Top Gun Mobility TG900RS User manual

Owner’s Manual
TG900RS
WARNING
Read the User Manual carefully before operating the TG900RS.
If you do not fully understand any part of this manual, please contact your dealer
or any of our Service Centres. Read this manual step by step, as injury or damage
may occur from misuse!
Electromagnetic Interference (“EMI”) can cause powered vehicles to behave
erratically, which could be dangerous to the user. For your safety and protection, it
is IMPERATIVE that you take time to read Chapter 8 (“EMI WARNING”) before
operating the TG900RS.

Page | 1
TABLE OF CONTENTS
I. CHAPTER 1 – Overview of the TG900RS (Main Features) 3
II. CHAPTER 2 – Safety Symbols for the TG900RS 4
III. CHAPTER 3 – Safety Instructions for the TG900RS 8
IV. CHAPTER 4 – Operating Instructions 19
V. CHAPTER 5 – Charging the TG900RS Batteries 23
VI. CHAPTER 6 – Maintenance 24
VII. CHAPTER 7 – Troubleshooting and Repairs 26
VIII. CHAPTER 8 – EMI Warning 28
IX. Specifications 30
X. Warranty & Storage Instructions 31
XI. Buyers Registration Form 32

Page | 2
CHAPTER 1 – Overview of the TG900RS (Main Features)
Congratulations on choosing the TG900RS as your electrically powered
scooter.
The TG900RS is designed for a maximum occupant mass of 150 kg.
The TG900RS is an indoor/outdoor scooter designed to work in normal
environmental conditions from very cold temperatures (-30ºC/-22ºF) to very
hot temperatures (+45ºC/+113ºF).
The TG900RS will operate in light rain showers, but extended use is not
recommended in heavy rain or snow.
The TG900RS is easy to operate. The relatively large wheels let the user drive on
unpaved roads, over moderately rough terrain and over obstacles as high as 4” (10
cm).
Refer to specification Sheet (Page 30) for the required tyre pressure.
The TG900RS can climb slopes with angles and loads as detailed in Figure:
Maximum Recommended Incline Angles (Page 9).
The TG900RS maximum safe slope is: 6º (10.5%).
The braking system stops the TG900RS smoothly and within a short distance
after the throttle control lever is released.
The TG900RS is equipped with both front and rear shock absorbers to give the
user a comfortable and smooth drive, even when using the vehicle on
moderately rough roads. The seat is spacious and comfortable, and can be
rotated for easy access (standard seats). It can be adjusted forward and
backward, and up and down by a technician.
All controls are conveniently mounted on the tiller and are simple to operate.
Under normal conditions, the TG900RS can travel up to 75 km before the
batteries require recharging.
After reading through this entire manual and before using the TG900RS, do a
visual check of all the parts of the vehicle, to make sure that there is no visible
damage. If you have any questions or concerns, contact your dealer.
The TG900RS was developed to use maintenance-free sealed batteries only.

Page | 3
CHAPTER 2 – Safety Symbols for the TG900RS
WARNING! An authorized supplier or qualified technician must
perform the initial setup of this scooter, and must perform all of the
procedures in this manual
The symbols below are used throughout this user’s manual and on the scooter to
identify warnings and important information. It is very important for you to read them
and understand them completely.
WARNING! Indicates a potentially hazardous condition/situation.
Failure to follow designated procedures can cause either personal
injury, component damage, or malfunction.
On the scooter, this is a triangular black symbol
MANDATORY! These actions must be performed as specified.
Failure to perform mandatory actions can cause personal injury
and/or equipment damage. On the scooter, this is a white symbol on
a dark background
PROHIBITED! These actions are prohibited. These actions must not
be performed at any time or under any circumstances. Performing a
prohibited action can cause personal injury and/or equipment
damage. On the scooter, this is a black symbol withacircle and
slash.
Please note and strictly adhere to the following Safety Instructions.
Additional Warnings and Notices are printed in this user manual; it is
imperative that you read carefully all chapters of this manual before
operating the TG900RS. It is also advisable to refresh your memory
by re- reading this manual periodically.
Get acquainted with the TG900RS and its operational features before
driving it. Drive slowly (speed limit dial set to MIN) until you get used
to the TG900RS, to its various functions, safety features, and to its
braking capabilities and limitations.
Watch carefully for pedestrians and drive your TG900RS accordingly.
In crowded areas, always drive with the speed limit dial set to MIN.
Drive only where permitted according to all applicable local laws and
ordinances. TG900RS is 66 cm (26") wide. Take great care not to hit
persons or any objects around the vehicle
Never remove any of the TG900RS safety parts such as fenders,
plastic covers or emergency brake lever.
Never remove any of the Warning labels

