Canon BJ-W3000 User manual

QY8-1366-000
REVISION 0
COPYRIGHT  2000 CANON INC. CANON BJ-W3000/3050 0100 GR 0.40-0 PRINTED IN JAPAN (IMPRIME AU JAPON)
JAN. 2000

0000 GR 0.40-0

Target Readers
This manual is published by Canon Inc. for qualified persons and contains the necessary technical
information for technical theory, installation, maintenance, and repair of products. This manual covers
all localities where the products are sold. For this reason, it may contain information that does not
apply to your locality.
Revisions
This manual may include technical inaccuracies or typographical errors due to improvements or
changes in the products. When amendments are made to the content of this manual, Canon will issue
technical information as the need arises. In the event of major alterations to the content of this manual
over a long or short period, Canon will publish a revised version of the manual.
The following paragraphs do not apply to any countries where such provisions are
inconsistent with local law.
Trademarks
The product names and company names appearing in this manual are the registered trademarks or
trademarks of the individual companies.
Copyright
This manual is copyrighted and all rights reserved. Under the copyright laws, this manual may not be
copied, reproduced, or translated into other languages, in whole or in part, without the express written
consent of Canon Inc. except in the case of internal business use.
Copyright 2000 by Canon Inc.
CANON INC.
Quality Engineering Center
30-2 Shimomaruko 3-chome, Ohta-ku, Tokyo 146-8501, Japan
This manual was produced on an Apple®Power Macintosh®G3 personal computer and Canon LASER
SHOT LBP-730PS laser beam printer; final pages were printed on Varityper®4300J.
All logos graphics were produced with Adobe®Illustrator®5.0J / 5.5J / 8.0J and MACROMEDIA
FREEHAND7.0J.
All documents and all page layouts were created with Adobe®Page Maker®6.5J and QuarkXPress3.3J.

ii
PREFACE
This Service Manual describes fundamental field service for the BJ-W3000/BJ-W3050 large
format printer.
This Manual is composed of the following chapters:
Chapter 1 General Description: Features, specifications and operating procedures
Chapter 2 Basic Operation: Operation of mechanical and electric functions
Chapter 3 Mechanical System: Mechanical setup and assembling/disassembling procedure
Chapter 4 Maintenance and Servicing: Periodic parts replacement, Standard service life of
consumables, Periodical services, points of maintenance and inspections
Chapter 5 Troubleshooting: Service mode, adjusting and settings, operation trouble
correction, image trouble correction
Chapter 6 Circuite diagrams
Appendix Menu guide
i

iii
PREFACE
Descriptions in this manual are based on the following conventions.
1. In the Basic Operation section, the roles of each function, relationships between electrical
and mechanical systems, and the timing for each part are summarized.
The mark indicates mechanical drive transmission. The mark
accompanying a signal name indicates the flow of electrical signals.
Flow charts are also used in the summary of operation.
The symbols used in the flow charts are as follows:
2. In the descriptions of digital circuits, "1" or "H" indicates a high voltage level, and "0" or
"L", a low voltage level. However, the actual voltage values vary depending on the circuit.
3. It is assumed that the Printed circuit board (PCB) will not be repaired by the user. There-
fore, the descriptions of the circuits on the PCB are limited to block diagrams.
4. Troubleshooting is described using procedural tables.
The procedural table is a variation of a general flow chart.
An example is shown below.
e.g. No power is supplied.
1
2
3
NO
NO
YES
Connect the power code to the
machine and outlet.
Explain to the customer that the
trouble is not attributable to the
machine.
Remove the cause of the blown
fuse and replace the DC power
PCB.
Is the power cord properly con-
nected to the receptacle on the
machine and the outlet?
Is the specified voltage applied to
the outlet?
Is the fuse on the DC power PCB
(F1) blown?
Step RemedyCheck item
Cause Result
• If you want to know the possible causes of any specific problem (suspected parts), refer to
the "Cause" column in the table.
In the event "No power is supplied" as shown in the above table, an unplugged power
source, power source failure, blown fuse, and other causes can be considered.
Unplugged power
source
Power source failure
Blown fuse
Start/completion Operation Decision Remedy Jump Stop
ii

