Princess 332848 User manual

EN Instruction manual
Garment Steamer
01.332848.02.001
Garmen
01.3

10
PARTS DESCRIPTION
10
1
2
4
5
6
7
8
9
11
12
3

Instruction manual
3
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using your Princess product. By ignoring
the safety instructions Princess cannot be held responsible for the
damage. When using an electrical appliance, basic safety
precautions should always be observed, including the following:
IMPORTANT: This appliance is not intended for use by persons
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children shall not use or
play with this appliance. Close supervision is necessary to keep
appliance and cord out of reach of children during use.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
• Never move the appliance by pulling the
cord and make sure the cord does not
become entangled. If the supply cord is
damaged, it must be replaced by the
manufacturer, its service agent or similarly
qualified persons to avoid a hazard.
• The appliance must be placed on a stable,
level surface.
• The user must not leave the device
unattended while it is connected to the
supply.
• This appliance is only to be used for
household purposes and only for the
purpose it is made for.
• To protect yourself against an electric shock,
do not immerse the cord, plug or appliance
in the water or any other liquid.
• CAUTION: In order to avoid hazard, this
appliance is not intended to be operated by
means of an external timer or separate
remote control system.
• To prevent fire or shock hazard do not
expose this appliance to rain or moisture.
• Do not allow children to use the device
without supervision.
• Always switch off and remove the power
cord from the electrical outlet before
changing accessories or approaching parts
that move in use.
• Always remove the power cord from the
electrical outlet if it is left unattended and
before assembling, disassembling or
cleaning.
• DO NOT overfill.
EN

Instruction manual
4
• Only use the appliance with the appropriate
connector.
• Surface are liable to get hot during
use.
• Warning: Serious injuries can occur in case
of misusing the appliance and accessories.
• WARNING: always unplug the garment
steamer before attaching or detaching the
fabric brush.
• WARNING: do not use the steamer directly
on the body, animals, or while wearing the
garments.
• Keep the appliance and its cord out of reach
of children less than 8 years of age when it is
energized or cooling down.
• Do not open the waterreservoir during use.
• Care should be taken when using the
appliance due to the emission of steam.
• Unplug the appliance during filling and
cleaning.
• THIS PRODUCT IS INTENDED FOR
HOUSEHOLD USE ONLY. Do not use this
appliance for anything other than its intended
use. Do not use outdoors.
FOR HOUSEHOLD USE ONLY
www.princesshome.eu

Instruction manual
5
INSTALLATION INSTRUCTIONS
1 2
3 4
Illustration1:
• Take the appliance and accessories out the box. Remove the
stickers, protective foil or plastic from the device.
• Loosen the lock nut of the rod. Place the telescopic pole and lock
it. (Picture 1)
• Unlock the telescopic pole lock to extend the post to the desired
height and then lock it in the right place. (Picture 2)
• Attach the hanger to the top and lock in place. (Picture 3)
• Connect the hose to the base of the hose connector. Screw the
hose connector nut into place. (Picture 4)
•FABRIC BRUSH ASSEMBLY
Illustration2:
• Turn off the appliance, wait until the steam stops spraying out of
the nozzle.
• Place the rods of the fabric brush onto the steam nozzle.
• Press the brush to the steam nozzle and lock in place.
EN

