INSTRUCTION MANUAL
LASER SENSOR
LS-B200
Thank you for purchasing the TOPCON LS-B200.
For the best performance of the instruments, please read these instructions
carefully and keep them in a convenient location for future reference.
GENERAL HANDLING PRECAUTIONS
Before starting work or operation, be sure to check that the system is functioning
properly.
• Remove the batteries from the instrument when you will not be using it for
long period.
• Replace all 4 dry batteries with new ones at the same time. Do not mix used
and new dry batteries, and do not mix different types of dry batteries together.
• Use alkaline dry batteries. Nickel hydrogen dry batteries and nickel cadmium
dry batteries can be used too, but the operating time is different from the time
of alkaline dry batteries.
• Do not submerge the instrument in water.
• This instrument is designed based on the International Standard IPX 6, but it
is not protected from a high pressure water stream or submergence.
• When washing the instrument, avoid spraying it with a high pressure stream
of water from a water hose. The inside of the instrument will be damaged by
the water.
• Be sure to charge the battery within the charging temperature range.
Charging temperature range: 10 to 40°C
• Battery is an expendable item. The decline in retained capacity depending on
the repeated charging/discharging cycle is out of warranty.
• Affection of the radio waves
When using the instrument in the following place, the strong radio wave may
cause faulty operation.
• Near the instrument occurring strong radio waves. (e.g. Transceiver)
• Near the radio wave towers such as television or radio.
• When transporting the instrument, provide some protection to minimize risk of
shock. Heavy shock may affect beam accuracy.
• In addition to the laser beam emitted from the rotating laser, the laser sensor
may be sensitive to smartphone screens, LED lamps, fluorescent lamps, con-
striction lamps, and other modulated lights. In this case, turn off these modu-
lated lights that may be the cause, or block them before performing
measurement.
• If an object (glass window, car windshield, etc.) that may reflect a laser beam
is close to this instrument, the laser sensor may malfunction. When using this
instrument, block the laser beam to the direction of a reflective object.
Examples of malfunctions:
• The display shows ""even though the location is not a datum posi-
tion.
• Errors occur for the datum position.
• The display does not show ""even though the location
is a datum position.
• Be sure that the laser emitting window of this instrument, and
the beam receiving window of the laser sensor are free from dirt
(oil, water droplets, etc.). The measurement result may be in
error if these windows are dirty.
PRECAUTIONS FOR SAFE OPERATION
For the safe use of the product and prevention of injury to operators and other
persons as well as prevention of property damage, items which should be
observed are indicated by an exclamation point within a triangle used with
WARNING and CAUTION statements in this operator's manual.
The definitions of the indications are listed below. Be sure you understand them
before reading the manual's main text.
DEFINITION OF INDICATION
STANDARD PACKAGE COMPONENTS
• LS-B200 Instrument ................................................. 1pc.
• Carrying case ........................................................... 1pc.
• Instruction manual .................................................... 1pc.
Dry battery type*
• Battery holder DB-83 ............................................ 1pc.
Dry batteries(4 x C) are sold separately.
*In some destinations, a rechargeable battery is already set in the main unit.
Rechargeable battery type (Optional accessories)
• Ni-MH battery pack BT-83Q ................................. 1pc.
• AC/DC converter AD-11........................................ 1pc.
PARTS OF THE INSTRUMENT AND FUNCTIONS
REPLACING THE BATTERY
Dry battery
1Remove the DB-83 battery holder by turning the battery cover knob.
2Remove the old batteries and replace with new ones.
Rechargeable battery
1Remove the BT-83Q by turning the battery cover knob.
2Attach the charged BT-83Q to the LS-B200.
3Attach the battery cover by turning the battery cover knob.

• Batteries generate power using a chemical reaction and as a result have a limited life-
time. Even when in storage and not used for long periods, battery capacity deteriorates
with the passage of time. This may result in the operating time of the battery shortening
despite having been charged correctly. In this event, a new battery is required.
OPERATION
1Position a rotating laser and turn on the laser.
2Raise or lower the machine blade or arm to position the cutting
edge or bucket at the desired grade elevation.
