Toro SMRT Logic SMRT-I User manual

Thank you for purchasing SMRT Logic™, a SMRTscape™ device. The SMRT Logic Wireless Gateway
allows users to intuitively set up and control their irrigation systems from anywhere they have internet access
via the web or the SMRTscape app.
Connect Hardware
1
1. Connect Ethernet cable from your internet router
or switch to the port on the back of the SMRT
Logic.
2. Plug in the AC adapter.
3. SMRT Logic lights ash. Left LED should
eventually settle on solid green.
Solid Green - connected to the internet
Red - no internet connection
Green - ashes when data is
transferring to and from
the controller.
Additional LED color related information can
be found in the Troubleshooting section of this
document.
Register
2
1. Next, register your SMRT Logic.
Point browser to www.smrtscape.com.
2. Click the Register link.
3. Fill out all elds and press Register.
4. A verication email will be sent to the specied
e-mail address. Click the verication link in the
e-mail. You will be taken to the SMRTscape
website.
Click the Complete Registration button.
5. You will be taken to the sign in page.
Enter e-mail address and password
then click Sign In.
Setup in 4 Easy Steps!
SMRT Logic
Quick Reference Setup Guide
SMRT Logic™
Quick Reference Setup Guide
Models: SMRT-T, SMRT-I
Models: SMRT-T, SMRT-I
©2016 The Toro Company Form Number 373-0875 Rev. B

Congure
3
Add Location
After signing in, you need to add the location of the
SMRT Logic.
1. Click + Add a Location.
2. Fill out the Name and Description elds.
3. On the Google Maps map, enter desired address
into the Address eld. Click Search map.
4. Click Submit.
Adding the SMRT Logic
Now you have to add
the SMRT Logic to your
SMRTscape account.
1. Click [Add].
2. Type in the
Smart ID found
on the bottom of
the unit.
3. Enter the
Security Key also
found on bottom.
Click Submit.
4. The SMRT Logic should be added to the system.
Enter address here
Add Controller to the SMRT Logic
Multiple controllers can be added.
Controllers must be added one at a time.
1. Click +Add a controller.
2. Select the Controller from the dropdown menu.
3. Enter the name, description, Climate Logic ID or
Smart ID, PIN (see PIN Setup below).
PIN Setup
The SMRT Logic PIN must match the PIN entered in
the EVOLUTION controller or Climate Logic device for
the system to operate.
Use the included SMRT Logic Information Card to
record the necessary info from the SMRT Logic device
and the irrigation controller for easy entry into the
SMRTscape.com website.
To setup a new PIN or view an existing one, at the
irrigation controller, follow these steps:
For an EVOLUTION controller:
Go to ADVANCED►ADD/REMOVE
DEVICE►REMOTE.
For a Climate Logic controller:
Go to MENU►REMOTE.
For a Climate Logic Mini Receiver (CL-MR):
1. Put the Mini Receiver into Learn Mode by
holding down the only button for more than 8
seconds.
2. Enter the PIN under the corresponding
SMRTscape controller page.
3. Manually turn a station ON or OFF.
4. The Mini Receiver will learn the new PIN
and exit Learn Mode.
The PIN can be set in the CL-MR using a
remote transmitter (CL-R1). See the CL-MR
manual for instructions.

4. Enter the number of active stations or zones used
by the controller.
5. Click Submit.
After a controller is added, it is possible to start and stop
watering, manually activate individual stations, test all
stations, give each station a descriptive name, and more.
Add Scene
A location can have up to 4 scenes.
1. On the Lighting and Auxiliary tab, select +Add a
Scene.
2. Enter the name and description.
Add a photo, if desired.
3. Under Schedule A, enter the days of the week and
time of the Scene.
It is possible to have an A Schedule and a B
Schedule for each scene. For example, one might
want security lights to stay on longer on Friday and
Saturday nights.
4. Add an additional time by clicking Add another
time.
5. Click Add Scene to complete the setup.
Add EVO-ARs or LPCU-As to the
SMRTscape™
EVO-ARs and LPCUs provide
wireless control of up to four
scenes which can be used for
lighting, irrigation, or any 120AC
device.
1. Adding EVO-ARs on the
Lighting and Auxiliary tab
of SMRTscape will provide
additional functionality
not currently available
in EVOLUTION. For that reason, if you use the
AUX-2 or AUX-3 programs at the EVOLUTION
controller, disable them. (See EVOLUTION user
guide for instructions on how to disable AUX-2 and
AUX-3 programs.)
2. At the SMRTscape website, click the Lighting and
Auxiliary tab at the top of the screen. Click on the
blue gear icon ( ) and select Congure Devices.
Press the Activate discovery mode button.
3. Press the button on the EVO-AR or LPCU-A when
prompted.
4. After a few seconds, the SMRT Logic PLUS should
detect the LPCU-A. Assign the scene and enter a
description.
5. Press Add LPCU when done.
6. Repeat steps 1-4 for each LPCU-A to add.
To add an LPRO, click Activate Discovery
Mode then power cycle the LPRO. The LPRO
may require a rmware update after adding. A
notication will be shown under Hardware on the
Location page.
Edit SMRT Logic Equipment
Click the blue pencil icon ( ) to edit controller settings
such as name, description, number of stations, and
more.
Delete SMRT Logic Equipment
To delete a controller, click the blue pen to edit the
controller, then click Delete Irrigation Controller.
Update the Firmware
If a rmware update is available for either the SMRT
Logic unit or the controller, a Manage Firmware
command will be displayed under ‘Hardware’ on the
Location screen.
Click the link to
update hardware.
Select the De-
vice(s) and click
Update Firmware
to start.
Support
Check the website for FAQ and detailed instructions. To
submit a help ticket, click on the Contact link then the
Submit a Ticket link.
LPCU / EVO-AR