Page | 4
Never put your hands, fingers, or legs into any moving parts or under
any protective cover, since moving parts and hot surfaces are under
those covers
When making adjustments (folding the seat back, adjusting the
armrest, moving the seat forward or backward, adjusting the tiller
distance), as well as when squeezing the throttle control lever, always
take care that your hands and fingers are not trapped between any of
the moving parts. When moving the tiller forward or backward, be
careful not to trap your fingers in the mechanism.
The load in the rear basket must not exceed 8 kg (17.6 lbs). The load
in the front basket must not exceed 5 kg (11 lbs).
The TG900RS is designed to carry ONE person only on the Single
Seat model. Never operate it with an additional person on board,
including a child
Never inflate the TG900RS tyres more than the manufacturer’s
recommended pressure shown on the tyres
Never use the TG900RS on stairs.
Never try to go over an obstacle that is more than the maximum
recommended slope angle and obstacle height given in the
specification sheet. When driving over an obstacle, always drive so
that the front of the TG900RS is facing the obstacle
If for any reason the TG900RS does not stop when you release the
throttle control lever, or takes longer to stop than it should (3 meters
on a level surface), turn the main key switch to OFF, and contact your
dealer
Do not use the TG900RS in heavy rain or extreme humidity, or at
temperatures below -30ºC (-22ºF) or above +45ºC (+113ºF)
The seat weighs 21 kg (46 lbs). Each battery weighs a minimum of
14kg (31 lbs). Be careful when lifting the seat and the batteries.
See instruction for lifting the seat and the batteries in Chapter 8:
Maintenance, and Chapter 9: Troubleshooting and Repair. Always lift
using your knees and legs, not your back
Use lead acid maintenance-free sealed batteries only.

Page | 5
If the TG900RS is involved in any kind of an accident in which parts
are damaged, you must get a qualified technician to examine it before
continuing to use it.
WARNING!!! Special care must be taken to prevent children from
operating the TG900RS.
Do not allow unsupervised children to play near the TG900RS scooter
while the batteries are charging.
Always drive carefully. Adjust your speed according to road
conditions. When turning at high speed, the TG900RS can become
unstable. Before making sharp turns, reduce speed to minimum to
prevent roll-over
The TG900RS is able to go up slopes higher than the recommended
safe slope. However, do not drive on slopes whose incline you do not
know. Always drive very slowly and do not drive on the side of such
slopes. Before starting to drive, make sure your emergency brake
operates properly.
Do not release either the manual or the manual release lever of the
electromagnetic brake (EMB) when the TG900RS is on a slope.
When on any sort of an incline, never place the TG900RS in
freewheel mode while seated on it or standing next to it.
The lights of the TG900RS should be on when visibility is reduced,
day or night
Since your seat upholstery is fire resistant, do not cover it or replace
with any upholstery other than upholstery of the same kind.
When removing the battery cover, watch out for hot parts. The motor,
axle, EMB, electronic cards and electronic controller might be hot, Do
not touch them until you have checked their temperature
Make sure your fingers are not squeezed between the levers and the
rubber grip
Do not use a cell phone, walkie-talkie, laptop, or other radio
transmitter while operating the TG900RS.
Removal of the grounding prong can create electrical hazard. If it is
necessary to use a 2-pronged electrical outlet, properly install an
approved 3-pronged adapter

Page | 6
Do not connect an extension cord to the AC/DC converter or to the
battery charger
Keep tools and other metal objects away from the battery terminals.
Contact with tools can cause electrical shock. Do not sit on the
TG900RS when it is on any type of lift/elevation product
Explosive conditions exist
Disposal and recycling: Contact your authorized dealer for information
on proper disposal of your TG900RS and its packaging
Wear Safety glasses
Contains Lead
The battery charger is for indoor use only
Flammable material. Do not expose to open flame
At the rear of the TG900RS is the manual release lever of the EMB.
When using this lever, be careful not to touch the internal surface of
the motor, as it could be very hot and cause injury. See the warning
label at the rear of the scooter near the lever