3Mount the LS-B200 onto the mast near the path of the laser beam
and turn on the LS-B200.
4Keep the machine blade or arm motionless and raise or lower the
LS-B200 and adjust until ON-GRADE position are blinking. This is
the ON GRADE position.
5Securely clamp the LS-B200 in place. The reference position has been set.
6While operating, use the LED display to continually check grade, moving the
blade or cutting / filling according to the direction of the LS-B200 display.
WARNING Ignoring this indication and making an operation error could possibly
result in death or serious injury to the operator.
CAUTION Ignoring this indication and making an operation error could possibly
result in personal injury or property damage.
This symbol indicates items for which caution (hazard warnings inclusive) is urged.
Specific details are printed in or near the symbol.
This symbol indicates items which are prohibited. Specific details are printed in or near
the symbol.
This symbol indicates items which must always be performed. Specific details are
printed in or near the symbol.
WARNING
There is a risk of fire, electric shock or physical harm if you attempt to disassemble or repair the
instrument yourself.
This is only to be carried out by TOPCON or an authorized dealer, only!
Risk of fire or electric shock.
Do not use damaged power cable, plug and socket.
Risk of fire or electric shock.
Do not use a wet battery.
May ignite explosively.
Never use an instrument near flammable gas, liquid matter, and do not use in a coal mine.
Battery can cause explosion or injury.
Do not dispose in fire or heat.
To prevent shorting of the dry battery in storage, apply insulating tape or equivalent to the termi-
nals. Otherwise shorting could occur, resulting in fire or burns.
Battery can cause explosion or injury.
Remove battery when using the connector for external power supply.
CAUTION
Do not touch liquid leaking from dry batteries. Harmful chemicals could cause burns or blisters.
Shape: Cylindrical
Dimension: 45 to 51mm in diameter
Please refer to the instruction manual for the machine or contact
the machine manufacturer for instructions on installing the mast
onto the machine (by welding, etc.).
45 to 51mm
Indicator
Battery holder/
Battery pack
(DB-83/BT-83Q)
Battery cover knob
Power switch
Power ON: Short press
Power OFF: Long press
Detective precision (Mode) switch
Clamp knob
Detector
Detector
Clamp
Connector for external power supply
Please refer to the page 2 of the
instruction manual for the indicator
display patterns.
Remove the battery when connecting.
Pipes that can be installed onto the LS-B200 are as described
below.
Zero-set switch
ON-GRADE

2
INDICATOR
Blinks quickly
Blinks slowly
Blinks more slowly
Indicator(LED) Detectiveprecision
Mode1: ±3mm (0.009ft)
Mode2: ±6mm (0.019ft)
Mode3: ±15mm (0.049ft)
Mode4: ±30mm (0.098ft)
±50mm/±0.16ft
(100mm/0.32ft width)
±87.5mm/±0.28ft
(175mm/0.57ft width)
When the laser beam
is off to the top or to
the bottom
Height alert warning of rotating laser
A blink signifies that the height alert function of rotating laser is
operating.
(This function is not usable to the rotating laser which does not
have the height alert and the function to output alarm signal.)
Rotating laser battery warning display
A blink shows that the rotating laser power is low.
(This function is not usable to the rotating laser which does not
have the function to output alarm signal.)
Goes out:
Battery is sufficient. (When Mode 1 is selected, the lamp will
light up.)
Blinks slowly:
The power is low, but sensor is still usable.
Blinks quickly:
Dead battery. Replace the dry battery with new one or recharge
the battery (BT-83Q Optional accessories).
Mode1
Mode2
Mode3
Mode4
Precision mode
Auto-cut off function(Effective only when using the internal battery)
Laser beam positions and display patterns
LS-B200 Battery remaining display
Battery remaining display LED
Power-save function(Effective only when using the internal battery)
This instrument will enter the power-save mode when no switches are
operated or no laser beam is received for about five minutes. During
the power-save mode, two LEDs (one yellow and one red) will blink.
(When the laser beam is received again, the power-save mode will be
automatically turned off. Or when the power switch is pressed again,
the power-save mode will be also turned off.)
To disable the power-save function, press the power switch for at least
five seconds to turn the power on. When the function is disabled, the
LED shown in the figure will blink twice.
