Torbal DRX-4 User manual

Instruction Manual:
DRX-4

- 1 -
Instruction Manual – DRX-4 Pharmacy Balance
Table of Contents
TableofContents
Chapter 1: Cautionary Notes and Warnings .................................................................................................... 2
Chapter 2: Specifications ................................................................................................................................... 4
Chapter 3: Parts Description .............................................................................................................................. 5
Chapter 4: Keys and Display Indicators ............................................................................................................ 7
Chapter 5: Unpacking the Scale and Getting Started ...................................................................................... 8
Chapter 6: Main Menu ..................................................................................................................................... 10
Chapter 7: Users ................................................................................................................................................. 11
Chapter 8: Calibration ...................................................................................................................................... 12
Chapter 9: Print .................................................................................................................................................. 14
9.1 Print Method ............................................................................................................................................................. 14
9.2 Print Configuration ...................................................................................................................................................
15
Chapter 10: Ports ............................................................................................................................................................. 16
10.1 Baud Rate .................................................................................................................................................................
16
10.2 Bits ............................................................................................................................................................................
17
10.3 Parity ........................................................................................................................................................................
17
10.4 Data Transmission and Exchange Protocol ..........................................................................................................
18
Chapter 11: Date and Time............................................................................................................................................ 20
Chapter 12: Sound ........................................................................................................................................................... 22
Chapter 13: Firmware .................................................................................................................................................... 23
Chapter 14: Restoring Default Settings ...................................................................................................................... 24
Chapter 15: Weighing ........................................................................................................................................ 25
15.1 Zeroing the Scale .........................................................................................................................................25
15.2 Taring the Scale ...........................................................................................................................................26
15.3 Clearing the Tare .........................................................................................................................................27
Chapter 16: Sealing the Calibration Switch .................................................................................................... 28
Chapter 17: Maintenance .................................................................................................................................. 29
Chapter 18: Accessories ................................................................................................................................... 29
Chapter 19: Replacement Parts ........................................................................................................................ 29
Chapter 20: Limited Warranty ....................................................................................................................... 30


- 2 -
Instruction Manual – DRX-4 Pharmacy Balance
Important handling Cautions and Warnings
Always handle your scale with care.
Damage caused by improper handling is not covered under the scale’s warranty.
Never drop or throw any
articles onto the scale’s pan
or onto any other parts of the
unit!
DO NOT let the scale fall or
drop from its tabletop
surface!
When moving the scale do
not press or apply force onto
the scales pan!
DO NOT pass or handle
liquids directly over the
scale to avoid spillage and
liquid damage!
Chapter 1: Cautionary Notes and Warnings

- 3 -
Instruction Manual – DRX-4 Pharmacy Balance
CAUTIONARY NOTES AND PRECAUTIONS
Always handle your scale with care. The correct location and proper environment makes an important
contribution to the accuracy of the weighing results of TORBAL precision scales.
The optimum location for your scale:
• Stable, vibration-free base as horizontal as possible
• Away from direct sunlight
• Not exposed to high temperature variations
• Away from direct drafts
• The best location is on a stable bench away from direct drafts,
doors, windows, radiators and air conditioner vents.
CAUTION:
• The scale is designed for indoor use only.
• Do not operate the scale in hazardous areas or under dangerous conditions.
• Do not use the scale in locations subject to high humidity or dust.
• Do not connect cables in ways other than those mentioned in this manual.
• Set the scale on a firm, stable, horizontal surface.
• Never stand on or lean on this product. Equipment may fall or collapse,
causing breakage and possible injury.
• Before moving the product, unplug it and unplug all cables connected to it.
• When storing, transporting or returning the scale for service, always use the
original packaging.
WARNING:
• Never attempt to repair, disassemble or modify the scale. Tampering with the
scale may result in injury and cause greater damage to the equipment.
• Be sure to use the specified power source.
• Do not allow foreign matter to fall onto the scale.
• If water or other liquid spills onto the scale, unplug the power cord
immediately and contact technical support.

