Tornado Tools JQ688A User manual

1
INSTRUCTION MANUAL
HAND HELD STEAM CLEANER
JQ688A-1
Read these instructions carefully before using your steam cleaner.
Please keep this instruction manual in safe place for future use.

2
Applicable Standards: EN60335-1
Product Characteristics
Technically Leading
With exclusive patented technology, high-temperature and high-pressure steam is
used for clearing away the dirts and stains on the floors, doors, windows and clothes.
The machine also can be used for removing dusts and killing bacteria on surfaces, and
thus is an environment-friendly and sanitary product.
Automatic control of heating is able to generate steam continuously and thus
continuous cleaning is easy. Using pure high-pressure water steam and no chemical
agents are added, it is completely environment-friendly.
Higher Safety
Designed to prevent heating empty boiler, after the water in the boiler tank is heated
and evaporated completely, the machine will automatically disconnect the power
supply and thus prevent empty heating. With high-sensitivity thermostat, 140℃
high-temperature steam is available, ensuring disinfection and sterilization. The safety
valve has automatic pressure release function. When there is high steam pressure in
the tank, the valve will automatically open and release the pressure.
Extended power cord with double insulation can effectively insulate the cable from
water and dust, and thus ensure safety.
Durable
The machine, designed with aluminum alloy die-casting boiler body with extra-thick
inner wall, can resist high pressure and has a long service life.
Complete plastic shell is made from quality PP and PA with anti-corrosion feautre
and high strength.
Energy-saving
With integrated design of specially made heating tubes and boiler body, overall
heating is provided, and thus is highly efficient and energy-saving.
Double-layer shell structure can effectively prevent heat loss, and thus is
environment-friendly and energy-saving.
Easy to use
Switch on power supply and the machine immediately starts heating process. When it
heats to specified temperature, press the steam button, and steam will be sprayed out
slowly. The machine is so easy to operate.
With complete cleaning accessories supplied, the machine can be assembled and
disassembled easily. It can be used to clean doors, windows, floors and clothes, and
thus is applicable widely.

3
Description of Parts
1. Body
2. Short sprayer nozzle
3. Safety cap
4. Steam button
5. Handle
6. Power cord
7. Power Indicator
8. Funnel
9. Measuring cup
10. Nylon round brush
11. Bent spray nozzle
12. Long spray nozzle
13. Extended connecting spray nozzle
14. General spray nozzle
15. Spray nozzle for door/window
16. Tower sleeve
Safety Precautions
This icon represents “Prohibition”
This icon represents “Warning”
1. Do not allow children to use this machine independently or little children
to be too near to this machine when no adults attend to them.
2. To prevent electrical shock, do not immerse power cord or power plug in
water or other liquids.
3. The power cord and power plug should be in good condition and must
not be damaged. Damaged or defective power cord and power plug must not
be used and should be repaired at appointed service center.
4. This product is only for use in households and must not be used for
industrial applications.
5. Do not turn on power supply until the tank is full of water.
6. Used power supply should comply with the product requirements of the
manufacturer.
7. During operation, the tank mouth must be plugged hermetically and
safety cap should be tightened in position.
8. A socket with special earthing wire must be used.
9. In use, the machine body must not be inclined at more than 45 degrees.
Otherwise boiling water will be sprayed out together with steam.
10. Do not direct the steam towards persons, animals or other electrical
products.

4
11. Before refilling water, ensure to unplug the power cord to disconnect
power supply. It is necessary to unplug the power cord after the machine is
used, before it is cleaned and while it is repaired.
12. Do not add into the tank any rust remover, odor-counteracting agent,
alcohol and detergent, which will possibly cause damage to the tank.
13. If the supply cord is damaged, it must be replaced by the manufacturer
or its service agent or a similarly qualified person in order to avoid a hazard.
14. The appliance has to be unplugged after use and before cleaning or user
maintenance of the appliance.
15. Do not use in swimming pools containing water.
16. Liquid or steam must not be directed towards equipment containing
electrical components, such as the interior of ovens.
17. The filling aperture must not be opened during use.
Important: Never overfill the tank. Otherwise the steam generation will be affected
or too high steam pressure will be caused.
Accessories supplied with the machine
Name
Funnel
Measuring
cup
Nylon
round brush
Towel sleeve
Long spray
nozzle
Qty
1
1
1
1
1
Name
Spray nozzle
for
door/window
General
spray
nozzle
Bent spray
nozzle
Extended
connecting
spray nozzle
This user
manual
Qty
1
1
1
1
1
Technical Specification
Rating of power supply: 220-240V, 50Hz
Tank capacity: 350ml
Suggest water capacity: 250ml
Rated power: 900W-1050W
Steam pressure: 0.25MPa
Injected steam capacity: 28g/min.
Temperature controller: functioning temperature: 135℃
Fuser: functioning temperature:169℃
Overall dimension: 415x131x215 mm
Net weight: 1.25kg