iv
PREFACE
• In order to remedy a problem, check the Steps in order. Answer the first "Check item"
question. If your answer matches that given in the "Result", follow the corresponding proce-
dure in the "Remedy" column. If your answer is not the same, go on to the next step and
repeat the same procedure.
• When checking voltages using a tester is required, it will be specified in the check item.
For instance; "measure the voltage between J102-1 (+) and JI02-2 (-) on the engine control-
ler PCB". In this case, apply the plus and minus leads of the tester to the (+) and (-) termi-
nals indicated after the connector numbers:
e.g. JI02-1 (+): Plus lead
JI02-2 (-): Minus lead
5. The signal address of the circuit diagram is shown by applicable pages of each controller
(indicated at the upper right of the circuit diagram) and its location.
CAUTION
Connect in the power code
to the machine and outlet.
Is the
power cord properly
connected to the receptacle
on the machine
and outlet?
YES
NO
1
<Remedy><Check item> <Result><Step>
Explain to the customer that
the trouble is not attributable
to the machine.
Is the specified
voltage applied to the outlet?
YES
NO
2
Remove the cause of the
blown fuse and replace the
DC power PCB.
Is the fuse
on the DC power PCB (F1)
blown?
NO
YES
3
When checking voltages with a tester, touching the components or connector terminals on
the PCB with the hands may cause an electric shock. It is advisable to wear rubber gloves
or the like when power is supplied to the machine to protect yourself from electric shock.
iii

v
PREFACE
CONTENTS
CHAPTER 1 GENERAL DESCRIPTION
CHAPTER 2 BASIC OPERATION
iv
I. SPECIFICATIONS ............................................ 1-1
1. Type............................................................. 1-1
2. Exterior ........................................................ 1-1
3. Mechanism .................................................. 1-2
4. Media ........................................................... 1-4
5. Others .......................................................... 1-6
II. NAMES OF COMPONENTS ............................. 1-7
A. External View............................................... 1-7
B. Carriage ....................................................... 1-8
C. Cable Connections ...................................... 1-8
D. Rear Side of Main Unit................................. 1-9
E. Printing Direction.......................................... 1-9
III. OPERATION ................................................... 1-10
A. Operation Panel......................................... 1-10
B. Printer States ............................................. 1-11
C. User Mode Menu .......................................... 13
1. Menu guide ............................................. 13
2. Menu and parameter setup .................. 1-14
3. Details of user mode menus ................ 1-14
4. Using the setup list............................... 1-25
5. Dump mode.......................................... 1-27
6. Image layout......................................... 1-27
D. Basic Operation ......................................... 1-29
E. Paper Thickness Adjustment Lever ........... 1-31
IV. CARTRIDGE REPLACEMENT ....................... 1-32
A. Replacing the BJ Print head ....................... 1-32
B. Replacing the Ink Tank ............................... 1-34
V. SIMM REPLACEMENT ................................... 1-36
A. About SIMM ............................................... 1-36
B. SIMM Installation ....................................... 1-36
C. SIMM Removal .......................................... 1-37
VI. CAUTIONS ON HANDLING............................ 1-38
A. Cartridges .................................................. 1-38
1. Cautions on handling the BJ print
head ..................................................... 1-38
2. Cautions on handling ink tanks ............ 1-38
B. Paper Storage Environment ...................... 1-39
C. Paper ......................................................... 1-39
D. After Printing .............................................. 1-39
VII. USER MAINTENANCE................................... 1-40
A. Head Cleaning ........................................... 1-40
B. Normal Cleaning ......................................... 1-40
VIII. INSTALLATION ENVIRONMENT................. 1-41
IX. PACKAGE CONFIGURATION ....................... 1-42
X. TRANSPORTING THE PRINTER ................... 1-43
I. BASIC OPERATION ......................................... 2-1
A. Functional Configuration.............................. 2-1
B. Interface Input/Output .................................. 2-2
1. Parallel interface ..................................... 2-2
2. Serial interface........................................ 2-6
C. Image Controller .......................................... 2-7
D. Engine Controller ....................................... 2-10
E. Engine controller Input/Output ................... 2-12
1. Engine controller input/output (1/3) ...... 2-12
2. Engine controller input/output (2/3) ...... 2-13
3. Engine controller input/output (3/3) ...... 2-14
F. Summary of Operation............................... 2-15
1. When the power switch is turned ON... 2-15
2. When media is loaded.......................... 2-17
3. Printing ................................................. 2-18
II. CARRIAGE UNIT ............................................ 2-22
A. Outline ....................................................... 2-22
B. Carriage Motor Control .............................. 2-24
1. Outline.................................................. 2-24
2. Operation ............................................. 2-24
3. Detection of front cover open/closed ... 2-25
C. Linear Encoder .......................................... 2-26
1. Outline.................................................. 2-26
2. Structure............................................... 2-26
3. Output signal ........................................ 2-26
4. Control.................................................. 2-27
D. Media Sensor............................................. 2-28
1. Outline.................................................. 2-28
2. Paper width detection........................... 2-28
3. Skew detection..................................... 2-29
4. Light compensation .............................. 2-31
5. Auto band adjustment .......................... 2-31
6. Automatic print position adjustment ..... 2-32
E. Detection of the Ink Tank........................... 2-34
1. Outline.................................................. 2-34
2. Method of detecting the ink tank .......... 2-34