- 4 -
Instruction Manual – DRX-4 Pharmacy Balance
Model DRX-4
Capacity (Max) 100g
Minimum load (Min) 0.02g
Reading unit (d) 0.001g
Verification unit (e) 0.01g
Tare range 100g
Accuracy class II
Temperature range +15C to +30C
Weighing time <3s
Certificate of Conformance NTEP Approved
Certificate Number: 04-061
Pan Dimensions 116mm
Scale Dimensions 235 x 245 x 80mm
Power Supply Input: 120VDC 60Hz 9.5W
Output: 12VDC 500mA
Scale weight 5kg
Calibrating weight 100g
Chapter 2: Specifications

- 5 -
Instruction Manual – DRX-4 Pharmacy Balance
Front Side Rear
Pan Pan Support Draft Ring
AC Adapter Leveling Feet Bubble Level Indicator
AC Adapter Socket | Service Switch Access | RS232 Port | USB Port (Select models)
Chapter 3: Part Specifications

- 6 -
Instruction Manual – DRX-4 Pharmacy Balance

- 7 -
Instruction Manual – DRX-4 Pharmacy Balance
Key Primary Function
Power On and Power Off
ÅÆT Tare – used to tare the weighing pan / Enter – Used to accept commands
Æ0Å Zero – used to zero the scale (Legal for Trade models only)
MENU Menu – used to access the main menu
Data Transfer – used to print data or transfer data to a PC via the RS232/USB
communication ports
Display Indicator Description
Stability Indicator - The weighing result has stabilized and an accurate reading may be
taken.
Zero - The scale is maintaining a “center of zero” condition. (Legal for Trade models only)
MODE Mode – The scale is in pill counting mode
NET A tare was taken and the scale subtracted the tare weight from the gross weight to obtain the
net weight.
AUT AZSM - Auto-zeroing Setting Mechanism is enabled (Always enabled in Legal for Trade
Scales)
Chapter 4: Keys and Display Indicators

- 8 -
Instruction Manual – DRX-4 Pharmacy Balance
1. Carefully remove the scale, pan, and all of its components out of the packaging. Place them on a stable
surface where the scale will not be affected by any mechanical vibrations or high air movements.
2. After removing the pan base and the pan from their packaging, carefully install the pan base (2) onto the
scale by seating it on the pan support located in the middle of the scale. Once the pan base has been
installed, carefully place the pan (1) on the base.
3. Once the pan has been installed, level the scale by adjusting the front feet (6) until the level indicator (7)
shows the “air bubble” is in the center position of the sight glass. The level indicator is located on the rear
left side of the scale.
1 – pan
2 – pan support (under pan)
3 – draft ring
6 – rotating legs
7 – level indicators
Correct Incorrect
Chapter 5: Unpacking the Scale and Getting Started

- 9 -
Instruction Manual – DRX-4 Pharmacy Balance
4. After leveling the scale, plug the AC adaptor to the AC adaptor socket located in the rear of the scale.
5. When the AC adaptor is plugged into the wall outlet, the scale will automatically turn on, and go through its
initialization process. If the scale is equipped with automatic internal calibration it will calibrate itself. The
calibration process will initialize automatically whenever the scale is turned on. The scale will also calibrate
whenever the temperature changes by 1 degree Celsius and at two-hour intervals. Calibration will initialize
only if the scale has been stable and idle for 60 seconds, in order not to interrupt weighing operations. The
scale will display “WWAIT” when calibrating.
Note – Automatic Internal Calibration Models: When the AC adapter is plugged into the wall outlet for
the first time, the scale will automatically and frequently initialize temperature calibration as the internal
parts of the scale heat up. The scale will display “WWAIT” when calibrating. Once the internal
temperature stabilizes, the scale will calibrate whenever the temperature changes by 1 degree Celsius and
at two-hour intervals.
Note: The scale will always start up in the mode that was enabled when it was turned off.
6. To put the scale into standby mode, leave the AC adaptor plugged into both the scale and the wall outlet and
press the Power “OFF” button. The “OFF” indicator will light up in the upper left corner of the display
signaling the scale is in standby mode.
WWAIT