5
Functions
·Disinfection and sterilization
Install the long spray nozzle on the main body. Aim the spray nozzle at the position
that needs disinfection and then press down the steam button. High-temperature steam
can kill bacteria.
·Cleaning clothes
Install the general spray nozzle on the main body. Cover the towel sleeve on it. Aim
the spray nozzle at hung clothes. Press down the steam button and move the nozzle up
and down as well as to the left and to the right at the same time. Then stains can be
removed from the clothes.
·Cleaning doors and windows
Install the general spray nozzle on the main body and then install the spray nozzle for
door/window on it. Aim the spray cup at a door/window. Press down the steam button
and move the nozzle up and down as well as to the left and to the right at the same
time. Then stains can be removed from the door/window.
·Cleaning floor surfaces
Install the extended connecting spray nozzle on the main body, then install bent spray
nozzle or round spray nozzle. Aim the spray nozzle at floor. Press down the steam
button to remove the dirt and stains on the floor and wall corners.
Operating Instructions
Operation Procedures
1Unpack the product. Check the accessories and this user manual supplied with the
product and make sure that the product and accessories are not damaged.
2Before use, please read the user manual carefully. The steam cleaner is only for
use in households.
3First, place the steam cleaner on a level platform. Push down the safety cover.
Unscrew the safety cap counterclockwise and install the funnel, as in the pictures:
(I) (II)
4Take suitable clean water with the measuring cup and add the water into the tank.
(Max. capacity of the tank is 350ml. Do not overfill the tank. Leave some space in
the tank). Re-install the safety cap and tighten it in position.
5Check the power supply and socket and confirm that they comply with the
requirements given in the user manual. Then, connect the power supply.
6Indicator lamp will turn off in 3 minutes after connecting with the power supply.
It means that steam is ready. At this time, put forward the safety switch on the

6
steam button then lightly press the steam button and check whether steam is
sprayed out of the nozzle. (Do not aim the spray nozzle at any animals, persons or
electrical products).
7If there is steam sprayed out, release the steam button and install suitable
accessories according to your needs then push the small button and press down the
steam button again in order to carry out the operations you require.
8When finishing the cleaning job or stopping the machine to do some other things,
raise the steam button. Then, the safety switch will take effect.
Installation of Accessories
1. Install the spray cup with hairbrush
Hold the pipe section of the spray cup with hairbrush in your hand. Align the
arrow on the spray cup with the single-line mark on the short spray nozzle on the
machine body and insert the spray cup in position. Rotate the spray cup in
clockwise direction and align the arrow on the spray cup with the double-line
mark on the short spray nozzle on the machine body, as shown in Figure 1. Fix the
spray cup on the machine body. To remove the spray cup with hairbrush, rotate
the spray cup inversely (counterclockwise), as shown in Figure 2, and align the
arrow on the spray cup with the single-line mark on the machine body. Then, the
spray cup with hairbrush can be pulled out.
(I) (II)
Install spray cup with round brush or bent spray cup
For direct installation on short spray nozzle, aim the spray cup with round brush
or bent spray cup at the top of the spray nozzle, as shown in Figure 3, and push the
spray cup upwards until it is in position. As the short spray nozzle and the spray
cup are positioned in six directions, the angle and direction can be adjusted during
the installation. Or first install the long spray cup and then the spray cup with
round brush or bent spray cup. The long spray cup is installed in the same method
as the installation of the spray cup with hairbrush. The spray cup with round brush
or bent spray cup and long spray cup can be installed in the same procedures as
the installation on short spray nozzle.
(III)

7
2. Installation of spray cup for door/window
First, install the spray cup with hairbrush on the short spray nozzle, as shown in
Figure 4 and Figure 5. Install the two small hooks of the spray cup for
door/window onto suspension lugs of the spray cup with hairbrush, and then
trigger the big hook of the spray cup for door/window, and push the spray cup for
door/window up and clutch it onto the body of the spray cup with hairbrush.
(IV) (V)
Refill water during operation
1. Unplug the power cord and disconnect the power supply.
2. Press down the steam button to release the pressure until no steam is ejected out.
3. Slowly unscrew the safety cap but do not remove it. And the residual steam will
be discharged slowly until no steam comes out. Then place the machine in a cool
place to cool it down for about five minutes. Finally, completely remove the
safety cap.
4. Use the funnel and measuring cup to refill a suitable quantity of cold or hot water
into the tank.
5. Re-install the safety cap onto the machine body and tighten it in position.
After the machine is used
1. After the cleaning machine is used, unplug the power cord and disconnect the
power supply.
2. Press down the steam button to release the pressure until no steam is ejected out.
When no steam is ejected out, raise the steam button then the safety switch will
take effect.
3. Slowly unscrew the safety cap but do not remove it. And the residual steam will
be discharged slowly until no steam comes out. Then, place the machine in a cool
place to cool it down for about five minutes. Finally, completely remove the
safety cap.
4. Empty the residual water in the tank and clean the external surface with a piece of
dry cloth.
5. Lastly, re-install the safety cap onto the machine body and tighten it in position.
Warnings:
Danger of scalding

8
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities or lack of experience and knowledge unless
they have been given supervision or instruction concerning the use of the appliance by
a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance. The
filling aperture must not be opened during use.
DO NOT direct steam towards persons, animals or other electrical products.
Correct Disposal of this product
This marking indicates that this product should not be disposed of with
other household wastes throughout the EU. To prevent possible harm to
the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was
purchased. They can take this product for environment-safe recycling.
