Instruction Manual:
ATN Series
Models: ATN110, ATN210, ATN1100, ATN2100, ATN60A, ATN110A

Table of Contents
Chapter 1: Cautionary Notes and Warnings ...........................................................................................................................2
Chapter 2: Specifications ........................................................................................................................................................ 4
Chapter 3: Parts Description...................................................................................................................................................5
3.1 Parts Description –ATN110, ATN210............................................................................................................................5
3.2 Parts Description –ATN1100, ATN2100 .......................................................................................................................6
3.3 Parts Description –ATN60A, ATN110A.........................................................................................................................7
3.4 Parts Description - Battery Placement and Installation ATN1100, ATN2100, ATN110, ATN210.................................. 9
3.5 Parts Description –Ports and Connectors ....................................................................................................................9
Chapter 4: Keys, Display Indicators and Commands.............................................................................................................10
Chapter 5: Unpacking the Scale and Getting Started ...........................................................................................................13
5.1 Unpacking the Scale and Getting Started –ATN1100, ATN2100, ATN110, ATN210 ..................................................13
5.2 Unpacking the Scale and Getting Started –ATN60A, AT120A....................................................................................15
Chapter 6: Main Menu.........................................................................................................................................................18
Chapter 7: Calibration ()...........................................................................................................................................19
7.1 Calibration - Automatic Internal: Models ATN60A, ATN110A ....................................................................................19
7.2 Calibration –External: Models ATN1100, ATN2100, ATN110, ATN210......................................................................20
Chapter 8: Units of Measure Selection () .....................................................................................................................21
Chapter 9: Mode Configuration ()..............................................................................................................................22
9.1 Animal Weighing Configuration..................................................................................................................................23
9.2 Parts Counting Configuration......................................................................................................................................25
9.3 Check Weighing Configuration....................................................................................................................................26
9.4 Display Hold Configuration .........................................................................................................................................27
9.5 Percent Weighing Configuration.................................................................................................................................29
9.6 Totalizing Configuration..............................................................................................................................................30
9.7 Density Measurement Configuration (ATNA Models only) ........................................................................................31
9.7.1 Solid..........................................................................................................................................................................32
9.7.2 Liquid........................................................................................................................................................................34
Chapter 10: Auto Zero Setting Mechanism –AZSM ()..................................................................................................35
Chapter 11: GLP Print and Data Configuration () ...........................................................................................................36
Chapter 12: Printing Data and Communication Ports ().............................................................................................39
12.1 Baud Rate..................................................................................................................................................................40
12.2 Bits.............................................................................................................................................................................40
12.3 Parity .........................................................................................................................................................................41
12.4 Send –Sending Data to PC or Printer........................................................................................................................42
Chapter 13: Time & Date ().......................................................................................................................................43
13.1 Time...........................................................................................................................................................................43
13.2 Date...........................................................................................................................................................................44
Chapter 14: Battery and Backlight () ........................................................................................................................45
14.1. Backlight...................................................................................................................................................................45
14.2. Battery......................................................................................................................................................................46
14.3. Auto Off....................................................................................................................................................................47
Chapter 15: Restoring Default Factory Settings ()......................................................................................................48
Chapter 16: Connecting to PC - Communication Protocol....................................................................................................49
16.1 Installing Drivers........................................................................................................................................................49
16.2 Data Transmission and Exchange Protocol...............................................................................................................50
Chapter 17: Weighing () ...........................................................................................................................................52
17.1 Zeroing the Scale.......................................................................................................................................................53
17.2 Taring the Scale.........................................................................................................................................................53
17.3 Clearing the Tare.......................................................................................................................................................54
Chapter 18: Animal Weighing ().............................................................................................................................55