Page | 7
CHAPTER 3 – Safety Instructions for the TG900RS
GENERAL
MANDATORY! Do not operate your new TG900RS scooter for
the first time without reading and understanding this user manual
completely.
Your TG900RS is a state-of-the-art life-enhancement device
designed to increase mobility. We provide an extensive range of
products to best fit the individual needs of the user. Please be
aware that the final selection and purchasing decision regarding
the type of TG900RS scooter to be used is the responsibility of a
user who is capable of making such a decision and of his or her
healthcare professional (i.e., medical doctor, physical therapist,
etc.)
The contents of this manual are based on the expectation that a
mobility device expert has properly fitted the TG900RS scooter to
the user and has assisted the prescribing
Healthcare Professionals and/or the authorized dealer to give
instructions for the use of the product.
There are certain situations, including some medical conditions,
where the user will need to practice operating the TG900RS
scooter in the presence of a trained attendant. A trained
attendant can be defined as a family member or care
professional specially trained in assisting a user in various daily
living activities.
As you begin using your TG900RS scooter during daily activities,
you will probably encounter situations in which you will need
some practice. Simply take your time and you will soon be in full
and confident control as you manoeuvre through doorways, on
and off elevators, up and down ramps, and over moderately
rough terrain.
Below are some precautions, tips, and other safety
considerations that will help you operate the TG900RS scooter
safely.
MODIFICATIONS
We have designed and engineered your TG900RS to provide
maximum mobility and utility. Under no circumstances should you
modify, add, remove, or disable any feature, part, or function of
your TG900RS.
WARNING! Do not modify your TG900RS in any way not authorized
by the manufacturer. Do not use accessories if they have not been
tested or approved by the manufacturer

Page | 8
REMOVABLE PARTS
WARNING! Do not attempt to lift or move your TG900RS
by any of its removable parts, including the armrests, seat,
or shroud
PRE-RIDE SAFETY CHECK
Get to know the feel of your TG900RS and its capabilities. We
recommend that you perform a safety check before each use to
make sure your TG900RS operates smoothly and safely.
Perform the following inspections prior to using your scooter:
•Check for proper tyre inflation. Maintain but do not exceed the
psi/bar/kPa air pressure rating indicated on each tyre.
•Check all electrical connections. Make sure they are secure
and not corroded.
•Check all harness connections. Make sure they are secured
properly.
•Check the brakes.
•Check the battery charge.
•If you discover a problem, contact your authorized TG900RS
dealer for assistance.
TYRE INFLATION
Your TG900RS is equipped with pneumatic tyres. Check the tyre
pressure at least once a week. Proper inflation pressures will prolong
the life of your tyres and help ensure the smooth operation of your
TG900RS.
WARNING! It is critically important that the psi/bar/kPa air pressure
indicated on each tyre is maintained at all times. Do not under-
inflate or over-inflate your tyres. Under-inflation may result in loss of
control, and over-inflation may burst the tyre. Failure to maintain the
indicated pressure rating at all times may result in tyre and/or wheel
failure.
WARNING! Inflate your scooter tyres from a regulated air
source with an attached pressure gauge. Inflating your tyres
from an unregulated air source could over-inflate them,
resulting in a burst tyre.

Page | 9
WEIGHT LIMITATIONS
Your scooter is rated for a maximum weight capacity. Refer to
Specification sheet for details.
MANDATORY! Stay within the specified weight capacity for your
TG900RS. Exceeding the weight capacity voids your warranty. We
will not be held responsible for injuries and/or property damage
resulting from failure to observe weight limitations. WARNING! Do not
carry passengers on your scooter. Carrying passengers on your
TG900RS may result in instability.
INCLINE INFORMATION
More and more buildings have ramps with specified degrees of
inclination, designed for easy and safe access. Some ramps may
have turning switchbacks (180-degree turns) that require you to
have good cornering skills on your TG900RS scooter.
•Proceed with extreme caution as you approach the downgrade
of a ramp or incline.
•Take wide turns with your TG900RS scooter around any tight
corners. If you do that, the scooter’s rear wheels will follow a
wide arc. Do not cut the corner short, and do not bump into or
get hung up on any railing corners.
•When driving down a ramp, keep the TG900RS scooter’s
speed adjustment set to the slowest speed setting to
ensure a safely controlled descent.
•Avoid sudden stops and starts.
•Refer to Figure below to determine the maximum slope
Maximum Recommended Incline Angles
When driving up an incline, try to keep your TG900RS moving. If you must stop,
start up again slowly, and then accelerate cautiously. When driving down an incline,
set the speed switch to MIN and drive forward only. If your TG900RS starts to move
down the incline faster than you want, allow it to come to a complete stop by
releasing the throttle control lever, then push the throttle control lever forward
slightly to ensure a safely controlled descent.
WARNING! When on any incline, never place the TG900RS in freewheel
mode while seated on it or standing next to it.
WARNING! When climbing an incline, do not zigzag or drive up at an angle. Always
drive your TG900RS scooter straight up the incline. This greatly reduces the
possibility of tipping over or a fall. Always exercise extreme caution when negotiating
an incline.