vi
PREFACE
CHAPTER 3 MECHANICAL SYSTEM
v
F. Remaining Ink Detection............................ 2-35
1. Outline.................................................. 2-35
2. Method of detecting remaining ink ....... 2-36
G. Cutter Unit.................................................. 2-38
1. Outline.................................................. 2-38
2. Cutting operation.................................. 2-38
III. BJ CARTRIDGE .............................................. 2-39
A. BJ Cartridge............................................... 2-39
1. Overview .............................................. 2-39
2. Structure............................................... 2-39
3. BJ print head ........................................ 2-41
4. Nozzle arrangement............................. 2-42
B. BJ Print head Drive.................................... 2-43
1. Construction of electric head unit......... 2-43
2. Print signal ........................................... 2-45
IV. PURGE UNIT .................................................. 2-46
A. Outline ....................................................... 2-46
B. Capping Function....................................... 2-51
1. Outline.................................................. 2-51
2. Operation ............................................. 2-51
C. Head Cleaning ........................................... 2-52
1. Outline.................................................. 2-52
2. Wiping .................................................. 2-52
3. Maintenance jet.................................... 2-53
4. Suction ................................................. 2-54
D. Waste Ink Absorber Unit............................ 2-56
1. Waste ink absorber unit ....................... 2-56
V. FEEDER UNIT ................................................ 2-57
A. Outline ....................................................... 2-57
B. Paper Feed Motor Control ......................... 2-58
1. Outline.................................................. 2-58
2. Operation ............................................. 2-58
C. Feeding Operation ..................................... 2-60
1. Outline.................................................. 2-60
2. Loading paper ...................................... 2-60
3. Paper feeding during printing ............... 2-61
4. Feeding operation ................................ 2-62
5. PE sensor............................................. 2-62
VI. FAN.................................................................. 2-63
VII. POWER SUPPLY ........................................... 2-65
A. Power Supply Outline ................................ 2-65
B. Power Circuit ............................................. 2-66
1. AC power supply .................................. 2-66
2. DC power supply.................................. 2-66
C. Power Circuit Protection ............................ 2-66
DISASSEMBLY AND ASSEMBLY.......................... 3-1
1. List of Main Parts ......................................... 3-2
2. Outline of disassembly and assembly of
main parts .................................................... 3-3
PRECAUTIONS FOR DISASSEMBLY
AND REASSEMBLY .............................................. 3-5
I. EXTERNALS ..................................................... 3-7
A. External Cover ............................................. 3-7
1. Removing the right cover ....................... 3-7
2. Removing the upper cover and
front cover .............................................. 3-7
3. Removing the lower cover...................... 3-8
4. Removing the front cover switch ............ 3-9
B. Operation Panel........................................... 3-9
1. Removing the operation panel ............... 3-9
C. Fan............................................................. 3-10
1. Removing the cooling fan..................... 3-10
2. Removing the suction fan..................... 3-12
II. CARRIAGE UNIT ............................................ 3-13
1. Removing the carriage unit .................. 3-13
2. Removing the carriage belt .................. 3-15
3. Installing the carriage belt .................... 3-16
4. Removing the linear scale.................... 3-17
5. Replacing the flexible cable ................. 3-18
III. PURGE UNIT .................................................. 3-21
1. Removing the purge unit ...................... 3-21
2. Removing the waste ink absorber
unit ....................................................... 3-23
IV. FEEDER UNIT ................................................ 3-24
1. Removing the pinch roller unit.............. 3-24
2. Removing the platen ............................ 3-25
3. Installing the platen .............................. 3-26
4. Removing the paper feed roller............ 3-27
5. Removing the PE sensor ..................... 3-27
V. DRIVING UNIT ................................................ 3-28
1. Removing the carriage motor............... 3-28
2. Removing the paper feed motor .......... 3-29
3. Installing the paper feed motor ............ 3-30
4. Fastening the paper feed roller set
screws .................................................. 3-30
VI. ELECTRICAL PART........................................ 3-32
1. Removing the image controller ............ 3-32
2. Removing the engine controller ........... 3-33
3. Removing the PCB box........................ 3-34
4. Removing the power switch ................. 3-35
5. Removing the DC power supply........... 3-35

