Notwithstanding the foregoing, this
limited warranty does not cover any damage that has resulted from abuse or
misuse of the Merchandise. This warranty: (1) excludes expendable parts
including but not limited to blades, belts, bits, light bulbs, and/or batteries; (2)
shall be void if this tool is used for commercial and/or rental purposes; and (3)
does not cover any losses, injuries to persons/property or costs.This warranty
does give you specific legal rights and you may have other rights, which vary
from state to state. Be careful, tools are dangerous if improperly used or
maintained. Seller’s employees are not qualified to advise you on the use of
this Merchandise. Any oral representation(s) made will not be binding on selle
r
or its employees. The rights under this limited warranty are to the original
purchaser of the Merchandise and may not be transferred to any subsequent
owner. This limited warranty is in lieu of all warranties,expressed or implied
including warranties or merchantability and fitness for a particular purpose.
Seller shall not be liable for any special, incidental, or consequential damages.
The sole exclusive remedy against the seller will be for the replacement of
any defects as provided herein, as long as the seller is willing or able to
replace this product or is willing to refund the purchase price as provided
above. For insurance purposes, seller is not allowed to demonstrate any
of these power tools for you.