Page | 10
WARNING! Do not drive your TG900RS scooter across an incline or diagonally up
or down an incline; if possible, do not stop while driving up or down an incline.
WARNING! Do not drive up or down a potentially hazardous incline (e.g., areas
covered with snow, ice, cut grass, or wet leaves).
WARNING!
Even though your TG900RS is capable of climbing slopes greater than those
illustrated in Figure, do not, under any circumstances, exceed the incline
guidelines or any other specifications presented in this manual. Doing so could
cause your TG900RS to become unstable. Note that public accesses ramps are
not subject to government regulation in all countries, and therefore do not
necessarily have the same standard degree of slope. Other inclines may be
natural or not be designed specifically for scooters. The figure above illustrates
your TG900RS stability and its ability to climb under various weight loads and
under controlled testing conditions.
These tests were conducted with the TG900RS seat in the highest position and in
its farthest rearward position. Use this information as a guideline. Your TG900RS
ability to travel up inclines is affected by your weight, scooter speed, your angle of
approach to the incline, and your TG900RS setup.
WARNING! Any attempt to go up or down a slope steeper than shown in Figure
C may make your TG900RS unstable position and cause it to tip.
WARNING! Never carry an oxygen tank weighing more than 15 lbs (6.8 kg). Never
put more than 5 Kg (11 lbs) in the front basket or more than 8 Kg (17.6lbs) in the
rear basket.
Figure B. Normal Driving Position Figure C. Increased Stability Drive Position
When you approach an incline, it is best to lean forward. See Figures B and C.
This shifts the centre of gravity of you and your TG900RS toward the front of the
TG900RS for improved stability.
NOTE: If the throttle control lever is released while you are moving forward up a
ramp, the TG900RS may roll back approximately 1 foot (30 cm) before the brake
engages. If the throttle control lever is released while you are moving in reverse, the
TG900RS may roll back approximately 3 feet (one meter) before the brake engages.

Page | 11
CORNERING INFORMATION
Excessively high cornering speeds can result in tipping. Factors that affect the
possibility of tipping include, but are not limited to, cornering speed, steering angle
(how sharply you are turning), uneven road surfaces, inclined road surfaces, riding
from an area of low traction to an area of high traction (such as passing from a
grassy area to a paved area – especially at high speed while turning), and abrupt
changes of direction. High cornering speeds are not recommended. If you feel that
you may tip over in a corner, reduce your speed and steering angle (i.e., lessen the
sharpness of the turn) to prevent your TG900RS from tipping.
WARNING! When cornering sharply, reduce your speed and maintain a stable
centre of gravity. When using your TG900RS at higher speeds, do not corner
sharply. This greatly reduces the possibility of a tip or fall. Always exercise your
common sense when cornering.
BRAKING INFORMATION
•Your TG900RS scooter is equipped with two powerful braking systems:
•Regenerative: Uses electricity to rapidly slow the vehicle when the throttle
control lever returns to the centre/stop position.
•Park Brake: Activates automatically after regenerative braking slows the
vehicle to a near stop, or when power is removed from the system for any
reason
OUTDOOR DRIVING SURFACES
•Your TG900RS is designed to provide optimum stability under normal
driving conditions, on dry, level surfaces of concrete, tarmac, or asphalt.
However, we recognize that there will be times when you will encounter
other surfaces. For this reason, your TG900RS is designed to perform well
on packed soil, grass, and gravel. Feel free to use your TG900RS safely on
lawns and in parks.
•Reduce your TG900RS speed when driving on uneven terrain and/or soft
surfaces.
•Avoid tall grass that can become tangled in the running gear.
•Avoid loosely packed gravel and sand.
•If you feel unsure about a driving surface, avoid it.
PUBLIC STREETS AND ROADWAYS
WARNING! Do not operate your TG900RS on public streets or roadways.
It may be difficult for traffic to see you when you are seated on your TG900RS.
Obey all local pedestrian traffic rules. Wait until your path is clear of traffic, and
then proceed with extreme caution.