vii
PREFACE
CHAPTER 5 TROUBLESHOOTING
CHAPTER 4 MAINTENANCE AND SERVICING
I. PERIODIC PARTS REPLACEMENT ................ 4-1
II. STANDARD SERVICE LIFE OF
CONSUMABLES............................................... 4-1
III. PERIODIC SERVICE ........................................ 4-1
IV. MAINTENANCE AND INSPECTION................ 4-2
A. Cleaning/Inspection Points .......................... 4-2
B. Lubrication Points ........................................ 4-3
vi
I. SERVICE MODE ............................................... 5-1
A. Outline.......................................................... 5-1
B. Service Mode Operation .............................. 5-1
1. How to enter the service mode .............. 5-1
2. Stopping the service mode .................... 5-1
C. Service Mode Map....................................... 5-2
D. Service Mode............................................... 5-3
1. Control display mode ............................. 5-3
2. Adjusting mode ...................................... 5-5
3. Operation/inspection mode .................... 5-6
4. Counter mode ........................................ 5-7
5. Initialization mode .................................. 5-8
II. ADJUSTMENTS AND SETTINGS .................... 5-9
A. About Adjustments and Settings.................. 5-9
B. Items for Adjustment and Setting................. 5-9
C. Adjustment and Setting Procedures ........... 5-10
1. Automatic printing position adjustment
and automatic band adjustment
(User-settable) ..................................... 5-11
2. Waste ink counter reset (for exclusive
use in service mode) ............................ 5-11
3. Replacing the image controller and
engine controller................................... 5-11
4. Paper feed accuracy compensation
value adjustment .................................. 5-13
5. Changing the parallel interface
communication mode ........................... 5-15
6. Image controller/engine controller
upgrade procedure............................... 5-16
III. ERROR/WARNING CODES ........................... 5-18
A. Outline ....................................................... 5-18
B. List of Error and Warning Codes ............... 5-18
1. 001xx (Media/feeding system) ............. 5-20
2. 003xx (Drive system) ........................... 5-22
3. 004xx (BJ Print head system) .............. 5-23
4. 005xx (Ink tank system) ....................... 5-24
5. 007xx (Purge system) .......................... 5-24
6. 008xx (Cutter system) .......................... 5-25
7. 011xx (Engine controller) ..................... 5-25
8. 012xx
(Internal communication system) .... 5-26
9. 015xx (Power supply related)............... 5-26
10.021xx (User-adjusted system) ............. 5-26
11.051xx (Image controller) ...................... 5-27
12.052xx (Serial interface communication
system)................................................. 5-27
13.053xx (Parallel interface communication
system)................................................. 5-27
14.060xx (Internal data processing
system)................................................. 5-28
15.061xx (GL command system) .............. 5-29
16.062xx (GL2 command system) ............ 5-29
17.063xx (RTL command system) ............ 5-29
18.064xx (ESC command system)............ 5-30
19.065xx (PJL command system)............. 5-30
20.067xx (TIFF command system) ........... 5-30
21.097xx (Direct error code from the image
controller) ............................................. 5-31
22.098xx (Direct error code from the engine
controller) ............................................. 5-31
23.099xx (Others) ..................................... 5-31
IV. CORRECTION OF OPERATION DEFECTS .. 5-32
1. 001xx (Media/feeding system) ............. 5-32
2. 003xx (Drive system) ........................... 5-33
3. 004xx (BJ Print head system) .............. 5-34
4. 005xx (Ink tank system) ....................... 5-34
5. 007xx (Purge unit)................................ 5-35
6. 008xx (Cutter system) .......................... 5-36
7. 011xx (Engine controller) ..................... 5-36
8. 012xx
(Internal communication system) .... 5-37
9. 015xx (Power supply related)............... 5-37
10.021xx (User-adjusted system) ............. 5-37
11.051xx (Image controller) ...................... 5-37
12.052xx (Serial interface communication
system)................................................. 5-38
13.053xx (Parallel interface communication
system)................................................. 5-38
14.060xx (Internal data processing
system)................................................. 5-38
15.061xx (GL command system) .............. 5-39
16.062xx (GL2 command system) ............ 5-39
17.063xx (RTL command system) ............ 5-39
18. 064xx (ESC command system) ........... 5-39