1
Instruction Manual –ATN and ATNA
Chapter 19: Parts Counting ().....................................................................................................................................57
Chapter 20: Check Weighing ()...................................................................................................................................60
Chapter 21: Display Hold () ....................................................................................................................................63
Chapter 22: Percent Weighing ()............................................................................................................................65
Chapter 23: Totalizing () .............................................................................................................................................68
Chapter 24: Density Measurement.......................................................................................................................................70
24.1 Solid...........................................................................................................................................................................70
24.2 Liquid.........................................................................................................................................................................72
Chapter 25: Common Errors and Trouble Shooting..............................................................................................................74
Chapter 26: Maintenance .....................................................................................................................................................75
Chapter 27: Accessories........................................................................................................................................................76
Chapter 28: Replacement Parts ............................................................................................................................................77
Chapter 29: Limited Warranty ..............................................................................................................................................78

2
Instruction Manual –ATN and ATNA
Important handling Cautions and Warnings
Always handle your scale with care.
Damage caused by improper handling is not covered under the scale’s warranty.
Dropping an object on the pan, rough handling, or exceeding weighing capacity will cause
loadcell overload, and loadcell damage which is not covered under the scale’s warranty.
Never drop or throw any articles
onto the scale’s pan or onto any
other parts of the unit!
DO NOT let the scale fall or drop
from its tabletop surface!
When moving the scale do not
press or apply force onto the
scales pan!
DO NOT pass or handle liquids
directly over the scale to avoid
spillage and liquid damage!
Chapter 1: Cautionary Notes and Warnings

3
Instruction Manual –ATN and ATNA
CAUTIONARY NOTES AND PRECAUTIONS
Always handle your scale with care. The correct location and proper environment makes an important contribution to the accuracy of the weighing
results of TORBAL precision scales.
The optimum location for your scale:
•Stable, vibration-free base as horizontal as possible
•Away from direct sunlight
•Not exposed to high temperature variations
•Away from direct drafts
•The best location is on a stable bench away from drafts,
doors, windows, radiators and air conditioner vents.
CAUTION:
•The scale is designed for indoor use only.
•Do not operate the scale in hazardous areas or under dangerous conditions.
•Do not use the scale in locations subject to high humidity or dust.
•Do not connect cables in ways other than those mentioned in this manual.
•Set the scale on a firm, stable, horizontal surface.
•Never stand on or lean on this product. Equipment may fall or collapse, causing breakage and possible injury.
•Before moving the product, unplug it and unplug all cables connected to it.
•When storing, transporting or returning the scale for service, always use the original packaging.
WARNING:
•Never attempt to repair, disassemble or modify the scale. Tampering with the scale may result in injury and cause
greater damage to the equipment.
•Be sure to use the specified power source.
•Do not allow foreign matter to fall onto the scale.
•If water or other liquid spills onto the scale, unplug the power cord immediately and contact technical support.
Damaged batteries must be handled
with extra care. Use rubber gloves and
safety glasses. Dispose only in
designated recycling centers.
Always disable charging before
installing disposable batteries
Charging non-rechargeable, alkaline
batteries can be hazardous and
cause damage to scale.
Always keep the scale and the
power supply from water or other
liquids.
Disposal of electronic equipment in
waste containers is forbidden by law