Rotating laser battery remaining warning LED
Blinks
Blinks
It is possible to change the detective precision of the instru-
ment. Please select Mode 1 to 4 according to the objective
of the operation.
(”Laser beam positions and display patterns”)
Pressing the detective precision (Mode) switch will change
the mode and the corresponding LED lamp will light up.
(During battery remaining display shown below, the lamp
will blink.)
Battery remaining for the LS-B200 will be displayed at 3 levels.
Detective precision (Mode) switch
This instrument will automatically power off when no switches are
operated or no laser beam is received for about 60 minutes after
entering the power-save mode. (To use the instrument again, press
the power switch once again.)
To disable the auto-cut off function, press the power switch for at least
five seconds to turn the power on. When the function is disabled, the
LED shown in the figure will blink twice.
Blinks
CHANGING THE ON-GRADE POSITION FUNCTION
The ON-GRADE position can be changed to the position where laser beam is detected.
Using this function when installing the LS-B200 on the pole of the machine allows easy
setting of the height at which the ON-GRADE will be displayed on the LS-B200. The
range in which the ON-GRADE position can be changed is ±50mm (total of 100mm)
from the center of the detective range.
In order to set the ON-GRADE position at high precision, set it while the laser beam is
stable. When setting the ON-GRADE position while the laser beam is unstable (when
using at a long-distance - more than 150m - or when atmospheric condition is unstable
due to air shimmering or other conditions), the sensor will automatically detect it and the
LED indicating the failure will be displayed while changing the ON-GRADE position.
Setting the ON-GRADE position change
The LED display while changing the ON-GRADE position
Canceling the ON-GRADE position change
1Long-press the zero-set switch while detecting the
laser beam.
When changing the ON-GRADE position, the LED
lights up for three seconds, as shown in the figure.
The position where the laser beam is being detected
will be the ON-GRADE position.
The LED blinks as shown in the figure for three sec-
onds when you have failed to change the ON-
GRADE position. Be careful not to change the posi-
tion at which the laser beam is detected and try set-
ting once again.
Blinks
The LED display indicating beam position and the LED
(1 green) in the center blinks.
Blinks quickly
1Long-press the zero-set switch when not detecting
the laser beam. The ON-GRADE position will be
reset.
When the ON-GRADE position change is cancelled,
the LED (3 green) blinks for three seconds.
Blinks
LED brightness adjustment function
(Effective only when using the internal battery)
This instrument detects the ambient brightness and automatically adjusts the LED
brightness (high/low). If you want to keep the LED brightness high, turn the power
switch on while holding down the detective precision (Mode) switch.

3
CONNECTOR FOR EXTERNAL POWER SUPPLY
Connecting the connector cable PC-18 (sold separately) to the connector for exter-
nal power supply will enable the use of the LS-B200 from an external power supply.
The LS-B200 will turn on when connection is made to external power supply. The
power switch of the instrument will not function when an external power supply is
used.
When the instrument is operated with the external power supply, the power-save
and the auto-cut off functions will be invalidated.
REGULATIONS
[U.S.A.] FCC Compliance (FCC-Class B)
WARNING:
Changes or modifications to this unit not expressly approved by the party responsi-
ble for compliance could void the user's authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interfer-
ence to radio communications.
However, there is no guarantee that interference will not occur in a particular instal-
lation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio / TV technician for help.
Means of conformity
This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter.
This equipment complies with FCC radiation exposure limits set forth for an uncon-
trolled environment and meets the FCC radio frequency (RF) Exposure Guidelines.
This equipment has very low levels of RF energy that is deemed to comply without
maximum permissive exposure evaluation (MPE). But it is desirable that it should
be installed and operated keeping the radiator at least
20cm or more away from person's body.
[California, U.S.A.] Proposition65
[California and NY, U.S.A.] Recycling Batteries
[Canada] ICES (ICES-Class B)
This class B digital apparatus meets all requirements of Canadian interference-
Causing Equipment Regulations.
Cet appareil numerique de la class B respecte toutes les exigences du Reglement
sur le materique brouilleur du Canada.