viii
PREFACE
CHAPTER 6 CIRCUIT DIAGRAM
A. GENERAL CIRCUIT DIAGRAM ........................ 6-1
B. IMAGE CONTROLLER....................................... 6-4
C. ENGIN CONTROLLER.................................... 6-16
D. CARRIAGE CONTROLLER ............................ 6-33
E. PAPER SENSOR ............................................ 6-41
F. OPERATION PANEL CONTROLLER ............. 6-42
APPENDIX
MENU GUIDE .........................................................A-1
vii
19.065xx (PJL command system)............. 5-39
20.067xx (TIFF command system) ........... 5-39
21.097xx (Direct error code from the image
controller) ............................................. 5-39
22.098xx (Direct error code from the engine
controller) ............................................. 5-39
23.099xx (Others) ..................................... 5-39
24. No power ............................................ 5-40
25.Nothing is indicated on the operation
panel .................................................... 5-41
26.Opening and closing of front cover is
not detected ......................................... 5-41
27.Wiper solenoid does not working ......... 5-41
28.Media is not fed.................................... 5-42
29.Suction fan does not rotate .................. 5-42
V. CORRECTION OF IMAGE DEFECTS ............ 5-43
A. Initial Inspection ......................................... 5-43
1. Installation environment ....................... 5-43
2. Media check ......................................... 5-43
B. Corrective Procedures for Image Defects.. 5-44
1. Non-ejection of ink ............................... 5-44
2. Vertical misalignment 1 ........................ 5-45
3. Vertical misalignment 2 ........................ 5-46
4. Low resolution ...................................... 5-47
5. Dislocation of dots of different colors ... 5-47
6. Dot misalignment ................................. 5-48
7. Lines (Carriage direction)..................... 5-49
8. White lines (Paper feed direction) ....... 5-50
9. Bleeding ............................................... 5-51
10.Dimensional accuracy problems .......... 5-51
11.Blotting boundary between filled
images.................................................. 5-52
VI. ELECTRICAL COMPONENTS ARRANGEMENT/
FUNCTIONS ................................................... 5-53
A. Sensors and Switches ............................... 5-53
B. Motors, Fans, and Solenoids ..................... 5-54
C. Logic boards .............................................. 5-55
D. Engine Controller ....................................... 5-56
E. Image Controller ........................................ 5-57