- 10 -
Instruction Manual – DRX-4 Pharmacy Balance
Users (USERS): Assign up to five unique User ID numbers. The User IDs can be included in the transaction
receipt when printing.
Calibration (Calib): Manually begin automatic internal calibration. Print out calibration reports.
Print (PRINT): Configure format of the print receipt (i.e. date, time, and user ID).
Serial Ports (PORTS): Configure baud rates of the USB and RS232 ports.
Date/Time (TIMME): Set the scale’s time and date.
Sound (SOUND): Enable/Disable the scale buzzer.
Firmware (FIRMMWW): Updates the sale firmware via PC.
Default (DEFAULT): Reset the scale to default factory settings.
Chapter 6: Main Menu

- 11 -
Instruction Manual – DRX-4 Pharmacy Balance
The Users menu allows for 5 unique user IDs to be entered into the system.
1. To set the user IDs, press the Menu key. Select “USERS” by pressing the T key.
1. Choose an ID to edit (i.e. ID 1, ID 2…ID 5) by pressing the T key when it is displayed.
2. Press the T key to add a digit. Press the Zero key to increment a digit.
3. Press the Menu key to accept the ID number.
Cha
p
ter 7: Users
(
Users
)
Id 1
0123
USERS

- 12 -
Instruction Manual – DRX-4 Pharmacy Balance
External calibration can be performed with an external calibration weight equal to the scale’s capacity.
1. Enter the Weighing Mode by pressing the menu key. Select “
WWeIgH" by pressing the T key.
2. Use a flathead screwdriver to gently remove the
Calibration Seal Screw located in the rear of the
scale.
3. Once the screw has been removed and the
calibration switch exposed, use a pen or another
pointing device to toggle the calibration switch to
the right (which is the ON position).
4. Upon toggling of the calibration switch, the
balance will go into Calibration Mode.
5. To start calibration, press the Menu key.
6. Select “Cal On” by pressing T key.
Chapter 8: Calibration
Pr_ON
CAL on
WWEIGH

- 13 -
Instruction Manual – DRX-4 Pharmacy Balance
7. Wait for the scale to tare.
8. When prompted, load a calibration weight equal to the weight displayed on the screen. (Calibration weight
varies by model).
9. Wait for the scale to calibrate.
10. When calibration has ended the scale will display Pr_On.
Toggle the calibration switch in the rear of the scale back
to its original position.
11. Insert the Calibration Seal Screw back into place.
-CAL- -------
LOAD
300
WWAIT
CCCCC
Pr_ON
0.000

- 14 -
Instruction Manual – DRX-4 Pharmacy Balance
A detailed transaction receipt can be printed after a count or compound has been completed. The receipt can be
produced automatically when the transaction ends or by manually pressing the print key. The scale can be
configured to print additional information with the transaction’s results.
9.1 Print Method
1. To configure the printing setup, press the Menu key. Select “PRINT” by pressing the T key.
2. Choose the method of printing by selecting either “auto” or “button” by pressing the T key.
Function Options:
Auto (auto) Receipts will print automatically at the end of a transaction.
Button (button) Receipts will print manually when the print button is pressed.
Cha
p
ter 9: Print
(
pRINT
)
auto button
PRINT

- 15 -
Instruction Manual – DRX-4 Pharmacy Balance
9.2 Print Configuration
The receipt can be customized to include the following information:
The receipt information can be enabled or disabled by following these steps:
1. To configure the print setup, select “Print” from the main menu by pressing the T key.
2. Select “setup” by pressing the T key.
3. Select a field to configure. Confirm the selection by pressing the T key.
4. Choose “On” to include the field or “off” to exclude the field. To confirm the selection press the T key.
Date – Date of the performed transaction
Time – Time at which the transaction was performed
User Id – shows the ID number of the user which
performed the weighing transaction
User Id
DATE
TIME
date
On
tImme
Off
PRINT
setup

