Top TGP58 Series User manual
Thank you for choosing TOP VME .
TGP58Series
Printer
Installation Guide
Contents
1. Introduction……………………………………………………………………………………………………… 1
1-1. Overview………………………………………………………………………………………………………… 1
1-2. Features ………………………………………………………………………………………………………… 1
2. Specification …………………………………………………………………………………………………… 2
2-1. General …………………………………………………………………………………………………… 2
2-2. Cutter …………………………………………………………………………………………………………… 2
2-3. Thermal Print head ……………………………………………………………………………………… 2
3. Dimension ……………………………………………………………………………………………………… 3
3-1. TGP58 Dimension ………………………………………………………………………………………… 3
3-2. TGP58-L Dimension……………………………………………………………………………………… 4
4. The hardware setup………………………………………………………………………………………… 5
4-1. Connection Setting ……………………………………………………………………………………… 5
4-2. LED and DIP Switch Setting ………………………………………………………………………… 6
4-3. Setting Step ………………………………………………………………………………………………… 7
5. Battery setup …………………………………………………………………………………………………… 8
6. Roll Installation Guide……………………………………………………………………………………… 8
7. RS232 Command Format ……………………………………………………………………………… 9
7-1. Reading the date and time…………………………………………………………………………… 9
7-2. Setting the date and time Command ………………………………………………………… 9
7-3. Upload trademark graphic formats …………………………………………………………… 9
7-4. Typeset print function ………………………………………………………………………………… 9
7-5. NO / NC choose…………………………………………………………………………………………… 11
7-6. Upload text …………………………………………………………………………………………………… 11
7-7. Clear diary …………………………………………………………………………………………………… 11
7-8. Cut the paper ……………………………………………………………………………………………… 11
7-9. Direct Print format graphics ………………………………………………………………………… 11
7-10. Print format text directly ……………………………………………………………………………12
7-11. Print Score Reports ………………………………………………………………………………………12
7-12. Print diary ……………………………………………………………………………………………………13
7-13. Back to the software version ………………………………………………………………………13
7-14. Read machine status……………………………………………………………………………………13
Contents
1
Printer
1
1. Introduction
1-1. Overview
TGP58 system with built-in clock, local time can be set before shipment, mark
the time on the printed document.
Provide users with one-day and summary reports, free to choose to delete,
the document has a typesetting function, users can easily download or
design document formats, trademarks, etc.The document format is stored
via TGP58 for future use.
1-2. Features
•Easy grasp data
•Recode data quickly and securely
•Query and print easily
TGP58 Series
2
2. Specification
2-1. General
Power Source 12V DC (10.8~13.2V DC)
Input/Output level HI : 12V LO : 0V DC
Roll Width 56 ± 0.5 mm
Installation Indoor
Power Consumption
TGP58
Standby：0.12A / 1.44W
Operation：2.1A / 25.2W
Maximum：2.5A / 30W
TGP58-L
Standby：0.23A / 2.76W
Operation： 2.22A / 26.64W
Maximum：2.61A / 31.32W
Weight Approx. 700g(without roll)
Temperature Range
Operation Temperature :
0° C~60° C
Storage Temperature :
-10° C~80° C
Humidity :
20%~70%RH(no condensation)
2-2. Cutter
Thickness Maximum0.12mm
Life Up to about 500,000 times
Time Fastest 1 time/ seconds
2-3. Thermal Print head
Life 30 km
Resolution 8 Ponints / mm
Speed 40 mm / sec
3
Printer
3
3. Dimension
3-1. TGP58 Dimension
Unit : mm [ inch ]
TGP58 Series
4
Unit : mm [ inch ]
3-2. TGP58-L Dimension
120.20
4.732
70.20 2.764
22.60 0.890 95.00 3.740
140.20
5.520
82.00 3.228
12.00 0.472
151.30
5.957
7.70
0.303
129.20
5.087
19.30 0.760
84.10 3.311
75.20 2.961
6.30
0.248
5
Printer
5
4. The hardware setup
4-1. Connection Setting
Please read the table below for information on connectors :
CN1 Serial Interface
PIN 1- GND PIN 5- RESET
PIN 2- X PIN 6- VCC (+5V DC)
PIN 3- PGD PIN 7- RX
PIN 4- PGC PIN 8- TX
PULSE MODE
PIN LINE COLOR FEATURES SIGNAL I/O
1 Red +12V DC
2 Black GND
3 Brown Coin PULSE I
4 Orange Note PULSE I
5 Yellow Payout PULSE I
6 Green NC
7 Blue Error Low active O
HOPPER MODE
PIN LINE COLOR FEATURES SIGNAL I/O
1 Red +12V DC
2 Black GND
3 Brown Coin PULSE I
4 Orange Note PULSE I
5 Yellow HOPPER SSR Low active I
6 Green HOPPER SW PULSE O
7 Blue Error Low active O
TGP58 Series
6
4-2. LED and DIP Switch Setting
A.Bezel LED：Normal - LED light，Error - LED is off
B. Status light：Normal : LED is green ; Error : LED is red .
LED
TGP58 TGP58-L
LED
7
Printer
7
C. DIP Switch
Features SW1 SW2 SW3 SW4
Paper cutting part OFF
Completely cut paper ON
Pulse Width 30ms OFF OFF
Pulse Width 50ms ON OFF
Pulse Width 100ms OFF ON
Pulse Width 200ms ON ON
Normal High (NC) OFF
Normal Low (NO) ON
D. KEY1 and KEY2
•Press KEY1 once，Print daily report
•Hold for KEY1 more than two sec ，The last record before printing
•Press KEY2，Paper forward
4-3. Setting Step
A. Connect the power cord to the PCBA signal CN7
B. will roll in accordance with the direction of the grating mounted to the
machine roll groove
C. RS-232 interface or bill format setting :
The RS232 cable connects CN1 computer terminals and printer’s COM
port.