Page | 12
STATIONARY OBSTACLES (STEPS, CURBS, ETC.)
WARNING! Do not drive near raised surfaces, unprotected ledges,
and/or drop-offs (curbs, porches, stairs, etc.).
WARNING! Do not try to go up or down an obstacle that is
too high. WARNING! Do not try to go backward down any
step, curb, or other obstacle. This may cause the TG900RS
to tip
WARNING! Be sure your TG900RS scooter is travelling perpendicular to any
curb you may be required to go up or down.
WARNING! Do not attempt to negotiate a curb that is higher than 10 cm (4").
PRECAUTIONS DURING INCLEMENT WEATHER
Avoid exposing your TG900RS scooter to inclement weather.
If you are suddenly caught up in rain, snow, severe cold or heat while operating
your TG900RS, proceed to shelter at the earliest opportunity.
Thoroughly dry your TG900RS before storing, charging, or operating it.
PROHIBITED! Do not operate your TG900RS in rain, snow, salt, mist/spray
conditions, or on icy slippery surfaces, as this can have an adverse effect on the
electrical system. Maintain and store your TG900RS in dry and clean conditions.
WARNING! Prolonged exposure to extreme hot or cold may affect the
temperature of parts of the TG900RS, possibly resulting in burns. Exercise
caution when using your TG900RS in extremely hot or cold conditions or when
exposing your TG900RS to direct sunlight for prolonged periods of time.

Page | 13
FREEWHEEL MODE
Your TG900RS is equipped with a manual freewheel lever that, when pushed
forward, allows the TG900RS to be pushed manually.
Your TG900RS is also equipped with an electric button located on the dashboard to
release the electromagnetic brake.
Turn the key switch to ON position. To activate, push the button and hold. To release
the brake just release the button. This function allows moving scooter manually.
WARNING! When your TG900RS is in freewheel mode, the parking system
is disengaged.
WARNING! Do not press the automatic freewheel button while
the TG900RS is moving.
•Disengage the drive motors only on a level surface.
•Stand beside the TG900RS to engage or disengage freewheel mode. Never
do this while sitting on the TG900RS.
•After you have finished pushing your TG900RS, always return it to the drive
mode to lock the brakes (pull the manual freewheel lever backward).
•When using the freewheel lever, be careful not to touch the internal surface of
the motor, as it could be very hot and cause injury. See the warning label at
the rear of the scooter near the lever.
STAIRS AND ESCALATORS
TG900RS scooters are not designed to travel up or down stairs or
escalators. Always use an elevator.
WARNING! Do not use your TG900RS scooter to negotiate stairs or escalators.
Automatic Freewheel Swtich

Page | 14
DOORS
•Determine whether the door opens toward or away from you.
•Use your hand to turn the knob or to push the handle or push-bar.
•If the door opens away from you, drive your TG900RS gently and slowly
forward to push the door open.
•If the door opens towards you, drive your TG900RS gently and slowly
backwards to pull the door open.
ELEVATORS
Modern elevators have a safety mechanism on the edge of the door that, when
pushed, reopens the door(s).
•If you are in the doorway of an elevator when the door(s) begin to close, push
on the rubber door edge or allow the rubber door edge to contact the
TG900RS and the door will reopen.
•Take care that handbags, packages, or TG900RS accessories do not
become caught in elevator doors.
NOTE: Sometimes manoeuvring your TG900RS may be difficult in elevators and building
entrances. Use caution when attempting to manoeuvre your TG900RS in small spaces, and
avoid areas that might pose a problem.
LIFTS/ELEVATION PRODUCTS
If you travel with your TG900RS, you may find it necessary to use a lift or elevation
product to aid in transportation. We recommend that you closely review the
manufacturer’s instructions, specifications, and safety information before using the
lift/elevation product. WARNING! Never sit on your TG900RS when it is being used
with any type of lift/elevation product. Your TG900RS was not designed for such
use, and any damage or injury resulting from such use is not our responsibility.
BATTERIES (see also Storage Instructions)
In addition to following the warnings below, be sure to comply with
all other battery handling information.
MANDATORY! Battery posts, terminals, and related accessories
contain lead and lead compounds. Wear goggles and gloves when
handling batteries, and wash hands after handling.
WARNING! Scooter batteries are heavy. If you are unable to lift that much weight,
be sure to get help. Use proper lifting techniques and avoid lifting beyond your
capacity.
WARNING! Always protect the batteries from freezing and never charge a frozen
battery. WARNING! Connect the battery cables correctly. RED (+) cables must be
connected to positive (+) battery terminals/posts and BLACK (-) cables must be
connected to negative
(-) battery terminals/posts. REPLACE damaged cables immediately. Protective
caps must be installed over all battery terminals.
NOTE: If the battery is damaged or cracked, immediately enclose it in a plastic bag and
contact your local waste disposal agency or authorized TG900RS dealer for instructions for
disposal or for recycling (which we recommend).

