iScooter iX5 User manual

iX5

Vehicle display 01
Name of major parts 02
Safety instruction 03
Product introduction
Unfolding/ pic
Foldingl pic
Display
Brake
Start
Riding
Lubrication
Tire
Stop riding
04
05
06
08
09
09
09
Riding operations
09
Basic operations 08
09
Battery and charger 10
Maintenance 11
11
Catalogue(EN)
11
Brake 11
Parameter table
General troubleshooting 11
12
Warranty 13

Vehicle display
11

Name of major parts
Brake lever Display
Handle bar
Ront light switch
Quick release clamp
Seat
Front tube
Rear fender
Front light
Rear motor
Disc brake pad Suspension
charger port
2

SAFETY INSTRUCTION
1、This product is suitable for adults which can be used only by one person.
2、Please wear the helmet and other protective equipment when you are
riding.
3、Please ride on the road safely and legally.
4、Practice before riding.
5、Be careful and safe; Both hands and feet should be keep on the scooter.
6、Don't turn off the power when you are riding.
7、Please try to avoid riding over 3cm steps which maybe hurt your body
and broken the scooter.
8、Move slowly when the road condition is not good.
9、Please adjust to the proper height to ensure safety.
10、Please do not ride on the slippery road.
11、Please do not use the product when the temperature is under -10℃
12、Do not immerse the product into water which the depth is more than
3cm to avoid the electrical parts ' broken.
13、Please ride in good weather.
14、Please charge every 20 days if the product is not used for a long time.
3

Product introduction
Unfolding pic
step1: press the foiding clamp to unfold the scooter
step2: lock the folding lever
4

step3: Expand the handlebar upward,keep the handlebar straight
step4: Adjust the handlebar to the suitable height.Tighten the quick
release clamp.
5

Folding pic
step1: pull the sleeve out and fold down the handlebar.
step2: Release the quick release on the front tube. press down the
handlebar to the bottom
6

step3: pull out the folding lever,pull the folding clamp,fold down
thefront tube
7

1. power switch
2. mode switch
3. thumb throttle
4. power display
5. speed display
6. mileage display
Basic operations
Display
1 . power switch
2.In the power on status，press “mode" to choose the mode,
there are three modes, the speed of mode3 is the fastest.
3.OTHER FUNCTIONS
1.1 In power off status,press the button for 3 seconds,the
display works.Keep the scooter on for 5 minutes without any
operation, it will turn off automatically
1.2 ln the power on status, press for 3 seconds, the device will
be turned off.
3.1.ERROR CODE
3.2. If the battery indicator flashes,please charge your scooter.
When power on, if abnormal occurs,error code will be showed
on the display screen. Please ask distributor for help.
Picture:
8

Start
Brake
Please avoid urgently braking, it will cause the tire broken and slip down.
1. Practice outside, choose good road condition.
2. Open the scooter according to the user manual.
3. Adjust the height of the handlebar to your suitable height.
4. open the seat, adjust the seat to the suitable height.
5. Lock the quick release clamp.
Riding
1. Press for 3 seconds，check the mode before riding.
2. Push your scooter front, and pull the display slowly at the same time,
the scooter goes.
3. Please set the riding mode,speed can be controlled by the throttle.
4. Please slow down or brake if necessary.
Stop riding
slow down,pull the brake lever lightly.Put one of your feet on the ground
until your scooter stopped.
Notice:
Please not drive the scooter on rainy day or on freezing weather,or it will
cause danger.
Riding operation
9

BATTERY AND CHARGER
Each scooter has its own battery and charger,each part has different
serial number. Please do not charger the scooter with other brands"
chargers.
Battery
Please charge your scooter when you get this scooter, it is better to take
your scooter full charged before riding.
Please charge your scooter at least 1 month a time, it will cause the
battery broken if no charging for a long time. Please contact the distribu-
tor if the battery can't be charged.
The warranty is invalid if the battery is deformative or caused by water
inside.
Charger
When full charged, the charger will stop charging.
The warranty is invalid if the charger is deformative or caused by water
inside.
Charging operation
1. Open the charger port protector, connect the plug with the charger
port.
2. The indicator light shows red means in charging,the indicator light
shows green means full charged.
3. Please charge your scooter in cool，dry，well-ventilated area.
10

Maintenance
Lubrication
Add some lubricant on the folding part of the handlebar every 6
months,keep the handlebar working smoothly.
Note: Do not add the WD40 on the scooter. Do not add any lubricant on
the front and rear whell.
Tire
Both front and rear tires are pneumatic tires,if it is broken obvious-
ly,please contact the distributor to replace them.
Please check your scooter every 3 months, make sure the screws are
tight enough.
Brake
General troubleshooting
This scooter is assembled with front and rear disc brake，if the braking
performance is not good enough,please contact the distributor to replace
the disc brake pad.
The battery can be charged circularly at least 600 times. lf the distance
reduces a lot when full charged, please contact the distributor to replace
a battery.
Please keep your scooter clean, and put your scooter in
dry,cool,well-ventilated area.
Please try to solve by yourself if following problems occur:
The scooter is power on.
lf all the actions are completed, the scooter still can't work,please contact
the distributor.
a. Check if is it in low power.
b. Check the brake lever is in right position,pull up and let it go.
c. All the plugs are connected well.
11

Parameter table
SPECIFICATION
PERFORMANCE
BATTERY
MOTOR
CHARGER
TIRE
BRAKE
Unfolding size 1160*600*1370mm
Folding size 1160*200* 460mm
N.W. 24.5Kg
Maximum load 150Kg
Maximum speed 25KM/h
Climbing ability 15-25°
Rated voltage
Distance
Capacity
Type
Motor type
Rated power output
Maximum speed
Rated power
Rated voltage
Output
Charging time
Tire size
Tire type
Brake
48V
35-40KM
15AH
Lithium battery
Brushless DC motor
9.5 N.m
1300rmp
600W
48V
2A
5-8h
10 inch
Pneumatic tire
Front electronic brake
+ front and rear disc brakes
12

WARRENTY
Any of the parts in the following sheet occurs failure in normal use,
please contact us, we will provide complete after-sale service.
Notice: Please use the scooter in the correct way.
The warranty is invalid if failure occurs in abnormal use.
Parts
Motor
Controller
Charger
Battery
Display
Frame
2 year
2 year
6 months
6 months
6 months
1 year
Quality
description
Failure occurs in
normal use
Warranty
period
Failure occurs in
normal use
Failure occurs in
normal use
Failure occurs in
normal use
Failure occurs in
normal use
Failure occurs in
normal use
service
Free
maintenance
Free
maintenance
Free
maintenance
Free
maintenance
Free
maintenance
Free
maintenance
13

Warranty invalid if caused by the following reasons:
1. Haven't do maintenance according to this manual.
2. Parts broken caused by playing or some dangerous actions.
3. Disassembling and assembling by users or use the other brand's
parts in this scooter. Parts broken cause by traffic accident or stroke
by user.
4. Water inside, serial number lost.
5. Parts broken caused by riding in very bad road.
6. Rental scooter Parts broken caused by force majeure.
14