This Class B digital apparatus complies with Canadian ICES-003
Cet appareil numerique de la Class B est conforme a la norme NMB-003 du
Canada.
This equipment complies with IC radiation exposure limits set forth for an uncon-
trolled environment and meets the RSS-102 of the IC radio frequency (RF) Expo-
sure Guidelines. This equipment has very low levels of RF energy that is deemed to
comply without maximum permissive exposure evaluation (MPE).
But it is desirable that it should be installed and operated keeping the radiator at
least 20cm or more away from person's body.
[EU/UK] EMC NOTICE (EMC-Class B)
In industrial locations or in proximity to industrial power installations, this instrument
might be affected by electromagnetic noise. Under such conditions, please test the
instrument performance before use.
This product complies with the electromagnetic environmental testing of industrial
locations.
Declaration of conformity is available depending on your request.
Contact your local dealer.
Manufacturer
Name: TOPCON CORPORATION
Address: 75-1, Hasunuma-cho, Itabashi-ku, Tokyo, 174-8580 JAPAN
Europe Representative and Importer
Name: Topcon Europe Positioning B.V.
Address: Essebaan 11, 2908 LJ Capelle a/d IJssel, The Netherlands
UK Importer
Name: Topcon Positioning (Great Britain) Ltd.
Address: Unit 2 Sandy Hill Park, Sandy Way, Tamworth, Staffordshire B77 4DU
U.K.
[EU] WEEE Directive
[UK] The Waste Electrical and Electronic Equipment Regulations
EXCEPTIONS FROM RESPONSIBILITY
• The manufacturer, or its representatives, assumes no responsibility for any
damage, or loss of profits (change of data, loss of data, loss of profits, an
interruption of business etc.) caused by use of the product or an unusable
product.
• The manufacturer, or its representatives, assumes no responsibility for any
damage, or loss of profits caused by usage different to that explained in this
manual.
• The manufacturer, or its representatives, assumes no responsibility for con-
sequential damage, or loss of profits due to heavy rain, strong wind, high-
temperature and humidity, or storing or use of the product under unusual
conditions.
• Product failures caused by rebuilding are out of warranty.
• Cautions and warnings included in this manual do not cover all the possible
events.
WARNING:
This product can expose you to chemicals including Lead, which
is known to the State of California to cause birth defects or other
reproductive harm.
For more information go to www.P65Warnings.ca.gov.
the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. For more detailed information
about the take-back and recycling of this product, please contact your
supplier where you purchased the product or consult.
The use of the symbol indicates that this product may not be treated
as household waste. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for

4
[EU] EU Battery Directive
[UK] The Waste Batteries and Accumulators Regulations 2009
[China] Chinese Environmental Directive
SPECIFICATIONS
Detective range : 175mm (6.8 in)
(The range in which the ON-GRADE
position can be changed : 100mm)
Detective angle : 360°
Detective precision : Mode1: ±3mm (0.009ft)
Mode2: ±6mm (0.019ft)
Mode3: ±15mm (0.049ft)
Mode4: ±30mm (0.098ft)
Detectable laser wave length : 633 to 785nm
Laser detecting range (diameter) : 800m (2625ft) (Using RL-200 1S/2S)
Internal battery :
:
C-size dry cells 4pcs.(sold separately)
Battery pack BT-83Q (sold separately)
External power supply : DC 10 to 30V
Continuous operating time (20°C/68°F) :
:
More than 100 hours
(Using alkaline dry batteries)
More than 50 hours
(Using Battery pack BT-83Q)
Operating temperature : -20 to 50°C (-4 to 122°F)
Water proof : IP66 (Based on the standard IEC60529)
Dimensions (W/D/H) : 158x166x357 (mm) (6.2x6.5x14.0 (in))
(With Mechanical Clamp)
Weight (Without cells) : 2.2kg (4.8lbs)
Detective angle, Detective precision and Laser detecting range may vary depending on
rotating laser being used or atmospheric conditions. Battery using time will vary depend-
ing on environmental conditions and operations done with LS-B200.