ix
PREFACE

CHAPTER 1
GENERAL DESCRIPTION
I. SPECIFICATIONS ............................................ 1-1
II. NAMES OF COMPONENTS ............................. 1-7
A. External View............................................... 1-7
B. Carriage ....................................................... 1-8
C. Cable Connections ...................................... 1-8
D. Rear Side of Main Unit................................. 1-9
E. Printing Direction.......................................... 1-9
III. OPERATION ................................................... 1-10
A. Operation Panel......................................... 1-10
B. Printer States ............................................. 1-11
C. User Mode Menu ....................................... 1-13
D. Basic Operation ......................................... 1-29
E. Paper Thickness Adjustment Lever ........... 1-31
IV. CARTRIDGE REPLACEMENT ....................... 1-32
A. Replacing the BJ Print head ....................... 1-32
B. Replacing the Ink Tank ............................... 1-34
V. SIMM REPLACEMENT ................................... 1-36
A. About SIMM ............................................... 1-36
B. SIMM Installation ....................................... 1-36
C. SIMM Removal .......................................... 1-37
VI. CAUTIONS ON HANDLING............................ 1-38
A. Cartridges .................................................. 1-38
B. Paper Storage Environment ...................... 1-39
C. Paper ......................................................... 1-39
D. After Printing .............................................. 1-39
VII. USER MAINTENANCE................................... 1-40
A. Head Cleaning ........................................... 1-40
B. Normal Cleaning ......................................... 1-40
VIII. INSTALLATION ENVIRONMENT................. 1-41
IX. PACKAGE CONFIGURATION ....................... 1-42
X. TRANSPORTING THE PRINTER ................... 1-43

CHAPTER 1. GENERAL DESCRIPTION
1–1
I. SPECIFICATIONS
1. Type
Type: Bubble jet printer
Purge system: Suction with tube pump
Paper feeding method: Cut sheet media; Manually set to the front.
Roll media; Automatic feeding (When manually set to the rear.)
Sheet feeder capacity: Cut sheet media; 1 sheet
Roll media; 1 unit (Outside dia.: 100mm or less, Media tube bore:
50.8mm (2"))
Media delivery system: Face-up delivery in front
Max. delivery sheets: 5 sheets (Plain paper)
Fixing method: Natural drying
Cutter: Automatic cutter (replaceable)
2. Exterior
A0-size model:
External dimensions (main unit only); 1462 x 388 x 345 mm
External dimensions (including stand); 1462 x 700 x 1204 mm
Weight (Main unit only); Approx. 31 kg
Weight (including stand); Approx. 46 kg
A1-size model:
External dimensions (main unit only); 1182 x 388 x 345 mm
External dimensions (including stand); 1182 x 700 x 1204 mm
Weight (main unit only); Approx. 26 kg
Weight (including stand); Approx. 40 kg

CHAPTER 1. GENERAL DESCRIPTION
1–2
Print modes according to media type <Corresponds to the Nos. of table 1-101.>
3. Mechanism
Print mode/Resolution
(No.) Mode Pass *1Resolution Drive frequency Dot size *3
(1) Monochrome draft 1 pass/Bi 180dpi x 360dpi 14.4kHz M
(2) Monochrome normal 1 pass/Uni 360dpi x 360dpi 7.2kHz L
(3) Monochrome enhanced 2 pass/Uni 360dpi x 360dpi 7.2kHz L
(4) Monochrome high enhanced 4 pass/Uni 360dpi x 360dpi 7.2kHz L
(5) Monochrome high resolution 4 pass/Uni 720dpi x 720dpi*27.2kHz S
(6) Color draft 1 pass/Bi 360dpi x 360dpi 7.2kHz Bk:M/Color:S
(7) Color normal 1 pass/Uni 360dpi x 360dpi 7.2kHz Bk:L/Color:S
(8) Color enhanced 2 pass/Uni 360dpi x 360dpi 7.2kHz Bk:L/Color:S
(9) Color high enhanced 4 pass/Unil 360dpi x 360dpi 7.2kHz Bk:L/Color:S
* 1: Bi=bi-directional, Uni=uni-directional
* 2: Equivalent
* 3: S=small dot, M=middle dot, L=large dot
Table 1-101
Media type Monochrome Color
Draft Normal Enhanced High resolution Draft Normal Enhanced
Maximum printing speed (Plain paper mode)
Print mode A0 size A1 size
Monochrome
mode
Color mode
Draft mode Approx. 2 minutes 15 seconds Approx. 1 minute 30 seconds
Enhanced mode Approx. 13 minutes Approx. 7 minutes
High Resolution mode Approx. 25 minutes Approx. 13 minutes 15 seconds
Draft mode Approx. 5 minutes 15 seconds Approx. 3 minutes
Enhanced mode Approx. 15 minutes Approx. 8 minutes 30 seconds
Plain paper (1) (2) (3) (5) (6) (7) (8)
Coated paper (1) (2) (3) (5) (7) (8) (9)
Tracing paper (2) (3) (4) (5) (7) (8) (9)
Matte film (2) (3) (4) (5) (7) (8) (9)
Table 1-102
Table 1-103