Page | 15
MOTOR VEHICLE TRANSPORTATION
The manufacturer recommends that you do not remain seated in your TG900RS
while travelling in a motor vehicle. The TG900RS should be stowed in the boot of a
car or in the back of a truck or van with the batteries removed and properly
secured. In addition, all removable TG900RS parts, including the armrests, seat,
and shroud, should be removed and/or properly secured during transportation.
WARNING! Although your TG900RS scooter may be equipped with an optional
tie-down belt, this belt is not designed to provide restraint during motor vehicle
transportation. Anyone travelling in a motor vehicle must be properly secured in
the motor vehicle seat with securely fastened seat belts.
WARNING! Do not sit on your TG900RS while it is in a moving vehicle.
WARNING! Always be sure your TG900RS and its batteries are properly secured
when it is being transported. Batteries must be secured in an upright position, and
protective caps must be installed on the battery terminals. Batteries must not be
transported with any flammable or combustible items.
PREVENTING UNINTENDED TRAVEL
WARNING! If you anticipate being stationary for an extended period of time, turn
off the power. This will prevent unexpected travel caused by accidentally
touching the throttle control lever.
GETTING ONTO AND OFF YOUR TG900RS
Getting onto and off your TG900RS requires a good sense of
balance. Please observe the following safety tips when getting on
and off your TG900RS:
•Remove the key from the key switch
•Ensure that your TG900RS is not in freewheel mode
•Ensure that the seat is secured in place
•Pivot the armrests up
WARNING! Position yourself as far back as possible in the seat to prevent the
TG900RS from tipping and causing injury.
WARNING! Avoid putting all of your weight on the armrests, and do not make the
armrests bear weight, such as during transfers. Such use may cause the
TG900RS to tip, resulting in a fall from the TG900RS and/or personal injury.
WARNING! Avoid putting all of your weight on the floorboard. Such use may cause
the TG900RS to tip.

Page | 16
REACHING AND BENDING
Avoid reaching or bending while driving your TG900RS. Bending forward creates
the risk of accidentally contacting the throttle control lever. Bending to the side
while seated creates the risk of tipping.
It is important to maintain a stable centre of gravity to keep the TG900RS from
tipping. We recommend that you determine your personal limitations and practice
bending and reaching in the presence of a qualified attendant.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from
the TG900RS deck or from either side of the TG900RS. Movements such as these
may change your centre of gravity and the weight distribution of the TG900RS,
causing it to tip. PROHIBITED! Keep your hands away from the tyres and wheels
when driving. Be aware that loose-fitting clothing can become caught in tyres and
wheels.
PRESCRIPTION DRUGS/PHYSICAL LIMITATIONS
The TG900RS user must exercise care and common sense when operating the
TG900RS. This includes awareness of safety issues when taking prescription or
over-the-counter drugs or when the user has specific physical limitations.
WARNING! Consult your physician if you are taking prescription or over-the-
counter medication or if you have certain physical limitations. Some medications
and limitations may impair your ability to operate your TG900RS in a safe
manner.
SMOKING
WARNING! The manufacturer strongly recommends that you do not smoke while
seated on your TG900RS, although the TG900RS seat has passed the necessary
testing requirements for cigarette smoking.
You must adhere to the following safety guidelines if you decide to smoke
cigarettes while seated on your TG900RS.
Do not leave lit cigarettes unattended.
Keep ashtrays a safe distance from the seat cushions
Always make sure cigarettes are completely extinguished before disposal.
ALCOHOL
WARNING! Do not operate your TG900RS while you are under the influence
of alcohol, as this may impair your ability to operate the TG900RS in a safe
manner.