Instruction manual
6
• Install the trouser press on the bottom of the steam nozzle and
lock it. Put the pants in the middle between the steam nozzle and
the trouser press, push the handle with one finger, and pull the
steam nozzle downwards, This will iron the pants.
BEFORE THE FIRST USE
• When operating the appliance for the first time, allow it to steam
for a few minutes. This will remove any impurities and odours that
might have been left by the manufacturing proces. You may want
to try the steamer on an old piece of fabric before steaming your
garment the first time.
• There may be leakage from the steam nozzle if the garment
steamer temperature is not high enough to vaporize water and
create steam. therefore, ensure that the garment steamer is
always preheated for 2-3 minutes prior to use.
• To avoid an electrical circuit overload, it is recommended that no
other appliances are plugged into the same circuit as your
garment steamer when it is in use.
• The garment steamer is easy to use and is perfect for removing
wrinkles from garments and curtains as well as refreshing
furnishing fabrics.
• If using the garment steamer without the fabric brush, keep a
distance of at least 5cm between the steam nozzle and the
garment.
• Do not directly hover the garment steamer over metal
accessories.
Filling the water tank
• Take out the water tank and unscrew the water tank nut.
• Fill the tank with water (the temperature of the water should be
under 50 °C).
• In order to prolong the life of the appliance, we recommend you to
use distilled water.
• Do not use the appliance if the water tank is nearly empty or if
there is water shortage during use, this will damage the
appliance.
USE
• The high-temperature steam spraying from the nozzle can only
soften the garment fabric. Hold the garment with one hand, and
hold the handle of the steam nozzle with the other. Touch the
steam nozzle to the garment tightly, moving it in an up and down
vertical motion. The high-temperature steam will remove wrinkles.
• Place the ironing board to the pocket and press the nozzle on the
pocket gently. Move the nozzle up and down to shape the
garment by high temperature steam.
• Hold the edge of both sides of the garment tightly when steaming
the bottom of the garment. Steam in different directions until the
fabric is wrinkle free. Be careful about the hot steam spraying out
of the steam nozzle.
• Press downward for a longer time on the garment collar, and
steam it back and forth.
• Straighten the sleeves, move up and down to remove wrinkles.
• Steam the back of the garment after finishing the front.
• After using the appliance, press the power button to turn it off.
Disconnect the power plug out of the socket.
• Take off the water tank and empty the remaining water from the
tank.

Instruction manual
7
CAUTION: the high temperature can reach 180 ºC, please confirm
whether the material is high-temperature resist or not before
steaming. Do not leave the spraying panel on the same spot for a
long time to avoid damage to the garment.
CAUTION: when not using the appliance and before storage,
continue steaming until the water tank runs out of water, then turn off
and unplug the appliance and wait until the appliance is cooled down
completely.
TROUBLESHOOTING
Problem Possible cause Solution/Tips
The unit fails to
steam. Indicating
lamps do not
illuminate.
Is the plug not inserted
in the mains socket
correctly
Insert the plug correctly.
Household circuit
breaker is tripped.
Reset the circuit outlet,
check the fuse of your
mains connection or
contact a qualified
electrician.
The unit fail to
steam. Indicating
lamps illuminate.
Mineral build-up in the
unit.
Follow the removal
mineral build procedure
to remove the mineral
residues.
The water tank is
empty.
Refill the water tank.
Excessive
gurgling sound
from hose or
steam nozzle.
condensation in hose. A gurgling sound is
normal during the steam
process. If there is an
excessive noise, hold the
hose vertically to allow
water to run back into
the water tank.
CLEANING AND MAINTENANCE
How to use the drain plug
• When the garment steamer is not in use for a long time, the water
inside may get deteriorated, or even breed bacteria.
• A gray drain plug is set at the bottom of the appliance. Screw the
drain plug anticlockwise to drain the water reservoir.
• After the reservoir is empty, replace and tighten the drain plug to
avoid the water to flow out.
Removal mineral build-up
To reduce the accumulation of minerals in the steamer, the use of
demineralised or distilled water is recommended. Follow the steps
below to remove the built-up mineral:
1. Turn off the unit and unplug the power cord .
2. Remove the steam hose and the telescopic pole.
3. Drain the water reservoir.
4. Mix a solution of 50% vinegar and 50% water, in general 2 cups
of mixture is sufficient.
5. Pour the mixture slowly from the hose connector to the water
tank.
6. Continue to pour the mixture into the hose connection until the
water reservoir is about half full, near the top of the hose.
EN

Instruction manual
8
7. Wait for about 40 minutes.
8. Drain the mixture by unscrewing the drain valve over a sink or
tub.
9. Pour clean water into the hose connector and the water tank and
let it drain. Repeat this step until the vinegar smell disappears.
10. Reassemble the unit.
• When not using the appliance and before storage, continue
steaming until the water tank runs out of water, then turn off and
unplug the appliance and wait until the appliance is cooled down
completely.
• Do not put the appliance in water. use a dry clean cloth to dry the
appliance, no special cleaning agent is needed.
• Make sure the main body is dry before storage or packing.
ENVIRONMENT
This appliance should not be put into the domestic garbage at
the end of its durability, but must be offered at a central point for the
recycling of electric and electronic domestic appliances. This symbol
on the appliance, instruction manual and packaging puts your
attention to this important issue. The materials used in this appliance
can be recycled. By recycling of used domestic appliances you
contribute an important push to the protection of our environment. Ask
your local authorities for information regarding the point of
recollection.
Support
You can find all available information and spare parts at
www.princesshome.eu!

© Copyright 2019