CHAPTER 1. GENERAL DESCRIPTION
1–3
Cartridge construction Head/Ink tank separation type
1 row of 160 nozzles (144 nozzles used) x 4 colors
Ink type Black: Pigment, Cyan/Magenta/Yellow: dye
Ink tank capacity Black: Approx. 23g,
Cyan/Magenta/Yellow: Approx. 20g
BJ print head service life A0 size: Approx. 400 sheets, A1 size: Approx. 500
sheets
(continuous printing on plain paper, 1-pass uni-
directional, at 20% duty (5% for each color))
Ink consumption A0 size: Bk; 25 sheets,
Cyan/Magenta/Yellow; 40 sheets
A1 size: Bk; 50 sheets,
Cyan/Magenta/Yellow; 80 sheets
(continuous printing on plain paper, 1-pass uni-
directional, at 20% duty (5% for each color))
Interface Parallel interface
Complies with IEEE1284 (Compatible mode/Nibble
mode)
Connector complying with IEEE1284-B Receptacle
Serial interface
Complies with RS-232C (DCE)
D-Sub 9-pin female connector
Emulation Complies with HP-GL, HP-GL/2, and HP-RTL
Kanji font Kanji JIS first and second standard
Memory Standard: 8MB (can be increased to 72 MB: 72-pin
60ns FPM type SIMMs)
EDO memory can be used in FPM mode.
Cutter Automatic cutter (replaceable)
Waste-ink tank Provided
Maintenance jet Provided
Capping system Provided
Paper thickness adjustment Provided
Automatic printing position adjustment Provided
Self diagnostics Provided
Skewed feed detection Provided
Head detection Provided
Head insertion error detection Not provided

CHAPTER 1. GENERAL DESCRIPTION
1–4
Ink tank detection Provided
Remaining ink detection Provided
Waste-ink full detection Provided
Media out detection Provided
Remaining roll media detection Not provided
Roll media end detection Provided
Media size detection
Cut sheet media: Automatic vertical/horizontal
detection
Roll media: Vertical; size or data designated
Horizontal; automatic detection
Carriage position detection Provided
Machine internal temperature detection Provided
4. Media
Media types Plain paper, coated paper, tracing paper, and matte
film (75 ~ 100µm)
Paper thickness 75 ~ 165µm (excluding matte film) / 64 ~ 128g/m 2
Maximum paper width A0 model: 914mm
A1 model: 634mm
Minimum paper width/length Width; 250mm Length; 150mm
Maximum printing length Cut sheet media: 1250mm
Roll media* : Windows95/98 driver; 4.6m
WindowsNT4.0 driver; 4.6m
ADI driver; 13m
HDI driver; 18m
* : Printing length of roll media varies depending on the type of application, operating system, or driver used.
Printing margin Cut sheet media: Leading edge; 5mm/15mm
Trailing edge; 20mm
Right/left edge; 5mm
Roll media: Leading edge; 5mm/15mm
Trailing edge; 5mm
Right/left edge; 5mm
Maximum printing area Excludes printing margins