4
Instruction Manual –ATN and ATNA
Model
ATN110
ATN210
ATN1100
ATN2100
ATN60A
ATN110A
Capacity
110g
210g
1100g
2100g
60g
110g
Readability (d)
0.001g
0.01g
0.0001g
Repeatability (Standard Deviation)
0.002
0.02
0.0002g
Linearity
+/- 0.002g
+/- 0.02g
+/- 0.0002g
Tare Range
110g
210g
1100g
2100g
60g
110g
Stabilization time (typical)
< 3s
< 3s
Automatic Internal Calibration
No
Yes
Load Cell Type
Strain-gauge
Electromagnetic
Accuracy Class
-
I (One)
Pan Dimension
4.5in (115mm)
5.9in (150mm)
3.5 (90mm)
Weighing Chamber
No
Yes
Scale Dimension
7.3 x 11.4 x 3.5 in (185 x 290 x 90 mm)
7.3 x 11.4 x 12 in (185 x 290 x 305mm)
Weighing Chamber Dimension
-
6 x 6.25 x 8 in (152 x 158 x 203mm)
Operating Temperature
+18C to +33C
RS232 Port
Bidirectional –Standard
USB Port
Type B
Power Supply
Input: 120VAC 60Hz; Output: 12V 1200mA
Battery Operated
Yes (4 x Ni-MH 2700mAh)
No
Battery Operating Time
Backlight ON: 30h | Backlight OFF: 50h
-
Display Type
LCD (13mm)
Display Size
3.75 in x 1 in (95.25 x 25.4 mm)
Weighing Units
Grams (g), Kilogram (kg), Carat (ct), Pound (lb), Ounce (oz), Ounce Troy (ozt), Penny Weight (pwt)
Application Modes
Weighing, Animal Weighing, Parts Counting, Check Weighing, Display Hold, Percent Weighing, Totalizing
Density Measurement
No
Yes
Printing
Yes
Scale Net Weight
3.08lbs (1.4 kg)
3.5lbs (1.6kg)
9.5lbs (4.3kg)
Warranty
One Year
Parts Counting
Sample Size
1 through 100
Min Piece Weight
30mg
300mg
3mg
Animal Weighing
Time Intervals
3 sec., 5 sec., 10 sec., 15 sec.
Modes (Min Weight)
Auto, Semi-Auto
(10mg)
Auto, Semi-Auto
(100mg)
Auto, Semi-Auto (1mg)
Totalizing
Modes (Min Weight)
Auto, Semi-Auto
(10mg)
Auto, Semi-Auto
(100mg)
Auto, Semi-Auto (1mg)
Display Hold
Modes (Min Weight)
Auto, Semi-Auto
(10mg)
Auto, Semi-Auto
(100mg)
Auto, Semi-Auto (1mg)
Chapter 2: Specifications

5
Instruction Manual –ATN and ATNA
3.1 Parts Description –ATN110, ATN210
Scale
Pan
Pan Support
Draft Ring
Power Adapter
Rechargeable Batteries (4)
Battery Access Cover
Chapter 3: Parts Description

6
Instruction Manual –ATN and ATNA
3.2 Parts Description –ATN1100, ATN2100
Scale
Pan
Pan Support
Power Adapter
Rechargeable Batteries (4)
Battery Access Cover

7
Instruction Manual –ATN and ATNA
3.3 Parts Description –ATN60A, ATN110A
Scale
Chamber Posts (4)
Chamber Top Frame
Post Screws (4: M3 X 8)
Post Screws Wrench
Chamber Glass (2: Front and Back)
Chamber Glass Access Door (Left)
Chamber Glass Access Door (Right)
Chamber Glass Access Door (Top)

8
Instruction Manual –ATN and ATNA
Pan
Pan Support
Draft Ring
Chamber Base Plate
Power Adapter

9
Instruction Manual –ATN and ATNA
3.4 Parts Description - Battery Placement and Installation ATN1100, ATN2100, ATN110, ATN210
1. Carefully remove the pan, pan support, and the draft
ring from the scale.
2. Turn the scale upside-down.
3. Unscrew (1) and remove the battery access cover (2).
4. Remove the battery pack box (3)
Caution!
Always disable charging before installing
disposable batteries
Charging non-rechargeable, alkaline batteries
can be hazardous and cause damage to scale.
3.5 Parts Description –Ports and Connectors

10
Instruction Manual –ATN and ATNA
Key
Primary Function
Secondary Function
Power On/Off
-
Tare –used to tare the weighing pan
Enter and YES (Accept) –Used to enter or accept
commands
Zero –used to zero the scale
No (Reject) –Used to reject commands or change
values
Menu –used to access the main menu
Recall –In Totalizing this key is used to recall the
Grand Total
Function –Used to select an application mode
Add/Start/Lock –In Totalizing (Manual) this key is
used to add a result to the total. In Animal Weighing
(Manual) this key is used to initiate the animal
weighing process. In Display Hold (Manual) this key
is used to lock the weighing result on display.
Data Transfer –used to print or transfer data to
a PC via the communication ports
Decimal –Used to enter a decimal when assigning
limit values in check-weighing
Clear/Cancel - Used to clear and cancel
operations
Exit –Used to exit submenus
Chapter 4: Keys, Display Indicators and Commands