LED Behavior Cause Solution
steady orange SMRT Logic unable to
get an IP address from
the network’s DHCP
server.
Conrm the network is congured to assign IP addresses. If
needed, a SMRT Logic can be manually congured to use
a static IP address. Refer to Advanced SMRT Logic network
setup on the website.
blinks green SMRT Logic unable to
reach the internet.
Conrm there is a valid internet connection using the same
Ethernet wire if possible.
Troubleshooting
FCC Statement - FCC ID: OF7SCG
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
In order to maintain compliance with the FCC RF exposure guidelines,
this device should be installed and operated with a minimum distance of
20cm between the radiator, and the body of the operator and/or nearby
persons.
Any change or modication not approved by the party responsible for
compliance could void the user’s authority to operate this device.
Permitted Low Gain Dipole Whip Antenna (2dBi).
IC Statement - IC: 3575A-SCG
1. Under Industry Canada regulations, this radio transmitter may only
operate using an antenna of a type and maximum (or lesser) gain
approved for the transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type and its gain should be
so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not
more than that necessary for successful communication.
Conformément à la réglementation d’Industrie Canada, le présent
émetteur radio peut fonctionner avec une antenne d’un type et d’un
gain maximal (ou inférieur) approuvé pour l’émetteur par Industrie
Canada. Dans le but de réduire les risques de brouillage radioélectrique
à l’intention des autres utilisateurs, il faut choisir le type d’antenne et
son gain de sorte que la puissance isotrope rayonnée équivalente
(p.i.r.e.) ne dépasse pas l’intensité nécessaire à l’établissement d’une
communication satisfaisante.
2. This radio transmitter has been approved by Industry Canada
to operate with the antenna types listed below with the maximum
permissible gain and required antenna impedance for each antenna type
indicated. Antenna types not included in this list, having a gain greater
than the maximum gain indicated for that type, are strictly prohibited for
use with this device.
Le présent émetteur radio (identier le dispositif par son numéro de
certication ou son numéro de modèle s’il fait partie du matériel de
catégorie I) a été approuvé par Industrie Canada pour fonctionner avec
les types d’antenne énumérés ci-dessous et ayant un gain admissible
maximal et l’impédance requise pour chaque type d’antenne. Les types
d’antenne non inclus dans cette liste, ou dont le gain est supérieur au
gain maximal indiqué, sont strictement interdits pour l’exploitation de
l’émetteur.
Antenna Approved/Antenne approuvé
Type/Type Max. Gain/Max. Gain Impedance/Impédance
Dipole Whip 2.0 dBi 50 Ω
3. This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation
of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas
produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
4. In order to maintain compliance with the IC RF exposure guidelines,
this device should be installed and operated with a minimum distance of
20 cm between the radiator, and the body of the operator and/or nearby
persons.
An de maintenir la conformité avec les directives d’exposition RF IC,
ce dispositif doit être installé et exploité avec une distance minimale
de 20 cm entre le radiateur et le corps de l’opérateur ou à proximité de
personnes.
FCC and IC Statements
Specications
Model Name: SMRT Logic
Model Number: SMRT-T, SMRT-I
Dimensions: 4.4” x 3.1” x 1.2” without antenna
Unit Weight: 3.4oz (95g) without accessories
Certication: FCC, IC, UL-Listed Power Adapter
Power: 5Vdc, 1A
Port Speed: 10/100 Mbps
Operating Temp: 32 to 104°F (0-40°C)
Storage Temp: -4 to 140°F(-20 to 60°C)
Operating Humidity: 10 to 80% RH, non-condensing
Go Mobile
4
Download the SMRTscape app for Apple iOS or
Android to control your irrigation system.