If a chemical symbol is printed beneath the symbol shown above, this
chemical symbol means that the battery or accumulator contains a heavy
metal at a certain concentration. This will be indicated as follows:
Hg: mercury(0.0005%), Cd: cadmium(0.002%), Pb: lead(0.004%)
These ingredients may be seriously hazardous to human and the global
environment.
Battery users must not dispose of batteries as unsorted general
waste, but treat properly.
ƻ˖㺘⽪䈕ᴹ∂ᴹᇣ⢙䍘൘䈕䜘Ԧᡰᴹ൷䍘ᶀᯉѝⲴ䟿൷൘⭥ᆀؑ᚟ӗ૱ѝᴹ∂ᴹᇣ
⢙䍘Ⲵ䲀䟿㾱≲ḷ߶㿴ᇊⲴ䲀䟿㾱≲ *%7 ԕл
h˖㺘⽪䈕ᴹ∂ᴹᇣ⢙䍘㠣ቁ൘䈕䜘ԦⲴḀа൷䍘ᶀᯉѝⲴ䟿䎵ࠪ⭥ᆀؑ᚟ӗ૱ѝᴹ
∂ᴹᇣ⢙䍘Ⲵ䲀䟿㾱≲ḷ߶㿴ᇊⲴ䲀䟿㾱≲ *%7
7KLVLQIRUPDWLRQLVDSSOLFDEOHIRU3HRSOHV5HSXEOLFRI&KLQDRQO\
⧟؍֯⭘ᵏ䲀ḷ䇶ᱟṩᦞ lj⭥ಘ⭥ᆀӗ૱ᴹᇣ⢙䍘䲀ࡦ֯⭘㇑⨶࣎⌅NJԕ৺
lj⭥ಘ⭥ᆀӗ૱ᴹᇣ⢙䍘䲀ࡦ֯⭘ḷ䇶㾱≲NJ6-7 ࡦᇊⲴˈ䘲⭘Ҿ
ѝഭຳ޵䬰୞Ⲵ⭥ᆀؑ᚟ӗ૱Ⲵḷ䇶DŽ

㾱᤹➗ᆹޘ৺֯⭘䈤᰾޵ᇩ൘↓ᑨ֯⭘⭥ᆀؑ᚟ӗ૱ᛵߥлˈӾ⭏ӗᰕᵏ㇇䎧ˈ൘↔
ᵏ䲀޵ӗ૱ѝᴹⲴᴹ∂ᴹᇣ⢙䍘н㠤⭏ཆ⋴ᡆケˈн㠤ሩ⧟ຳ䙐ᡀѕ䟽⊑ḃᡆሩ
ަӪ䓛ǃ䍒ӗ䙐ᡀѕ䟽ᦏᇣDŽӗ૱↓ᑨ֯⭘ˈ㾱ᓏᔳ൘⧟؍֯⭘ᒤ䲀޵ᡆ㘵ࡊࡠᒤ䲀
Ⲵӗ૱ˈ䈧ṩᦞഭᇦḷ߶䟷䘲ᖃⲴᯩ⌅䘋㹼༴㖞DŽ ཆˈ↔ᵏ䲀нҾ䍘䟿  ࣏㜭
Ⲵ؍䇱ᵏ䲀DŽ
7KH0DUNDQG,QIRUPDWLRQDUHDSSOLFDEOHIRU3HRSOHV5HSXEOLFRI&KLQDRQO\
䫵
3E
⊎
+J
䭹
&G
ޝԧ䬜
&U9,˅
ཊⓤ㚄㤟
3%%
ཊⓤҼ㤟䟊
3%'(
ᴹǂᇣǂ⢙ǂ䍘
˘ӗ૱ѝᴹᇣ⢙䍘Ⲵ〠৺䟿˚
 ѫᵪ䜘ս h ƻ h ƻ ƻ ƻ
 ⭥Ⓚ䜘ս h ƻ ƻ ƻ ƻ ƻ
 䱴Ԧ h ƻ ƻ ƻ ƻ ƻ
 ⴂᆀ ƻ ƻ ƻ ƻ ƻ ƻ
䜘Ԧ〠
https://www.topcon.co.jp
GLOBAL GATEWAY https://global.topcon.com
Please see the following website for contact addresses.
1054305-01-A
2022