Page | 17
ELECTROMAGNETIC AND RADIO FREQUENCY INTERFERENCE (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and
radio frequency waves can have an adverse affect on the
performance of electrically powered mobility vehicles.
EMI/RFI can come from sources such as cellular phones, mobile
two-way radios (such as walkie-talkies), radio stations, TV stations,
amateur radio (HAM) transmitters, wireless computer links,
microwave signals, paging transmitters and medium- range mobile
transceivers used by emergency vehicles. In some cases, they can
cause unintended movement or damage to the control system. Every
electrically powered mobility vehicle has an immunity (or resistance)
to EMI.
The higher the immunity level, the greater the protection against EMI. This
product has been tested and has passed at an immunity level of 20 V/M.
WARNING! Be aware that cell phones, two-way radios, laptops, and other types of
radio transmitters may cause unintended movement of your electrically powered
TG900RS due to EMI. Exercise caution when using any of these items while
operating your TG900RS and avoid coming into close proximity of radio and TV
stations.
WARNING! The addition of accessories or components to an electrically powered
mobility vehicle can increase its susceptibility to EMI. Do not modify your TG900RS
scooter in any way not authorized by the manufacturer.
WARNING! The TG900RS itself can interfere with other electrical devices located
nearby, such as alarm systems.
NOTE: For further information refer on EMI/RFI chapter or ask your
authorized dealer.

Page | 18
CHAPTER 4 – Operating Instructions
NUMBERS REFER TO FIGURE A
#1
Key Switch
•The main key switch is located on side of tiller column
•The key switch has two positions:
•OFF: The TG900RS cannot be driven and the EMB is locked.
•ON: Power is supplied to the TG900RS and the EMB is
released automatically when the throttle control lever is
squeezed.
To operate the TG900RS, insert the key in the key switch and turn it
to ON (clockwise). The switch will remain in this position and the
Power indicator will be lit.
Note: The key switch is used to operate the TG900RS, not for locking.
#2
Handlebar
Adjustment
lever
Adjust the position of the handlebars (height and distance) as follows:
1. Push the handlebar adjustment lever (which locks the
handlebars in place), and move the handlebars to the
position you want.
2. Release the lever to lock the handlebars in place.
#3
Charging
Socket
Before attempting to drive the TG900RS, make sure the plug is
disconnected from the charging socket.
Note: While the plug is in the charging socket, the TG900RS
cannot be operated.
Insert the charger plug in the charging socket located on the right side
of the tiller column to charge your scooter.
IMPORTANT: READ CHAPTER 5 FOR MORE INFORMATION
REGARDING CHARGING INSTRUCTIONS.
(#1) Key switch
(#2) Handlebar
adjustment lever
(#3) Charging socket
FIGURE A

Page | 19
FIGURE B
NUMBERS REFER TO FIGURE B
#1
Battery
Status
Indicator
The battery status indicator is located on the tiller panel and shows
you the remaining capacity of the batteries. Like petrol gauges in
cars, the indicator is not absolutely accurate; it is merely a guide to
help stop you running out of fuel.
The accuracy of the indicator also depends on the type and age of the
batteries. When the indicator shows 4 bars, recharge batteries as
soon as possible.
When the indicator shows 2 bars, recharge immediately.
#2
LED
Maintenance
When the LED is flashing, it blinks the code of the fault.
#3
Speed Limit
Dial
The speed limit dial is located on the handlebar panel.
•When the speed limit dial is set to MAX, the TG900RS will
drive at approx. 15 km/hr.
•When the speed limit dial is set to MIN, the TG900RS will drive
at approximately 3km/hr.
Do not change the speed limit dial setting while the TG900RS is
moving.
Set the speed limit dial to MIN:
•Until you get used to driving your new TG900RS, and
•When driving the TG900RS inside a building or in a crowded
area
Lights ON LED
High / Low speed indicator
Power indicator
(#2) Maintenance LED
(#3) Speed limit dial
(#4) High / Low
speed mode switch
(#6) Right turning
(#6) Left turning
(#9) Automatic
Freewheel switch
(#10) Lights ON switch
(Head and rear lights)
(#7) Hazard button
(#8)Horn/Buzzer
(#5) Throttle
Control Lever
(#5) Throttle Control Lever
(#5) Throttle Control Lever
(#1)Battery Status
Indicator