D. Turn the power on, put paper in the printer, the machine automatically
senses the paper (about 2 seconds) and the feed paper into the printer.
If the installation is successful, the operated lights will turn on and turn
into standby mode on the panel.
TGP58 Series
8
5. Battery setup
1、2 PIN shorted : Enable 2、3 PIN Short : Disable
Enable is default setting, the battery will charge after connecting power,
that will supply the internal clock when turn off power.
6. Roll Installation Guide
1. The new paper roll into the clockwise direction
2. The printer lever pushed clockwise
9
Printer
9
7. RS232 Command Format
7-1. Reading the date and time
Byte1 Byte2
1Bh F0h
7-2. Setting the date and time Command
Command :
Byte1 Byte2 Byte3~12 Byte13
1Bh F1h Data Format
Return code:
Byte1 Byte2
77h 33h
Style :
Format Command
yy/mm/dd 0x00
mm/dd/yy 0x01
dd/mm/yy 0x02
yy/dd/mm 0x03
For example : at 17:33 on August 13, 2014
The command is : 1Bh F1h 31h 34h 30h 38h 31h 33h 31h 37h 33h 33h
7-3. Upload trademark graphic formats
Byte1 Byte2 Byte3 Byte4 Byte5~52
1Dh F4h Graphic size low-
tuple
Graphic size high-
tuple Data
Return code :
48bytes Data received correctly 42h
All data reception is completed ABh
7-4. Typeset print function
Byte1 Byte2 Byte3~ Byte32
33h BBh Data
*Parameters1：Byte3,Byte5,Byte7~~~~~~~,Byte31 Information Content
TGP58 Series
10
Blank lines 20h Character2 75h
Trademark 4Ch Character3 76h
Two-dimensional code 51h Character4 77h
Fraction 50h Character5 78h
date 44h Character6 79h
Barcode 42h Character7 7ah
character1 74h Character8 7bh
*Parameters1：Byte4,Byte6,Byte8~~~~~~~,Byte32 Information Content
If the parameter 1 is a trademark of a two-dimensional code, date or
barcode, please set parameter 2 to B0h
No parameters B0h
If the parameter 1 is to choose a score, a text 1, text 2,text 3, or text 4.
The Parameter 2 options are set as follows:
1*1 Font B1h 2*4 Font B4h
1*2 Font B2h 3*3 Font B5h
2*2 Font B3h 3*6 Font B6h
If this parameter 1 is set to a "blank line" Parameter 2 options are set as
follows :
Empty 1 row 1h Empty 6 row 6h
Empty 2 row 2h Empty 7row 7h
Empty 3 row 3h Empty 8 row 8h
Empty 4 row 4h Empty9 row 9h
Empty 5 row 5h Empty 10 row 10h
Receive information is complete, it will respond to 06h.
11
Printer
11
7-5. NO / NC choose
Byte1 Byte2 Byte3
33h BCh Data
Byte3= 00h (pulse normal High)
Byte3= 01h (pulse normal Low)
7-6. Upload text
Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 Byte8 Byte9
33h BDh Data1 Data2 Data3 Data4 Data5 Data6 Data7
Byte10 Byte
11~34
Byte
35~58
Byte
59~82
Byte
83~106
Byte
107~130
Byte
131~154
Byte
155~178
Byte
179~202
Data
8
Data
9Data 10 Data 11 Data
12
Data
13
Data
14
Data
15
Data
16
Byte3 ~ Byte10 :
Left 00h
Middle 01h
right 02h
7-7. Clear diary
Byte1 Byte2
1Bh F2h
7-8. Cut the paper
Byte1 Byte2
1Bh F5h
7-9. Direct Print format graphics
Byte1 Byte2 Byte3~50
1Dh F8h Data
Printer will respond to 06h, indicating reception success
Printer will respond 0Ah, representing the failure to receive
TGP58 Series
12
7-10. Print format text directly
Byte1 Byte2 Byte3 Byte4~9 End character
1Dh F7h Mode ASCII
Character 0Dh
Printer will respond to 06h, indicating reception success
Printer will respond 0Ah, representing the failure to receive
Location Print size
(width x height)
Mode = 00h 1x1
Mode = 01h 1x2
Mode = 02h 2x2
Mode = 03h 2x4
Mode = 04h 3x3
Mode = 05h 3x6
ASCII Character input 1~6 digital
7-11. Print Score Reports
Byte1 Byte2
1Bh F9h
Printer will respond to 06h, indicating reception success
7-12. Print diary
Byte1 Byte2
1Bh F9h
Printer will respond to 06h, indicating reception success
7-13. Back to the software version
Byte1 Byte2
1Bh FBh
Printer will respond to 12 Bytes of data
7-14. Read machine status
Byte1 Byte2
1Bh FCh
Printer will be a normal response to 00h, 01h represent run-out to paper 02h
represent that cutter is malfunction.