11
Instruction Manual –ATN and ATNA
Display Indicator
Description
OFF
Power Off
The scale is turned OFF and in standby mode.
AUT
AZSM (Auto-Zero Setting Mechanism)
AZSM is enabled and the scale maintains a “center of
zero” condition within +/- 6d.
NET
Net Result
A tare was taken and the scale subtracted the tare
weight from the gross weight to obtain the net
weight.
Zero
The scale is maintaining a “center of zero” condition.
O
Current Setting
Indicated enabled functions or settings.
MODE
Main Menu
Indicates Main Menu Functions.
Stability Indicator
The weighing result has stabilized and an accurate
reading may be taken.
MIN
Minimum
In check weighing MIN indicates that the weighing
result is below the selected under limit.
MAX
Maximum
In check weighing MAX indicates that the weighing
result is above the selected over limit.
OK
Accept
In check weighing OK indicated that the weighing
result is between the selected limits and the result is
acceptable.
TOTAL
Total Result
In totalizing this indicator signals that the displayed
result is a total sum.
PCS
Pieces
In parts count this indicator shows that the result is a
piece count
%
Percent
In percent weighing this indicator shows that the
result is a percentage.
Command or Abbreviation
Description
- - - - - -
Taring or re-zeroing in progress
CAL
The scale is in the calibration mode.
TARING
The scale is taring before the calibration process.
LOAD XXX g
Place a calibration weight on the pan to begin calibration.
C
Calibration in progress
CAL FIN
Calibration procedure is finished.
AW –X
In Animal Weighing, this command represents the average weighing time.
CONT
In Parts Counting, taring a container is required before continuing the counting
transaction.
SAPL ON
In Parts Counting, or percent weighing this command indicates to place the
sample on the pan.
SPL –XX
In Parts Counting, this command represents the current sample size setting.
FILL
In parts counting, begin counting.
UNDER
In Check Weighing, this command represents the under limit and indicates under
result.
OVER
In Check Weighing, this command represents the over limit and indicates an over
result.

12
Instruction Manual –ATN and ATNA
ACCEPT
In Check Weighing, this command indicates that the weighing result is within the
limit range.
TARE
In Check Weighing, tare before continuing.
SAMPLE
In Percent Weighing, this command indicates the weight of a stored reference
weight.
READY
In Percent Weighing, this command indicates that the scale is ready for percent
weighing based on a stored reference weight.
YES-NO
In Totalizing, this command indicates that a confirmation is required before the
Totals are cleared.
PRINT
Printing in progress
COUNT FINISH, TO START
COUNT PRESS C
In Parts Counting this command indicates that Parts Counting is finished.

13
Instruction Manual –ATN and ATNA
5.1 Unpacking the Scale and Getting Started –ATN1100, ATN2100, ATN110, ATN210
8. Carefully remove the scale, pan, and all components out of the
packaging. Place them on a stable surface where the scale will
not be compromised by any mechanical vibrations or high air
movements.
9. After removing the pan base and the pan from their packaging,
carefully install the draft ring (3–ATA110 and ATA210), and pan
base (2) onto the scale by seating it on the pan support located in
the middle of the scale. Once the pan base has been installed,
carefully place the pan (1) on the base
10. Once the pan has been installed, level the scale by adjusting the
front feet (6) until the level indicator (7) shows the “air bubble” is
in the center position of the sight glass. The level indicator is
located on the rear left side of the scale.
1 –pan
2 –pan support (under pan)
3 –draft ring
4 –display LCD
5 –keys
6 –rotating legs
7 –level indicator
8 –draft shield (option)
9 –draft shield cover (option)
Correct
Incorrect
Chapter 5: Unpacking the Scale and Getting Started