- 16 -
Instruction Manual – DRX-4 Pharmacy Balance
After a weighing or counting transaction is completed, a result data receipt can be printed. To initiate printing,
press the data transfer key. Data may be sent to a printer or a PC via the Torbal Communication Software.
10.1 Baud Rate
1. To configure the Baud Rate select “bAud” by pressing the T key.
2. Choose the baud rate to be used (“1200”, “2400”, “4800”, “9600”,
“19200”, “38400”, “57600”, and “115200”). To confirm the selection, press the T key.
Cha
p
ter 10: Ports
(
Port
)
BAUD

- 17 -
Instruction Manual – DRX-4 Pharmacy Balance
10.2 Bits
3. To configure the number of bits select “bIts” by pressing the T key.
4. Choose “7 bIts” or “8 bIts”. To confirm the selection, press the T key.
10.3 Parity
5. To configure the parity type select “PARITY” by pressing the T key.
6. Choose the parity type to be used (“none”, “odd”, and “even”). To confirm the selection, press the T key.
7 - bIt 8 - bIt
bIts
none odd
PARITY

- 18 -
Instruction Manual – DRX-4 Pharmacy Balance
10.4 Data Transmission and Exchange Protocol
Data Transmission (LONG):
Transmission Parameters: 8 bits, 1 stop bit, no parity, baud rate 4800bps,
Exchange data:
 Transmit the weight (equivalent to the Print Key, , in weighing:
Computer→Scale: S I CR LF (53h 49h 0Dh 0Ah) – initiating signal,
Scale→Computer: scale sends 16 Bytes of data as follows:
Byte 1 - The charater ‘-‘ or space
Byte 2 - space
Bytes 3,4 - digit or space
Bytes 5-9 - digit, comma, or space
Byte 10 - digit
Byte 11 - space
Byte 12 - k, l, c, p or space (for kg,lb,ct,pc,
or%)
Byte 13 - g, b, t, c or %
Byte 14 - space
Byte 15 - CR
Byte 16 - LF
 ‘Tare the weight’ (corresponds to the →T← key in weighing):
Computer→Scale: S T CR LF (53h 54h 0Dh 0Ah),
Scale→Computer: no response.
 ‘Zero the scale’ (corresponds to the key →0← in weighing):
Computer→Scale: S Z CR LF (53h 5Ah 0Dh 0Ah),
Scale→Computer: no reponse.
 ‘Turn On / Off the Scale (corresponds to the key I/ in weighing):
Computer→Scale: S S CR LF (53h 53h 0Dh 0Ah),
Scale→Computer: no response.
 ‘Display the MENU’ (corresponds to the key MENU in weighing):
Computer→Scale: S F CR LF (53h 46h 0Dh 0Ah),
Scale→Computer: no response.
 Setting the threshold 1 (optional):
Computer→Scale: S L D1...DN CR LF (53h 4Ch D1...DN 0Dh 0Ah)
where: D1...DN – Threshold value, up to 8 characters,
Scale→Computer: no response,

- 19 -
Instruction Manual – DRX-4 Pharmacy Balance
 Example:
To set 1000g in weight B1.5 (d=0.5g) type:
S L 1 0 0 0 . 0 CR LF (53h 4Ch 31h 30h 30h 30h 2Eh 30h 0Dh 0Ah).
To set 100kg in weight B150 (d=50g) type:
S L 1 0 0 . 0 0 CR LF (53h 4Ch 31h 30h 30h 2Eh 30h 30h 0Dh 0Ah),
 Setting the threshold 2 (optional):
Computer→Scale: S H D1...DN CR LF (53h 48h D1...DN 0Dh 0Ah),
where: D1...DN – threshold value, up to 8 characters,
Scale→Computer: no response
Cable WK-1 Configuration
Cable WD-1 Configuration