CHAPTER 1. GENERAL DESCRIPTION
1–5
Printable papers
Paper standard mm inch A1 model A0 model
ISO A Vertical Horizontal Vertical Horizontal
A0 841.0 ×1189.0 33.1 ×46.8 NG NG OK NG
A1 594.0 ×841.0 23.4 ×33.1 OK NG OK OK
A2 420.0 ×594.0 16.5 ×23.4 OK OK OK OK
A3 297.0 ×420.0 11.7 ×16.5 OK OK OK OK
A4 210.0 ×297.0 8.3 ×11.7 NG OK NG OK
JIS B
B1 728.0 ×1030.0 28.7 ×40.6 NG NG OK NG
B2 515.0 ×728.0 20.3 ×28.7 OK NG OK OK
B3 364.0 ×515.0 14.3 ×20.3 OK OK OK OK
B4 257.0 ×364.0 10.1 ×14.3 OK OK OK OK
ISO B
B1 707.0 ×1000.0 27.8 ×39.4 NG NG OK NG
B2 500.0 ×707.0 19.7 ×27.8 OK NG OK OK
B3 353.0 ×500.0 13.9 ×19.7 OK OK OK OK
B4 250.0 ×353.0 9.8 ×13.9 OK OK OK OK
ANSI
E 863.6 ×1117.6 34.0 ×44.0 NG NG OK NG
D 558.8 ×863.6 22.0 ×34.0 OK NG OK OK
C 431.8 ×558.8 17.0 ×22.0 OK OK OK OK
B 279.4 ×431.8 11.0 ×17.0 OK OK OK OK
A 215.9 ×279.4 8.5 ×11.0 NG OK NG OK
ANSI ARCH
6 914.4 ×1219.2 36.0 ×48.0 NG NG OK NG
5 762.0 ×1066.8 30.0 ×42.0 NG NG OK NG
4 609.6 ×914.4 24.0 ×36.0 OK NG OK OK
3 457.2 ×609.6 18.0 ×24.0 OK OK OK OK
2 304.8 ×457.2 12.0 ×18.0 OK OK OK OK
1 228.6 ×304.8 9.0 ×12.0 NG OK NG OK
ISO Over
A0 910.0 ×1245.0 35.8 ×49.0 NG NG OK NG
A1 627.0 ×900.0 24.7 ×35.4 OK NG OK OK
A1L 627.0 ×1250.0 24.7 ×49.2 OK NG OK NG
A2 460.0 ×645.0 18.1 ×25.4 OK NG OK OK
A3 340.0 ×465.0 13.4 ×18.3 OK OK OK OK
EURO DIN
A0 881.0 ×1229.0 34.7 ×48.4 NG NG OK NG
A1 634.0 ×881.0 25.0 ×34.7 OK NG OK OK
A2 460.0 ×634.0 18.1 ×25.0 OK OK OK OK
A3 337.0 ×460.0 13.3 ×18.1 OK OK OK OK
A4 250.0 ×337.0 9.8 ×13.3 OK OK OK OK
KOREAN
m 540.0 ×790.0 21.3 ×31.1 OK NG OK OK
s 390.0 ×540.0 15.4 ×21.3 OK OK OK OK

CHAPTER 1. GENERAL DESCRIPTION
1–6
5. Others
Power source AC: 100 ~ 240 V (-15%, +10%)
Frequency 50/60Hz
Power consumption Max.: 120W or less
At stand-by: 22W or less
Noise Sound pressure level (Complies with ISO 9296.)
When operating: Approx. 52dB (A) or less
At stand-by: Approx. 20dB (A) or less
Operating environment Temperature: 5 ~ 35°C
(Printing quality assured: 15 ~ 30°C)
Humidity: 10 ~ 90%RH
(Printing quality assured: 20 ~ 80%RH)
Atmospheric pressure: 1013 ~ 709hPa
Storage environment* Temperature: 0 ~ 35°C
Humidity: 5 ~ 95% (RH)
* : Should be free from condensation and rapid temperature variations.

CHAPTER 1. GENERAL DESCRIPTION
1–7
II. NAMES OF COMPONENTS
A. External View
Figure 1-201
[1]
[8]
[7]
[6]
[5]
[4]
[2]
[3]
[1] Front cover
[2] Carriage
[3] Operation panel
[4] Paper release lever
[5] Wiper (Cleaner blade)
[6] Cutter unit
[7] Platen
[8] Pinch roller