14
Instruction Manual –ATN and ATNA
11. After leveling the scale, you may plug the AC adaptor to the AC adaptor socket located in the rear of the scale.
12. When the AC adaptor is plugged into the wall outlet, the scale will automatically turn on, and go through its
initialization process.
13. To put the scale into standby mode, leave the AC adaptor plugged into both the scale and the wall outlet and press
the Power “OFF” button. The “OFF” indicator will light up in the upper left corner of the display signaling the scale is
in standby mode.

15
Instruction Manual –ATN and ATNA
5.2 Unpacking the Scale and Getting Started –ATN60A, AT120A
1. Carefully remove the scale, pan, and all components out of the
packaging. Place them on a stable surface where the scale will not be
compromised by any mechanical vibrations or high air movements.
2. Firmly screw in the chamber posts into the screw hole
openings located in the corners of the scale’s top housing.
3. Place the chamber top frame on the
posts and firmly secure it in place by
screwing in the post crews with the
provided wrench.
4. Install the back-chamber glass by inserting the
bottom edge into the scale housing (C’) and
securing the top edge in the chamber top
frame (C’’).
5. Install the left and right chamber access door
by sliding it into the scale housing and the
chamber top frame (C’’’).

16
Instruction Manual –ATN and ATNA
6. Install the front-chamber glass by
inserting the bottom edge into the
scale housing (D’) and securing the top
edge in the chamber top frame (D’’).
7. Insert the top chamber glass access
Door by sliding in the rear edge of the
glass onto the chamber top frame.
8. Install the chamber base (F’) on the top of the scale’s
housing.
9. Once the chamber base is in place, install the draft ring
pan support and the pan (F’’’).

17
Instruction Manual –ATN and ATNA
10. Once the chamber has been assembled and pan components installed, level the scale by adjusting the front feet
until the level indicator shows the “air bubble” is in the center position of the sight glass. The level indicator is
located on the rear left side of the scale.
11. After leveling the scale, you may plug the AC adaptor to the AC adaptor socket located in the rear of the scale.
12. When the AC adaptor is plugged into the wall
outlet, the scale will automatically turn on, perform
automatic internal calibration and go through its
initialization process.
13. To put the scale into standby mode, leave the AC
adaptor plugged into both the scale and the wall
outlet and press the Power “OFF” button. The “OFF”
indicator will light up in the upper left corner of the
display signaling the scale is in standby mode.
Note –When the AC adapter is plugged into the wall outlet for the first time, the scale will automatically and
frequently initialize temperature calibration as the internal parts of the scale heat up. The scale will display “”
when calibrating. Once the internal temperature stabilizes, the scale will calibrate whenever the temperature
changes by 1 degree Celsius and at two-hour intervals. The scale loses internal temperature only when the unit is
completely unplugged from the wall electrical outlet. When the unit is turned off with the On/Off key, the scale goes
into standby mode and internal temperature is maintained.
Correct
Incorrect






18
Instruction Manual –ATN and ATNA
The Main Menu is used to configure the scale and its weighing modes. There are ten options within the Main Menu:
Calibration (  ), Unit (  ), Mode (  ), AZSM (), GLP (), Ports (  ), Time/Date (), Power –
Battery and Backlight (), Reset (  ), Firmware () .
Note:
Power () Option available only on battery powered modes (ATN1100, ATN2100, ATN110,
ATN210)
Before entering the menu, complete and clear any active function by pressing the “Cancel” key.
1. To enter the Main Menu, press the “MENU” key.
2. The scale will display available menu options sequentially. When the desired
option is displayed, press the “T” (Yes) key to make the selection.
Example (Selecting Calibration):
Note: Scrolling through the options may be accelerated by manually pressing the “→0”(NO) key.
3. To exit the Main Menu, Press the “Cancel” key.
Chapter 6: Main Menu











